SMART Alpha
INSTALLATION INSTRUCTIONS
a
SAFETY FIRST
PLEASE READ THE FOLLOWING INSTRUCTIONS BEFORE INSTALLATION
DO NOTexpose this product to dripping or splashing and no objects filled with liquids, such as vases,
should be placed near the apparatus. If liquid enters the chassis immediately unplug from the wall
socket.
DO NOT impede ventilation by covering the ventilation openings with items, such as newspapers,
table-cloths, curtains, etc.;
DO NOT expose this product to naked flame sources, such as lighted candles, these should not be placed
near the apparatus;
MAKE SURE that this appliance (CLASS 1) is connected to a mains outlet socket with protective earth.
PLEASE NOTE that the mains plug is used as the disconnect device and must remain readily operable.
OUTPUT SOCKETS
ADDITIONAL INFORMATION ON FUSING AND RATINGS
A
The eight output sockets marked 'A' are designed for use with all electrical appliances. These
are protected by 10A fusing, located on the back panel and will provide a maximum continous
total load for all eight sockets together (A) of 2300W.
SERVICE & REPAIR
NO USER SERVICEABLE PARTS INSIDE
Should the unit fail, or cease to function, or function in a manner which seems unusual,
please immediately turn off and unplug from the mains supply.
Send an email to: support@isoteksystems.com
IMEI code:
A
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Isotek SMART Alpha
Summary of Contents for Isotek SMART Alpha
- Page 1 SMART Alpha IMEI code: INSTALLATION INSTRUCTIONS SAFETY FIRST PLEASE READ THE FOLLOWING INSTRUCTIONS BEFORE INSTALLATION DO NOTexpose this product to dripping or splashing and no objects filled with liquids, such as vases, should be placed near the apparatus. If liquid enters the chassis immediately unplug from the wall socket.
-
Page 2: Set-Up & Instructions
SET-UP & INSTRUCTIONS After unboxing your IsoTek SMART power product, please connect the power cord and LAN Ethernet cable, this being connected directly to your router. Connect components to the output sockets via the power cables provided. RS232, and Micro USB ports are also available for installation programmability, if required. - Page 3 Upon completion of the registration email, you will then be able to connect to your SMART power device. Please return to the URL: https://smartpower.isoteksystems.com/login Click the left ‘Sign in’ button and enter your email address and dedicated password. You will now be logged into the control environment for managing SMART power products.
- Page 4 SMART power front panel lights will start to flash. At this point press the small ‘Pair’ icon button on the front of the SMART power unit to connect your IsoTek product to the on-line control interface. Once successfully paired the Delta control interface will be displayed.
- Page 5 To remove a SMART power device from the web interface control screen simply press the delete button. This will remove your connection to the IsoTek SMART power product. To reconnect a user would need to log back in entering user name and password.
- Page 6 The Device scheduler allows your SMART device to be programed to give timed socket start up or shut down events. It is quick and easy to program an event for multiple output sockets, or multiple events covering individual output socket actions. A flexible system allowing users to program as they would prefer.
- Page 7 20 output sockets are required. In this situation IsoTek SMART devices can be grouped together to act as a single entity and be given a unique group name.
