- Page 1 INSTRUCTION MANUAL HIGH PRESSURE COMPRESSOR AKHL1320E(UK) BEFORE USING THIS COMPRESSOR, STUDY THIS MANUAL TO ENSURE SAFETY WARNING AND INSTRUCTIONS. KEEP THESE INSTRUCTIONS WITH THE TOOL FOR WARNING FUTURE REFERENCE.
- Page 2 DEFINITIONS OF SIGNAL WORDS WARNING: Indicates a potentially hazardous situation which, if not avoided, could result in death or serious injury. CAUTION: Indicates a potentially hazardous situation which, if not avoided, may result in minor or moderate injury. NOTE: Emphasizes essential information.
- Page 3 Fig.A/Abb.A Fig.B/Abb.B...
- Page 4 Fig.C/Abb.C Fig.D/Abb.D Fig.E/Abb.E Fig.F/Abb.F Fig.G/Abb.G Fig.H/Abb.H Fig.I/Abb.I Fig.J/Abb.J Fig.K/Abb.K Fig.L/Abb.L...
- Page 5 Fig.N/Abb.N Fig.O/Abb.O Fig.M/Abb.M Fig.P/Abb.P Fig.Q/Abb.Q Fig.R/Abb.R Fig.S/Abb.S Fig.T/Abb.T Fig.U/Abb.U Fig.V/Abb.V Fig.W/Abb.W Fig.X/Abb.X...
-
Page 7: Table Of Contents
ENGLISH ORIGINAL INSTRUCTION INSTRUCTION MANUAL INDEX 1. SYMBOLS ................7 2. SAFETY INSTRUCTIONS ..........8 3. SPECIFICATIONS ............12 4. INSTRUCTIONS FOR OPERATION ........ 14 5. PROTECTIVE DEVICE............. 20 6. ABNORMALITIES DURING OPERATION....... 20 7. BUZZER TYPES............... 21 8. HOW TO INSTALL OPTIONAL 1320E TANK ....22 9. -
Page 8: Safety Instructions
In observance of European Directive 2012/19/EU DO NOT USE IN THE RAIN on waste electrical and electronic equipment and Using the compressor in these its implementation in accordance with national or similar conditions will in- law, electric equipment that have reached the end crease the risk of electric of their life must be collected separately and re- shock, dangerous malfunction,... - Page 9 SURE AIR. FOR USAGE OF HIGH PRESSURE AIR, HIGH PRESSURE COMPRESSOR IS DE- 8. KEEP WORK AREA CLEAN AND WELL LIT SIGNED ONLY FOR MAX POWERLITE NAILERS Keep work area clean and well lit. Cluttered or AND POWERLITE HOSE. UNSPECIFIED USAGE dark areas invite accidents.
- Page 10 Tab.1 SECTION VALID FOR A MAX LENGTH OF 20m COMPRESSOR VOLTAGE MINIMUM GAUGE AKHL1320E (UK) a.c. 110V 2.5mm 19. KEEP HANDLES DRY, CLEAN AND FREE WARNING FROM OIL AND GREASE Avoid electrical shock hazard. Never use this Slippery handles do not allow for safe handling compressor with a damaged or frayed electrical of the compressor in unexpected situations.
- Page 11 31. WHENEVER USING THE HIGH PRESSURE pressor grips with both SIDE OF THE MAX POWERLITE COMPRES- hands. SOR, THE GENUINE PARTS FOR THE MAX POWERLITE TOOLS, POWERLITE HOSE MUST BE USED. • With the optional 32. NEVER USE A TRANSFORMER FOR THE AKTH15 air tank: POWER SUPPLY OF THIS COMPRESSOR.
-
Page 12: Specifications
AKTH15: Hold the air tank grips. 41. DO NOT USE ANY ADAPTER PLUGS (See Fig.X) WITH THE COMPRESSOR The compressor is factory-equipped with a specific electric cord and plug for connection to a proper electric power source. Never modify the plug in any way. Do not use any adapter plugs with the compressor. - Page 13 Product No. AKHL1320E (UK) + AKTH15 573mm Dimensions 425mm 496mm Weight 26.4Kg Power supply a.c.110V±10% 50Hz±1% Ø1 Rated current Tank capacity 5.0L×5 Motor power Class Ι Protective earthing Protective structure IP20 Working temperature 0°C to +40°C Working humidity 85%RH or less. No dew condensation. Height above sea level UP to 1000m Storage temperature...
-
Page 14: Instructions For Operation
4. INSTRUCTIONS FOR OP- 3. CHECK WITH A QUALIFIED ELECTRICIAN OR SERVICEMAN WHEN THE GROUND- ERATION ING INSTRUCTIONS ARE NOT COM- PLETELY UNDERSTOOD, OR WHEN IN Unpack the compressor and check for any defi- DOUBT AS TO WHETHER THE PRODUCT ciency, damage caused during transportation IS PROPERLY GROUNDED. - Page 15 4. NEVER USE THE MACHINE IN AN UNSTABLE PLACE. Never use it in a place where it could move or fall of itself. Be sure to install the compressor on a flat floor, with leg rubber underneath it; the al- lowable tilt angle of the floor is up to 10 de- grees.
- Page 16 (HIGH). (24.5 bar maximum) 6 Pressure gauge (REGULAR) It indicates the set pressure on the pressure-reduction valves (REGULAR). (8.3 bar maximum) 7 High pressure air chuck (for MAX It connects the MAX air hose for the tools. tools) 8 Regular pressure air chuck (for It connects the air hose for the regular pressure nailers.
- Page 17 Control Panel (See Fig.B) jPOWER LED kTEMPERATURE OR ELECTRICAL PROBLEM LED See the buzzer types in Chapter 7. (See page 21) lSERVICE REQUIRED LED If it is lit up, it is due to a failure on the inverter or motor. Send the machine to your dealer or authorized service facility to have their checkup or repair.
- Page 18 4. MACHINE OPERATING PROCE- 5. Turn the adjustment handle (in 2 loca- DURE tions) of the pressure-reduction valve ful- ly clockwise until you cannot move it anymore and make sure that the above Inspection and checkup prior to oper- operation moves the pressure gauge ation pointer (Fig.F) at both locations.
- Page 19 4. Connect the high pressure hose to the turn the adjustment handle of the pres- high pressure air hose for MAX PowerLite sure-reduction valve to adjust the operat- tools to the high pressure air chuck on...
-
Page 20: Protective Device
5. PROTECTIVE DEVICE 1. The following problems may occur even when there are no problems with the If internal heat builds up during operation due to power supply or wiring: (See "PROTEC- TIVE DEVICE" on page 20.) clogging of the airflow orifice, if the machine is •... -
Page 21: Buzzer Types
7. BUZZER TYPES In normal operation Buzzer sounds Symptom Actions taken At powering on A one-time short beep sound (Pi) When the quiet mode is switched In cases of abnormal operation Buzzer sounds Cause Actions taken LAMP Power supply is over 138V or Examine the state of the None below 90V... -
Page 22: How To Install Optional 1320E Tank
8. HOW TO INSTALL OPTION- 2. (Fig.D) Open the drain cock of the com- pressor and optional air tank and drain AL 1320E TANK compressed air from the tank. 3. (Fig.V) Disconnect the connector of the flexible pipe from the air chuck 44K. Turn WARNING the sleeve of the air chuck 44K counter- clockwise , and push the sleeve to remove... -
Page 23: In Order To Maintain Performance
If the circuit breaker trips, the power supply 7. ABOUT PRODUCTION YEAR AND MONTH switch of the compressor moves to the OFF This product bears production number in the position. RATING LABEL. The three digits of the Stop using other power tools on the same pow- number from left indicates the production er source as the compressor. - Page 24 AKHL1320E(UK) EXPLODED VIEW AND SPARE PARTS LIST 34 35 48 49 77 78 78 79...
- Page 25 AKHL1320E (UK) AKHL1320E (UK) ITEM PART ITEM PART MATERIAL ENGLISH MATERIAL ENGLISH AK70845 PP, PET, ABS, Steel COVER 1320 ASSY(UK) BB40837 Steel BOLT 8×70 AK16226 GATE LABEL(1320CE) AK16114 FLEXIBLE PIPE 1310 AK16176 BRAND PLATE RED AA32802 Steel SCREW 5×20 CC41103 Steel HEX NUT 1-4 AK14674...
- Page 26 AKHL1320E (UK) ITEM PART MATERIAL ENGLISH INVERTER UNIT(1320E/ AK81428 USA) AK16130 Aluminium UNDER COVER 1310A AK16129 CORNER PROTECTOR 1310 AK16127 Rubber RUBBER FOOT 1310 RUBBER FOOT COLLAR AK16128 Aluminium 1310 PLANE WASHER EE39193 Steel 6.2X18X1.6 AA32803 Steel S-TITE SCREW 5×25 SPECIFICATION AK16244 LABEL(1320E/UK)
- Page 27 Noise Emission in the Environment by Equipment for Use Outdoors Directive 2000/14/EC Body: TÜV Rheinland LGA Products GmbH Tillystraße 2, 90431, Nürnberg, Germany Title: Senior Manager Environment & Quality Assurance Department Being the responsible person appointed by the manufacturer and employed by MAX CO., LTD. 161209...
- Page 28 6-6 NIHONBASHI HAKOZAKI-CHO, Antennestraat 45 CHUO-KU, TOKYO, JAPAN 1322 AH, Almere, The Netherlands POST CODE 103-8502 Phone: +31-36-546-9669 TEL: (03) 3669-8131 FAX: +31-36-536-3985 FAX: (03) 3669-7104 wis.max-ltd.co.jp/int/ (GLOBAL Site) www.max-europe.com (EUROPE Site) 4103663 231226-00/ 02 PRINTED IN JAPAN...
