Summary of Contents for Cardinal CSG12H
- Page 1 CSG12H Operations Manual STUMP GRINDER...
- Page 2 Table of Contents 1. SAFETY INFORMATION - Fire Safety - Operating Safety - Service Safety - Electric Motors - Plugs - Extension Cables - NVR - No Volt Release - Health and Safety 2. EQUIPMENT DATA - Features - Equipment Specifications - Maximum Recommended Cord Length 3.
- Page 3 Register Your Equipment Thank you for purchasing CARDINAL® equipment! Your product is covered by the CARDINAL® Warranty policy, but in order to activate your warranty, we need you to register your product. In addition to activating your equipment warranty, product registration will grant you access to important product updates, streamlined customer service and more.
- Page 4 CARDINAL®. The information contained in this manual is based on machines in production at the time of publication. CARDINAL® reserves the right to change any portion of this information without notice. No part of this publication may be reproduced in any form or by any means, electronic or mechanical, including photocopying, without express written permission from CARDINAL®.
- Page 5 1.2.2 NEVER use accessories or attachments for this equipment, which are not recommended by CARDINAL®. Damage to the rammer and/or injury to user may occur. 1.2.3 NEVER leave machine running unattended.
- Page 6 1.3.2 ALWAYS replace worn or damaged components with spare parts designed and recommended by CARDINAL ®. 1.3.3 ALWAYS keep machine clean and labels legible. Replace all missing and hard-to-read labels. Labels provide important operating instructions and warn of dangers and hazards.
- Page 7 1.4 Fuel Safety For your own personal protection and for the safety of those around you, please read and ensure you fully understand the following safety information. It is the responsibility of the operator to ensure that he/she fully understands how to operate this equipment safely. If you are unsure about the safe and correct use of this equipment consult your supervisor.
- Page 8 2.2 STARTING THE ENGINE 2.2.1 Lock the wheel by pulling brake lever fully back 2.2.2 Make sure the throttle is in slow position. DO NOT ALLOW the rope to snap back, return it by hand to prevent damage to the starter. 2.2.3 If the engine is cold move the choke lever to the closed position.
- Page 9 2.4 PREPARE THE GRINDER AT THE STUMP 2.4.1 Removing Roots 1. Make sure the throttle is set to fast, the cutter will accelerate to cutting speed. 2. Swing the cutting wheel to one side, then lower it into the nearest roots that are buried at the foot of the stump.
- Page 10 2.4.2 Cutting The Full Stump Removing Roots Continued Cut the remaining roots as described in STEP 2 until satisfactorily removed. 3. SHUTTING DOWN MACHINE 3.1 Shutting Off the Grinder 1. When stopping the machine after normal operation, lower the engine speed to slow, and push the emergency switch.
- Page 11 4. MACHINE MAINENTANCE 4.1.1 Make sure all nuts, bolts and screws are tightened 4.1.2 Never store the equipment with fuel in the tank inside a building where fumes can reach an open flame or spark. Allow the engine to cool before moving the grinder. 4.1.3 To reduce fire hazards, keep the engine and fuel storage area free of grass, grease, and dirt.
- Page 12 8. MAINTENANCE RECORD CARDINAL® tools are assembled with care and will provide years of service when properly maintained. Preventative maintenance and routine service are essential to the long life of your tamping rammer. Adhere to reading through this manual thoroughly. You will find that you can do some of the regular maintenance yourself.
- Page 13 Your new CARDINAL® equipment is warranted to the original purchaser for a period of one-year. (12 months) from the original date of purchase. The CARDINAL® warranty is against defects in design, materials and workmanship. The following are not covered under the warranty: 1.
- Page 14 3,550 lbs/ft Vibratory Rammer 3,550 lbs/ft Vibratory Rammer 3,400 lbs/ft Plate Compactor 3,400 lbs/ft Plate Compactor 3,000 lbs/ft Plate Compactor 3,000 lbs/ft Plate Compactor Part#: TR68H Part#: TR68H Part#: TPC90H Part#: TPC90H Part#: TPC80 & TPC80H Part#: TPC80 & TPC80H 3.6 HP Honda GXR120 Engine 3.6 HP Honda GXR120 Engine 5.5 HP Honda GX160 Engine...
- Page 15 USE CODE SAVE10 AT CHECKOUT FOR 10% OFF YOUR ORDER AT WWW.TOMAHAWK-POWER.COM INVERTER SERIES INVERTER SERIES INVERTER SERIES INVERTER SERIES 2000 Watt Inverter Generator 2000 Watt Inverter Generator 210 Amp Portable Welder Generator 210 Amp Portable Welder Generator Part#: TG2000i Part#: TG2000i Part#: TWG135Ai Part#: TWG210A...
