9503-S/B-E
GIUNTO PASSANTE
JOINTING CONNECTOR
Dati tecnici
Technical data
- Corrente e tensione nominale
- Rated current and voltage
Caratteristiche
Characteristics
— Corpo in policarbonato. Colori disponibili: nero (B) e bianco (W)
— Polycarbonate body. Available colours: black (B) and white (W)
— Contatti in lega di rame
— Copper alloy contacts
fissaggio ad innesto
snap-in fixing
Marchi di qualità
Quality marks
Class 2 (2A-48Vdc/4A-24Vdc)
Note
Notes
19-06-2023
9503-S/W-E
classe III
class III
SELV
Direttive Europee
European directives
Conforme "RoHS"
"RoHS" compliant
A.A.G. STUCCHI s.r.l. u.s.
Via IV Novembre 30/32
23854 Olginate (Lc) - ITALY
Ph. +39-0341-653111
Fax +39-0341-653250
info@aagstucchi.it
www.aagstucchi.it
15A/60V dc
Pesi e confezioni
Weights and packaging
Art.
Codice prodotti
Peso netto
Product references
Net weight
9503-S/B-E
9503-S/W-E
EUTRAC STROMSCHIENEN GMBH
Volkmarstraße 18
D-12099 Berlin - GERMANY
Ph: +49-(0)30-270009-0
Fax: +49-(0)30-270009-248
service@eutrac.de
www.eutrac.de
g
n° pz
n° pz
per sacco
per scatola
per bag
per box
n° pz
per cartone
per carton
PAG 1
