What's Included
PREPARATION FOR USE
1. Controls and Indicators
Button (Volume Up / Skip Forward)
1
2
Button (Volume Down / Skip Back)
Power/Pairing/Charging LED Indicators
3
Power/Play/Pause Button
4
USB Charging Port
5
AUX Jack
6
Microphone
7
2. Charging Your Headphones
Make sure to charge the battery before using the headphones for the
first time.
Connect the included USB charging cable to a powered USB port or a
USB/AC adapter, and then connect the smaller plug to the USB
charging port on the headphones. The Charging Indicator will glow red
while the headphones are charging, and will turn off when fully charged.
When fully charged the battery should provide up to 24 hours of use.
NOTE: While charging, the headphone power will turn off to conserve
battery power.
OPERATING INSTRUCTIONS
1. First Time Power On: Auto Pairing
PRESS and HOLD the Power/Play/Pause Button on the right earcup for about 3 seconds until the LED flashes. The first time the headphones are
powered on they will enter auto-pairing mode, indicated by flashing red and blue LEDs.
a) Make sure Bluetooth is enabled on your device (check in Settings or Options).
b) "ekids B52" will apear on your device's Bluetooth menu.
c) Select "ekids B52" to complete pairing. NOTE: If your Bluetooth device asks for a Password or a PIN, enter "0000" on the keypad of your device.
2. Manually Pairing Your Headphones With Your Bluetooth Device
With the headphones in 'Off' mode, PRESS and HOLD the Power/Play/Pause Button on the right earcup for about 7 seconds, the LEDs will flash red
and blue. Release the Power/Play/Pause Button. Follow the a-c pairing instructions in Step 1 above to complete pairing.
Function
Turn headphones On
Increase volume
Decrease volume
Answer an incoming phone call
End a call
Transfer a call between the
phone and the headphones
Last number redial
Siri/Google Assistant
Reset Bluetooth/Clear all paired devices
Turn headphones Off
This product bears the selective sorting symbol for waste electrical and electronic equipment (WEEE).
This means that this product must be handled pursuant to European Directive 2012/19/EU in order to be recycled or dismantled to minimize its impact
on the environment.
For further information, please contact your local or regional authorities.
Electronic products not included in the selective sorting process are potentially dangerous for the environment and human health due to the presence of
hazardous substances.
For environmental reasons, electrical equipment must be disposed of separately from household waste. Contact the municipality for the nearest collection point.
We, KIDdesigns, declare that this device complies with the essential requirements of the RED Directive 2014/53/EU.
Operation frequency range: 2.402-2.480GHZ
RF output power: 6.5dBm
EU Authorized Representative: BMD – 3 Boulevard des Bretonnieres, 49124 St Barthelemy d'Anjou, France
WIRELESS HEADPHONES
Action Required
When headphones are 'Off', press and hold the Power/Play/Pause Button for 3 seconds until the LED indicator flashes blue.
Press the
button during playback (hold for rapid setting)
Press the
button during playback (hold for rapid setting)
Short press the Power/Play/Pause Button when you hear the incoming ring sound.
NOTE: Music will automatically pause when you are answering a call and resume when you end the call.
Short press the Power/Play/Pause Button to end the call and 'hang up'.
While the call is in progress, press and hold the Power/Play/Pause Button for 2 seconds.
When no call is in progress, double press Power/Play/Pause button to redial the last number.
Press and hold the Power/Play/Pause button for 2-3 seconds.
Press and hold the
for 5 seconds during pairing mode.
Press and hold Power/Play/Pause button for 5 seconds until the LED indicator turns red and then shuts off. Headphones will shut off automatically
if no music plays for 60 minutes.
USB Charging Cable
Detachable Audio Cable*
(*select models only)
1
2
3
4
5
Computer connected
to working outlet
Model: B52 Series
CHARGE BEFORE USE
Use the AUX jack to listen to music on any device
with a 3.5mm headphone jack. Connect the
included audio cable to the AUX jack on your
headphones, and to the headphone jack of your
auxiliary music source. Your headphones should be
in the Power "Off" mode.
6
7
Computer
USB port
OR
USB Adaptor
(not included)
ENG
