INTELLIGENT TOILET
Product Manual
Product Name: Intelligent Toilet
SKU: VO23200
#: 07-KW010001010000C
Thank you for purchasing our product. Please read this manual before installation and use to ensure that your product will function at
peak performance.
Read this manual thoroughly and store in a safe place for future references.
Advertisement
Table of Contents
Summary of Contents for VIITA VO23200
- Page 1 INTELLIGENT TOILET Product Manual Product Name: Intelligent Toilet SKU: VO23200 #: 07-KW010001010000C Thank you for purchasing our product. Please read this manual before installation and use to ensure that your product will function at peak performance. Read this manual thoroughly and store in a safe place for future references.
- Page 2 IMPORTANT SAFEGUARDS SAVE THESE INSTRUCTIONS When using electrical products, especially when children are present, GROUNDING INSTRUCTIONS basic safety precautions should always be followed, including the following: READ ALL INSTRUCTIONS BEFORE USING This product should be grounded. In the event of an electrical short circuit, grounding reduces the risk of electric shock by providing an escape wire for the electric current.
-
Page 3: Table Of Contents
Model Category 07-KW010001010000C Functions Unlimited wash Rear wash Front wash Aerated wash Auto wash new features to offer you an enjoyable experience Oscillating wash Parts Information Cleaning H/C massage Overview Adjustable water pressure Button control Adjustable water temperature Remote Control Adjustable nozzle position Detachable nozzle Warnings And Safety... -
Page 4: Button Control
H/C Massage Front Wash Flush Rear Wash Nozzle Position Flushing after Warm / Cold Massage Clean your front Clean your rear Adjust the nozzle VO23200-02 toilet position (back and forth) Caution Label VO23200-01 VO23200-11 Massage Flush Button control VO23200-10 Night... - Page 5 Warnings And Safety /03/ /04/...
- Page 6 /05/ /06/...
-
Page 7: Remote Control
Before You Install Confirmation of water pressure Required tools for installation.Please have these tools prepared prior to installation. ●The minimum dynamic operating water pressure is 35 psi, and the maximum static water pressure is 108 psi. Determination method for minimum water flow Drill Silicone gun Teflon tape... -
Page 8: Installing Your Product
Installing Your Product Install the ceramic body, water supply hose,T-valve 1. Place the wax ring on the drain hole at the bottom 4.Attach the flush water hose to the T-valve and tighten. of the ceramic. 2. Install sealing ange into drain outlet. 3. - Page 9 depth 1.Open the water supply angle valve to maximum 1.Connect to the grounding. (1) Check to see if the power light as shown in the figure. 2.Plug in AC 120V power plug. is on. (2) Press the side power button, 120V~ confirm the toilet is power on.
- Page 10 Power/Stop When the seat sensor no longer detects a user, it will automatically flush. Flush Standby mode: Long Press the button for 3 seconds The toilet will only flush once. to power on. Powered on and not seated: Long Press the button Powered on with no functions running.
- Page 11 ● Slow-closing lid/seat Preserve your toilet’s life and allows you to close the lid/seat silently. ● Damper The product has installed the damper which provide the toilet cover and toilet seat with a bu er function, to achieve the mute e ect. ●...
-
Page 12: Maintenance
Maintenance of product surface and ceramics Wipe dust or stains with a soft wet cloth. A wet soft brush, cloth or sponge may be used to clean the ceramic area. Do not use abrasive cleaning solutions, such as alcohol, bleach, paint thinner, cresol, benzene, gasoline, etc. -
Page 13: Power Button
Dryer Phenomenon Fault Diagnoses Solutions Check whether or not the dryer Regulate the temperature of dryer according to switches off the instruction manual The dryer blows cold air Check whether or not the heating Please contact with our qualified maintenance element of dryer is damaged personnel for repairing Heated Seat... - Page 14 Rated voltage 120V~ Frequency 60Hz Rated power input 1050W(When inlet water temp in 59℉) Seat and dryer temperature range 4 diffdrent levels Dryer temperature range 95℉-131℉ Water supply hose type DN15(G1/2″ ) Minimum pressure 35psi, ensuring a flow of water at least 10.57gal/min Water Inlet Maximum pressure 108psi (static state)
