KINGDOM GH-516 User Instruction

Thanks for your purchasing this item. Please read and understand these instructions and keep this manual for
future reference. This item uses solar power to recharge the batteries so it is always working after the battery
recharged. The Passive Infrared sensor(PIR) detects motion and triggers the ultrasonic speaker emitting a tone
that animals can feel and chase away these animals.
Overview
Featuring 5 modes of operation, Solar animal & bird repeller is a versatile and effective bird and animal
repellent! Unlike other pest repellents that only offer one repellent mode, it offers Five pest repellent modes to
ensure your property is protected from birds, insects, deer, raccoons, armadillos, opossums, skunks, cats, dogs,
rodents, bats, geese. Solar animal & bird repeller is ideal for use in gardens, backyards, open patios, courtyards,
boats, docks and is designed for long term use, allowing you to place it and leave it to repel pests. It is
weatherproof allowing it to work year-round.
Specifications
Product Name
Model No.
Materials
Power Supply
Solar Panel
Working Voltage/Current
Battery
Waterproof Grade
Sensor Distance
Detection Range
DB Value
Indicator lights
Ultrasonic Frequency
Seven-color flash LED
SET UP
- - Button "Volume" (Left): By turning the knob clockwise, you can adjust the sound from minimum to maximum.
- - Button "Frequency" (Right): This is to control frequency. By turning the knob clockwise, the frequency will be
increased.
- - Button "Frequency" position as below (it will be works 30 seconds after activated in each mode):
Solar Animal and Bird Repeller
USER INSTRUCTION
Solar animal repellent
GH-516
ABS Plastic
Solar or USB cable (included)
4.V, 55mA // Polysilicon 50*50mm
3.7V/60mA // DC 5V 500mah
3.7V, 2000mAh, 18650 Lithium Battery
IP44
6-8meters (depends on environment, temperature)
220°// 2-side PIR Sensors
90-110dB
Red light - Working
Blue light - Charging
Light off - fully charged
9-45.5kHz
6pcs // Only light up when working at night mode//
When LED lights working, the light blinks slowly for 5 seconds,
then blinks fast for 10 seconds(work cycle two times, in total 30s)
