- Page 1 SP10000 EOS Extraoral Dental Suction System Instructions For Use P/N：8027313 Version：A Date of Issue：2020-03-18...
-
Page 2: Table Of Contents
Extraoral Dental Suction System,Instructions For Use Contents I n t r o d u c t i o n s … … … … … … … … … … … … … … … … … … … … … … … … … … … … … … … … 1 1 . -
Page 3: Intended Application And Use
Extraoral Dental Suction System,Instructions For Use 1. Product Introduction Before the use, please must to read the Warning and Cautions of the user instructions. Please must to keep the use instructions carefully, re-reading the use instructions again if any doubt. Correctly use to improve effectiveness. 1.1 Intended Application And Use Greatly thank for selecting our products, committed to the Dust &... -
Page 4: Cautions
Extraoral Dental Suction System,Instructions For Use Cautions ADS will not be responsible for that the equipment is damage or failure caused by below issues. The product is not installed, remoulded, or maintained by ADS designated operator. The product is damaged or failure due to some products in other companies not purchased from ADS. - Page 5 Extraoral Dental Suction System,Instructions For Use 3) Before the use, paying attention to below matters ① Ensure to connect ground electrode completely. ② Ensure all electric wires were connected correctly. 4) Paying attention to below matters during the use ① Do not use for overtime and overload ②...
-
Page 6: Product Structure
Extraoral Dental Suction System,Instructions For Use 3 Product Structure 8026563 HEPA Filtration 8026752 The First Suction Arm 8026749 Filter Box 8026899 The First Joint 8026695 Box Door 8026734 Centre Pillar 8026722 Dust Filtration 8026614 Drag Hand 8026740 Suction Cap Cover A121938 Power Source 8026746... -
Page 7: Product Specifications
Extraoral Dental Suction System,Instructions For Use 4 Product Specifications Model Voltage AC220V 50-60Hz Power 1200W Suction Power 10KPa 10 Level Adjustment Traffic 3000L/Min Power（W） 4W*2 Voltage（V） 30±15% Electricity（mA） 145±15% UV Light Radiation Intensity ≥8 @1m (μW/cm Average Lifetime (h) ＞8000(Continuously light up) H14 ,stopping virus and germs ≥0.3μm with HEPA Filter Filtering Level... -
Page 8: Product Installation
Extraoral Dental Suction System,Instructions For Use 5 Product Installation 1、Insert the mounting hole of the first joint in the suction arm into the centre pillar of the host, and the thumb screw aligns to the centre pillar groove, tightening the screw. Caution: The spring port of suction arm is installation port. -
Page 9: Product Use
Extraoral Dental Suction System,Instructions For Use 6 Product Use 6.1 Warning For Use • When moving chairs up and down, the Extraoral Suction System to be avoided touching patient, as well as the objects including shadowless lamp, chairs, tables, etc. •... - Page 10 Extraoral Dental Suction System,Instructions For Use Armrest Utilize on the Moving by using horizontal ground armrest...
-
Page 11: Preparation
Extraoral Dental Suction System,Instructions For Use 6.2 Preparation The 3P plug of the power source wires connects to the 220V, over 15A dedicated belts connect to the floor socket. Utilize the equipment by pressing the turn-on button to connect the power. Cautions：... - Page 12 Extraoral Dental Suction System,Instructions For Use l 6.3 Start Up l Ensure to keep the sucked substances away from the suction cup. l Please make sure the suction arms supporting steadily. l The suction cup should be used away 10 cm from the patient's mouth. l Press the start-up button.
-
Page 13: O P E R A T I O N P R I N C I P L
Extraoral Dental Suction System,Instructions For Use 6.5 Operation Principle This equipment uses a suction cap to collect D ro p l et s , B a c te r i a l A e ro s o l s , a n d D u st produced during dental treatment. - Page 14 Extraoral Dental Suction System,Instructions For Use 7 Cleaning and Replacement Parts • When installing or striking the suction cap, please catch the root near the connection part instead of catching the suction cap port. • In terms of cleaning the surface of the equipment, please use the soft cloth to wipe out after wringing out water.
- Page 15 Extraoral Dental Suction System,Instructions For Use 7.2 Suction Arm [Daily Clean] • Please wipe out the surface by using dedicated atomizing disinfectant or disinfect soft cloth. • In terms of cleaning the inner of the suction arm, the atomizing disinfectant can be used in spraying toward the suction cap cover during the power-on states, or the disinfectant sucked in the suction arm to disinfect.
- Page 16 Extraoral Dental Suction System,Instructions For Use 7.3 The methods of replacement filtration Percentage of remaining lifetime The service time of the system default settings is 12 months, and the indicator will show the life percentage of the filter every time. Time will be different base on the differentiation of the actual use environment.When the negative voltage is obviously insufficient or the panel beeps, replace the whole...
- Page 17 Extraoral Dental Suction System,Instructions For Use 7.3.2 The replacement methods of dust filtration • Please cut off the power switch,and then plucking out the power plug from the power socket. • Please do not touch with wet hands. • Wear gloves. [Caution]The replacement of the suction arm will be disposed of as medical garbage.
- Page 18 Extraoral Dental Suction System,Instructions For Use [Caution]The replacement of the suction arm will be disposed of as medical garbage. [Caution] Confirm the HEPA filtration to toward down Reset Button [Caution] After replacement of a filtration set, press reset button 5 seconds and loosen it when hearing a beep 3 seconds, eliminating the alarm.
- Page 19 Extraoral Dental Suction System,Instructions For Use 7.5 The replacement methods of fuse wire • Please cut off the power switch, and then plucking out the power. • Please do not touch with wet hands. ① Pulling out the power source wire. ②...
-
Page 20: C O N S U M A B L E
Extraoral Dental Suction System,Instructions For Use 8 Daily Maintenance In order to use clean equipment every day, please pay attention to avoid dirty for the suction cap cover and clean it frequently. • About the suction arm disinfection, please use dedicated atomizing disinfectant or disinfect soft cloth to wipe out. - Page 21 Extraoral Dental Suction System,Instructions For Use 8026563 HEPA Filtration 8026752 The First Suction Arm 8026749 Filter Box 8026899 The First Joint 8026695 Box Door 8026734 Centre Pillar 8026722 Dust Filtration 8026614 Drag Hand 8026740 Suction Cap Cover A121938 Power Source 8026746 The Third Suction Arm 8026617...
-
Page 22: Electromagnetic Compatibility
Extraoral Dental Suction System,Instructions For Use 11 Electro Magnetic Compatibility Caution ： • Extraoral Dental Suction System meets the requirements of the YY0505 standard. • Users should install and utilize base on the electromagnetic compatibility information of the document. • Portable and mobile radio frequency communication equipment may affect the features of the Extraoral Dental Suction System, avoiding disturbing by the strong electromagnetic such as mobile phone or induction cooker. - Page 23 Extraoral Dental Suction System,Instructions For Use The statement of the Guide & Manufacturer— Electromagnetic Immunity Extraoral Dental Suction System expected that it should be used in the below electromagnetic environmental requirements, the buyers or users should guarantee that it can be used in this electromagnetic environment. Electromagnetic Electromagnetic IEC6061 Test Level...
- Page 24 Extraoral Dental Suction System,Instructions For Use The statement of the Guide & Manufacturer— Electromagnetic Immunity Extraoral Dental Suction System expected that it should be used in the below electromagnetic environmental requirements, the buyers or users should guarantee that it can be used in this electromagnetic environment. Electromagnetic Test Level Electromagnetic Environment—...
- Page 25 Extraoral Dental Suction System,Instructions For Use Recommended isolation distance between portable and mobile RF communication equipment and Dentistry Electric Suction System EP320 Dentistry Electric Suction System are intended for use in electromagnetic environments where RF radiation disturbances are controlled. Depending on the maximum rated output power of the communication device, the purchaser or user can prevent electromagnetic interference by maintaining the minimum distance between portable and mobile RF communication devices (transmitters) and Dentistry Electric Suction System as recommended below...
- Page 26 Extraoral Dental Suction System,Instructions For Use 12 Symbols Descriptions Symbols Descriptions Carefully Placed Waterproof Caution,refere to the attached document Serial Number Ground Protection Vertical During The Transportation Caution Type B Machine Power Switch Activate Button Speed-up Button Speed-cut Button...
- Page 27 We reserve the right to make any alterations which may facilitate technical improvements.
