Item #201837
Model #UMB-921131
USE AND CARE GUIDE
NEW 8.5' SQUARE OFFSET UMBRELLA WITH BASE
I
Questions, problems, missing parts?
Before returning to the store, call Customer Service
8 a.m. - 7 p.m., EST, Monday - Friday, 9 a.m. - 6 p.m., EST, Saturday
1-800-00-4663-3
IMPORTER: SERVICIOS HOME DEPOT, S. DE R.L. DE C.V.
HOMEDEPOT.COM.MX
Ricardo Margain 605 Santa Engracia, San Pedro
Garza García, Nuevo León, México C.P. 66267
Tel. 01-800-00-4663-3
THANK YOU
We appreciate the trust and con dence youi have placed in StyleWell through the purchase of this umbrella. We strive to continually create quality
products designed to enhance your home. Visit us online to see our full line of products available for your home improvement needs. Thank you
for choosing StyleWell!
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for StyleWell NEW UMB-921131
Summary of Contents for StyleWell NEW UMB-921131
- Page 1 THANK YOU We appreciate the trust and con dence youi have placed in StyleWell through the purchase of this umbrella. We strive to continually create quality products designed to enhance your home. Visit us online to see our full line of products available for your home improvement needs. Thank you...
-
Page 2: Warnings And Cautions
Table of Contents Warnings and Cautions ......2 Umbrella Assembly ....... . Operation. -
Page 3: Pre-Installation
Pre-Installation PLANNING INSTALLATION Before beginning the assembly of this product, make sure all parts are present. Compare parts with the Package Contents and the Hardware Included lists. If any part is missing or damaged, do not attempt to assemble the product, and return it to the place of purchase. NOTE: Hardware not shown to actual size. -
Page 4: Package Contents
Pre-Installation (continued) PACKAGE CONTENTS Part Description Quantity Outer Base Components Inner Base Components Lower Cross Leg Upper Cross Leg Holder Pole w/ Control Knobs Pole Support Cup 360° Swivel Foot Pedal for 360° Swivel Base Cap Umbrella Frame with Canopy Umbrella Cover... - Page 5 Umbrella Assembly Attaching the 360 Swivel to the Cross Legs and Holder Pole Attach the Foot Pedal (H) to the 360°swivel (G) by Screw M5 (AA) and Hex Wrench M5 (DD). Place Upper Cross Leg (D) over Lower Cross Leg (C) to be “X”...
- Page 6 Umbrella Assembly (continued) Lay base components (A&B) on top of cross legs to be Putting Base Components to the rectangular base. Then insert Pole Support Cup (F) into Cross Legs Holder Pole (E) as below drawings. Unscrew Base Caps (M) from each Base Components (A&B) and fill with sand or water no less than 150lbs.
-
Page 7: Operation
Umbrella Assembly (continued) Inserting Umbrella Frame into Holder Pole and Finishing Assembly Insert Umbrella Frame (N) into Holder Pole (E) and tighten control knobs to secure the umbrella in place. Now the umbrella is ready to use. Please unfasten storage straps (V) before use. Offset Assembly (continued) Operation To open umbrella, pull out Lever Clamp (Q) to release Glide Handle (R). - Page 8 Offset Assembly (continued) Operation (continued) To swivel umbrella, step on the footrest. Turn the umbrella pole around its axis to move the canopy over desired area. To store umbrella, rst, fasten storage straps before putting Umbrella Cover (P) on. Then st on the umbrella base, hold the rib of the Umbrella Cover (P), and cover whole umbrella frame.
-
Page 9: Care And Maintenance
Care and Maintenance Use mild soap and warm water to clean the canopy. Rinse with clean water and dry thoroughly. Do not machine wash. Do not iron. Air dry the canopy thoroughly before storing for extended periods of time. Make sure the canopy is completely open during drying process to prevent shrinkage. - Page 10 Questions, problems, missing parts? Before returning to the store, call StyleWell Customer Service 8 a.m. - 7 p.m., EST, Monday - Friday, 9 a.m. - 6 p.m., EST, Saturday 1-800-00-4663-3 HOMEDEPOT.COM.MX Retain this manual for future use.
