Thank you for choosing SAIC MAXUS Automotive Co.,Ltd. May our products and services bring fresh joy to your life!
Please take time to read and understand this Handbook and other publications supplied with it. Thus you can familiarize yourself with
the vehicle and enjoy a driving experience with comfort, safety as well as economy.
This Driver's Handbook will provide you with the information necessary for getting familiar with your vehicle, including how to drive the
vehicle, how to carry out routine maintenance checks, and what to do in an emergency.
This Handbook contains the latest information upon the time of printing and all modifications, interpretations and explanations should
be reserved by the company. Based on the consideration that the products will be upgraded or in any other way(s) modified constantly,
the company reserves the right to apply these changes mentioned here before without notice when the Handbook has been hereby
printed and published and will accept no liability.
This Handbook is an indispensable part of the vehicle. If you want to sell the vehicle, please remember to provide the new owner with
this Handbook.
Special Announcement
Driver's Handbook and Warranty & Service Handbook specify the agreement between the company and the user on establishment
and termination of rights and obligations concerning the quality warranty and after-sales service of product. Please be sure to read the
Driver's Handbook and Warranty & Service Handbook carefully before using the product. If any damage is caused by misuse, neglect,
incorrect operation or unauthorized refit, the user will have no right of claim, and any warranty request will be refused by SAIC MAXUS
Automotive Co.,Ltd Service Dealer(hereinafter referred to as "Service Dealer").
Unauthorized re-production of this Handbook, whether electrically, physically or in any other way, and/or storing the Handbook in any
inquiry system of any form or type shall not be permitted.
Wish you a pleasant driving!
SAIC MAXUS Automotive Co.,Ltd. Address: #2500, Jun Gong Road, Yang Pu District, Shanghai Postcode: 200438
SAIC MAXUS Automotive Co.,Ltd reserves the final right to interpret this Handbook

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the D90 Series and is the answer not in the manual?

Questions and answers

Patrick Kila
August 7, 2025

is the Maxus LDV d90 both in manual and auto gear box?

0

Related Manuals for SAIC D90 Series

Summary of Contents for SAIC D90 Series

  • Page 1 Driver's Handbook and Warranty & Service Handbook carefully before using the product. If any damage is caused by misuse, neglect, incorrect operation or unauthorized refit, the user will have no right of claim, and any warranty request will be refused by SAIC MAXUS Automotive Co.,Ltd Service Dealer(hereinafter referred to as "Service Dealer").

  • Page 3: Table Of Contents

    Contents Perface................1 Front passenger seat adjustment..........26 Manual Introduction.............. 1 2nd row seats adjustment ............26 3rd row seats adjustment .............30 About this manual................1 Seat middle armrest adjustment ..........31 Prompt information .................1 Head restraints ................32 Precautions................3 Occupant Protection Device..........33 Hazardous materials ..............3 Properly seated ................33 Child/Animal ...................3 Seat belt ..................33...
  • Page 4 Contents Airbag Warning Lamp..............58 ECO Indicator Lamp..............66 Driver and Front Passenger Seat Belt Warning Lamp ....59 SPORT Indicator Lamp ..............66 Rear Seat Belt Warning Lamp............59 Fuel Filter Water Level Warning Lamp .........66 Brake System Warning Lamp............59 Glow Plug Indicator ..............66 ABS (Anti-lock Brake System) Warning Lamp ......60 DPF (Diesel Particulate Filter) Warning Lamp ......67 EBD (Electronic Brake Force Distribution) Warning Lamp ...60...
  • Page 5 Contents Recommendation for A/C operation ..........94 MP5+Radio (Type 2) ..............121 Common troubleshooting ............122 Rearview Mirrors..............94 2 Starting and Driving ...........125 Exterior Rearview Mirrors.............94 Interior rearview mirror ..............96 Before Starting and Driving ..........126 Interior Devices..............97 Ignition Switch ..............126 Ceiling reading lamps..............97 Key start ..................126 On-board inverter .................98 Keyless start................127...
  • Page 6 Contents DPF (Diesel Particulate Filter)............139 EPB (Electronic Parking Brake) ..........172 AUTO HOLD ................175 Fuel ..................142 Warning lamp ................176 Fuel filler cap ................142 Constant Speed Cruise Control System......176 Refueling ..................143 Gasoline detergent ..............144 Set cruise control................177 Save fuel ..................144 Terminate the cruise control ............179 Precautions for cold weather............145 Clear speed memory ..............179 Manual Transmission............146...
  • Page 7 Contents Hazard Warning Lamps .............222 Gasoline engine vehicles ............244 Diesel engine vehicles..............245 Warning Triangle..............222 Engine Hood ..............246 Wheel Replacement ............223 Open the engine hood..............246 Jack ....................223 Close the engine hood ...............246 Spare wheel ................223 Engine Oil ................247 Wheel replacement ..............225 Vehicle Towing..............228 Check and refill................247 Engine oil consumption ..............249...
  • Page 8 Contents Battery installation ..............258 Tires ...................258 Tire pressures ................258 Wear indicators ................259 Tire check and rotation...............260 Other Maintenance ............261 Vehicle wash ................261 Engine carbon deposit cleaning ..........261 Underbody corrosion protection ..........262 Seat and interior trim ..............262 Door seals ..................262 Windows..................262 5 General Technical Parameters ........263 Main Vehicle Dimension Parameters .........264 Complete Vehicle Mass Parameters ........265...

  • Page 9: Perface

    Manual Introduction Prompt information Warning About this manual This manual applies to D90 series Passenger car. This sign means that you must abide by relevant steps strictly and accurately in order to avoid Caution causing personal injuries to yourself and other The information covered by this manual does not aim to persons.
  • Page 10 Preface Note Arrows It indicates the described object. Note: This is suggestive description which is useful for you. It indicates the moving direction of an object. Environmental protection Please refer to Everyone is obliged to protect the environment. This symbol intends to remind you to pay attention The content referred.

  • Page 11: Precautions

    Preface Precautions Child/Animal An accident and personal injury may be caused Hazardous materials if any unsupervised child or animal operates the control devices and switches installed on the vehicle Most liquids and some substances used on a motor or contacts any equipment or objects transported vehicle are toxic.

  • Page 12: Vehicle Identification

    Preface Vehicle Identification When you contact our Service Dealer, you shall provide the vehicle identification number (VIN). The engine number may also be required if the engine is involved during communication. Vehicle Identification Number (VIN) VINs on the vehicle: • On the right front longitudinal beam of vehicle (seal position). •...

  • Page 13: Vehicle Plate

    Preface Vehicle plate Location of vehicle identification plate The vehicle identification plate (1) is located on the door frame Information contained on the vehicle plate of front door. • Vehicle identification number • Type • Engine Model • MNEP(Maximum net engine power) •...

  • Page 15: Before You Drive

    Before You Drive Keys 12 Doors and Locks 20 Windows 23 Seats 33 Occupant Protection Device 48 Instruments and Controls 49 Instrument Cluster 51 Information Center 58 Warning Lamps and Indicators 67 Instrument Panel Switch 69 Floor Console Switches 74 Switches on Steering Column and Steering Wheel 82 Steering Wheel Adjustment 82 Horn...

  • Page 16: Keys

    Before You Drive Keys to manufacture a same key with the lost one. Any uncoded key cannot start the engine but can lock/unlock doors. The vehicle is equipped with 1 ordinary key and 1 remote key, or 2 remote keys or 2 remote keys with passive entry & passive Ordinary key start system (hereinafter referred to as PEPS).

  • Page 17: Extension/Retraction Of Mechanical Key Portion

    Before You Drive Extension/Retraction of mechanical key portion Mechanical key portion of a remote key with PEPS Mechanical key portion of remote key can be extended or Press the release button on the remote key with PEPS, remove retracted，hereinafter referred to as mechanical key portion. the rear trim panel and pull the mechanical key portion from the key body.

  • Page 18: Replace Battery In Remote Key

    Before You Drive Replace battery in remote key To replace the battery, operate as per the following steps: Key battery has the risks of fire, explosion and Replace battery in remote key combustion. Do not charge the battery. The used 1 Extend the mechanical key portion;...
  • Page 19 Before You Drive Remote key with PEPS battery replacement 1 Release the button on the remote key with PEPS. 2 Remove the key head from the key itself. 3 Pry the upper and lower panels of the main body, remove the PCB (with battery) from the lower panel.

  • Page 20: Doors And Locks

    Before You Drive Doors and Locks Central lock system Using ordinary key, mechanical key section of remote Preventing the vehicle from theft control If you leave the vehicle while occupants are left in it, Perform manual lock/unlock operation on the driver door from even if the departure time is very short, be sure to outside with the ordinary key or mechanical key section of remove the key from the ignition switch, and special...
  • Page 21 Before You Drive Locking all doors Press the button (1) to lock all doors, but the prerequisite is that all doors are closed. Note: All turning signal lamps flashing once represents the confirmation for locking, if any door is not fully closed, there will be no audio alarm, please press the button (1) again after closing all doors.
  • Page 22 Before You Drive Remote door lock with PEPS Using central lock switch PEPS system allows you to lock or unlock the doors without This switch can enable or disable all door locks from inside. taking the remote key out of your pocket, wallet, or suitcase. Press the LOCK button to lock all doors.

  • Page 23: Manual Tailgate

    Before You Drive Manual tailgate The door can also be unlocked by pulling the inner handle twice. Door unlock/opening from outside When all doors are locked or unlocked with the key, remote key or central locking switch, the tailgate will also be locked or unlocked.

  • Page 24: Power Tailgate

    Before You Drive Power tailgate Remote key Long press the on the remote key for 2 seconds, and the Note: The tailgate swings up to open. When opening the tailgate will perform the opening/closing action. tailgate, make sure there are no objects or people near the rear of the vehicle.
  • Page 25 Before You Drive Foot kick sensing switch on the tailgate Caution The tailgate is equipped with an inductive opening system, with When operating the power tailgate, ensure that no one is in the remote key (The remote key must be in a semicircular area the opening and closing path of the tailgate, or you or others with a radius of about 1 m of the tail gate of the vehicle), take may be injured.
  • Page 26 Before You Drive Tailgate height setting Fully open mode The fully open mode is the vehicle default mode. Garage mode For the garage mode, you need to press the tailgate garage mode switch mode button at the reading lamp, and then the tailgate will be opened to the set garage height in each opening.

  • Page 27: Child Safety Door Lock

    Before You Drive Child safety door lock opposite direction to avoid the obstacle. After the obstacle removal, you may operate the power tailgate again. If the Where a child sits in the rear passenger seat, the tailgate encounters obstacles for consecutive 3 times in doors should be locked by the child safety door the power closing or opening process, the power function locks.

  • Page 28: Windows

    Before You Drive Windows The right rear door’s child safety door lock It is dangerous to leave children, incapacitated adults or pets on the vehicle with windows closed. They may faint out due to high temperature, or suffer permanent injury or even death due to heat stroke.
  • Page 29 Before You Drive Close all doors, pull up the window glass lifting button, until the window is fully closed, hold the button for about several seconds after the window is fully closed; then press the window glass lifting button until the window is fully open, hold the button for about several seconds after the window is fully open , the automatic up/down function will resume.

  • Page 30: Power Sunroof

    Before You Drive Power sunroof Position 4 – ：sunshade Close switch. Note: Both the opening and closing of sunshade switch are equipped with jog and auto function, make it easy to control the opening and closing process of the sunshade. Short press the second gear of he operating button, the sunshade will be automatically opened or closed.

  • Page 31: Seats

    Before You Drive Seats Backrest adjustment The tilt angle of driver seat should not be too large, Driver seat adjustment the seat belt can provide the maximum protection only when the seat back forms an angle of about 25° Do not adjust the driver seat while the vehicle is with the vertical direction.
  • Page 32 Before You Drive Electrically adjusted driver seat When the button (5) is pushed backward (arrow B), the seat will move backward, and when the seat slides to the desired position, release the button (5) to stop the seat sliding. Backrest adjustment The tilt angle of driver seat should not be too large, the seat belt can provide the maximum protection only when the seat back forms an angle of about 25°...
  • Page 33 Before You Drive Cushion height adjustment Massaging When the rear end of button (5) is pulled upward (arrow E), Press the button (4) to carry out a massaging, 10 minutes the cushion will move upward, when the cushion raises to the later, the massaging will be automatically turned off after the desired position, release the button (5) to stop the cushion completion of 30 seconds’...

  • Page 34: Front Passenger Seat Adjustment

    Before You Drive Front passenger seat adjustment 2nd row seats adjustment Manually adjusted front passenger seat Type I Only forward/backward sliding and seat backrest adjustment can be made, and its adjustment is consistent with that of manually adjusted driver seat. Electrically adjusted front passenger seat Only forward/backward sliding, seat backrest adjustment and lumbar support adjustment can be made, and its adjustment is...
  • Page 35 Before You Drive Lumbar support adjustment Type II Its adjustment is consistent with that of electrically adjusted driver seat. Lumbar support massaging Its adjustment is consistent with that of electrically adjusted driver seat. Foldable cup holder The left individual seat is equipped with a foldable cup holder, press the location indicated by the arrow, the cup holder will eject.
  • Page 36 Before You Drive 2nd row seat will be automatically flattened. Pull the handle (4) Easy entry function for the 2nd row three-abreast seats outward, the left 2nd row seat will be automatically flattened. This function will provide convenience for the entry/exit of 3rd row passengers.
  • Page 37 Before You Drive After the entry/exit of the passenger, restore the seat backrest Entry/exit of 3rd row passengers from the left side position, and press the cushion downward to the locked position Pull up the unlock lever (6), tilt the seat backrest forward at after the backrest is locked.

  • Page 38: 3Rd Row Seats Adjustment

    Before You Drive 3rd row seats adjustment Move the head restraint to the lowest position before the adjustment. Pull the unlock strap at the upper part of the seat Seat backrest folding forward backrest forward to unlock the seat backrest, fold the backrest forward until it is against the cushion.

  • Page 39: Seat Middle Armrest Adjustment

    Before You Drive Seat middle armrest adjustment Seat backrest unfolding backward Pull the unlock strap at the back of the seat backrest to rear Pull it down and push it forward for use. upper side, to unfold the seat backrest backward to the locked position.

  • Page 40: Head Restraints

    Before You Drive Head restraints Type II To reduct the risk of neck or head injury, the head restraints shall be adjusted to support the back of the head rather than the neck. Before driving, adjust and ensure that the head restraints of front and rear seats are in locked position (this locked position is the safe use position).

  • Page 41: Occupant Protection Device

    Before You Drive Occupant Protection Device Seat belt Improper seat belt wearing or use may result in the Properly seated serious personal injury or death. The seat belt is one The seats and the occupant protection device are designed to of life-saving equipments.
  • Page 42 Before You Drive Do not hold an infant or child on your lap. They will When not in use, be sure to fully retract the seat belt become too heavy to restrain in case of collision. webbing, straighten the webbing and put the locking tab in place, keep the webbing and locking tab clean Prevent the foreign materials (especially the sugary and away from dust and impurities.
  • Page 43 Before You Drive Adjustable Seat Belt with Pretensioner (Shoulder Belt Adjustable Seat Belt with Dual Pretensioners (Shoulder / Pretensioner) Lap Belt Pretensioner) In the event of serious collision accident, the pretensioner In the event of serious collision accident, the dual pretensioners (integrated into the retractor) will be activated by the sensor, the (one integrated into the retractor, the other integrated into the shoulder belt (1) will be retracted a little immediately to prevent...
  • Page 44 Before You Drive Seat Belts for Front Seats Seat Belts for 2 Seats in Second Row The seat belts for 2 seats in 2nd row are fastened and released Fastening in the same way as the seat belts for front seats. Pull out the seat belt slowly, have it passed over the shoulder and then the front of the body, confirm that it is not twisted or tied, then push the locking tab into the buckle until a click is heard.
  • Page 45 Before You Drive Seat Belts for 2 Seats in Third Row Ceiling Seat Belt for Middle Seat in Third Row (With 3 Seats) The seat belts for 2 seats in third row are fastened and released in the same way as the seat belts for front seats. Fastening Pull out the seat belt from the ceiling, have the fixed locking tab (2) pushed into the left buckle, and have the movable locking tab...
  • Page 46 Before You Drive Releasing To withdraw the seat belt comfort guide ring, squeeze both edges of the seat belt together and remove the seat belt from the guide ring. Then stow the guide ring in the seat back storage bag. The movable locking tab (1) is unlocked by pressing the red button on the right buckle.
  • Page 47 Before You Drive Plastic Hooks for Side Seat Belts Seat Belt Height Adjustment When not in use, the side seat belts for second and third rows Ensure that the sliding adjuster is secured after the can be snapped into the side seat belt hooks. adjustment.

  • Page 48: Seat Belt Pretensioner

    Before You Drive Seat belt pretensioner Airbag Do not damage or repair the pretensioner. None protection device is absolutely safe, when it contains the ignition device, so it can only be used to avoid the occurrence of serious collision, repaired by our Service Dealer. it may result in the personal injury or death.
  • Page 49 Before You Drive For the seat with seat airbag, it is forbidden to set the The disposal of the undeployed airbag on the vehicle seat cover or other decorative items that affect the exists the potential risk, it should be deployed before deployment of seat airbag.
  • Page 50 Before You Drive Airbag and Pretensioner Inspection movement of the driver and the front passenger, thereby reducing the risk of injury to the head and upper torso. If the ignition switch is turned on, the warning light After the deployment, the airbags deflate immediately, which is not turned on or not turned off after 6 seconds, or ensures that the driver's forward vision is not obscured.

  • Page 51: Child Restraints (Not Available With The Vehicle)

    Before You Drive Child restraints (not available with the vehicle) Replacement of SRS Components after a Collision Collision accidents may damage the SRS on May result in death or serious injury! the vehicle. Airbags may not function properly The airbag can kill the children under 12-year old. after damage, and can not protect you and other The backward-facing child or infant restraint device passengers when a collision accident occurs, which...
  • Page 52 Before You Drive Compared with adults, children are more vulnerable by the anchorage). Unless using ISOFIX lower anchorages, use expanded airbag. So, it is recommended that the children the seatbelt complete the installation in line with the child under 12 years old should seat on the rear seat. Generally the restraint manufactures instructions.
  • Page 53 Before You Drive Type I of 2nd row seat Type II of 2nd row seat Front of vehicle 8 seats variant 7 seats variant 5 seats variant ISOFIX TOP TETHER Front of vehicle Attaching clip...
  • Page 54 Before You Drive Child seat groups and installation positions Only the child restraints which are approved and suitable for children are allowed to use. Children above 1.5m in height can directly use the seat belt. The child seats shall comply with relevant regulations or standards, such as European regulations ECE-R44, ECE-R129, and Chinese regulations GB27887-2011.
  • Page 55 Before You Drive Adaptability of ISOFIX child restraints in different ISOFIX positions ISOFIX Positions on the Vehicle Mass Group Size Categories Fixed Module First-row Second-row Left Second-row Right Third-row ISO/L1 Portable Bed ISO/L2 0 Group (Less than 10 kg) ISO/ R1 ISO/R1 0+ Group (Less than 13 kg) ISO/R2...

  • Page 56: Instruments And Controls

    Before You Drive Instruments and Controls Front passenger airbag A/C control panel Hazard warning lamp switch Entertainment system Ignition switch Wiper & washer stalk switch Instrument cluster selection and cruise switch Instrument pack Driver airbag 10 Voice control, Bluetooth phone, steering wheel heating and customized switch 11 Combination lamp control &...

  • Page 57: Instrument Cluster

    Before You Drive Instrument Cluster Instrument cluster type II Trip computer interface Instrument cluster type I Other interfaces...

  • Page 58: Speedometer

    Before You Drive Engine coolant temperature gauge 1 Speedometer 2 Tachometer Indicates the approximate temperature of the engine coolant. If the coolant overheats, the "Engine Coolant Temperature 3 Fuel gauge Warning Lamp (red)" will illuminate. 4 Engine coolant temperature gauge Caution Caution If the red warning lamp illuminates, stop the engine as soon...

  • Page 59: Information Center

    Before You Drive Information Center Short press the button in the instrument cluster selection Information center type I switch on the steering wheel to achieve the switching of following interfaces: Trip Computer interface→Active The information center display is located at the right side of the Safety interface(when your vehicle is equipped with this instrument cluster.
  • Page 60 Before You Drive • Since the reset You can set the instrument cluster display brightness. • Time setting Displays the trip, average speed, driving time, average fuel consumption since the last reset. You can set the time on the instrument cluster. •...

  • Page 61: Information Center Type Ii

    Before You Drive Information center type II of following interfaces: Trip Computer interface→Navigation Map interface(when your vehicle is equipped with this The information center display screen is located in the middle of function)→Multimedia interface→Contacts interface→Active instrument cluster. Safety interface(when your vehicle is equipped with this function)→Settings interface→Failure Inquiry interface (if a failure is available)→Trip Computer interface.
  • Page 62 Before You Drive Displays the trip, average speed, driving time, average fuel Active safety interface consumption since the last reset. It displays the relevant driver assistant information. Long press the OK button in this interface to reset the trip, • Adaptive cruise average speed, driving time and average fuel consumption.

  • Page 63: Alarm Messages

    Before You Drive Alarm messages You can turn on and off the overspeed alarm. When the overspeed alarm is turned on, the overspeed alarm triggering Most of the alarm messages will have a corresponding graphic speed value can be adjusted. and text description on the instrument cluster.

  • Page 64: Fatigue Driving Detection And Reminder

    Before You Drive Fatigue driving detection and reminder Prompt messages Prompt messages will automatically disappear after 3 seconds. Fatigue driving detection and reminder function is to remind drivers not to drive the vehicle at the time Caution of fatigue. The system will record the continuous Do not ignore the alarm messages, or severe damage to the driving time, while monitoring the steering wheel vehicle may occur.

  • Page 65: Tire Pressure Monitoring System

    Before You Drive Tire pressure monitoring system speed is higher than 65km/h, the instrument cluster display will display the following interface, accompanied with voice The tire pressure monitoring system can conduct real-time prompts. automatic monitoring on the tire conditions, providing an effective safety assurance for driving.

  • Page 66: Warning Lamps And Indicators

    Before You Drive Warning Lamps and Indicators Rear Fog Lamp Indicator Direction Indicator "Rear Fog Lamp Indicator (yellow)" illuminates when the rear fog lamp is turned on. The right or left "direction indicator (green)" Position Lamp Indicator blinks when making a turn. The right and left direction indicators blink simultaneously when the hazard warning lamp switch is pressed.

  • Page 67: Driver And Front Passenger Seat Belt Warning Lamp

    Before You Drive a malfunction. Please contact our Service Dealer for service as a short time or flash for a short time and sound a warming, it soon as possible. indicates that the rear seat belt is not properly secured, please fasten your seat belt.

  • Page 68: Abs (Anti-Lock Brake System) Warning Lamp

    Before You Drive ABS (Anti-lock Brake System) Warning Lamp ESP (Electronic Stability Program) Indicator Lamp When the ignition switch is turned to the ON position, "ABS warning lamp (yellow)" illuminates, the system conducts When the ignition switch is turned to the ON position, the self-check and the lamp goes off after several seconds.

  • Page 69: Hill Descent Indicator Lamp

    Before You Drive Hill Descent Indicator Lamp Please contact Service Dealer for service as soon as possible, meanwhile, avoid the too high engine speed or fast acceleration. When the Hill Descent is turned on and the operating Oil Pressure Warning Lamp conditions are met, the "Hill Descent Indicator Lamp (green)"...

  • Page 70: Body Theft Deterrent Warning Lamp

    Before You Drive Battery Charging Indicator Lamp If the "Engine Immobiliser Warning Lamp (yellow)" blinks, it indicates that the immobiliser control system has a malfunction, the engine can not be started, please contact Service Dealer for When the ignition switch is turned to the ON position, service immediately.

  • Page 71: Adaptive Cruise Vehicle-To-Vehicle Distance Indicator Lamp

    Before You Drive Lane Departure Alert Warning Lamp Indicator Lamp (green)" illuminates. When the adaptive cruise control system is in standby mode, the "Adaptive Cruise Control (ACC) Indicator Lamp" on the instrument cluster will change from With the ignition switch placed in ON position, when green to white.

  • Page 72: Auto Hold Indicator Lamp

    Before You Drive conditions are not met, the "Intelligent Start/Stop System HOLD is on, the vehicle speed exceeds 3 km/h and the seat belt is not fastened, the “AUTO HOLD Indicator Lamp (green)” illuminates to remind the driver that the AUTO HOLD On state Indicator Lamp (white)"...

  • Page 73: Electronic Parking Brake (Epb) Malfunction Indicator Lamp

    Before You Drive Electronic Parking Brake (EPB) Malfunction Front Collision Warning (FCW)/Automatic Indicator Lamp Emergency Braking (AEB) Warning Lamp When the ignition switch is turned to the ON position, With the ignition switch placed in ON position, when "EPB Malfunction Indicator Lamp (yellow)" illuminates, the the front collision warning system is operative, and the automatic system conducts the self-check and the lamp goes off after emergency braking warning system does not give a warning,...

  • Page 74: Traffic Signs Warning Lamp

    Before You Drive SPORT Indicator Lamp is successfully locked, the "Electronic Differential Lock Indicator Lamp (yellow)" illuminates. With the ignition switch placed in ON position, the "Electronic Turn the ignition switch to ON position. For models with Differential Lock Indicator Lamp (red)" illuminates, it indicates the SPORT mode switch, press the SPORT switch, "SPORT that the electronic differential lock system has a malfunction, Indicator Lamp (green)"...

  • Page 75: Dpf (Diesel Particulate Filter) Warning Lamp

    Before You Drive Instrument Panel Switch Caution If the indicator stays on after the engine is started, please Instrument panel illumination control switch contact Service Dealer for service as soon as possible. The instrument panel illumination control switch is located on the instrument panel at driver side.

  • Page 76: Headlamp Leveling Switch

    Before You Drive Headlamp leveling switch Adaptive front-lighting System The headlamp leveling switch is located on the instrument panel If your vehicle is equipped with AFS (Adaptive Front-lighting at driver side. System), the system automatically adjusts the headlamp beam height according to the driving speed, vehicle load and ramp With this function, the headlamp leveling can be adjusted to angle.

  • Page 77: Hazard Warning Lamp Switch

    Before You Drive Floor Console Switches Hazard warning lamp switch Switch group in left front side of the shift lever Press the hazard warning lamp switch to activate all turning signal lamps meanwhile, and the "direction indicator lamp (green)" on the instrument cluster will illuminate and flash. Then Position 1–...

  • Page 78: Switch Group In Left Rear Side Of The Shift Lever

    Before You Drive Switch group in left rear side of the shift lever gear indicator lamp of the switch illuminates; for more information, please refer to "Four Wheel Drive (4WD)" in Type I the Starting and Driving section. Position 5– : driver seat heating. There are three gears for driver seat heating.
  • Page 79 Before You Drive Type II Position 6– ECO : economic mode switch. Press down this switch to drive the vehicle under the economic mode, under which the engine power will be relatively weak. It is unable to enable the economic mode under the 4L mode. Position 7–...

  • Page 80: Switch Group In Right Side Of The Shift Lever

    Before You Drive Switch group in right side of the shift lever Position 3– SPORT : sport mode switch. Position 4– ECO : economic mode switch. Position 5– AUTO : automatic mode switch. Position 6– ROCK : rock mode switch. Position 7–...
  • Page 81 Before You Drive its indicator lamp and turn off the engine intelligent start/stop lock On/Off state with the EDL switch. Please refer to "Electronic system; re-press the switch to turn on the system. For more Differential Lock (EDL)" in the Starting and Driving section for information, please refer to "Intelligent Start/Stop System"...

  • Page 82: Switches On Steering Column And Steering Wheel

    Before You Drive Switches on Steering Column and Steering Ignition switch and steering lock Wheel Pull out the key. Then the steering lock will be activated to prevent the steering wheel from rotating. In order to pull out the key from the ignition switch, please turn the key to ACC position.

  • Page 83: Combination Lamp Control & Direction Indicator Lamp Stalk Switch

    Before You Drive Combination lamp control & direction indicator Note: Initial position of headlamp switch is suggested to lamp stalk switch AUTO position. Position 3 – : Width lamps on. When width lamps are turned Lighting control switch on, the following lamps will be turned on meanwhile: •...
  • Page 84 Before You Drive Position 7 – : Rear fog lamps on. When the ignition switch is High beam and low beam lamps placed in ON position and the lighting control switch is placed position, turn the switch to , and then rear fog lamps will be turned on.

  • Page 85: Wiper & Washer Stalk Switch

    Before You Drive Wiper & washer stalk switch Daytime running lamp The daytime running lamp make it easier for others to see the Front windshield wipers and washer front of the vehicle during the daytime. If your vehicle is equipped with the daytime running lamp, when the ignition switch is placed in ON position, the daytime running lamp will illuminate.
  • Page 86 Before You Drive Intermittent wiping/interval adjustable Caution In cold or hot days, in order to prevent damaging wipers, If worn wiper blades cannot clear rain from the front please clear barriers from the windshield (such as snow) if windshield, the forward visibility will be lowered, wiper blades are frozen or adhere to the windshield.

  • Page 87: Instrument Cluster Selection And Cruise Switch

    Before You Drive Instrument cluster selection and cruise switch Rear window wipers and washers Rotate the stalk switch to the desired position. Position 1, 4 – : washers spraying water and wipers running. Position 1 – : instrument cluster selection button. Press up, down, left and right to enter the instrument cluster for page Position 2 –...
  • Page 88 Before You Drive Constant speed cruise control system Adaptive Cruise Control (ACC) Position 2 – : Cruise on/off switch. Press this button to turn Position 2 – : adaptive cruise master switch, press it to turn on/off the cruise control system. The "Constant Speed Cruise the system on or off.

  • Page 89: Voice Control, Bluetooth Phone, Steering Wheel Heating And Customized Switch

    Before You Drive Voice control, Bluetooth phone, steering wheel heating and customized switch Position 1 – : audio source switch. Press SRC to switch between the radio and MP3 playback interfaces, press up to Type I increase the volume, press down to decrease the volume; short press , switch to previous band/MP3 track, long press , fast rewind;...

  • Page 90: Steering Wheel Adjustment

    Before You Drive Steering Wheel Adjustment Horn Do not adjust the steering wheel position during Regardless of the ignition switch position, the horn can work driving. This is extremely dangerous. once you press the button. Adjust the steering wheel position to adapt to your driving posture through the following steps: 1 Fully release the steering wheel adjusting handle on the steering column downwards;...

  • Page 91: Heating, Ventilation And Air Conditioning

    Before You Drive Heating, Ventilation and Air Conditioning Front vents The air conditioning system can cool down the air and remove the moisture and the dust (e.g., pollen) in the air. The heating system utilizes the heat generated by the engine, so it can heat the air in the vehicle sufficiently only when the engine gets to the normal operating temperature.

  • Page 92: Rear Vent

    Before You Drive Rear vent Central vent Move the lever (1) in the center of the grille up and down, right Turn the grille or move the lever (1) in the center of the grille to and left to change the direction of the air distribution. change the direction of air distribution.

  • Page 93: Automatic A/C Front Control Panel

    Before You Drive Automatic A/C front control panel AUTO button This is the automatic air conditioning control mode button. Press the AUTO button to enter the full AUTO state, each control will enter the automatic working state, the AUTO indicator illuminates, in the full AUTO state, press the AUTO button again to disable it.
  • Page 94 Before You Drive infotainment display will display the information about the related OFF button air distribution mode. When the panel is in the working state, press the OFF button, The operation of MODE is invalid in the OFF state, the mode will the A/C panel enters the off state, the A/C output is closed, the recover the non-defrosting mode memorized before powered off.
  • Page 95 Before You Drive When the SYNC indicator lamp is off, the user may adjust the A/C is controlled automatically in AUTO mode, and it changes set temperature at driver side or front passenger side without to the manual control from AUTO control by operating the A/C affecting each other.
  • Page 96 Before You Drive the infotainment display vary according to the rear defrost state that the front A/C control panel resumes its control on the front (vehicle is started). A/C, and the rear A/C can only be adjusted with the rear A/C control panel.

  • Page 97: Electronic A/C Front Control Panel

    Before You Drive Electronic A/C front control panel Temperature selection knob Adjust the A/C set temperature. The temperature selection knob can be rotated and adjusted in 15 levels, if it is rotated counterclockwise, the set temperature is gradually reduced; if it is rotated clockwise, the set temperature is gradually rising.
  • Page 98 Before You Drive In the ON state, if the Distribution to Feet Mode button is A/C button pressed, the corresponding indicator comes on and it becomes Switch on and off the compressor. the Distribution to Feet Mode, the operation of the Distribution With the blower in ON state, press the A/C button, the to Feet Mode button is invalid at this time, and it will change to corresponding indicator lamp illuminates and the compressor is...

  • Page 99: Automatic A/C Rear Control Panel

    Before You Drive Automatic A/C rear control panel For vehicles equipped with the heated exterior rearview mirror, press the Rear Defrost Button to activate the heated exterior rearview mirror, to help clear the fog or frost on the surface of rearview mirror.
  • Page 100 Before You Drive Rear A/C temperature selection button Press the air volume button int the OFF state, the controller will exit the OFF state and return to the state before OFF, and the There are 2 rear A/C temperature selection button, namely, air volume level before OFF in memory will be recalled.

  • Page 101: Electronic A/C Rear Control Panel

    Before You Drive Electronic A/C rear control panel damper in sequence: Distribution to Face mode, Distribution to Face and Feet mode, Distribution to Feet mode. Rear A/C AUTO button After pressing the AUTO button, the A/C enters the AUTO control mode, the AUTO icon is displayed on the LCD.

  • Page 102: Recommendation For A/C Operation

    Before You Drive Rearview Mirrors Recommendation for A/C operation • If the vehicle is parked in a place that is exposed to the direct In order to extend the view range, exterior rearview mirrors are sunlight, open the windows before operation. convex-shape, which makes objects look smaller and farther •...
  • Page 103 Before You Drive Switches equipped with power folding function • Automatic power folding/unfolding of rearview mirrors When rearview mirrors are folded and the ignition switch is placed in OFF position, the key to unlock, then rearview mirrors will be unfolded automatically. Or, rearview mirrors will be automatically unfolded as long as there is a legitimate remote key with PEPS existing within the range of 1 meter around the vehicle, press the micro switch on the driver door...

  • Page 104: Interior Rearview Mirror

    Before You Drive Interior rearview mirror Exterior rearview mirrors automatically tilt during reversing Adjust the rearview mirror to obtain the required rear view. When the driver shifts the lever to the R gear position, the Manual adjustment of interior rearview mirror exterior rearview mirrors on both sides will tilt automatically, letting the driver see the curbs or rear wheels and facilitating the Operate the adjusting lever on the bottom of rearview mirror to...

  • Page 105: Interior Devices

    Before You Drive Interior Devices Turn off the reading lamp Press , to turn off the internal reading lamp. Ceiling reading lamps With the doors closed, place the switch in position, press the Front ceiling reading lamp black cover, and turn on the internal reading lamp. Rear ceiling reading lamp On/off switch When the front ceiling reading lamp is in the door control mode,...

  • Page 106: On-Board Inverter

    Before You Drive On-board inverter • High battery voltage. Please wait for the battery voltage to return to normal. Please pay attention to electric safety during usage. • 220V power supply temperature is excessively high. Prevent children from contacting this outlet. Danger! Please remove the electric appliance and wait for the High voltage! green lamp to go on.

  • Page 107: Usb Port

    Before You Drive USB port The USB port at the rear bottom side of central armrest The USB ports are located in the storage box of floor console,at The USB port at the rear bottom side of central armrest can the rear bottom side of central armrest, and on the left rear side be used for charging or multimedia file playback, (this function armrest.

  • Page 108: 12V Power Outlet

    Before You Drive 12V power outlet Right rear side armrest The power outlets are located at the rear bottom side of central armrest between the driver and front passenger, on the right rear side armrest, at the left side of luggage compartment, they are mainly used for providing power supply connection for external electric devices.

  • Page 109: Cigar Lighter

    Before You Drive Cigar lighter Ashtray Release the cigar lighter in time after pressing it, There is a fire risk in the ashtray. A fire may be otherwise it may be damaged. caused if you place a lighted cigar and combustible matter together.

  • Page 110: Cup Holder

    Before You Drive Cup holder Cup holder on the armrest of second row seats Cup holder on the floor console Cup holder at both sides of third row seats...

  • Page 111: Storage Box

    Before You Drive Storage box Storage box under the front armrest Storage box at driver side Type I The storage box at driver side is located below the front of the Lift the armrest to open the storage box. floor console at driver side. It can be opened by releasing the storage box upper buckle.

  • Page 112: Glove Box

    Before You Drive Glove box Sun visor and vanity mirror Pull both sun visors upwards or downwards to block the sunshine Do not place a sharp, heavy or hazardous object in through windshield. Besides, sun visors can be rotated towards the glove box at front passenger side.

  • Page 113: Glasses Box

    Before You Drive Glasses box Fire extinguisher Flip the glasses box in the direction of the arrow to open it. Note: It is subject to the actual configuration of the vehicle you purchased. Note: The glasses box should be used when the vehicle is stopped.
  • Page 114 Before You Drive The use of the portable fire extinguisher at the liquid surface directly, so as to prevent the flammable liquid from splashing due to the impact force and expanding 1 Pull out the safety pin; the fire, resulting in fire fighting difficulties. When fighting the ordinary fire of solid materials, spray by aiming at the most violent combustion area, and spray in the up and down, left and right direction;...

  • Page 115: Vehicle Tools

    Before You Drive Vehicle tools 3 The cylinder body is free of rust, deformation, and all components have no deformation and damage. The vehicle tools are placed at the bottom of the luggage compartment(for vehicles with three rows of seats) or behind Note: Non-professionals are not allowed to disassemble the the second row of seats(for vehicles with two rows of seats).

  • Page 116: Mp3+Radio

    Before You Drive MP3+Radio Panel features description 1 Mute Button 2 PWR/VOL: Power On/Off button Volume adjustment knob 3 System Setting Button 4 Preset Button 1/ Pause Button USB track confirmation function: Press to enter playback state 5 Preset Button 2/ Repeat Playback Button 6 Preset Button 3/ Random Playback Button 7 Preset Button 4 8 Preset Button 5/ Next Directory(USB mode)

  • Page 117: Audio Adjustment

    Before You Drive Audio adjustment Volume Rotate the PWR/VOL knob to adjust the volume. For safety Power On/Off reasons, please choose the proper volume to ensure that you With the ignition switch in ACC or ON, short press the PWR/VOL can still hear the external traffic signal sound (whistle, police button to turn on the unit, and short press the button again to whistle, etc).

  • Page 118: Radio Reception

    Before You Drive Radio reception previous stations stored in FM 1-3 bands or AM 1-2 bands will be overwritten. Band Long press the AST/ button to enter the Automatic Station Press BND button to select the desired band. The band can be Storage state, then: switched among FM1, FM2, FM3, AM1, AM2, then the system •...

  • Page 119: Playing In Usb Mode

    Before You Drive Playing in USB mode Caution There is no external USB port on the player panel, the USB port The player is to be initialized to search for MP3 files as is located on the floor console, which can be connected with your the USB storage device is just connected, the waiting time U disk or portable media player.
  • Page 120 Before You Drive Fast Forward/Rewind Playback Caution Long press the SCN/ button during the playback to fast forward • The USB port of this unit supports to charge external the track from the current playback node. devices whose voltage is within the following range (e.g. mobile phone charging).

  • Page 121: Bluetooth

    Before You Drive Bluetooth Caution The Bluetooth connection between the mobile phone and the • The Bluetooth pairing requires your mobile phone system must be completed before operating the system. This supporting HFP (Hands-Free Profile) Bluetooth application connection is based on the mating connection between the protocol.
  • Page 122 Before You Drive Bluetooth Connection Answering and Rejecting Incoming Calls Long press "Answer Incoming Bluetooth Call" button to enter the After the connection is established, when there is an incoming Bluetooth pairing mode. The radio display will display the word call, the radio will display the word "PHONE", and the incoming "PHONE"...
  • Page 123 Before You Drive Redialing of Latest Number and Disconnection "Answer Incoming Bluetooth Call" button Under this situation ... Short press Answering button Redialing of Latest Number External calls Answering Incoming Calls After the connection is established, long pressing the "Answer Incoming Bluetooth Call"...

  • Page 124: Aux In Interface

    Before You Drive AUX IN interface Volume during reversing There is no external AUX IN port on the player panel, but s When it is reversing, the infotainment system is controlled by standard audio interface of 3.5mm is reserved on the floor the reversing lines, so the volume of all sound sources will be console, you can connect an audio playback device with reduced, then the volume of original source will be resumed...

  • Page 125: Common Troubleshooting

    Before You Drive Common troubleshooting If you find some features of the car audio are inoperative, please read the operating guide in this manual carefully before sending it to repair, then make the inspection according to the following table, this contributes to the troubleshooting. Symptoms Possible Causes and Solutions General Conditions...
  • Page 126 Before You Drive Symptoms Possible Causes and Solutions Artist/Track/Title can not be Displayed This unit does not support the ID3 information display. The music pauses intermittently during playback This may be caused by the different compression formats. Confirm that the hard drive has only one partition, as this unit does not support the multiple disk partitions.

  • Page 127: Mp5+Radio

    Before You Drive MP5+Radio Caution • The product shall be kept away from moisture. Precautions before use • Be sure to drive safely. For the instructions of MP5+Radio in the vehicles, please refer • Make sure to follow the rules of safe driving and existing to the operating instructions accompanied with the entertainment traffic regulations.

  • Page 128: Mp5+Radio (Type 1)

    Before You Drive MP5+Radio (Type 1) highlighted. If they are not connected, the relevant icons will not be displayed. 2 Time display The current system time is displayed. 3 Volume button The current volume information is displayed. Touch this button to show the volume bar. Slide the volume bar can directly adjust the volume.

  • Page 129: Mp5+Radio (Type 2)

    Before You Drive MP5+Radio (Type 2) Application Center For the related guide, we prepare for a user manual on the homepage of the screen. Please click and see. 1 Click the central icon on the bottom. 1 HOME Button In main interface mode, long press for about 3 seconds to power off, then press for about 10 seconds to restart.

  • Page 130: Common Troubleshooting

    Before You Drive Common troubleshooting Symptoms Possible Causes Solution Improper Brightness Setting Enter the screen setting to adjust the brightness of screen. Screen Too Dark Vehicle Headlamp Normally ON Vehicle Headlamp OFF Appliance Power Supply or Please ask Service Dealer to replace it with the fuse of correct Not Power On Vehicle Fuse Blown type.
  • Page 131 Before You Drive Symptoms Possible Causes Solution The USB flash disk has poor Make sure that the USB flash disk is original and quality-assured. quality. The capacity of USB flash disk Please use the USB flash disk with a capacity within 32G. exceeds the limit of 32G.

  • Page 133: Starting And Driving

    Starting and Driving 126 Before Starting and Driving 126 Ignition Switch 129 Keyless Start System 131 Engine Immobilizer System 132 Start/Stop the Engine 133 Intelligent Start/Stop System 136 Driving 138 Catalytic converter 142 Fuel 146 Manual Transmission 147 6AT Automatic Transmission 149 8AT Automatic Transmission 158 Electric Power Steering Device 159 Four Wheel Drive System...

  • Page 134: Before Starting And Driving

    Starting and Driving Before Starting and Driving Ignition Switch Key start • Conduct daily/weekly maintenance checks on the vehicle in accordance with the provisions in Maintenance - Owner Do not pull out the key during driving. Otherwise you Checks. will lose control of vehicle direction. •...

  • Page 135: Keyless Start

    Starting and Driving Keyless start Note: Do not leave the key in ACC position for a long time, so as to prevent unnecessary battery power loss. ON: The ignition switch is on, and all instruments, control devices and circuits can operate. Note: When the engine is not running, do not leave the key in ON position.
  • Page 136 Starting and Driving • Emergency Flameout Depress the clutch pedal all the way down and hold. • Automatic Transmission W hen the vehicle speed is higher than 5km/h during driving, press the ignition switch for 3 times continuously or long press Place the shift lever in P or N position.

  • Page 137: Keyless Start System

    Starting and Driving Keyless Start System • The remote key is left in the vehicle • The remote key is not in the sensing range Keyless unlocking • The remote key battery is low • The driver's door is open When all doors are locked, enter the sensing area with a remote key and press the microswitch, the central lock will unlock Note: It is feasible to lock doors with the central locking...

  • Page 138: Backup Starting

    Starting and Driving Note: If the starting conditions are not met, every time you press the start-stop switch, the power supply positions will be switched among OFF, ACC and ON in a cycle. If the remote key is not in the vehicle, after depressing the brake pedal, the indicator lamp will not illuminate, and the power supply position switching or ignition action will not be performed after the start-stop switch is pressed.

  • Page 139: Engine Immobilizer System

    Starting and Driving Engine Immobilizer System Enable/disable When the key is switched from LOCK position to ON position, if Keys the authentication succeeds, the IMMO warning lamp (yellow) The keys have been coded electronically for your vehicle. The on the instrument cluster will keep off for a long time. If the coded keys can be used for the corresponding vehicle only.

  • Page 140: Start/Stop The Engine

    Starting and Driving Start/Stop the Engine Note: During starting, do not keep the starter running for 10s above. If the engine is not started, wait for at least 30s Starting after turning off the ignition switch and try again. CO is a harmful gas and may cause coma, even Vehicles with Diesel Engine death.

  • Page 141: Warm-Up

    Starting and Driving Intelligent Start/Stop System Warm-up When the engine temperature is relatively low, there will be Note: It is suitable for vehicles installed with intelligent a poor effect if the engine is warmed up with the vehicle in start/stop system. stationary state.

  • Page 142: Shutdown And Startup Of Engine

    Starting and Driving Shutdown and startup of engine Basic conditions of usage for the intelligent start/stop system: • The driver door has been closed. Vehicles with automatic transmission • The driver has fastened the seatbelt. Please conduct a full braking to the vehicle; after the vehicle •...

  • Page 143: Instructions

    Starting and Driving Instructions Caution Normal intelligent start/stop action may be interrupted due to When the engine is shut down, please depress the brake different system conditions. pedal to avoid vehicle slip. If the engine intelligent start/stop system switch on the floor console is pressed during the The engine is not shut down engine stop phase, the engine will get started automatically.

  • Page 144: Driving

    Starting and Driving Driving interrupted. The engine gets started again without the action of the driver. "Running-in" of new vehicle • The vehicle rolls like on a slope. • The windshield is being defrosted. The vehicle does not need intentional "running-in". In order to •...

  • Page 145: Driving

    Starting and Driving Driving Wading driving In order to avoid damage to your vehicle, when passing a road During driving, do not place any portable container with gathered water, please: filled with fuel in the vehicle. Otherwise a fire may •...

  • Page 146: Catalytic Converter

    Starting and Driving Catalytic converter Water and mud can affect the braking system and lengthen braking distance, leading to an accident! The catalytic converter will release a lot of heat (even • Slightly depress the brake pedal to keep brake within a short time after engine shutdown), which parts dry and recover performance.

  • Page 147: Dpf (Diesel Particulate Filter)

    Starting and Driving DPF (Diesel Particulate Filter) Caution In order to protect the catalytic converter from being damaged, Note: It applies to models equipped with diesel engine. the following precautions must be observed: The main function of DPF is to collect particles in vehicle •...
  • Page 148 Starting and Driving The vehicle speed is not equal to zero interval of 10 seconds, and the "DPF (Diesel Particulate Filter) 10: Engine speed failed to reach the proper range warning light (yellow)" on the instrument cluster flashes at 1 Hz. 11: Engine torque failed to reach the proper range During regeneration, "xx% of DPF regeneration has been 12: Accelerator pedal not released...
  • Page 149 Starting and Driving transmission), apply the parking brake (or activate the Caution parking brake), and turn off the ignition key (or ignition DPF regeneration temperature is very high, please park the switch) for 2 minutes; vehicle in an open and ventilated place, and make sure there 2 Start the vehicle;...

  • Page 150: Fuel

    Starting and Driving Fuel • The regeneration steps were not followed. Regeneration steps for high load driving Fuel filler cap 1 Carry out high-load conditions cycles, such as high-speed Before opening the fuel filler cap, please turn on the fuel filler flap driving (vehicle speed is maintained at 60km/h and above);...

  • Page 151: Refueling

    Starting and Driving Refueling Rotate the fuel filler cap counterclockwise to remove it, and secure it on the bracket of the filler flap, then refuel. After It is prohibited to mix fuel with engine oil, kerosene, refueling, 3 clicks need to be heard when tightening the fuel paraffin, water or other liquids for use, which may filler cap clockwise, which indicates that the fuel filler cap has damage the fuel system.

  • Page 152: Gasoline Detergent

    Starting and Driving Gasoline detergent Save fuel Fuel consumption is mainly influenced by three factors: Note: It applies to vehicles equipped with gasoline engine. • Vehicle maintenance mode The gasoline detergent, with the functions of improving the – Please go to our Service Dealer for regular maintenance of vehicle driveability, cleaning the gasoline, fuel injector, air the vehicle in accordance with the provisions in the "Warranty intake valve, combustion chamber and fuel pipeline system...

  • Page 153: Precautions For Cold Weather

    Starting and Driving Precautions for cold weather The following driving precautions will help you to save fuel and protect the environment. It is prohibited to use lamp oil (kerosene) as the • Ensure the tire pressures are correct. additive. • Avoid accelerating immediately after starting, and avoid depressing the accelerator pedal all the way In order to reduce possible problems which may occur in cold down.

  • Page 154: Manual Transmission

    Starting and Driving Manual Transmission Note: Do not shift to R gear before the vehicle stops. The shift lever cannot be directly shifted from the 1st to R gear Gear Shift and must be shifted to N first. During the gear shift, depress the clutch pedal completely, and R gear: Place the shift lever in N position, press the button in the then move the shift lever.

  • Page 155: 6At Automatic Transmission

    Starting and Driving 6AT Automatic Transmission Check for the condition of pedestrians near the vehicle, especially children, before shifting to D Operation (drive) gear or R (reverse) gear. Make sure the shift lever is in P (park) position before leaving the driver seat; then set the parking brake and shut down the engine.

  • Page 156: Gears

    Starting and Driving Gears D (Drive) It is a common Drive gear position. The transmission will P (Park) automatically shift among 6 gears in sequence to provide the most fuel-efficient and the maximum power. Engaging P (park) gear during vehicle running will cause transmission damage.

  • Page 157: Manually Release P Gear Lock

    Starting and Driving 8AT Automatic Transmission Manually release P gear lock In case of a dead battery or transmission computer failure, the Gear vehicle will be unable to recognize the signal from the brake P (Park Gear) pedal, and it is required to manually release the P gear lock. Push the vehicle to a safe place.
  • Page 158 Starting and Driving N gear is powerless and the transmission system does not After the engine is started, normal gear shift operations can be transfer any power. performed. D (Drive gear) D gear is generally a forward gear. When driving normally, it is recommended to use D gear.
  • Page 159 Starting and Driving Shift to R, N and D gear • In R gear • In P/D gear Push or pull the shift lever briefly in the desired direction (two positions forward and backward). When the shift lever is • In N gear released, it will return to the neutral position.
  • Page 160 Starting and Driving M gear (Manual) Caution If the gear shift time selected by the driver is inappropriate in M gear can be operated only in the automatic mode the manual mode, such as upshifting while the engine speed D gear; do not try to move the shift lever to the right is too low or downshifting while the vehicle speed is too high, in other gears.
  • Page 161 Starting and Driving Temporary manual mode (steering wheel paddle) Caution The temporary manual mode is for temporary use only, not Note: It applies to models with steering wheel paddle. a long-term manual state. If the shift paddle is not operated again for a period of time, the system will return to the automatic mode D gear.
  • Page 162 Starting and Driving Shift to R, N and D gear • In P gear 1 P gear button • In N gear 2 Unlock button Shift to P gear When the vehicle is stationary, press the P gear button (1) to shift to P (park) gear.
  • Page 163 Starting and Driving • In R gear When shifting from P (park) gear to R (reverse) gear, it is necessary to depress the brake pedal and press the unlock button (2); when shifting to D (drive) gear, it is necessary to depress the brake pedal.

  • Page 164: Auto Park Function

    Starting and Driving Caution If the gear shift time selected by the driver is inappropriate in the manual mode, such as upshifting while the engine speed is too low or downshifting while the vehicle speed is too high, the transmission will not respond, and the vehicle will still be driving in the original gear.

  • Page 165: Manual Release Of P Gear Lock (Towing Mode)

    Starting and Driving Manual release of P gear lock (Towing mode) 2 A yellow pull ring (1) and a metal bracket (2) can be seen after removal. When the vehicle fails (dead battery, transmission controller failure and shifter failure, etc.), and cannot shift out of P (Park) gear, the transmission shall be shifted manually and forcibly from P (Park) gear to N (Neutral) gear for towing.

  • Page 166: Electric Power Steering Device

    Starting and Driving Electric Power Steering Device Caution If the vehicle is powered up or started at this time, the The electric power steering gear enables you to make a turn with instrument will prompt "P gear lock failure", indicating less force.

  • Page 167: Four Wheel Drive System (4Wd)

    Starting and Driving Four Wheel Drive System (4WD) • If “4WD MIL (red)” on the instrument cluster Part-Time 4WD System illuminates, please go to our Service Dealer for inspection as soon as possible. The part-time 4WD switch is located on the floor console, and •...
  • Page 168 Starting and Driving When the 2H/4H switch on the floor console is selected, “The Caution 2H/4H mode has been selected” will be displayed on the When shifting to/out of 4L mode, stop the vehicle. For instrument cluster information center; when the switching is manual transmission models, fully depress the clutch pedal;...

  • Page 169: Real-Time 4Wd System

    Starting and Driving Real-Time 4WD System • If “4WD MIL (red)” on the instrument cluster The real-time 4WD switch is located on the floor console, and information center illuminates, please go to our Service is used to select the mode of 2H (HS 2WD), AUTO(automatic), Dealer for inspection as soon as possible.
  • Page 170 Starting and Driving Switching between 2H & 4L, 4H & 4L and AUTO & 4L Caution Stop your vehicle and place the ignition switch in "ON" mode. When shifting to/out of 4L mode, stop the vehicle. For manual transmission models, fully depress the clutch pedal; For manual transmission models, fully depress the clutch pedal for automatic transmission models, push the shift lever to when switching;...

  • Page 171: All-Terrain Four Wheel Drive System (Ats)

    Starting and Driving All-Terrain Four Wheel Drive System (ATS) Precautions before Use • When driving on a road which is dry and in good condition, ATS system optimizes the relevant control system between the if the SAND, MUD or ROCK mode is selected, the tire wear powertrain, chassis and etc., controls the vehicle by operating will accelerate, and fuel efficiency will decrease.
  • Page 172 Starting and Driving Instructions for Switching All-Terrain 4WD System Switch ATS Mode Constant Speed Adaptive Cruise on Floor Drive Mode Driving Conditions ESP System Indicator Cruise System System Console For general highways and expressways (2WD state ECO(Economy) On by default Available Available and better fuel economy).
  • Page 173 Starting and Driving “ECO/AUTO/SPORT/SNOW/MUD/SAND Mode” will Caution displayed on the instrument cluster information center. When switching into or out of the ROCK mode, be sure to stop the vehicle and shift the lever to N gear position. Switching between modes of The switching to or out of the ROCK mode may take 3～5 ECO/AUTO/SPORT/SNOW/MUD/SAND - ROCK seconds, please wait in patient until the instrument cluster...

  • Page 174: Electronic Differential Lock

    Starting and Driving Electronic Differential Lock EDL use instruction EDL Locking The electronic differential lock (EDL) switch is located on the floor console, select the differential lock On/Off state with the When the wheel speed difference between two rear wheels is EDL switch.

  • Page 175: Brake System

    Starting and Driving Brake System General status Ensure carpet or other objects will not hinder the Service brake operation of brake pedal. Duel-pipeline hydraulic brake system Do not take the brake pedal as the foot rest, since it During driving, if one hydraulic pipeline fails, the may lead to brake overheat, efficiency degradation and excessive wear.

  • Page 176: Abs (Anti-Lock Brake System)

    Starting and Driving ABS (Anti-lock brake system) Wet conditions ABS is used to prevent wheels from locking in an emergency When driving in a heavy rainy day or on a muddy brake, thus to help you maintain the control on direction No road, the efficiency of vehicle brake system will special driving skills are required.
  • Page 177 Starting and Driving ABS function This can prevent the wheels from being locked to ensure the control on direction. ABS may not be able to shorten the brake distance, depending on road surface conditions, brake Precautions for driving a vehicle with ABS distance may vary significantly.

  • Page 178: Esp (Electronic Stability Program)

    Starting and Driving ESP (Electronic Stability Program) TCS (Traction Control System) TCS automatically controls the driving force at the start-off and ESP function acceleration to prevent wheels from spinning, so as to maintain ESP covers the functions of ABS, EBD, TCS, VDC, EBA, RMI, the driving stability.
  • Page 179 Starting and Driving HAS (Hill-start Assist System) When the vehicle speed is less than 8km/h or within 35-60km/h, HDC does not work but is in standby state. When the vehicle drives uphill, HAS can prevent the vehicle from sliding backwards after the driver releases the brake pedal. The When the vehicle speed exceeds 60km/h, HDC function will exit driver has up to 1.5s to move his foot from the brake pedal to the automatically;...

  • Page 180: Epb (Electronic Parking Brake)

    Starting and Driving EPB (Electronic Parking Brake) OFF switch is disabled at this time, the EPB can be manually clamped or released. When the 4WD system confirms the The EPB switch is located in the switch group which is in front switching to 2H mode, the ESP system automatically resumes of the central armrest and at the lower left side of the shift lever, on, and the "ESP OFF Indicator Lamp (yellow)", "HDC Indicator...
  • Page 181 Starting and Driving 5 When the vehicle is on a ramp, please rotate the steering wheel to ensure that the vehicle is aligned with the road Malfunction Indicator Lamp (yellow)" illuminates, edge in case of slipping. and EPB can not be released with normal operation, please contact our Service Dealer.
  • Page 182 Starting and Driving Starting off Emergency Braking Function Pull up and hold the EPB switch to activate the emergency Manually release the EPB. braking function. At the time, the vehicle will brake all four 1 The ignition switch is placed in ACC/ON position. wheels by activating the hydraulic braking system, and its 2 Depress the brake pedal.

  • Page 183: Auto Hold

    Starting and Driving AUTO HOLD request the EPB clamping parking. The "AUTO HOLD Indicator Lamp (green)" goes out, and the "EPB Indicator Lamp (red)" The AUTO HOLD switch is located in the switch group which illuminates. is in front of the central armrest and at the lower left side of the shift lever, you can control the start assist system on or off with When AUTO HOLD is operative, opening a door or unfastening this switch.

  • Page 184: Warning Lamp

    Starting and Driving Constant Speed Cruise Control System Warning lamp The warning lamps related to the brake system are: "Brake Cruise control can be dangerous where you can System Warning Lamp (red)", "ABS Warning Lamp (yellow)", not drive safely at a steady speed. Therefore, do "EBD Warning Lamp (red)", "ESP Indicator Lamp (yellow)", not use the cruise control on winding roads or in "ESP OFF Indicator Lamp (yellow)", "EPB Indicator Lamp (red)",...

  • Page 185: Set Cruise Control

    Starting and Driving Set cruise control : Cruise cancel switch. Press this button to cancel the cruise function without clearing the set speed in the memory. Set cruise control RES+ : Cruise recovery/acceleration switch. To store the set If the cruise control stays on when you do not use speed, press this button to recover this speed.
  • Page 186 Starting and Driving Resume set speed Decelerate with the cruise control system enabled If you have set the cruise speed of constant speed cruise control If the constant speed cruise control system has been enabled: system, the cruise control function will be disabled when you •...

  • Page 187: Terminate The Cruise Control

    Starting and Driving Parking Assist System Terminate the cruise control There are three ways to disable the cruise control: Note: The type of parking assist system equipped on • Slightly depress the brake pedal once; the "Constant Speed your vehicle is subject to the actual vehicle configuration Cruise Indicator Lamp"...

  • Page 188: Front And Rear Radar Sensors

    Starting and Driving Front and rear radar sensors Operating state of reverse radar parking assist system: When the R gear is selected and the vehicle speed is less than The parking assist system is not always reliable. It 15km/h, the system will activate the detection function. only plays the guiding role! Reverse radar sensors may be unable to detect certain types of barriers, Note: If the system keeps ringing for a long time after the...
  • Page 189 Starting and Driving Operating state of reverse radar parking assist system: During reversing: When the D gear or N gear is selected and the vehicle speed is The device will begin to sound warning chimes when the rear of less than 15km/h, the system will activate the detection function, the vehicle is 1.5m away from the obstacle, or the front of the at this time, the front parking radar enables the audible and visual vehicle is 0.6m away from the obstacle, the shorter the distance...

  • Page 190: Reverse Cameras

    Starting and Driving Reverse cameras The reverse camera parking assist system is not always reliable. It only plays the guiding role! Reverse cameras have limited view ranges and cannot detect barriers outside the view ranges. Operating state of reverse camera parking assist system: After shifting the gear to R, the image of entertainment system display screen will be switched to the reverse camera operating state, and the entertainment system display will show the...

  • Page 191: 360° Around-View System

    Starting and Driving 360° Around-view system Operating state of 360° around-view system: After shifting the gear to R, the entertainment system display The parking assist system is not always reliable. screen will automatically switch to the 360° around-view It only plays the guiding role! Reverse cameras interface, and then you can judge the relative position between have limited view ranges and cannot detect barriers the vehicle and barrier according to the image.

  • Page 192: Intelligent Semi-Automatic Parking Assist System

    Starting and Driving Intelligent Semi-Automatic parking assist center display, and the parking assist system searches for system the parking space and determines whether the space is spacious enough; when an appropriate parking space is The system is a parking assist system, which is found, it will display the Parking Space Found interface, not applicable in all cases, and can not completely then the vehicle movement direction will be displayed in the...
  • Page 193 Starting and Driving Pull-out function of parallel parking mode (with P gear is selected) 1 Press the automatic parking switch on the floor console to switch to pull-out function, and switch the pull-out direction by turning on the turning signal lamps (Left pull-out is the system default).

  • Page 194: Driver Assist System

    Starting and Driving Driver Assist System Precautions for Semi-Automatic Parking • Before parking, please make sure there are no obstacles in Note: The type of driver assist system on your vehicle the parking space, such as Stones, thin pillars, towbars or depends on the actual configuration of your vehicle.
  • Page 195 Starting and Driving • Traffic Sign Recognition (TSR) Restrictions for Cameras There are some restrictions for the camera unit, which limit the function of the unit. • Limited view Like human eyes, the view of the camera is also limited, i.e. the camera will have poor sight in The camera unit is located at the upper side of the windshield, storm, blizzard, fog, severe dust storm or snowy if the information center of the instrument cluster displays...
  • Page 196 Starting and Driving Cause Action If the window before any camera unit of the windshield is cracked, scratched or damaged No remedy available. by stone impact, and the affected area is about Direct sunlight and strong Sometimes, the recognition 0.5x3.0mm or greater, then contact our Service oncoming light or severe road function of the camera is Dealer for the windshield replacement and service.
  • Page 197 Starting and Driving • Limited view The camera unit has a limited view. In some cases, the camera cannot detect another vehicle, or the detection starts later than expected. – On the curves, the ACC may respond to the vehicle in another lane, or it may not have time to respond to the vehicle in the same lane.
  • Page 198 Starting and Driving disable the ACC by brake intervention immediately and Driver assistance system millimeter-wave radar control the vehicle by himself. The millimeter-wave radar of the driver assistant system is used to realize the following functions: • Blind Spot Detection (BSD) •...

  • Page 199: Adaptive Cruise Control (Acc)

    Starting and Driving Adaptive Cruise Control (ACC) Overview The ACC helps the driver to maintain the same speed with the The distance between the vehicle and the front vehicle is front vehicle and keep the preset interval. For long distance measured by the camera unit.
  • Page 200 Starting and Driving RES+ : increase the stored speed or re-activate the adaptive Do not use the ACC for city traffic, intersection, cruise control and resume the stored speed. slippery road, flooded or muddy road, overcast, rainy/snowy weather, poor visibility, twisted road or SET- : decrease the stored speed or activate the adaptive cruise entrance/exit of the motorway.
  • Page 201 Starting and Driving Information center display of instrument cluster The ACC gives warning only to the vehicles detected by the camera, so it may not send an alarm, or there may be a certain delay for the alarm. When braking It indicates the ACC is in STANDBY mode, ahead vehicle is required, apply the brake before receiving the indicator lamp depends on whether the front vehicle is...
  • Page 202 Starting and Driving Set ACC speed Note: When the ACC is enabled, increase the vehicle speed by the accelerator pedal, during the period from depressing Different ACC speed can be set. When the ACC is enabled, the accelerator pedal to releasing the pedal, the cruise the cruise speed can be changed by the button on the steering control will be disabled, and the information center of the wheel.
  • Page 203 Starting and Driving • When pressing the button on the steering wheel, the Standby mode under driver intervention vehicle-to-vehicle interval will shift within level 1 - 3 in a Under the following situations, you can disable the ACC for a circular manner.
  • Page 204 Starting and Driving • When the vehicle speed is below 5km/h, and the ACC cannot Target change and auto braking by ACC be sure whether it is a stationary vehicle or other objects in At some speed, the ACC can change the target and brake. the front, for example, speed hump.
  • Page 205 Starting and Driving • When the front vehicle is turning at a speed below 5km/h, the • Shift to P, N or R gear. ACC stops to follow it. • The ACC is set to the STANDBY mode by the driver. Auto Braking Auto Activation of Parking Brake For short stay related to slow motion at slow traffic or traffic lights,...
  • Page 206 Starting and Driving Restrictions for ACC Symbol Message Meaning The ACC will be restricted under some situations. Always use Please slightly the ACC on level roads. When driving on the steep downhill depress the Restart the ACC under heavy load, it is hard to keep a correct distance between accelerator pedal at the STANDBY your vehicle and the front vehicle by this function, in this case,...

  • Page 207: Fcw And Aeb

    Starting and Driving FCW and AEB The AEB can decrease the vehicle speed to 40km/h at most, this avoids collisions with the front vehicle or bicycle. The FCW alerts the driver of the front pedestrian, bicycle or vehicle by visual and acoustic signals. If the driver fails to take If the speed difference is higher than 40km/h, then the AEB actions within a rational time, the system will trigger the AEB cannot avoid the collision automatically.
  • Page 208 Starting and Driving cadence braking. For low speed, emergency braking or When the AEB is enabled and the brake is applied, the acceleration, no tactile warning is provided. "FCW/AEB Warning Lamp (red)" on the instrument 2 Brake Support cluster will illuminate, and it will send an acoustic alarm to If the risk of collision has already escalated, then the auxiliary indicate that the function is enabled or has been initiated.
  • Page 209 Starting and Driving Set in the vehicle state mode in entertainment system: Vehicle Vehicle State Mode→Vehicle Control→Driving Assist; Options: The FCW/AEB is able to detect most of the static vehicles High/Medium/Low. and the vehicle moving in the same direction. To ensure the The sensitivity determines the warning distance of the system FCW/AEB can detect vehicles at night, the headlamp and tail and controls the distance triggered by visual, acoustic and tactile...
  • Page 210 Starting and Driving means the warning and braking will be delayed or cannot be The FCW/AEB is an auxiliary function which cannot realized. detect all bicyclists for all cases, nor can it see any vague bicyclist, for example, bicyclists who cover The pedestrian can also be detected by the headlamp, their body with the clothes, bicycles which load large FCW/AEB at night.
  • Page 211 Starting and Driving The brake distance will be prolonged on wet and slippery Driver Intervention roads, this can degrade the anti-collision capacity of the AEB. • Reverse Under these conditions, the anti-lock brake and ESP will apply When reversing your vehicle, the FCW/AEB will be disabled the optimum braking force and maintain the stability.
  • Page 212 Starting and Driving Symbol and Message of FCW/AEB If the camera unit fails to detect the pedestrian, bicyclist or vehicle accurately due to any traffic The information center of the instrument cluster will display some condition or external factor, then the system may symbols and messages related to the FCW/AEB.

  • Page 213: Lane Keeping Assist (Lka)

    Starting and Driving Lane Keeping Assist (LKA) LKA interface： The purpose of the LKA is to help the driver to reduce the risk of unexpected departure on the motorway or similar road for some cases. The lane assist system has two versions: •...
  • Page 214 Starting and Driving Steering Assist No Intervention of Lane Assist The steering assist (LKA) can be enabled when the driver holds the steering wheel with both hands. The system will keep monitoring this operation. If the driver does not do so, the symbol system and LKA will use the steering message to alert the driver to control the vehicle by the information center of the instrument cluster.
  • Page 215 Starting and Driving • Working conditions in a tunnel. White lane markings are displayed in the instrument cluster information center interface. The LDW warning lamp • Winter road. • Severe weather with reduced visibility and sloping roads. illuminates white. Enable/Disable LKA When the vehicle runs at a speed above 60km/h and the system detects the left/right lane line, green lane line occurs Enable LDW/LKA...

  • Page 216: Traffic Sign Recognition (Tsr)

    Starting and Driving Traffic Sign Recognition (TSR) center of instrument cluster will illuminate in blue and the LDW The TSR helps the driver to observe the speed sign when the warning lamp will illuminate in blue. vehicle passes. Sensitivity Setting of LDW When the LDW function is enabled, its sensitivity can be set.

  • Page 217: Blind Spot Detection (Bsd)

    Starting and Driving Blind Spot Detection (BSD) Enable/disable TSR Set in the vehicle state mode in entertainment system: Vehicle The BSD is not always reliable. It is not the State Mode→Vehicle Control→Driving Assist, optional function: alternative but the supplementary to safe driving Enable/disable TSR.
  • Page 218 Starting and Driving 2 Left adjacent area • When multiple vehicles pass the area ② or area ③ in succession, alarm may be issued only for the first vehicle 3 Right adjacent area passed by, and may not be issued for the subsequent Early warning mode vehicles.

  • Page 219: Lane Change Assistance (Lca)

    Starting and Driving Lane Change Assistance (LCA) The lane change assistance system warning lights are located on both exterior mirrors. The LCA system can be switched on/off with a touch button on the entertainment system. Lane change assistance When the target vehicle enters the detection zone ②, and rapidly approaches your vehicle, lane change could cause Blind spot detection collision, the lane change assistance system warning light on...

  • Page 220: Rear Cross Traffic Alert (Rcta)

    Starting and Driving Rear Cross Traffic Alert (RCTA) The lane change assistance system warning lights are located on both exterior mirrors. The RCTA system can be switched on/off with a touch button on the entertainment system. When the vehicle is backing out of the warehouse, the target vehicle enters the monitoring area (about 30 meters on both sides) and there is a collision risk, the warning light of lane change auxiliary system on the corresponding side flashes.

  • Page 221: Door Opening Warning (Dow)

    Starting and Driving Door Opening Warning (DOW) DOW only serves as an auxiliary safety system, and the perceived distance may differ from the actual one. Don't rely on the DOW solely to identify the vehicle's surrounding risks, please carefully observe the vehicle surroundings. The DOW warning lights are located on the exterior rearview mirrors at both sides.

  • Page 222: Tires

    Starting and Driving Tires Monitoring area It is very dangerous to use nonconforming or damaged tires! Do not drive the vehicle if you find a tire or tires are excessively worn, damaged or have incorrect inflating pressure. Vehicle overload is forbidden. Incorrect tire inflating pressure or imbalance between wheel and tire assembly may affect the vehicle stability severely, especially Pre-alert mode:...

  • Page 223: Winter Tires

    Starting and Driving Winter tires The maximum vehicle speed allowed by the winter tire is subject to the tire speed code. The vehicle speed shall not exceed the maximum Speed Code Maximum Speed (km/h) speed allowed by the winter tires installed. It's very likely to cause accidents due to sudden loss of pressure, thread separations or even tire blowouts when the vehicle speed exceeds the maximum...

  • Page 224: Tire Chain

    Starting and Driving Loading In addition, it is recommended to set the overspeed alert. Specific operations: the touch button on the big screen of the entertainment system controls the ON/OFF state of the In accordance with regulations, each driver is obliged to ensure overspeed alert function.

  • Page 225: Luggage Compartment

    Starting and Driving Luggage compartment Luggage compartment net bags Luggage compartment binding rings The luggage compartment net bags has two types: vertical net bags and bottom net bags. Use the binding rings when it is required to secure and protect the objects on the luggage compartment floor.
  • Page 226 Starting and Driving Luggage compartment cover curtain Do not place the luggage on the cover curtain, otherwise the cover curtain may be damaged. Cover Curtain Usage 1 Firstly, take the luggage compartment cover curtain out of the luggage compartment. Take up (1) from the right end with your right hand, then take out in parallel with (2) shown in the figure.
  • Page 227 Starting and Driving 2 Press the button at both sides of the cover curtain to extend the cover curtain arm. Cover Curtain Retraction 1 Shrink the support arms at the two sides of the cover curtain. 3 Fit both sides of cover curtain arm into the mounting holes 2 Put the left side of cover curtain into the left side of bin.

  • Page 228: Roof Rack And Load Carrier

    Starting and Driving Roof rack and load carrier If other roof rack system is used, its own weight must be included in the load capacity. Be sure to properly place the luggage on the roof The load must be evenly distributed, and cannot be left rack, otherwise it may lead to an accident.

  • Page 229: Emergency Troubleshooting

    Emergency Troubleshooting 222 Hazard Warning Lamps 222 Warning Triangle 223 Wheel Replacement 228 Vehicle Towing 230 Fuel Filter Water Drain 231 Jump Start 233 Fuse Replacement 239 Bulb Replacement...

  • Page 230: Hazard Warning Lamps

    Emergency Troubleshooting Hazard Warning Lamps Warning Triangle When you need to stop or slow down the vehicle in case of a The warning triangle is placed at the bottom of the luggage vehicle failure, always press the hazard warning lamp switch compartment(for vehicles with three rows of seats) or behind on the instrument panel.

  • Page 231: Wheel Replacement

    Emergency Troubleshooting Wheel Replacement Spare wheel Regularly check the air pressure of spare wheel. The Jack use of a spare wheel with incorrect tire pressure will Placement affect wheel stability, which may lead to dangerous The jack is placed at the bottom of the luggage compartment(for consequences and will cause permanent damage vehicles with three rows of seats) or behind the second row of to the tire.
  • Page 232 Emergency Troubleshooting 6 After the spare wheel reaches the ground, rotate the wheel nut wrench counterclockwise continuously and pull out the spare wheel. Excessive rotation of the wrench is prohibited, 4 Unscrew the spare wheel rotary cap. or the spare wheel device will be damaged. 7 Remove the tray from the spare wheel.

  • Page 233: Wheel Replacement

    Emergency Troubleshooting Wheel replacement Spare wheel storage 1 Place the wheel on the ground with the air valve facing up Vehicle parking (be careful not to place it reversely). 2 Place the wheel at the rear bottom of the vehicle. Please choose a solid and flat place to park the vehicle, where will neither hinder the traffic, nor 3 Place the spare wheel tray in the rim center, and then adjust...
  • Page 234 Emergency Troubleshooting Jack placement jack should be aligned with the camber of the horizontal stabilizer bar bracket. The jack should be used on level firm ground wherever possible. It is recommended that the wheels of the vehicle be chocked. No person should remain in a vehicle that is being jacked.
  • Page 235 Emergency Troubleshooting Spare wheel replacement 4 Mount the auxiliary rotary post and then rotate the wheel nut wrench clockwise till the wheel to be replaced gets off During the lifting, do not start the engine. Do not the ground. stand under the lifted vehicle. Before removing the wheel nut, make sure the vehicle is stable and will not slide or move.

  • Page 236: Vehicle Towing

    Emergency Troubleshooting Vehicle Towing 10 Put away the replaced wheel, auxiliary rotary post of the jack, wheel nut wrench, jack and vehicle tool kit. When towing a vehicle or making a vehicle be towed, be sure to observe relevant national regulations on vehicle towing. Towing eye Front towing eye The front towing eye is located at the lower side of front bumper.
  • Page 237 Emergency Troubleshooting Rear towing eye The application range of towing rope is as shown below: If it is required to tow a vehicle from rear side, remove the towing eye plug from the left side of rear bumper, and screw the rear towing eye in the vehicle tool kit into the rear bumper.

  • Page 238: Towing

    Emergency Troubleshooting Fuel Filter Water Drain Towing Before being towed Note: It applies to vehicles equipped with diesel engine. To ensure the steering gear can rotate freely, turn Be sure to wear proper gloves to protect hands from the ignition switch to "ON" position and keep it touching diesel.

  • Page 239: Jump Start

    Emergency Troubleshooting Jump Start Battery disconnection Wear protective gloves and goggles during the operations related to battery. Do not use open fires, generate sparks or smoke in the battery area. Or you will be injured and the vehicle will be damaged. To disconnect the battery, be sure to disconnect the negative (-) grounding terminal first and then the positive (+) one.

  • Page 240: Jump Start

    Emergency Troubleshooting Jump start Caution • Before disconnecting the battery, be sure to shut down the It is never allowed to start the vehicle by pushing or engine and turn off all electrical appliances for more than towing. 2 minutes. Please avoid the terminals from contacting with Make sure that both batteries are of the same rated metal components of the body during disconnection.

  • Page 241: Fuse Replacement

    Emergency Troubleshooting Fuse Replacement 5 Make sure all connecting devices contact well. 6 Check whether jumper cables contact with any moving parts Fuses of this vehicle are respectively placed in two boxes. when engine starts. 7 Check whether the parking brake handles of both vehicles Caution have been engaged and whether the shift lever is in N gear.
  • Page 242 Emergency Troubleshooting Specification Fuse Function Fuses in the driver compartment fuse box can be identified by ACC4(Cigar lighter) FS11 the label on the back of lower storage box cover at driver side. Active noise control FS12 TBOX/12-inch display screen FS13 Ignition switch/(PEPS ECU/kick sensor) FS14 10A/15A...

  • Page 243: Front Compartment Fuse Box

    Emergency Troubleshooting Specification Fuse Function Front compartment fuse box Panoramic sunroof The front compartment fuse box is located at the right of Front blower relay compartment wall at the front hood bottom and behind the right ACC relay headlamp (viewed from the front of vehicle). IG relay Trunk light relay Type I...
  • Page 244 Emergency Troubleshooting Type II Caution Before opening the fuse box cover, make sure its surroundings are dry and no fluid flow from any direction into the opened fuse box, otherwise the fuse box will be damaged, leading to serious consequences. Fuse can be accessed by just removing the cover of front compartment fuse box.
  • Page 245 Emergency Troubleshooting Fuse Specification Fuse Specification Function Function A/C compressor/battery sensor Left high beam FS28 IEC power supply 3 Right high beam FS10 FS29 Fog lamp/position lamp/daytime running lamp FS11 FS30 Left low beam Right low beam IEC power supply 8 FS12 FS31 Headlamp leveling...

  • Page 246: Fuse Replacement

    Emergency Troubleshooting Fuse Specification Fuse Specification Function Function Wiper power relay IG power supply 1 FS13 Wiper speed relay IG power supply 2 FS14 Main relay IG power supply 3 FS15 A/C compressor relay IG power supply 4 FS16 Rear fog lamp relay FS17 Front axle clutch Diesel filter relay power(used for diesel engine...

  • Page 247: Bulb Replacement

    Emergency Troubleshooting Bulb Replacement Pull out the fuse with a puller provided in the fuse box to remove the fuse. Determine whether the fuse is blown according to wires inside the fuse (as indicated by the arrow). Before replacing any bulb, turn off the ignition switch and lighting switches to avoid any possible short circuit.

  • Page 248: Bulb Replacement

    Emergency Troubleshooting Bulb replacement Open the engine hood, then you can find it at the rear of front combination lamp: The method for bulb removal is shown below. For other bulbs • Rotate the bulb cover counterclockwise to remove it. to be replaced but not in the list, please contact with authorized •...

  • Page 249: Maintenance And Service

    Maintenance and Service 242 Safety 243 Regular Maintenance 243 Owner Checks 244 Front Compartment 246 Engine Hood 247 Engine Oil 249 Coolant 251 Brake Fluid 252 Washer Fluid 252 Washer Nozzles 253 Wiper Blade 254 Seat Belt 255 Battery 258 Tires 261 Other Maintenance...

  • Page 250: Safety

    Maintenance and Service Safety to "Jump Start" in Emergency Troubleshooting section). If components under the engine hood shall During vehicle inspection or maintenance, take care to reduce be inspected when the engine is running, make sure the vehicle is on a level ground, the parking brake risks of personal injury or vehicle damage, and always observe handle has been pulled up and the shift lever is in N the following safety precautions.

  • Page 251: Regular Maintenance

    Maintenance and Service Regular Maintenance Owner Checks Regular maintenance of the vehicle will be beneficial to the To ensure the reliability and economy of driving, the vehicle economy, safety and reliability of your vehicle. It is important to owner must carry out the following simple but important checks: remember that the responsibility for ensuring vehicle safety and suitable for road travel is ultimately your own (owner / operator).

  • Page 252: Weekly Check Or Check Before A Long Trip

    Maintenance and Service Front Compartment Weekly check or check before a long trip • Check fluid level / refill. Gasoline engine vehicles - Engine Oil - Coolant - Windshield Washer Fluid - Power steering fluid - Brake fluid • Check the condition and pressure of all tires (including spare wheel).

  • Page 253: Diesel Engine Vehicles

    Maintenance and Service Diesel engine vehicles Type 2 Type 1 1 Engine coolant reservoir 2 Brake fluid reservoir 1 Engine coolant reservoir 3 Oil fill cap 2 Brake fluid reservoir 4 Water-air intercooler pressure cap 3 Oil fill cap 5 Washer fluid reservoir 4 Washer fluid reservoir 6 Battery 5 Battery...

  • Page 254: Engine Hood

    Maintenance and Service Engine Hood Close the engine hood When the ignition switch is in "ON" position, the Open the engine hood radiator fan may start at any time (even if the engine Pneumatic Rod is not running). Always ensure your hands, loose 1 Pull the engine hood release lever below the splash guard at clothing (such as ties, scarves, etc.) stay away from driver side to unlock the engine hood.

  • Page 255: Engine Oil

    Maintenance and Service Engine Oil Check and refill Do not exceed the maximum mark when refilling. It is recommended to use the oil of correct grade, please refer to "Recommended Fluids" in the General Technical Parameters Long-term frequent exposure to used engine oil can section for the specifications.
  • Page 256 Maintenance and Service Diesel engine vehicles Gasoline engine vehicles The oil level indication must be between "MAX" and "MIN". Diesel engine vehicles Caution Check the engine oil level frequently, and refill as necessary. Both excessive and insufficient refilling of engine oil is likely to damage the engine, and the damage are not covered by warranty.

  • Page 257: Engine Oil Consumption

    Maintenance and Service Coolant Engine oil consumption The engine oil consumption is affected by a variety of factors The coolant is harmful, Don't swallow it. Do not (these factors also affect fuel consumption), of which the allow coolant come into contact with your skin and oil type and driving pattern (especially in the "running-in"...

  • Page 258: Check And Refill

    Maintenance and Service Check and refill Do not remove the expansion tank cap while the system is hot, for escaped water vapor or hot coolant may cause injury. If you have to add coolant when the engine is hot, please wait for 10 minutes, cover a thick cloth on the expansion tank cap, slowly rotate the coolant reservoir cap counterclockwise to release the pressure inside the coolant reservoir,...

  • Page 259: Brake Fluid

    Maintenance and Service Brake Fluid Check and refill Be sure to check the brake fluid level after the vehicle is parked If the brake fluid level drops obviously, contact on a flat ground and the system is in cold state. The brake Service Dealer for service as soon as possible.

  • Page 260: Washer Fluid

    Maintenance and Service Washer Fluid Washer Nozzles Check and refill Adjust and clean Front Washer Nozzle It is dangerous to drive the vehicle while the washer Front washer nozzle is not adjustable. system is inoperative. be sure to check the system before driving.

  • Page 261: Wiper Blade

    Maintenance and Service Wiper Blade Replacement Removal Check - Lift the wiper arm from the windshield to make an angle of about Check the edge of wiper blades for roughness or damage, and 15 degrees between the blade and the arm. check if the blade rubber is secure from top to bottom.

  • Page 262: Seat Belt

    Maintenance and Service Seat Belt Maintenance Don't try to fix retractor or buckle mechanism by Check any means or modify the seat belt. If the seat belt has been stretched in the event of an accident, The seatbelt is equipped with a sensitive retractor, please ask Service Dealer to replace it and check which will be locked only in hard acceleration, the anchor point.

  • Page 263: Battery

    Maintenance and Service Battery immediately neutralize it with rich soap solution and rinse with plenty of water. If you mistakenly drink acid, go to see a doctor immediately. Warning notice on battery: Open flames, electric sparks, strong light and Wear glasses! smoking are prohibited! Avoid sparking when handling cables and electrical equipment and...

  • Page 264: Car Parking Period

    Maintenance and Service First remove the negative cable, then the positive one Caution to remove the battery. Always turn off the ignition switch when parking, otherwise, Turn off all the electrical appliances before energizing it will greatly reduce the parking time. the battery again.

  • Page 265: Battery Removal

    Maintenance and Service and charged with ground equipment (operating in accordance Caution with the charging device manufacturer's instructions). • Keep children away from the battery, battery acid and When charging with a low current (such as a small charging charging devices. device) , generally it is not required to remove the battery •...

  • Page 266: Battery Replacement

    Maintenance and Service Tires Battery replacement Battery installed on your vehicle is designed according to It is very dangerous to use nonconforming or appropriate mounting position. If the battery is to be replaced, damaged tires! Do not drive the vehicle if you find a the new battery should have the same voltage (12V), structure tire or tires are excessively worn, damaged or have form and safety mark as those of the original one.

  • Page 267: Wear Indicators

    Maintenance and Service Wear indicators The spare tire should maintain the recommended maximum pressure and make adjustments before use. An accurate tire There are wear indicators in the treads of the original tire. When pressure gauge should be used to check the air pressure when the tire wears to the degree that the tread is 1.6 mm left, the the tire is cold, instead making an impairment calculation when tread of the entire cross-surface will show wear indicators.

  • Page 268: Tire Check And Rotation

    Maintenance and Service Tire check and rotation Tire Rotation Patterns for Vehicles Equipped with Full-size Spare Tires To ensure even tire wear, it is recommended to have the tire check every 5,000 kilometers. When uneven tire wear is found, the tire position should be changed. After the tire rotation, check the tires for proper dynamic balance.

  • Page 269: Other Maintenance

    Maintenance and Service Other Maintenance • After cleaning, you should check whether there is damage or stone chips on the paint. If necessary, repair the paint. Use Vehicle wash polishing wax occasionally to protect the paint surface. • Keep the sprayer moving when using a high pressure When driving the vehicle for the first time after cleaning device.

  • Page 270: Underbody Corrosion Protection

    Maintenance and Service Underbody corrosion protection The underbody of your vehicle has been treated with corrosion protection. Check the corrosion protection of vehicle underbody regularly. You can use a sprayer to clean the dust or mud accumulated on the underbody. Especially in winter, when salt is used on icy and snowy road.

  • Page 271: General Technical Parameters

    General Technical Parameters 264 Main Vehicle Dimension Parameters 265 Complete Vehicle Mass Parameters 267 Complete Vehicle Performance Parameters 268 Main Engine Parameters 269 Chassis Technical Parameters 270 Recommended Fluids 272 Wheels and Tires 273 Wheel Alignment Parameters...

  • Page 272: Main Vehicle Dimension Parameters

    General Technical Parameters Main Vehicle Dimension Parameters Product Model SV9A-1300 SV9A-1310 SV9A-1100 SV9A-1110 4X2, Front-engine 4X4, Front-engine 4X2, Front-engine 4X4, Front-engine Driving type Rear-drive Rear-drive Length of overall dimension, mm 5005 Width of overall dimension, mm 1932 Height of overall dimension, mm 1875 Wheel base, mm 2950...

  • Page 273: Complete Vehicle Mass Parameters

    General Technical Parameters Complete Vehicle Mass Parameters Product Model SV9A-1300 SV9A-1310 Engine Model 20L4E 20L4E Total Mass, kg 2800, 2900 2960 Curb weight, kg 2130, 2210 2330 1140/1660 Axle load (Front/rear axle load under 1270/1690 total mass), kg 1180/1720 1060/1070 Axle load (Front/rear axle load under 1180/1150 curb weight), kg...
  • Page 274 General Technical Parameters Product Model SV9A-1100 Engine Model SC20M163Q5A SC20M218Q5A Total Mass, kg 2900, 3000 2900, 3000 2900, 3000 2900, 3000 2900, 3000 2900, 3000 Curb weight, kg 2200, 2265 2230, 2310 2240, 2320 2210, 2280 2245, 2320 2255, 2330 1330/1570 1280/1620 1270/1630...

  • Page 275: Complete Vehicle Performance Parameters

    General Technical Parameters Complete Vehicle Performance Parameters Product Model SV9A-1300 SV9A-1310 SV9A-1100 SV9A-1100 SV9A-1110 Engine Model 20L4E 20L4E SC20M163Q5A SC20M218Q5A SC20M218Q5A Maximum design speed, km/hour Maximum gradability, % 45 (2WD) 55 (4WD) 45 (2WD) 45 (2WD) 55 (4WD) Emission level reached when the Euro V Euro V Euro V...

  • Page 276: Main Engine Parameters

    General Technical Parameters Main Engine Parameters Engine Model 20L4E SC20M163Q5A SC20M218Q5A In-line 4-cylinder, In-line 4-cylinder, In-line 4-cylinder, water-cooled, turbochargd water-cooled, turbochargd， water-cooled, turbochargd， Type intercooled, in-cylinder intercooled, direct injection, intercooled, direct injection, central direct injection diesel engine diesel engine gasoline engine Displacement, L 1.995 1.996...

  • Page 277: Chassis Technical Parameters

    General Technical Parameters Chassis Technical Parameters Item Parameters Front Suspension Structure Double wishbone independent suspension Rear Suspension Structure Five-link non-independent suspension Residual dynamic unbalance allowable at one side: below 10 grams Dynamic Balance Requirements of Maximum balance block applied at outer side is 60 grams, and the total of two sides shall not Steel Wheels exceed 120 grams Residual dynamic unbalance allowable at one side: below 8 grams...

  • Page 278: Recommended Fluids

    General Technical Parameters Recommended Fluids Item Grade Capacity 20L4E Engine lubricating oil, L ACEA C3 5W-30 SC20M163Q5A Engine lubricating oil, SAE 5W-30 ACEA C3 SC20M218Q5A Engine lubricating oil, SAE 5W-30(PRO) ACEA C3 20L4E Engine coolant, L D-35(-35℃) 11.5 SC20M163Q5A, SC20M218Q5A D-35(-35℃) 13.5 Engine coolant, L...
  • Page 279 General Technical Parameters Item Grade Capacity Rear axle lubricant, L TEMPO GL-5 80W-90 1.74 Transfer case lubricant (real-time Mobil LT 4WD system), L Transfer case lubricant (all terrain 4WD system of gasoline engine Mobil LT model), L Transfer case lubricant (all terrain 4WD system of diesel engine model), MERCON LV Transfer case lubricant (part-time...

  • Page 280: Wheels And Tires

    General Technical Parameters Wheels and Tires Item Parameters Wheel Specification 7Jx17 7.5Jx18 7.5Jx19 8.5Jx21 Tire specification 255/65R17 255/60R18 255/55R19 265/45R21 220kPa/2.2bar/32psi 220kPa/2.2bar/32psi 220kPa/2.2bar/32psi 230kPa/2.3bar/33psi Front wheels 220kPa/2.2bar/32psi 220kPa/2.2bar/32psi 220kPa/2.2bar/32psi 230kPa/2.3bar/33psi Tire Pressure (cold) 220kPa/2.2bar/32psi 220kPa/2.2bar/32psi 220kPa/2.2bar/32psi 230kPa/2.3bar/33psi Rear wheels 270kPa/2.7bar/39psi 270kPa/2.7bar/39psi 270kPa/2.7bar/39psi 280kPa/2.8bar/41psi Small Size Spare Tire Specification 245/65R17 245/65R17...

  • Page 281: Wheel Alignment Parameters

    General Technical Parameters Wheel Alignment Parameters Item Parameters 0 ± 0.15° Toe-in angle Total toe-in≤0.15° 0 ± 0.5° Front wheels Camber angle Difference value between left and right ≤0.5° 3.6 ± 0.5° Kingpin caster Difference value between left and right ≤0.5° Toe-in angle 0°±0.25°...

Table of Contents

Save PDF
