LY N X H O M E U S E R I E S B AT T E R Y
User manual

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the LYNX HOME U Series and is the answer not in the manual?

Questions and answers

Summary of Contents for Marley LYNX HOME U Series

  • Page 1 LY N X H O M E U S E R I E S B AT T E R Y User manual...
  • Page 2 LYNX HOME U SERIES BATTERY User guide Copyright Statement User Manual V1.8-2023-08-25 Copyright ©GoodWe Technologies Co., Ltd., 2023. All rights reserved No part of this manual can be reproduced or transmitted to the public platform in any form or by any means without the prior written authorization of GoodWe Technologies Co., Ltd.

  • Page 3: Table Of Contents

    Content User Manual V1.8-2023-08-25 TABLE OF CONTENTS 01 About This Manual ..............01 1.1 Applicable Model ..................01 1.2 Target Audience ..................01 1.3 Symbol Definition ..................01 02 Safety Precaution ............... 03 2.1 General Safety ..................... 03 2.2 Battery Safety ....................04 2.3 Emergency Measures ................
  • Page 4 Content User Manual V1.8-2023-08-25 LYNX HOME U SERIES BATTERY User guide 6.5 Indicator Status(LX U5.4-20) ............... 23 6.5.1 Normal State ......................23 6.5.2 Alerting ........................23 6.5.3 Faulty ........................24 6.6 Power Off ...................... 25 6.7 Install the Plastic Cover ................25 07 Technical Parameters ..............
  • Page 5 01 About This Manual User Manual V1.8-2023-08-25 Updates The latest document contains all the updates made in earlier issues. V1.0 01.02.2024...

  • Page 6: About This Manual

    LYNX HOME U SERIES BATTERY User guide 01 About This Manual User Manual V1.8-2023-08-25 01 About This Manual This manual describes the product information, installation, electrical connection, commissioning, troubleshooting and maintenance. Read through this manual before installing and operating the product. All the installers and users have to be familiar with the product features, functions, and safety precautions.
  • Page 7 01 About This Manual User Manual V1.8-2023-08-25 Updates The latest document contains all the updates made in earlier issues. V1.0 01.02.2024...

  • Page 8: Safety Precaution

    LYNX HOME U SERIES BATTERY User guide 02 Safety Precaution User Manual V1.8-2023-08-25 02 Safety Precaution Please strictly follow these safety instructions in the user manual during the operation. NOTICE The products are designed and tested strictly to comply with related safety rules. Read and follow all the safety instructions and cautions before any operations.

  • Page 9: Battery Safety

    02 Safety Precaution User Manual V1.8-2023-08-25 2.2 Battery Safety DANGER • The battery system exists low voltage during the equipment running. Please keep Power Off before any operations to avoid danger. Strictly follow all safety precautions outlined in this manual and safety labels on the equipment during the operation. •...

  • Page 10: Emergency Measures

    LYNX HOME U SERIES BATTERY User guide 02 Safety Precaution User Manual V1.8-2023-08-25 Label Description Symbol Description Symbol Description Potential risks exist. Wear proper Install the equipment away from PPE before any operations. fire sources. High voltage hazard. Power off...

  • Page 11: Eu Declaration Of Conformity

    02 Product Introduction User Manual V1.8-2023-08-25 Fire • The battery may explode when the ambient temperature exceeds 150℃. Poisonous and hazard gas may be released if the battery is on fire. • In the event of a fire, please make sure that the carbon dioxide extinguisher or Novac1230 or FM-200 is nearby.

  • Page 12: Product Introduction

    User Manual V1.8-2023-08-25 03 Product Introduction • This manual introduces Lynx Home U Series(LV) Battery System (hereinafter referred to as the Battery System), including the product introduction, application, installation, commission, and technical parameters, etc. • At most 6 batteries can be connected in this Battery System.

  • Page 13: Dimensions

    03 Battery Introduction User Manual V1.8-2023-08-25 3.2 Dimensions...

  • Page 14: Storage And Package

    LYNX HOME U SERIES BATTERY User guide 04 Storage and Package User Manual V1.8-2023-08-25 04 Storage and Package 4.1 Storage Environment If the equipment is not to be installed or used immediately, please ensure that the storage environment meets the following requirements: •...

  • Page 15: System Installation

    05 System Installation User Manual V1.8-2023-08-25 05 System Installation 5.1 Installation Environment • Install the Battery System on the ground with sufficient bearing capacity and flatness. Increase the bearing capacity and flatness of the ground by laying the foundation, adding bearing plates and so on.
  • Page 16 LYNX HOME U SERIES BATTERY User guide 05 System Installation User Manual V1.8-2023-08-25 The installation distance shall statisfy the requirements of the battery and the inverter at the same time when an inverter is connected with the battery system. For the installation distance requirement of the inveter, please refer to the related inverter's user manual.

  • Page 17: System Installation

    05 System Installation User Manual V1.8-2023-08-25 5.3 System Installation NOTICE If multi batteries are to be connected, check and select batteries with similar production date and a same cell grade. 5.3.1 Floor Mounting Step1 Screw the anti-dumping bracke on the battery. Step2 Align the battery and the wall, then put the anti-dumping bracket close to the wall.

  • Page 18: Wall Mounting

    LYNX HOME U SERIES BATTERY User guide 05 System Installation User Manual V1.8-2023-08-25 5.3.2 Wall Mounting NOTICE Wall mounting needs to be done by two persons. Step1 Place the wall mounting plate close to the wall firmly, mark the drilling position and remove the wall mounting plate.

  • Page 19: Cable Connection

    05 System Installation User Manual V1.8-2023-08-25 5.3.3 Cable Connection Overview of the cable connection Take SBP inverter series as an example connection here. Terminal resistor 2≤N≤6 Battery 1 Battery 2 Battery N Power Cable Power Cable Ground Standard for Negative for Positive Cable Net Cable...
  • Page 20 LYNX HOME U SERIES BATTERY User guide 05 System Installation User Manual V1.8-2023-08-25 Power Cable Connection NOTICE • Connect the red power cable to the red wire harness, and the black power cable to the black wire harness. The cross-sectional area of the crimping part is 25mm².
  • Page 21 05 System Installation User Manual V1.8-2023-08-25 Communication Cable Connection NOTICE The two communication cables are the same. • Do not use RJ45 cable with protective cover. • When one battery is applied, connect one communication cable to the inverter by RJ45 connector and connect the other cable to the terminal resistance.

  • Page 22: Install The Wire Harness Fix Bar

    LYNX HOME U SERIES BATTERY User guide 05 System Installation User Manual V1.8-2023-08-25 Installing the terminal resistor 5.3.4 Install the Wire Harness Fix Bar...

  • Page 23: System Operation

    06 System Operation User Manual V1.8-2023-08-25 06 System Operation 6.1 Check Before Power On Check the following items before power on. Otherwise, the Battery System may be damaged. Items The equipment is installed firmly in a place where is convenient for operation and maintenance.
  • Page 24 LYNX HOME U SERIES BATTERY User guide 06 System Operation User Manual V1.8-2023-08-25 Single battery Inverter Battery DC Breaker (Only for Australia ) Parallelized batteries Inverter DC Breaker (Only for Australia ) 2≤N≤6 DC Breaker (Only for Australia ) Battery N...

  • Page 25: Battery Parameter Settings

    06 System Operation User Manual V1.8-2023-08-25 6.3 Battery Parameter Settings Select the right options on SolarGo after connecting the battery and the inverter. APP Installatin and Connection: Connect the smartphone Download with the inverter. and Install Wi-Fi SSID: Solar-WiFi** SolarGo Passwaord: 12345678 Select the battery model on SolarGo: Select “LX U5.4-L or LX U5.4-20”...

  • Page 26: Normal State

    LYNX HOME U SERIES BATTERY User guide 06 System Operation User Manual V1.8-2023-08-25 6.4.1 Normal State Button Indicator SOC Indicator Description ﹤ 5%≤SOC ﹤ 25%≤SOC ﹤ Standby:green light blinking for 1s Working:green light on 50%≤SOC ﹤ 75%≤SOC ﹤ SOC≥95% 6.4.2 Alerting...

  • Page 27: Faulty

    06 System Operation User Manual V1.8-2023-08-25 6.4.3 Faulty Button SOC Indicator Fault Solution Indicator Temp. sensor failure Restart the battery. If the problem persists, please contact GoodWe for help. MOS Failure Circuit-Breaker Turn on the Circuit-Breaker.If the problem Failure persists, please contact GoodWe. Power off and check the communication cable.

  • Page 28: Indicator Status(Lx U5.4-20)

    LYNX HOME U SERIES BATTERY User guide 06 System Operation User Manual V1.8-2023-08-25 6.5 Indicator Status(LX U5.4-20) SOC Indicator Button Indicator Button Indicator Status Green Light Standby, Working Red Light Alert, Faulty 6.5.1 Normal State Button Indicator SOC Indicator Description ﹤...

  • Page 29: Faulty

    06 System Operation User Manual V1.8-2023-08-25 6.5.3 Faulty NOTICE • Restart the battery by pressing the switch button. Button SOC Indicator Fault Solution Indicator Power off for 2 hours.If the problem persists, Steady red Overvoltage please contact GoodWe. Red light blink 1 Under voltage Contact GoodWe for help.

  • Page 30: Power Off

    LYNX HOME U SERIES BATTERY User guide 06 System Operation User Manual V1.8-2023-08-25 Restart the battery. If the problem persists, Precharge Failure please contact GoodWe for help. Power off for 2 hours.If the problem persists, Overtemperature please contact GoodWe. Fault...

  • Page 31: Technical Parameters

    07 Technical Parameters User Manual V1.8-2023-08-25 07 Technical Parameters Technical Data LX U5.4-L 2*LX U5.4-L 3*LX U5.4-L 4*LX U5.4-L 5*LX U5.4-L 6*LX U5.4-L Rated Energy (kWh)*1 10.8 16.2 21.6 32.4 Usable Energy (kWh)*2 14.4 19.2 28.8 Cell Type LFP(LiFePO4) Cell Configuration 16S1P 16S2P 16S3P...
  • Page 32 LYNX HOME U SERIES BATTERY User guide 07 Technical Parameters User Manual V1.8-2023-08-25 Technical Data LX U5.4-20 2*LX U5.4-20 3*LX U5.4-20 4*LX U5.4-20 5*LX U5.4-20 6*LX U5.4-20 Usable Energy (kWh) 5.4 kWh 10.8 kWh 16.2 kWh 21.6 kWh 27 kWh 32.4 kWh...
  • Page 33 07 Technical Parameters User Manual V1.8-2023-08-25 For Australia: Technical Data LX U5.4-20 2*LX U5.4-20 3*LX U5.4-20 4*LX U5.4-20 5*LX U5.4-20 6*LX U5.4-20 Rated Energy (kWh) 10.8 16.2 21.6 27.0 32.4 Usable Energy (kWh) 10.8 16.2 21.6 27.0 32.4 Cell Type LFP(LiFePO4) Cell Configuration 16S1P...

  • Page 34: Maintenance

    LYNX HOME U SERIES BATTERY User guide 08 Maintenance User Manual V1.8-2023-08-25 08 Maintenance Item Period Fully charge the battery and discharge it to 25~50% if the Once Every 6 months battery is not in use. Check the wall mounting plate, fix it if it is not secured.
  • Page 36 LYNX HOME U SERIES BATTERY User guide Tell me more Call 01283 722588 Email info@marley.co.uk Or visit marley.co.uk Marley, Lichfield Road, Branston, Burton upon Trent, DE14 3HD V1.0 01.02.2024...
