Summary of Contents for Rheavendors caffe europa
- Page 1 Installation and maintenance manual To be kept inside the machine www.rheavendors.com Downloaded from www.vendingbar.gr...
- Page 2 DISPLAY SELECTION KEYPAD COIN ENTRY LOCK RFID SLOT STATION COIN RETURN...
- Page 3 INDEX " " Downloaded from www.vendingbar.gr...
- Page 4 Technical Data and Declaration of Conformity DIMENSIONS Height 1830 mm Width 575 mm Depth 660 mm WEIGH From 100 Kg to 120 Kg according to the version CONNECTION TO THE MAIN WATER SUPPLY Water inlet pressure between 0,1 MPa (1 bar) and 0,8 MPa (8 bar) mains water connection 3/8”...
- Page 5 +39.02.9655086 or surf our web site www.rheavendors.com or send en e-mail at the address rheavendors@rheavendors.com. In order to speed up the response to your requests it will be necessary to supply: - All data appearing on the Serial Number Label.
- Page 6 Obtainable Beverages All beverages obtainable from your machine are shown in the list attached to this manual, and they vary substantially according to the version of the machine. It is possible to program the machine by the Rheaction software using the Rhea black flash card. For further information contact Rhea vendors Customer Service. Advice for the installer Installation and maintenance operations described in text with normal background (white) must be carried out only by qualified technical personnel.
- Page 7 Dispensing of sugar This supply is pre-set only for the models of machine equipped with the sugar dispensing group (models PB) in the event sugared beverages being selected. For the other models, always when the beverage requires it, the sugar is dispensed simultaneously with the preparation of the instant beverages and with the same procedure (see after).
- Page 8 2) The corresponding solenoid valve in the refrigerating group is activated and the correct quantity of water is poured into the mixing bowl to dissolve the ingredients; 3) If present, the mixing bowl is activated; 4) The geared motor activates the screw feeder of the canister of the corresponding ingredient, which conveys the correct quantity of ingredient into the mixing bowl.
- Page 9 10.2 Diagnostics cycle of the switching up When the safety key is inserted, the machine carries out a diagnostics cycle to check the position of the mobile components, the correct quantity of some ingredients and the correct water mains supply pressure. The display shows: rheavendors...
- Page 10 Only for PB versions: PLEASE WAIT espresso module - SUGAR + At the end of checks, the standard invitation message will appear on the display, e.g.: rheavendors - SUGAR + Caffè Europa 2008 Espresso - SUGARO +...
- Page 11 Until the right temperature is reached inside the boiler. rheavendors - SUGAR + Caffè Europa 2008 Espresso - ZUCCHERO + (Version SM) Pressing buttons MIX1, MIX2, MIX3 and MIX4 the machine pours water from one of the beverage outlet spouts.
- Page 12 Remove all the ingredients canisters from the machine (including the canister for coffee in beans, if present) separate the main body from covers and slides and immerse all parts in the solution previously prepared. Remove aspiration unit of the mixing bowl. Turn in the clock wise sense the red lever under the mixing bowl. Remove the mixing bowl itself, the bowl support and the mixer's fan.
- Page 13 11.2.3 Refilling of cups It is recommended to use only cups specifically designed for automatic vending machines. Cups must not be transparent or of light absorbing dark material. Diameters can be as per details reported in the table. The distance between the rims of two cups stacked and positioned side by side must be between 2.6 and 3.2 mm.
-
Page 14: Cpu Board
bucket for coffee grounds In models PB a liquid waste disposal bucket is supplied. Pull the support of the bag out from underneath the espresso group. Slide the bag around the support and replace the support and bag back to the original position. Programming of the machine 12.1 Memory The machine is controlled by a programme master stored in the microprocessor of the FLASH memory installed on... -
Page 15: End Programming
• Wait until the display shows: 1 = KEY - - - > VMC 2 = VMC - - - > KEY • Press button 1. The display shows: Programming EAROM data Programming • Switch off the machine. • Extract the flash card. 12.3 How to enter and exit from the programming mode To modify the operation parameters of the machine it is necessary to enter in the programming mode. - Page 16 PROGRAMMING - - - -COINS - - - - - - - - - - - PROGRAMMING - - - -TEMPERATURE - - - PROGRAMMING - - - -MISCELLANEOUS - - DIAGNOSTICS - - - - - - - - - - - - - - - - - - - - - - SALES AUDIT - - - - - - - - - - - - - - - - - - - - - PROGRAMMING- - - -...
- Page 17 To associate a selection to button which is going to be programmed, confirm FUNCTIONING. For the FP versions it is possible programme cold drinks selecting the function FUNCTIONING COLD. Press button 2. The display shows: COFFEE WATER 0=inhib. This parameter is present only in machines with the coffee brewer. Use this parameter to adjust the coffee beans water quantity.
- Page 18 Pressing 4 and 5 increase or decrease respectively the mixer start delay after the beginning of the selection. Pressing again 2 the display shows: speed MIXER X Pressing 4 and 5 increase or decrease respectively the mixer speed of the selection (0 = maximum speed, 5 = minimum speed).
- Page 19 All the settings described in this and in following paragraphs can be set in an easier way using rheaction software. For further information contact rheavendors Customer Service ATTENTION: if all the parameters of a button set as FUNCTIONING are programmed at 0, the vending machine will dispense ONLY CUP.
-
Page 20: Programming Temperature
12.5.2 Pre-setting of the normal sale prices One price for each selection available can be memorised in the machine. When a selection is matched to a price set to zero, the selection is in the free vend mode. To modify sale prices, in the programming mode, press button 1 until the sub-menu PROGRAMMING - - - PRICES - - - - - - - - - -... - Page 21 12.5.5 Modifying other operation parameters (miscellaneous) To modify parameters, in the programming mode, press 1 until the sub-menu PROGRAMMING MISCELLANEOUS is visualised. Pressing 2, the display shows: MACHINE CODE A Pressing again 2, the display shows: MACHINE CODE B Press 4 and 5 to associate to each vending machine personal codes. These numbers are useful only when a data audit system is used with the machines.
- Page 22 WARNING: the appliance recognizes automatically the presence of a serial MDB payment system at the switching on. Entering again 2, the display shows: access code To protect all the data set into the PROGRAMMING mode and the access to the test-vend modality, it is possible to introduce a 3 digits secret code;...
- Page 23 + 00.0% Setting this parameter you can adjust in percentage the quantity of the product dispensed from each ingredient motor of the machine. Entering 4 and 5 you can decrease or increase this value from –30% to +30%. Entering again 2, the display shows: disintallation 4 = start...
- Page 24 Read the parameter, in the programming mode, by pressing 1 until the sub-menu SALES DATA - - - - - - - - - - - - - - - - - - - - - - - is displayed. Then press 2 and the following counters are shown in sequence: TOTAL SELECTIONS This value indicates the total sale cycles of the machine.
- Page 25 This value indicates the total number of beverages paid by means of RFID Rhea card. N. PAR. SEL. CARD This value indicates the number of beverages paid by means of RFID Rhea card starting from the last reset operation. Finally, partial counters are available for each sale price. By pressing 2 several times, the values from SELECTION 1 SELECTION 17 appear the number of beverages supplied for each sale price starting from the last reset operation.
- Page 26 is displayed. Press 4 and 5 and modify the values of the function displayed. Another characteristic of the MDB/ICP machine with system for change is the multisale function. This means that, instead of giving back the correct change and end vend cycle, as usually provided for, the machine keeps the possible residual credit available for the next selection.
- Page 27 week: Monday will appear. These functions are foreseen to adjust the current time (hh.mm), the current month (mm) and day (dd) and the current year (yy), the current day of the week (Monday), respectively. Press 2 and 3 and choose the function, which requires to be altered.
-
Page 28: Maintenance
how many seconds the motor should work to finish the product and pre-set the value of the relative counter. EG: If inside the coffee canister, which corresponds to motor 1, you fill in 1000 g of coffee and the coffee motor dispenses 1 g of coffee in two seconds then the canister will be empty in 2000 seconds;... - Page 29 Press buttons 4 and 5 to change the value of the parameter shown. Set 0 to each coin from a to j that the coin- mech has to accept when the RFID Rhea card is not present and 1 to each coin that must not be accepted in this case.
- Page 30 14.1 Daily cleaning The objective of these operations is to avert any growth of bacteria in areas in contact with foodstuff. Before any operation, wash your hands thoroughly. To carry out these operations use two clean cloths as well as a clean brush (only for models PB with traditional group);...
- Page 31 Empty, clean or replace the containers of liquid waste disposal and coffee grounds (Versions PB). 14.2 Weekly cleaning These operations are carried out once a week, after completing the daily cleaning operations. Make sure that the machine is off. With a damp cloth clean the surface where the ingredient canisters lay and the bottom of the machine to remove any powder eventually spilled during loading.
- Page 32 14.4 Refilling of ingredients Read the indication of the ingredient to load on the canister. Fill in the canisters after removing the cover. Use a quantity of product suitable for a period between two refilling, and in any case do not exceed the quantities shown in the table here below.
- Page 33 Ordinary and prevention maintenance 15.1 Monthly maintenance 15.1.1 Disinfecting of components in contact with ingredients These operations must be carried out once a month to ensure the hygiene of the machine. These operations have already been described in the paragraph "Cleaning and Disinfecting of components in contact with ingredients". 15.1.2 Maintenance A new MAINTENANCE menu has been introduced to have the possibility to improve maintenance operations.
- Page 34 temperature of about 75-80° C. Proceed with usual coffee brewer cleaning. Use a lot of water and dry. At the end of the procedure place all parts in their correct position. 15.1.6 Regeneration of the water softener filter This section applies only to machines equipped with water softener filter. Check that the maximum quantity of softened water between two filter regenerations has not been reached.
- Page 35 Clean the inside and the outside with a damp cloth. Protect the outside of the machine with a piece of cloth or a plastic film. The machine must be kept in a sheltered place and at a temperature not lower than 5° C. 16.2 Definitive out of service Before carrying out the definitive out of service operation, it is necessary to carry out all operations to empty the machine of ingredients and water according to instructions given in the above section.
- Page 36 Further advice for the user The automatic vending machine in your hands is safe for those who follow the loading and ordinary cleaning instructions indicated in this manual. The user must not gain access to areas in the machine, which feature a cover requiring a tool to be removed.
-
Page 37: Troubleshooting
Troubleshooting 18.1 Problems visualised by the machine The problems described in this section are shown by an error message on the display of the machine. SYMPTOM PROBABLE CAUSE REMEDY The display shows " OFF 1A-1B: No cups inside one of the cups Load the cups into the cups columns tower columns tower... - Page 38 through the coffee group The mills of the grinder are worn Replace them Dismount and clean the volumetric The display shows " OFF 7": does Versions) Check counter not vend beverages through the volumetric counter coffee brewer Lost of data programming Enter into the programming mode, The display shows "...
- Page 39 Try to load the slave file with the flash card Communication problems between Check the connecting USB cable The display shows " OFF 51": the CPU board and Coffee Brewer and the boards. machine is out of order board Communication problems between Check the connecting USB cable The display shows "...
