1. NOTES • GUIDELINES • WARRANTY 1.1. GENERAL SAFETY INFORMATION • The radial fans meet EC machinery directives and have been developed using the latest technology. These fans meet recognized safety standards and guidelines, are reliable and are of high-quality. •...
CAUTION: Improper transport of the machine can cause damage to it. Inspect the radial fan for damage immedi- ately upon delivery– where applicable, file any complaint with the haulage company. Check that the delivery is complete, including accessories. Compare the information on the machine's type plate with the information on the delivery note.
DIN VDE 0100 and DIN VDE 0100-710. 3.4. PIPE CONNECTION ON THE INPUT SIDE NW 160 NW 200 NW 125 NW 160 NW 200 NW 125 EH.VE.8679 EH.VE.8680 EP .VE.29421 EP .VE.29422 EP .VE.29423 EP .VE.29424 EP .VE.29425 EP .VE.29426 EP .VE.29427...
Type Output Nominal current at 50 HZ (3~400 Volt) (3~230 Volt) 3×230V 3×400V Squirrel cage motor Squirrel cage motor EH.VE.8679 0,12 kW 1,12 A 0,64 A 3×400 Υ 3×230 Δ EH.VE.8680 0,25 kW 1,58 A 0,91 A EP.VE.29421 0,06 kW...
Starting for the first time after a successful test run: 1. Connect the fan to the supply/exhaust system using the elastic sleeve. 2. From the control unit, switch on the unit. 3. After reaching the operating speed, measure the current consumption. Compare this value with the nominal current on the type plate.
7.2. CONTINUOUS OPERATION ANNUAL ROUTINE • Check free passage through air openings and condensation outlets (only EH.VE.8679/8680) INSPECTION • Check that the screw connections are secure • Check for low-vibration running (if there are vibrations, refer to 5.5.) •...
7.4. CLEANING • Only to be carried out on the rotor and condensate drain (only EH.VE.8679/8680) • Clean the internal air passages when working with fluids with a strong tendency to crystallize Do not use the following: 1. Cutting tools 2.
8. REMOVING THE COMPONENTS OF EH.VE.8679/8680 NOTE: When using electrical tools, please observe the following: ¡ max. torque 2.4–2.5 nm ¡ max. speed 500 upm ¡ minimal axial thrust when screwing in screws/bolts CAUTION: Only carry out the work when disconnected from the power supply. See 6!
8.1. REMOVING THE DRIVE UNIT 1. Remove CAUTION: 2. Remove from Do not use any sharp-edge tools! 3. Undo . Note the instructions concerning electrical tools! The rotor is very sensitive to 4. Remove together with carefully. rough interventions on the 5.
Page 13
Fault Possible causes of fault Remedy A. Deposits on the rotor or nozzle Rotor grinding Inspect the region around the B. Change the opposite position rotor for foreign matter, check the between rotor and nozzle motor attachment, undo support, centre rotor/nozzle, and tighten the bolts back up A.
