Summary of Contents for albinus 08-02-040
- Page 1 20 L 230 V 1200 W Part No. 08-02-040 30 L 230 V 1200 W Part No. 08-02-041 40 L 230 V 1200 W Part No. 08-02-042 60 L 230 V 1200 W Part No. 08-02-043 80 L 230 V 1200 W Part No.
- Page 3 5.1 - AC connection diagram 6 - Maintenance 6.0 - Maintenance 6.1 - AC maintenance 7 - Product disposal 8 - Spare parts 9 - Dimensions INSTALLATION AND USER MANUAL - ALBINUS STAINLESS STEEL PREMIUM WATER HEATERS - REV0001 2023-09...
- Page 4 Our long experience in the nautical sector has enabled us to develop a series of water heaters with innovative features compared to the market standard. The advantages that albinus water heaters offer are: • High-quality materials ensuring durability and resistance over time.
- Page 5 1200 W 1200 W power rating Fittings diameter 1/2" 1/2" 13.4 16.3 Weight 29.5 35.9 (1) 1 Bar = 100 kPa • (2) with equipment vacuum INSTALLATION AND USER MANUAL - ALBINUS STAINLESS STEEL PREMIUM WATER HEATERS - REV0001 2023-09...
- Page 6 DISCONNECTED FROM THE ELECTRICAL SYSTEM. Albin Group accepts no responsibility for inadequate connection of users to the electrical system and inadequate safety of the electrical system. INSTALLATION AND USER MANUAL - ALBINUS STAINLESS STEEL PREMIUM WATER HEATERS - REV0001 2023-09...
-
Page 7: Installation / Use
Close the taps as soon as only water starts to flow out. • Check that there is no leakage from the fittings. INSTALLATION AND USER MANUAL - ALBINUS STAINLESS STEEL PREMIUM WATER HEATERS - REV0001 2023-09... -
Page 8: Cautions For Use
• Refi t the protection cover. THERMOSTAT TEMPERATURE SETTING KNOB • Restore the power supply. The thermostat regulates the water temperature only when operating with electric element. PROTECTION COVER INSTALLATION AND USER MANUAL - ALBINUS STAINLESS STEEL PREMIUM WATER HEATERS - REV0001 2023-09... -
Page 9: Wiring Diagram
5.0 - Hydraulic connection FIG.1 FIG.2 HOT TAP WATER OUTPUT ENGINE COOLING LIQUID COLD TAP WATER INPUT EXPANSION TANK HOT WATER TAP WATER TANK COLD WATER WATER PUMP INSTALLATION AND USER MANUAL - ALBINUS STAINLESS STEEL PREMIUM WATER HEATERS - REV0001 2023-09... - Page 10 5 - Wiring diagram 5.1 - AC connection diagram FIG.3 FIG.4 THERMOSTAT TEMPERATURE SETTING KNOB PHASE NEUTRAL EARTH SWITCH RESET BUTTON AC NETWORK NETWORK LIVE NEUTRAL INSTALLATION AND USER MANUAL - ALBINUS STAINLESS STEEL PREMIUM WATER HEATERS - REV0001 2023-09...
-
Page 11: Maintenance
• Periodically check the effi ciency of the electrical system. 6.1 - AC maintenance WARNING: Albinus water heaters are equipped with a double thermostat with manual reset that cuts off the power supply in the event of too high water temperature. -
Page 12: Product Disposal
Local regulations may impose severe penalties for the improper disposal of this product. INSTALLATION AND USER MANUAL - ALBINUS STAINLESS STEEL PREMIUM WATER HEATERS - REV0001 2023-09... -
Page 13: Spare Parts
08-92-047 ELECTRIC ELEMENT SEAL 08-92-048 DOUBLE THERMOSTAT KIT 15A 270MM 08-92-049 PIPE END WASHERS 08-92-050 FIXING KIT 20L 08-92-051 FIXING KIT 30L–40 08-92-052 FIXING KIT 60L–80L INSTALLATION AND USER MANUAL - ALBINUS STAINLESS STEEL PREMIUM WATER HEATERS - REV0001 2023-09... - Page 14 Stainless Steel Premium Water Heaters 9 - Dimensions 20L 5.3 GAL 30L 8 GAL - 40L 10.5 GAL 60L 15.8 GAL - 80L 21.1 GAL INSTALLATION AND USER MANUAL - ALBINUS STAINLESS STEEL PREMIUM WATER HEATERS - REV0001 2023-09...
- Page 15 204 (8" 1/32) 85 (3" 11/32) Ø 400 (15" 3/4) 270 ÷ 285 (10" 5/8 ÷ 11" 7/32) 320 (12" 19/32) 204 (8" 1/32) 323 (12" 23/32) INSTALLATION AND USER MANUAL - ALBINUS STAINLESS STEEL PREMIUM WATER HEATERS - REV0001 2023-09...
- Page 16 Stainless Steel Premium Water Heaters SS Premium Water Heater 20 L 230 V 1200 W Part No. 08-02-040 SS Premium Water Heater 30 L 230 V 1200 W Part No. 08-02-041 SS Premium Water Heater 40 L 230 V 1200 W Part No.
