AMP25B-1.1/28
Programming Guide
Specifications
•
Wire-free 1.1Nm rechargeable motor with built-in
Li-ion battery
•
Approximately 500 up/down cycles per each full charge
•
Micro USB Charger Port
•
3 motor speed settings: 20, 24 or 28rpm
•
Sound level ~46dB
•
5 year warranty
AMP 2 color logo: PMS Cool Gray 2 & PMS 306 B
Advertisement
Table of Contents
Summary of Contents for AMP AMP25B-1.1/28
- Page 1 AMP 2 color logo: PMS Cool Gray 2 & PMS 306 B Upgrade to the industry’s most advanced Motor Program: AMP Motorization features 2-way technology with superior value and innovation paired with a smart, seemless user interface. Specifications • Wire-free 1.1Nm rechargeable motor with built-in Li-ion battery AMP25B-1.1/28...
-
Page 2: Table Of Contents
AMP Motorization Table of Contents AMP 2 color logo: PMS Cool Gray 2 & PMS 306 Blue Declarations Safety Instructions AMP25B-1.1/28 Overview P1 Button Instructions Remote Overview ™ Initial Set-up Adjust Limits Favorite Position Add or Remove Additional Remote Adjust Motor Speed... -
Page 3: Declarations
Declarations U.S. Radio Frequency FCC Compliance This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) This device must accept any interference received, including interference that may cause undesired operation. This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. -
Page 4: Safety Instructions
Safety Instructions Attention Never drop, knock, drill or submerge the motor. Keep the power cable in the proper position as shown below. Read all safety instructions before installation. Incorrect installation can lead to serious injury and will void manufacturer’s liability and warranty. ×... -
Page 5: Amp25B-1.1/28 Overview
AMP25B-1.1/28 Overview Fields of Application Roller Sheer Banded Roman Motor Head Button Instructions LED light P1 button Lithium Battery Switch 3. Charging Instructions This motor has a built in Li-ion battery pack with integrated charge management. Max power input for recharging: 5V 2A. -
Page 6: P1 Button Instructions
Test Motor Happening as you press for 1 second when released Press P1 Less than 1 sec. Motor Response: Wakes & Runs Activate Pairing Mode Happening as you press for 2 seconds when released Press P1 Approx. 2 sec. Until Shade:... -
Page 7: Amp
Remote Function ™ Remote Button Instructions LCD Display Stop Down Lower Higher Channel Channel Switch Replace/Install CR2450 Battery Gently insert the included ejector tool into the small pinhole opening and apply a small amount of pressure to the cover and slide the cover off. Battery Install battery (CR2450) with positive (+) side facing up. - Page 8 Advanced Setting - Disable Limit Setting Remove the cover from the backside of remote, the lock switch is in the right corner. Switch Move the switch to the “Lock” position to disable the following commands, remote will show “L” (lock): - Change Motor Direction - Setting the Upper and Lower Limit - Adjust Limit...
-
Page 9: Initial Set-Up
Initial Set-up Pair / Unpair Remote Control Press “P1” button (about 2 sec) on the motor head until Action on Motor motor jog x1 and beep x1. In the next 10 secs, press and hold “Stop” button on the Motor Response Jog x1 Beep x1 remote control until motor jog x2 and beep x3. -
Page 10: Adjust Limits
Adjust Limits 1. Adjust the Upper Limit Action on Remote Control Stop Press and hold (about 5 sec) “Up” and “Stop” buttons simultaneously until motor jog x1 and beep x1. Motor Response Jog x1 Beep x1 Use “Up” button to raise the shade to the desired highest position, and use “Up”... -
Page 11: Favorite Position
Favorite Position 1. Set Favorite Position Action on Remote Control Down Use “Up” or “Down” button to move the shade to desired Favorite position. Motor Response Beep x1 Jog x1 Press one “P2” button on the back of remote control until motor jog x1 and beep x1. -
Page 12: Add Or Remove Additional Remote
Add or Remove Additional Remote 1. Using Current Remote Control Action on Current Remote Control Current Remote Control Remote Control On the current remote control, press one “P2” button until motor jog x1 and beep x1. Motor Response Once more, on the current remote control, press one Jog x1 Beep x1 Jog x1... -
Page 13: Adjust Motor Speed
Adjust Motor Speed 1. Acceleration Speed Action on Remote Control Press one “P2” button until motor jog x1 and beep x1. Press “Up” button until motor jog x1 and beep x1. Motor Response Jog x1 Beep x1 Jog x1 Beep x1 Once more, press “Up”... -
Page 14: Roller Or Sheer Mode
Roller or Sheer Mode 1. Roller Shade Mode - continue movement Action on Remote Control after a short press - Default Mode Down Press and hold (about 5 sec) “Up” and “Down” buttons Motor Response Jog x1 simultaneously until motor jog x1. Press and hold (about 2 sec) “Stop”... -
Page 15: Quick Index
Down + Stop (hold down for 2s) 4 Add / Remove Favorite Position > Stop > Stop 5 Roller Mode & Sheer Mode Switch Up + Down (hold down for 5s) > Stop Upper Limit: Up + Stop (hold down for 5s) >...
