- Page 1 INSTRUCTION MANUAL DAAB AUTOMATIC MAGNETIC LOCK DB310 For DAAB automatic control unit EP103 EP104 EP105 FAAC Nordic AB BOX 125, SE-284 22 PERSTORP SWEDEN, +46 435 77 95 00, support@faac.se www.faac.se...
- Page 2 INSTRUCTION MANUAL AUTOMATIC MAGNETIC LOCK DB310 Technical data Dimensions (WxHxD) 36x90x62 mm Power supply 24VDC Temperature range 0 to 50°C Output 1x max 1 A magnet Indication 2x LEDs Degree of protection The circuit card is designed for internal installation in an enclosure Revision 9...
-
Page 3: Safety Instructions
INSTRUCTION MANUAL AUTOMATIC MAGNETIC LOCK DB310 Safety instructions See instruction manual for automatic control units EP103/EP104/EP105. General description Add-in card that magnetises and demagnetises an electromagnet. Demagnetisation takes place for about 3 seconds on each start of both opening and closing movements of the gate. The recommended power supply to the DB301 and magnet is FAAB's transformer SPD. - Page 4 INSTRUCTION MANUAL AUTOMATIC MAGNETIC LOCK DB310 Example of connection for two magnetic locks: Power Supply Automatic control Magnetic lock control unit Magnetic lock control unit 24VDC units: DB310 DB310 EP103 or EP104 with software version 4.06 or lower Lock magnet Lock magnet Power supply Automatic control...
- Page 5 INSTRUCTION MANUAL AUTOMATIC MAGNETIC LOCK DB310 Settings for EP103 with magnetic lock When an electric magnetic lock is used, the magnetism must have time to release before the gate is allowed to start moving. It is therefore possible to delay the start of gate movement with an adjustable time in channel C39, 0.00 to 0.99 seconds.
