1 Checking the Package Contents Your package should • ZyWALL 1050 include one of each • Power cord of the following: • Rack-mounting kit 2 Rack-mounted Installation Mount the ZyWALL in a 19-inch rack or place it on a sturdy, flat surface.
3 Connecting the Hardware Make sure that the power switch on the rear panel is turned off before you make the hardware connections. 1 It is recommended that you configure the ZyWALL before using it to protect your network. Use an Ethernet cable to connect a computer to port 1.
Page 4
2 Click Yes to proceed if you get a security alert or certificate screen. 3 Enter admin as the user name and 1234 as the password. Click Login. 4 It is strongly recommended that you change the password. Type and retype a new password, and click Apply.
5 Installation Setup Wizard The Status screen opens. Click the Wizard icon in the upper right corner. Use an installation setup wizard to connect to the Internet and register the ZyWALL and/or activate trial services, like IDP and content filter. Note: Use the installation wizard only for initial configuration starting from the default configuration.
Page 6
The wizard screens vary depending on the encapsulation type you use. Refer to information provided by your ISP and the web help screens to know what to enter in each field. You can leave fields blank if you don’t have that information. 6 Default Settings and Port Details The ZyWALL is configured for the following network topology by default.
Port Interface Zone IP Address and DHCP Settings 2, 3 ge2, ge3 WAN DHCP clients 4, 5 ge4, ge5 DMZ None, DHCP server disabled DIAL BACKUP aux None None CONSOLE None None Label DIAL BACKUP, CONSOLE RS-232 Note: The USB ports, extension card slots, and hard disk slot are reserved for future use. 7 Troubleshooting Problem Corrective Action...
Page 8
8 Procedure to View a Product’s Certification(s) 1 Go to www.zyxel.com. 2 Select your product from the drop-down list box on the ZyXEL home page to go to that product's page. 3 Select the certification you wish to view from this page.
1 Prüfen des Packungsinhalts Prüfen Sie ob alle • ZyWALL 1050 Teile vorhanden • Netzkabel sind: • Rackmontage-Zubehör 2 Rackmontage Montieren Sie die ZyWALL an einem 19"-Rack oder stellen Sie es auf eine stabile Unterlage. Hinweis: Lassen Sie seitlich 10 cm und hinten 20 cm Platz.
Page 10
3 Anschließen der Hardware Stellen Sie sicher, dass der Netzschalter an der Rückseite des Geräts ausgeschaltet ist, bevor Sie die ZyWALL in Betrieb nehmen. 1 Es wird empfohlen, die ZyWALL zu konfigurieren, bevor Sie sie zum in Ihrem Netzwerk einsetzen. Schließen Sie einen Computer mit einem Ethernetkabel an 2 Schließen Sie an Port 2 und/oder Port 3 Ihren Router mit Internetzugriff an.
Page 11
2 Wenn eine Sicherheitswarnung oder ein Zertifikatsfenster erscheint, klicken Sie auf Ja, um fortzufahren. 3 Geben Sie als Benutzername admin und als Kennwort 1234 ein. Klicken Sie auf Login. 4 Es wird dringend empfohlen, das Kennwort zu ändern. Geben Sie zweimal das neue Kennwort ein, und klicken Sie auf Apply (Übernehmen).
Page 12
5 Installationsassistent Das Fenster Status (Status) wird angezeigt. Klicken Sie in der rechten oberen Ecke auf das Assistent-Symbol Stellen Sie mit dem Installationsassistenten eine Verbindung zum Internet her und registrieren Sie den ZyWALL und/oder aktivieren Sie Testdienste wie IDP und Inhaltsfilter. Hinweis: Verwenden Sie den Setup-Assistenten beginnend mit der Standardkonfiguration nur für die Erstkonfiguration.
Page 13
Das zweite Fenster des Assistenten hängt vom verwendeten Encapsulation ab. In den Handbüchern Ihres Internetprovider und auf dessen Online- Hilfeseiten erfahren Sie, was in die einzelnen Felder eingegeben werden muss. Wenn Ihnen bestimmte Daten nicht vorliegen, Internetprovider. 6 Standardeinstellungen und Anschlussdetails Der ZyWALL ist standardmäßig für die folgende Netzwekrtopologie konfiguriert.
Page 14
Anschluss anschluss Zone 2, 3 ge2, ge3 4, 5 ge4, ge5 DIAL BACKUP aux CONSOLE n. V. (KONSOLE) Bezeichnung 1 - 5 DIAL BACKUP, CONSOLE (KONSOLE) Hinweis: Die USB-Anschlüsse, Erweiterungskartensteckplätze und der Festplattenschacht werden für die spätere Benutzung reserviert. 7 Problembeseitigung Problem Lösungsmöglichkeit Es leuchtet keine...
Page 15
Installationsassistenten aus, um sicherzustellen, dass Sie die richtigen Einstellungen eingegeben haben. 8 Schritte zum Ansehen von Produktzertifizierung(en) 1 Besuchen Sie www.zyxel.com. 2 Wählen Sie auf der ZyXEL-Homepage aus der Liste der Ihr Produkt aus. 3 Wählen Sie auf dieser die gewünschte Zertifizierung. DEUTSCH Führen Sie noch einmal den...
1 Comprobación del contenido del paquete Su paquete debería • ZyWALL 1050 incluir cada uno de • Cable de aliment- los siguientes ación elementos: • Kit para montaje en un equipo 2 Instalación en un rack Monte el ZyWALL en un rack de 19 pulgadas o colóquelo sobre una superficie resistente y plana.
Page 17
3 Conectar el hardware Compruebe que el interruptor de alimentación del panel posterior esté apagado antes de realizar las conexiones del hardware. 1 Se recomienda que configure el ZyWALL antes de usarlo para proteger su red. Utilice un cable Ethernet para conectar un ordenador al puerto 1.
Page 18
4 Acceso a la Web 1 Abra su navegador y vaya a http://192.168.1.1 (el ZyWALL le llevará automáticamente a https://192.168.1.1). 2 Haga clic en Sí para continuar si se ha abierto una pantalla de alerta de seguridad o certificado. 3 Escriba admin como nombre de usuario y 1234 como contraseña.
Page 19
4 Se recomienda que cambie la contraseña. Escriba y vuelva a escribir la nueva contraseña y haga clic en Apply (Aplicar). 5 Asistente para la instalación Aparecerá la pantalla Status (Estado). Haga clic en el icono del Asistente la esquina superior derecha.
Page 20
Las pantallas del asistente varían según el tipo de encapsulación usado. Consulte la información facilitada por su ISP y las pantallas de ayuda web para saber qué escribir en cada campo. Deje un campo en blanco si no tiene esa información. 6 Configuración predeterminada y detalles de los puertos El ZyWALL está...
Page 21
Puerto Interfaz Zona 2, 3 ge2, ge3 WAN Clientes DHCP 4, 5 ge4, ge5 DMZ Ninguna, servidor DHCP DIAL BACKUP Ning (APOYO DE MARCADO) CONSOLE Ning (CONSOLA) Etiqueta DIAL BACKUP, CONSOLE (CONSOLA) Nota: Los puertos USB, ranuras de extensión para tarjeta y la ranura para disco duro están reservadas para su uso en el futuro.
Page 22
8 Procedimiento para ver la(s) certificación(es) del producto 1 Vaya a www.zyxel.com. 2 Seleccione su producto de la lista desplegable en la página inicial de ZyXEL para ir a la página de ese producto. 3 Seleccione el certificado que desee visualizar en esta página.
1 Vérification du contenu de l'emballage Votre emballage • ZyWALL 1050 devrait inclure les • Cordon d'alimentation éléments suivants : • Kit de montage en rack 2 Installation avec montage en rack Montez le ZyWALL dans un rack de 19 pouces ou placez-le sur une surface solide et plane.
Page 24
3 Connecter le matériel Vérifiez que le commutateur d'alimentation situé sur le panneau arrière est éteint avant d'effectuer les connexions matérielles. 1 Il est recommandé de configurer leZyWALL avant de l'utiliser pour protéger votre réseau. Utilisez un câble Ethernet pour connecter un ordinateur au port 1. 2 Utilisez un autre (d'autres) câble(s) Ethernet pour connecter le port 2 et/ou le port 3 à...
Page 25
4 Ouverture d'une session web 1 Lancez votre navigateur web et allez à http://192.168.1.1 (le ZyWALL vous redirige automatiquement vers https:// 192.168.1.1). 2 Cliquez sur Oui pour continuer si vous recevez une alerte de sécurité ou un écran de certificat. 3 Entrez admin comme nom d'utilisateur et 1234 comme mot de passe.
Page 26
4 Il est fortement recommandé de changer le mot de passe Tapez et retapez un nouveau mot de passe, et cliquez sur Apply (Appliquer). 5 Assistant d'installation L'écran Status (Etat) s'ouvre. Cliquez sur l'icône l'Assistant dans le coin supérieur droit. Utilisez un assistant d'installation pour vous connecter à...
Page 27
Les écrans de l'assistant varient en fonction du type d'encapsulation que vous utilisez. Reportez-vous aux informations fournies par votre ISP et les écrans d'aide du web pour savoir ce que vous devez entrer dans chaque champ. Laissez un champ vide si vous n'avez pas cette information.
Page 28
Port Interface Zone 2, 3 ge2, ge3 4, 5 ge4, ge5 DIAL BACKUP (SAUVEGARDE DE NUMÉROTATION) CONSOLE Etiquette DIAL BACKUP (SAUVEGARDE DE NUMÉROTATION), CONSOLE Remarque : Les ports USB, les logements de carte d'extension, et le logement de disque dur sont réservés à...
Page 29
8 Procédure pour afficher la (les) certification(s) d'un produit 1 Allez à www.zyxel.com. 2 Sélectionnez votre produit dans la liste déroulante dans la page d'accueil du ZyXEL pour aller à la page de ce produit. 3 Sélectionnez la certification que vous désirez consulter dans cette page.
1 Controllo del contenuto della confezione La confezione • ZyWALL 1050 dovrebbe comprende • Cavo di alimentazione un esemplare di tutti • Kit di montaggio su gli elementi elencati rack di seguito: 2 Installazione su rack Montare lo ZyWALL in un rack da 19 pollici o appoggiarlo su una superficie piana e stabile.
3 Collegamento dell'hardware Verificare che l'interruttore di accensione dietro sia spento prima di effettuare i collegamenti dell'hardware. 1 Si consiglia di configurare ZyWALL prima di utilizzarlo per proteggere la rete. Utilizzare un cavo Ethernet per collegare un computer alla porta 1. 2 Utilizzare altri cavi Ethernet per collegare la porta 2 e/o la porta 3 a un jack Ethernet con accesso a Internet.
Page 32
2 Fare clic su Sì per procedere se viene visualizzato un avvisto di protezione o una schermata per il certificato. 3 Immettere admin come nome utente e 1234 come password. Fare clic su Login. 4 È vivamente consigliato cambiare la password. Digitare e ridigitare una nuova password, quindi fare clic su Applica.
Page 33
5 Configurazione guidata installazione Viene aperta la schermata Stato. Fare clic sull'icona della procedura guidata nell'angolo superiore destro. Utilizzare la configurazione guidata per connettersi a Internet e registrare il ZyWALL e/o attivare i servizi offerti per valutazione, come ad esempio IDP e il filtraggio dei contenuti. Nota: Utilizzare l'installazione guidata solo per la configurazione iniziale partendo dalla configurazione predefinita.
Page 34
Le schermata della procedura guidata variano a seconda del tipo di incapsulamento utilizzato. Vedere le informazioni fornite dall'ISP e le schermate della guida online per sapere cosa immettere in ciascun campo. Lasciare un campo vuoto se non si possiedono queste informazioni. 6 Impostazioni predefinite e dettagli delle porte ZyWALL è...
Page 35
Porta Interfaccia 2, 3 ge2, ge3 4, 5 ge4, ge5 DIAL BACKUP (COMPOSIZIO NE DI BACKUP) CONSOLE Etichetta DIAL BACKUP (COMPOSIZIONE DI BACKUP), CONSOLE Nota: Le porte USB, gli slot delle schede di espansione e lo slot del disco rigido sono riservate per uso futuro.
Page 36
8 Procedura per visualizzare le certificazioni di un prodotto 1 Aprire la pagina www.zyxel.com. 2 Selezionare il prodotto dall'elenco di riepilogo a discesa nella Home Page di ZyXEL per passare alla pagina del prodotto in questione. 3 Selezionare da questa pagina la certificazione che si desidera visualizzare.
1 Проверка комплектности В комплект • Устройство ZyWALL 1050 входят • Сетевой шнур следующие • Монтажный комплект для позиции, по 1 шт.: установки в стойку 2 Установка в стойку Устройство ZyWALL может устанавливаться в 19-дюймовую стойку или на любую твердую плоскую...
Page 45
3 Подключение Перед подключением убедитесь, что выключатель питания на задней панели находится в положении “выключено”. 1 Перед подключением устройства ZyWALL к защищаемой сети рекомендуется его сконфигурировать. Подключите компьютер к порту 1 кабелем Ethernet. 2 Подключите кабелями Ethernet к портам 2 и/или 3 линии Ethernet, по которым осуществляется доступ...
Page 46
4 Встроенный web-сервер 1 Запустите web-браузер и перейдите на страницу http://192.168.1.1 (произойдет автоматическое перенаправление на адрес https://192.168.1.1). 2 В случае вывода каких-либо запросов на подтверждение потенциально небезопасных операций или приема сертификатов для продолжения нажмите Yes. 3 Введите в поле User name имя пользователя...
Page 47
4 Рекомендуется сразу же сменить пароль. Наберите новый пароль в поле New Password и еще раз поле Retype to Confirm; затем нажмите кнопку Apply. 5 Мастер первоначальной настройки Installation Setup Wizard После открытия экрана Status воспользуйтесь значком Wizard расположенным в правом...
Page 48
В процессе работы мастера могут появляться те или иные экраны, в зависимости от используемого типа инкапсуляции. Используйте для заполнения полей сведения, предоставленные интернет-провайдером и содержащиеся в web-системе справки. В отсутствие необходимой информации оставьте поле пустым. 6 Значения конфигурационных параметров и использование портов...
Page 49
Порт интерфейс Зона IP-адрес и настройки DHCP 2, 3 GE2, GE3 4, 5 GE4, GE5 DIAL BACKUP aux CONSOLE Нет Маркировка DIAL BACKUP, CONSOLE RS-232 Примечание. Порты USB, гнезда для дополнительных плат и гнездо для жесткого диска в данной модели не используются. 7 Диагностика...
Page 50
и проверьте, все ли параметры заданы верно. 8 Просмотр информации о соответствии продукта нормативным требованиям 1 Перейдите на сайт ZyXEL по адресу www.zyxel.ru. 2 Выберите свой продукт из раскрывающегося списка для перехода к странице продукта. 3 Просмотрите информацию о соответствии нормативным требованиям.
