Scope of Supply
ACCTENMBTCPK
▪ Network Interface Board
▪ USB stick including software and manual
▪ M12 4-pin connector
▪ Extension cable (20cm) with RJ45 socket and M12 4-pin
connector
▪ Quick reference
▪ Mounting screws
Installation
▪
Network Interface board
Please plug the
Network Interface board
holes of the
▪ Now press the
Network Interface board
the board.
▪ Exchange the blind screw on the CT box by M12 4-pin connector and connect the wires corresponding to the colors as shown in
the table below.
Color
Connection
into the place provided, which is located beside the display. In the correct position, the
match with the thread holes of the CT box.
down to connect it with the
Blue
White
RX-N
RX-P
Installation of the Network Interface board into Optris CT
Electronic Box
Optris CT Electronic Box
Orange
TX-N
Network-Interface-Kit
. Use both M3x5 screws for fixing
Yellow
TX-P
ACCTENMBTCPK-MAD-E2024-01-A
I
