12 Connect the DSP/Amplifier Wiring Harnesses before beginning your installation. 15 Mount the Borla Sound Controller Borla Performance Industries recommends a professional aftermarket parts installer 18 Install the DSP/Amplifier Unit perform the installation of this system. If you choose to install our Borla Performance 19 Power Up Your Borla Active Performance™...
INSTALL THE SPEAKER ENCLOSURE STEP 3: Next, remove the inside, factory bumper nuts. There will be two 15mm nuts on each side of the factory bumper in the cavity that was exposed earlier. Remove all four nuts to prepare to mount the enclosure brackets. STEP 1: Remove the under body panel.
Page 5
STEP 6: With the passenger side bracket assembled, begin assembling the driver side bracket STEP 8: With the brackets installed, next move on to routing the BOR-FMESPK-HAR into the area by attaching the remaining two rubber isolators to bracket “1” using two of the 10mm exposed by removing the under body panel.
ROUTE THE SPEAKER WIRING STEP 10: Next, re-install the Factory Alert Speaker to bracket “2/4/5” on the passenger side using two provided 10mm nuts and the factory 10mm bolts that previously secured the Factory Alert Speaker to the underside of the vehicle. Reconnect the factory harness STEP 1: Route the Speaker Wiring Harness to the front of the vehicle following the factory wiring to the speaker.
STEP 3: To remove the driver door sill panel you will need to remove the frunk release handle. STEP 1A: On some 2023 Mach-E vehicles, accessing the battery and firewall grommet requires Make sure to pull the release handle twice to have access to the frunk area for a future a slightly different procedure.
STEP 3: Next, move on to installing the Data Wiring Harness (BOR-DATA-HAR). You will need to STEP 6: Take the DSP/Amplifier Unit and connect the supplied Ground Cable (BOR-FMEGND- remove the bottom of the steering wheel cover. There will be two 7mm bolts to remove. HAR) to the spot marked “Ground”...
Page 9
STEP 2: Feed the 4 pin connector end through the 1/2 inch hole and pull through (A). Then, STEP 4: With the Harness routed and the Controller mounted in place, connect the 16 pin using a wire snake or similar, route the 4 pin connector end down to the driver side kick connector that was routed to the driver side kick panel area in a previous step to the panel area (B).
INSTALL THE DSP/AMPLIFIER UNIT STEP 3: To complete the installation, install the supplied fuse into the fuse holder on P-BOR- PWR-HAR that was previously installed near the battery. Proceed with testing the system for functionality and putting the vehicle back together. STEP 1: With the Harnesses now connected to the DSP/Amplifier Unit, proceed with mounting the Unit in place.
