- Page 1 Installation, Operation, & Maintenance Manual #99999 Large Fontana Pizza Oven #99999 Extra Large Fontana Pizza Oven #99999 Large Fontana Pizza Oven #99999 Extra Large Fontana Pizza Oven...
-
Page 2: Table Of Contents
Contents Safety Instructions Caution if your smell gas Installation Instructions LPG Connection NG Connection Maintenance Storage & Preservation Indicators 10-12 Model 6050-PRO Model 6070-PRO Model 8070-PRO 13-16 Lighting 6050-PRO 6070-PRO 8070-PRO Igniter 17-18 Troubleshooting Igniter failure or malfunction Technical safety notes... - Page 3 Safety Instructions All work must be carried out under conditions of safety and with the gas line shut off and/or disconnected. WARNING: Improper connection as well as any alterations or improper maintenance can cause material damage to property or persons and even death in extreme cases. Read the instructions carefully before installing and using the appliance.
- Page 4 Safety Instructions • The parts sealed by the manufacturer must not be • Your wood fired oven is designed for outdoor modified by the user. use; if it is installed indoor or in an enclosed area, make sure you have good ventilation for •...
- Page 5 Installation Instructions Oven exterior walls may reach temperatures above 50°C (120°F) any flammable materials must not be within 1 meter of the oven. It is recommended to place the oven during use at a sufficient distance from flammable materials or materials that may be damaged by heat. Place the oven protected from wind or strong air currents which may alter the oven’s perforamance.
- Page 6 Installation Instructions LPG Connection (Liquid Propane Gas) Connect The LP Cylinder to te Oven The cylinder, which is always equipped with a pressure regulator (not supplied), must be connected to the oven via a suitable flexible rubber hose (not supplied) between 60 and 150 cm in length.
- Page 7 Installation Instructions Pressure Regulator (Not Supplied) This appliance must be equipped with a pressure regulator in compliance with local/national standards and/or regulations with a nominal pressure output of: • Category 13+(28-30/37) Propane 37 mbar. Butane 28-30 mbar • Category I3B/P (30) Propane/Butane 30 mbar •...
- Page 8 Installation Instructions NG Connection (Natural Gas) The oven can be fitted for natural gas operation on request when ordering. The conversion consists of fitting calibrated nozzles and minimum adjustment specific to the gas category. Approved countries and pressures are indicated on the following pages. Connection to a domestic natural gas line must be carried out in accordance with local regulations and only by qualified personnel.
- Page 9 Maintenance When the oven is cold or before each use, remove any food residue from the hob due to previous preparations. With a vacuum cleaner clean and release the area around the burner to avoid malfunctions due to ash or food residues. The external parts must be kept clean regularly to prevent oxidation phenomena, especially steel parts.
-
Page 10: Model 8070-Pro
The above instructions apply to the entire range of ovens illustrated in this manual. The technical specifications of the models are as follows: • 6050-PRO • 6070-PRO • 8070-PRO Models: 6050-PRO... - Page 11 Indications GAS CATEGORY: I3B/P (50 mbar) Injector bore Ø 1.70 mm GAS PRESSURE: 50 mbar (butane G30, propane G31 or mixtures G30/G31) (DE , AT , CH , SK ) • METHANE (G20-G25) GAS CATEGORY: 2H, 2E, (20 mbar) Injector bore Ø 2.90 mm (AT , BG , CH , CY , CZ , DE , DK , EE , FI , GB , GR , IE , IT , LT , LU , LV , NL , NO , PL , PT , RO , SE , SI , SK , AL , HR , MK , TR) GAS CATEGORY: 2E+ (20/25 mbar)
- Page 12 Indications • METHANE (G20-G25) GAS CATEGORY: 2H, 2E, (20 mbar) Injector bore Ø 3.30 mm Pilot injector bore 2xØ 0.29mm (AT , BG , CH , CY , CZ , DE , DK , EE , FI , GB , GR , IE , IT , LT , LU , LV , NL , NO , PL , PT , RO , SE , SI , SK , AL , HR , MK , TR ) GAS CATEGORY: 2E+ (20/25 mbar) Injector bore Ø...
- Page 13 Lighting IMPORTANT • Before turning on the oven, check all connections and gas connections. • Do not lean over the oven when lighting the gas and keep face and body away from the opening of the oven. • When lighting, the door must NOT be closed, the opening of the oven must be open. •...
- Page 14 Lighting Lighting Models: 6050 - Pro 1. To light the oven burner, press and turn the control knob counter-clockwise to the high flame symbol. 2. While holding down the control knob, simultaneously press the ignition button to light the burner. N.B. Lighting the burner for the first time, or after it has cooled down, may require several attempts due to air in the gas supply line.
- Page 15 Lighting Lighting Models: 6070 - Pro, 8070 - Pro (With Pilot Lights) 1. To ignite the pilot light, press and turn the control knob to the spark symbol. 2. While holding down the control knob, simultaneously press the ignition button to ignite the pilot light. N.B. Igniting the pilot light for the first time, or after it has cooled down, may require some attempts due to air in the gas supply line.
- Page 16 Lighting Caution: If the flame does not ignite on all models during the ignition phase, release the control knob and return it to the zero (OFF) position, wait a few minutes to allow any unburned gas to disperse into the air and repeat the lighting procedure. Any accumulation of gas may give rise to potentially hazardous flames and/or detonations resulting in damage, burns or even death in extreme circumstances.
-
Page 17: Troubleshooting
Troubleshooting Ignition Failure or Malfunction Ignitor: If this doos not operate, the burner flame will not ignite Check the condition of the igniter batteries (1.5V AA), if flat or show signs of oxidation, replace them. For extended periods of oven inactivity, it is advisable to remove the battery in order to prevent malfunctions or damage to the igniter itself. - Page 18 Troubleshooting BURNER: may result in flashbacks or partial ignition. If there are flame returns, immediately close the gas supply (cylinder or domestic line) and turn off the fire. Probably the venturi tube has obstructions that must be removed, even simple cobwebs can compromise its operation. If the flame front does not burn completely along the entire length of the burner, as well as not heating adequately, small pops or flashbacks may occur.
-
Page 19: Technical Safety Notes
Technical & Safety Notes CAUTION: Danger of Burns • Very hot parts during operation of the appliance • Wear personal protective equipment (gloves or similar) to prevent accidents and burns Even the door handle, despite being made of silicone, may scald after prolonged use of the oven when not handled using gloves. - Page 20 Technical & Safety Notes Models: 6050-PRO MAX. POWER OUTPUT: 16kW CONSUMPTION: (1164 g/h - LPG) (1525 dm³/h - NG) Ø INJECTOR CATEGORY I3+ (28-30/37 mbar) 1.95 mm CATEGORY I3B/P (30 mbar) 1.95 mm CATEGORY I3B/P (50 mbar) 1.70 mm Ø INJECTOR CATEGORY 2H, 2E (20 mbar) 2.90 mm...
- Page 21 Technical & Safety Notes Models: 6070-PRO MAX. POWER OUTPUT:20kW CONSUMPTION: (1455 g/h - LPG) (1906 dm³/h - NG) Ø INJECTOR Ø PILOT INJECTOR CATEGORY I3+ (28-30/37 mbar) 2.25 mm 1x0.22 mm CATEGORY I3B/P (30 mbar) 2.25 mm 1x0.22 mm CATEGORY I3B/P (50 mbar) 1.95 mm 1x0.22 mm Ø...
- Page 22 Technical & Safety Notes Models: 8070-PRO MAX. POWER OUTPUT:22kW CONSUMPTION: (1601 g/h - LPG) (2096 dm³/h - NG) Ø INJECTOR Ø PILOT INJECTOR CATEGORY I3+ (28-30/37 mbar) 2.35 mm 1x0.22 mm CATEGORY I3B/P (30 mbar) 2.35 mm 1x0.22 mm CATEGORY I3B/P (50 mbar) 2.05 mm 1x0.22 mm Ø...
-
Page 23: Example Of Data Plate
Technical & Safety Notes Example of Data Plate The shape may change while retaining the same information Disposal Information: At the end of its life cycle, the product must be taken to a suitable collection point for iron, electrical or electronic waste. - Page 24 IGNITION CAP KG055(B)_00 IGNITION RING KG055(C)_00 ELECTRIC IGNITOR PV1F240SS IGNITION BUTTON RP1037_00 CAP FOR BULL LOGO RP1042_00 BASE SUPPORT FOR LARGE GAS PIZZA OVEN RP1050_00 INTERNAL FLAME PROTECTOR RP1051_00 BASE FOR LARGE GAS PIZZA OVEN (60x60) RP1055_00 BURNER BOX COVER...
-
Page 25: Exploaded Illustrations Large Gas Pizza Oven
Exploaded Illustrations - Large Gas Oven... - Page 26 ELECTRIC IGNITOR PV1F240SS IGNITION BUTTON RP1008_02 INTERNAL FLAME PROTECTOR RP1016_01 REAR CAP RP1037_00 CAP FOR BULL BRAND RP1040_01 BASE FOR EXTRA LARGE GAS PIZZA OVEN (60x60) RP1041_01 BURNER BOX COVER RP1042_01 BASE SUPPORT FOR EXTRA LARGE GAS PIZZA OVEN RP1043_01...
- Page 27 Exploaded Illustrations - XL Gas Oven...
- Page 28 Parts List - Large Wood Oven Code Description (CO) MA004 REFR BRICK (CO) MI012 (61X40) BOARD PLUS (CO) PI003 FOOT FOR LARGE WOOD PIZZA OVEN (CO) TER03 TEMPERATURE GAUGE FOR PIZZA OVEN (CO) TU150CF01 CHIMNEY PCass051_R2 SS ASSEMBLY PLATE (INCLUDING TONGUE) PCass057_R1 SS ASSEMBLY TUBE PIZ052_R3...
- Page 29 Exploaded Illustrations - Large Wood Oven...
- Page 30 Parts List - XL Wood Oven Code Description (CO) MA004 REFR BRICK (CO) MI012 (61X40) BOARD PLUS (CO) PI003 FOOT FOR XL WOOD PIZZA OVEN (CO) TER03 TEMPERATURE GAUGE FOR PIZZA OVEN (CO) TU150CF01 CHIMNEY PCass051_R2 SS ASSEMBLY PLATE (INCLUDING TONGUE) PCass057_R1 SS ASSEMBLY TUBE PIZ052_R3...
- Page 31 Exploaded Illustrations - XL Wood Oven...
-
Page 32: Warranty
Warranty In compliance with Italian and European regulations, ovens are covered by the legal guarantee, payable by the retailer, 24 months from the date of purchase. After the 24-month warranty period, all repairs will be borne by the consumer. You are required to keep the receipt or purchase invoice to be shown to the retailer. Good maintenance and proper use can help prolong the shelf life of the product.
