Summary of Contents for Trifecte BU-145D
- Page 1 Wine Cellar User Manual BU-145D BU-88D (Features and Size May Vary) PLEASE READ THIS MANUAL CAREFULLY BEFORE INSTALLING AND OPERATIN...
-
Page 2: Important Safeguards
IMPORTANT SAFEGUARDS When using this appliance, always exercise basic safety precautions, including the following: Read all of the instructions before using this appliance. This appliance is not intended for use by persons (including children) with reduced physical, sensory or mental capabilities, or lack of experience and knowledge, unless they have been given supervision or instruction concerning use of the appliance by a person responsible for their safety. - Page 3 SAVE THESE INSTRUCTIONS DANGER Risk of child entrapment. Before you throw away your old wine cellar, take off the doors. Leave the shelves in place so that children may not easily climb inside. Model number Thank you for using our product. This easy-to-use manual will guide you in getting the best use of Serial number your wine cellar.
-
Page 4: Table Of Contents
Table of Contents IMPORTANT SAFEGUARDS .......................... 2 Wine Cellar Features and Use ........................5 Initial Setup ............................... 5 Temperature Adjustment ..........................6 Shelving ................................6 Parts and Features ............................7 Installation as a Built-In Cellar ........................8 Reversing the Door Swing ........................... 9 Installing the Handle ............................. -
Page 5: Wine Cellar Features And Use
Electrical Requirement Make sure there is a suitable power Outlet (115 volts, 15 amps outlet) with proper grounding to power the wine cellar. Avoid the use of three plug adapters or cutting off the third grounding in order to accommodate a two plug outlet. This is a dangerous practice since it provides no effective grounding for the wine cellar and may result in shock hazard. -
Page 6: Temperature Adjustment
Once you have plugged the unit into an electrical outlet, let the unit run for at least 30 minutes to acclimate before making any adjustments. Temperature Adjustment When the wine cellar is plugged in for the first time, the LED displaywill show the factory preset temperature of 50°F. -
Page 7: Parts And Features
Parts and Feature Door Control Panel Outside Canbinet Handle Long Shelf Control Panel Gasket Short Shelf Lock Adjustable Front Louver Foot Control Panel Door Outside Canbinet Long Shelf Handle Control Panel Gasket Short Shelf Lock Front Louver Adjustable Foot YOUR WINE CELLAR ALSO INCLUDES THE FOLLOWING: ... -
Page 8: Installation As A Built-In Cellar
Installation as a Built-In Cella (380mm) (570mm) > (860mm) (860mm) These cut out dimensions show the minimum space required for your wine cellar to perform as designed. -
Page 9: Reversing The Door Swing
Reversing the Door Swin Before you begin: Tape down shelves to avoid movement during the process The door of this appliance can be hung to open on the left or rightside. To reverse the door swing of your cooler and open from the opposite side, please follow the instructions and diagram below. - Page 10 4. Unscrew the upper hinge and bottom hinge 5. Pry out the plastic caps at the left side of the cabinet, and move them to the right side. 6. Install the hinge set which are packed as accessories with the instruction manual to the opposite side.
-
Page 11: Installing The Handle
7. Rotate the door 180° so that the top is now the bottom, and install it b attaching the support rod with screws. Installation the Handle • Remove the exterior and interior packing materials. • 24 hours Let the appliance stand upright for approximately before connecting it to the power source, which helps to reduce the possibility of a cooling-system malfunction from handling during transportation. -
Page 12: Operating Your Wine Cellar
OPERATING YOUR WINE CELLA Each wine cellar includes an operating panel on the front of the unit. The operating panel includes the following feature Upper Zone Temp.Up Display Window Lock / Unlock Temp.Down Power Lighting ºC/ºF Bottom Zone Zone Select Interchange Display Window ... -
Page 13: Before You Start
Defaults: Power ON (when plugged in) Unlocked Temp Digits O BEFORE YOU START: The wine cellar should be placed in a location where the ambient temperature is between 60-80°Fahrenheit. If the ambient temperature is outside this range, the performance of the unit may be affected. -
Page 14: Temperature Settings For Serving Wine
Temperature Settings for Serving Win Although optimal storage temperature is generally regarded to be 53-57°F, different varietals of wine require different service temperature settings. The recommended temperature ranges for serving different varietals of wine are listed below. Your wine cellar will indicate when you have set the Upper/Lower zones to the below temperature ranges. -
Page 15: Proper Wine Cellar Care And Cleaning
Proper Wine Cellar Care and Cleanin Cleaning and Maintenance Warning: To avoid electric shock always unplug your wine cellar before cleaning. Ignoring this warning may result in death or injury. Caution: Before using cleaning products, always read and follow manufacturer’s instructions and warnings to avoid personal injury or product damage. -
Page 16: Troubleshooting
Power Interruption Occasionally there may be power interruptions due to thunderstorms or other causes. Remove the power cord from AC outlet when a power outage occurs. When power has been restored, wait 3 to 5 minutes then re-plug the power cord to AC outlet. Vacation and Moving Care ...
