Lumineux Alwen Installation Instructions

Dimensions:
Part No. Description L (mm)
430916 Alwen Plug & Play 103
Linear MW Sensor
End Of Life Disposal:
Disassembly instructions for end of life disposal available on website.
Disposal of Electronic Equipment WEEE Directive 2002/96/EC This product falls within the scope of the
Waste Electrical & Electronic Equipment Directive (WEEE), which means the product should not be
disposed of as normal household waste. Please recycle where facilities exist or check with your Local
Authority. RoHS – All components and materials used in this product are RoHS 2002/95/EC compliant.
Specifications may change from time to time. The information contained in this leaflet is for guidance only
and should not be considered as always accurate and should be treated as not representative.
Manby Park, Manby, Louth, Lincolnshire, LN11 8UT
Lumineux Group is a trading name of B&T Associates Ltd.
W (mm) H (mm) Weight
26 30 50g
Installation Instructions
Alwen Plug & Play Sensor
Input
Max Load
Operating Temp
Connection Type
Sensor Type
Mounting Height
Control Type
Box Contents:
• Alwen MW Sensor
Tools Required For Installation:
•
N/A
READ THESE INSTRUCTIONS THOROUGHLY BEFORE INSTALLATION
This product must be installed by a qualified electrician or competent person,
and in accordance with current building and IET wiring regulations.
Warranty:
This part is warranted for a period of Years from the date of purchase**. The warranty could be invalidated
should the product not be installed according to these instructions, outside the scope of the specification or
the product has been altered or tampered with in any way. Please see website for terms and conditions.
Rev L1.0 241879
www.lumineux.co.uk
220-240V AC 50/60Hz
200W (LED)
-20°C — +50°C
Quick Connector
Microwave
6m Max.
ON/OFF
KEEP THESE INSTRUCTIONS FOR FUTURE REFERENCE.
IMPORTANT:
5
Scan for more
Information
Technical Helpline:
+44(0)1507 328031
