- Page 1 DTPA-UART-0808S Test board Manual ※ support model: DTPA-UART-0808S 1. Features • • • • • • • • • • • • • • • 1 2. Requirements • • • • • • • • • • • • • • 1 3.
- Page 2 DIWELL Electronics Co., Ltd. The DTPA-UART-0808S is an industrial-grade infrared array thermometer that is fully calibrated with 8x8 pixels. It contains 64 IR pixels and supports UART interface. With the provided Test Board, it is easy to connect and measure temperature without the need for additional circuitry. Please refer to the datasheet for more detailed information.
- Page 3 High Alarm setting range: 32°C … 200°C Low Alarm setting range: -20°C … 30°C It is possible to turn off the alarm or mute the sound manually. < background color : Red > DTPA-UART-0808S Test board Manual 2 / 3 V.1.0.1...
- Page 4 ※ Avoid exposing the product to direct sunlight, chemicals, heat, or fire. ※ This product is not water-resistant. ※ Do not remove the sensor during communication. Additional information Manufacturer: DIWELL Electronics Co., Ltd. (South Korea) Technical support: mailto:expoeb2@diwell.com, mailto:dsjeong@diwell.com Revision history...
