the
excelPTZ
range
Installation and Operation Manual
Serial Data Distributors 2 RS485 In ~ 4/8/16 Out
Models covered
PTZ740
PTZ742
PTZ744
PTZ740 2x RS485 IN 4 OUT
PTZ742 2xRS485 IN 8 OUT
PTZ744 2xRS485 IN 16 OUT
Version 1
For updates to these instructions visit
www.excelPTZ.com
Advertisement
Summary of Contents for excelPTZ PTZ740
- Page 1 Installation and Operation Manual Serial Data Distributors 2 RS485 In ~ 4/8/16 Out Models covered PTZ740 PTZ742 PTZ744 PTZ740 2x RS485 IN 4 OUT PTZ742 2xRS485 IN 8 OUT PTZ744 2xRS485 IN 16 OUT Version 1 For updates to these instructions visit www.excelPTZ.com...
- Page 2 1. Please read the operation manual carefully before installing and operating the product. 2. The PTZ740, PTZ742 and PTZ744 Serial Data Distributors require a 12v DC power supply. A power supply and lead with a 13amp plug is supplied with each unit.
- Page 3 PTZ740 The PTZ740 has two RS485 inputs A and B. Ensure that the correct polarity is connected to the DVR and/or keypad. An RS232 input is also provided at C. Plug the 12vDC power supply into D. Up to four PTZs can be connected to 1 ~ 4 on CAT5. Ensure you use a matched twisted pair.
- Page 4 PTZ. The maximum connection range is 1200 meters using a UTP twisted pair for each PTZ. You can connect to further units of PTZ742 and PTZ744. Note that only one input operates at a time. Model PTZ740 PTZ742 PTZ744 Data Input...
