Summary of Contents for Brightline 6060
- Page 1 Low-Voltage DMX Control OPERATION GUIDE Specifications are subject to change without notice. ©2023 Brightline LP All Rights Reserved.
-
Page 2: Owner's Record
The 6060 Power Driver ships configured for field operation. • If there is more than one 6060 Power Driver within the system, the installer will need to set the DMX starting address on the additional 6060 Power Drivers (see page 3). -
Page 3: Operating Mode
Overview Operating Mode Each 6060 Power Driver is configured to the required operating mode. If there is more than one 6060 Power Driver refer to DMX addressing information below. A separate 6060 Power Driver is required for each fixture type in the installation. If the device is inadvertently reset to factory settings, call Tech Support at 1-412-206-0106 ex.113 or email... -
Page 4: System Integration
To connect the CTRL-WS-LV-SR516 to the 6060 Power Driver, run the RJ45 to bare lead cable from the wall station to the DMX IN port on the back of the 6060 Power Driver, or to a DMX gateway networking device for integration with other controls. - Page 5 3. Feed wire through the strain relief and insert into the wire nut. 4. Homerun wiring back to the 6060 Power Driver and insert into the provided Phoenix connectors. Distribute load evenly over positions for best heat management. (2 positions will remain unused in a device with maximum fixture modules.)
- Page 6 3. Feed wire through the strain relief and insert into the wire nut. 4. Homerun the bundle back to the 6060 Power Driver and insert into the provided Phoenix connectors. Ensure that all 3 runs for a fixture are connected to a single port for accurate control.
- Page 7 2. At the fixture connect the circular connector. 3. Homerun the bundle back to the 6060 Power Driver and insert into the provided Phoenix connectors. Ensure that all 4 pairs for a fixture are connected to a single port for accurate control.
- Page 8 3. Feed wire through the strain relief and insert into the wire nut. 4. Homerun the wiring back to the 6060 Power Driver and insert into the provided Phoenix connectors. Ensure that both runs for a fixture are connected to a single port for accurate control.
- Page 9 3. Feed wire through the strain relief and insert into the wire nut. 4. Homerun the wiring to the 6060 Power Driver and insert into the provided Phoenix connectors. 5. Once wiring is seated in the Phoenix connectors, insert into each port.
- Page 10 3. Feed wire through the strain relief and insert into the wire nut. 4. Homerun the wiring to the 6060 Power Driver and insert into the provided Phoenix connectors. 5. Once wiring is seated in the Phoenix connectors, insert into each port.
-
Page 11: Warranty
If any product is found to be unsatisfactory under this warranty, the buyer must notify Brightline immediately. Once a course of action has been determined, if it is necessary to return the product to Brightline a Return Authorization (RA) will be issued. Ship the product directly to Brightline, 580 Mayer Street, Building #7, Bridgeville, PA 15017, USA.
