- Page 1 VANAD 500 USER'S MANUAL IGS Audio Igor Sobczyk UL. 3 Maja 76d, 41-400 Mysłowice, Poland e-mail: igs@o2.pl ph: +48 601 597 592 www.igsaudio.com...
- Page 2 The information in this document is subject to change without notice. IGS Audio makes no warranty of any kind with respect to the material in this document and shall not be liable for errors contained herein or for incidental or consequential damages related to the use of the material.
- Page 3 Please check for any signs of transit damage. If any signs of mishandling are found please notify the carrier and your dealer immediately. Your VANAD 500 packing should contain an VANAD 500 with IGS Audio tag (packed in ESD bag) and this manual with the Warranty and RoHS/CE/WEEE Declaration attached.
- Page 4 IGS AUDIO VANAD 500 – Optical Compressor VANAD 500 is a mic/instrument preamp designed in the API 500 standard. The module is transformer balanced on inputs and outputs using Carnhill transformers. All regulators on the front panel are stepped (switches).
- Page 5 GAIN REDUCTION INPUT LED BAR OUTPUT +48V MIC/HI-Z PHASE INPUT input level: from 0dB(Line) to +30dB(Mic); step = 3dB OUTPUT output level: from +0dB to +30dB; step = 3dB +48V phantom power: ON/OFF PHASE phase reverse: ON/OFF HPF 6dB/Oct high pass filter: OFF/30/100Hz MIC/HI-Z input: HiZ(front)/XLR(rear)
- Page 6 VANAD 500 main functions and technical specification: ✔ 500-series mono module ✔ Preamp Mic/Line/HiZ ✔ All stepped manipulators ✔ Precise LED bar scale ✔ Carnhill input and output transformers ✔ Phantom power +48V ✔ Phase reverse ✔ 3 year warranty...
- Page 7 Troubleshooting My unit doesn't light up (LED bar is dark): – Please check if the rack power supply is on (check the LEDs at the front plate of the rack). – Make sure that the signal source (i.e. the microphone) is properly connected to the module –...
- Page 8 Warranty: This device is declared to be free from defects in material and workmanship for a period of three years. Any device found defective within three years from the delivery date and returned to the factory, will be repaired, adjusted, or replaced and sent to the customer with no charge.
