Summary of Contents for PICOTE MIDI STEAMER
- Page 1 These instructions are for your personal safety. Always ensure that you have read and understood these instructions before using the equipment. SAVE THESE INSTRUCTIONS FOR FUTURE REFERENCE.
-
Page 2: Table Of Contents
To watch practical demonstration videos, take a course, or to download an electronic copy of these Instructions, please visit www.picoteinstitute.com. Please note that videos and courses are not intended as a replacement or alternative to this operating and safety manual, but only as an additional learning tool. Picote Solutions Oy Ltd www.picoteinstitute.com... -
Page 3: Safety Information
2. Before each use inspect the Midi Steamer carefully for any potential damage. 3. Only use the Midi Steamer with the official accessories and spare parts offered by Picote Solutions. Accessories and spare parts should only be used in the manner intended and as described by Picote Solutions. -
Page 4: Environment, Transport, Storage & Disposal
Operational Ambient Temperature Range: -5°C to +40°C (23 to 104°F) TRANSPORT: Always transport the Picote Midi Steamer in the vertical/upright position and secured to prevent any movement. The Midi Steamer should be empty if transported in temperatures below 0°C (32°F). -
Page 5: Ce Declaration Of Conformity
CE DECLARATION OF CONFORMITY SAVE ALL WARNINGS AND INSTRUCTIONS FOR FUTURE REFERENCE We Picote Solutions Oy Ltd as the responsible manufacturer, declare that the following Picote Solutions Oy Ltd steam generator: Midi Steamer Model No: 110V/120V & 230V/240V is of series production and... -
Page 6: General Information
Weight (empty) 25.5kg (56.2 lbs) Midi Steamer Products Part Number Product 2400000001 Picote Midi Steamer 240V / 15A EU 2400000001AUS Picote Midi Steamer 240V / 15A AUS 2400000001US Picote Midi Steamer 240V / 15A US 2400000002US Picote Midi Steamer US 2x110V / 15A+15A Two Sperate Power Plugs. - Page 7 GENERAL INFORMATION SAVE ALL WARNINGS AND INSTRUCTIONS FOR FUTURE REFERENCE Picote Solutions Oy Ltd www.picoteinstitute.com...
-
Page 8: Pull Handle Operation
SAVE ALL WARNINGS AND INSTRUCTIONS FOR FUTURE REFERENCE Pull Handle Operation: To unlock the pull handle extension, turn the locking knobs on each side anti-clockwise. To lock the pull handle to the desired elevation, turn the locking knobs on each side clockwise. Picote Solutions Oy Ltd www.picoteinstitute.com... -
Page 9: Before Operation
5. If steam starts to come out of the bottom left hand side port, turn off the steam and check the following: • Check that there are no blockages between Midi Steamer steam output and steam port on the tool head assembly. -
Page 10: Safety Fill Cap
Never make any modifications, changes, or repairs to the Safety Cap! Cooling Fan Operation: The Midi Steamer is equipped with an automatic cooling fan. The cooling fan will turn on when internal component temperatures reach 40°C (104°F) and will turn off when the unit cools down to 25°C (77°F). - Page 11 Half power is most suitable for connection collars and patches. • Using full power heats up the water faster and is recommended if the Midi Steamer is not able to produce enough heat due to long installation distance or when steam curing linings.
-
Page 12: Steaming
Connect other end of steaming hose to connection collar, patch, or liner. • If there isn’t a valve between the Steaming Hose and connection collar, patch, or liner, be sure air pressure is already set from Midi Steamer to avoid a collapse. 5. Setting the Curing Time: •... -
Page 13: Adjusting The Steam Flow
1. After curing has finished, wait for the connection collar, patch, or liner to cool down before disconnecting the air supply. 2. The Midi Steamer starts the cooling process automatically after the Timer goes to 0. 3. Timer will give an audible sound when the cooling process starts. -
Page 14: Maintenance: Descaling The Boiler
Check the Cooling Fan Air Filter once a month. The filter should be cleaned when it gets clogged. Clean it by removing the protective grill by hand. After this, the filter can then be washed and dried, or vacuumed. Do not vacuum through the fan while the filter is still on the Midi Steamer! Picote Solutions Oy Ltd... -
Page 15: Fault Finding Charts
FAULT FINDING CHARTS SAVE ALL WARNINGS AND INSTRUCTIONS FOR FUTURE REFERENCE 2 - No Steam or Low Pressure 1 - Midi Steamer Does Not Turn ON Picote Solutions Oy Ltd www.picoteinstitute.com... - Page 16 FAULT FINDING CHARTS SAVE ALL WARNINGS AND INSTRUCTIONS FOR FUTURE REFERENCE 3 - No Steam Coming Out Picote Solutions Oy Ltd www.picoteinstitute.com...
-
Page 17: Warranty Policy And Procedure
SAVE ALL WARNINGS AND INSTRUCTIONS FOR FUTURE REFERENCE Limited Warranty: Picote warrants to the original End User that the Product purchased by such End User will operate in accordance with, and substantially conform to their published specifications when shipped or otherwise... - Page 18 Revision number: Rev. 2 Date: 27th December, 2023 Author: Accepted: Dawn Greig 28/12/2023 Please Contact: Your Reseller / Salesperson or Picote www.picotegroup.com Production & R&D International Offices Technical Support Pienteollisuustie 24 Finland. United Kingdom. USA. support@picotesolutions.com 06450 Porvoo, Finland support@picotesolutions.com...
