Summary of Contents for Lumisys L35 Series
- Page 1 Lumisys L35 Series 1800 Sandy Plains Industrial Park • Suite 216 B • Marietta, GA • 800-241-9173 • www.Lumisys.com...
- Page 2 Lumisys Lighting and its affiliates assume no responsibility for any consequences related to the improper use of this manual. www.Lumisys.com Page 2 Due to continuous product improvement, Lumisys reserves the right to change product specifications without notice.
-
Page 3: Table Of Contents
Installing the Switch Input Expansion Board ......................24 Connecting Expansion Board Switch Inputs ......................27 Installing Digi-Touch Module (DDN-L35) ......................28 Terms and Conditions of Sale ...........................30 www.Lumisys.com Page 3 Due to continuous product improvement, Lumisys reserves the right to change product specifications without notice. -
Page 4: L35 Series
(16) are shipped in a separate carton as spares. Lumisys recommends one spare relay be ordered with each panel. Spare Lumisys LTR relays: 2 www.Lumisys.com Page 4 Due to continuous product improvement, Lumisys reserves the right to change product specifications without notice. -
Page 5: Parts List - Unassembled "Can Ahead" Method
Interior and Trim in the future to fill these spaces as Ships First Ship later facility applications arise. for “rough in” customer specified date www.Lumisys.com Page 5 Due to continuous product improvement, Lumisys reserves the right to change product specifications without notice. -
Page 6: Parts List - Additional Accessories - Lexp-35
Panel with no Requires L3532 relay Requires L3548 Requires L3560 Requires L3548 panel relay panel relay panel LEXP relay panel minimum. minimum. minimum. minimum. www.Lumisys.com Page 6 Due to continuous product improvement, Lumisys reserves the right to change product specifications without notice. -
Page 7: Parts List - Additional Accessories - Ldiv35
L35 Series Parts List - Additional Accessories - LDIV35 The Lumisys LDIV35 is a high voltage compartment divider for L35 Series Lighting Panels that provides the capability to separate normal and emergency circuits within the unit’s high voltage compartment. The LDIV mounts in a single relay position, reducing the overall panel capacity by one (1) relay. -
Page 8: Overview
The L35 Series comes in four basic units based upon relay capacities: L3516, L3532, L3548 and the L3560. Each unit may contain up to the number of relays indicated. Enclosure sizes for each of the four units will vary. Refer to the L35 Series Data Sheet for more information. -
Page 9: Wiring Applications
2-wire EIA-485 on Port S2 Example Lighting Network Devices Lumisys L28 Series Qwik-Kit LD200DIM L35 Series Lighting Panel Dimming Integration Lighting Panel Module www.Lumisys.com Page 9 Due to continuous product improvement, Lumisys reserves the right to change product specifications without notice. -
Page 10: Bacnet Ip
2-wire EIA-485 on Port S2 Example Lighting Network Devices Lumisys L28 Series Qwik-Kit LD200DIM Lighting Panel L35 Series Dimming Integration Lighting Panel Module www.Lumisys.com Page 10 Due to continuous product improvement, Lumisys reserves the right to change product specifications without notice. -
Page 11: Bacnet Over Ms/Tp
2-wire EIA-485 on Port S2 Example Lighting Network Devices Lumisys L28 Series Qwik-Kit LD200DIM Lighting Panel L35 Series Dimming Integration Lighting Panel Module www.Lumisys.com Page 11 Due to continuous product improvement, Lumisys reserves the right to change product specifications without notice. -
Page 12: Modbus Rtu
2-wire EIA-485 on Port S2 Example Lighting Network Devices Lumisys L28 Series Qwik-Kit LD200DIM Lighting Panel L35 Series Dimming Integration Lighting Panel Module www.Lumisys.com Page 12 Due to continuous product improvement, Lumisys reserves the right to change product specifications without notice. -
Page 13: N2 / Metasys
Lumisys 2-wire EIA-485 Network Example Lighting Network Devices Lumisys L28 Series Qwik-Kit LD200DIM Lighting Panel L35 Series Dimming Integration Lighting Panel Module www.Lumisys.com Page 13 Due to continuous product improvement, Lumisys reserves the right to change product specifications without notice. -
Page 14: Installation
If flush mounting, secure the enclosure between the wall studs. Be sure to allow for the thickness of the drywall and 7/8” for the overhang of the cover so that the panel’s cover will mount flush on the finished wall and away from adjacent panels. www.Lumisys.com Page 14 Due to continuous product improvement, Lumisys reserves the right to change product specifications without notice. -
Page 15: Connecting The Power Supply
Connecting the Power Supply The L35 Series can be powered by either 120 or 277VAC. A fuse and dual primary transformer are utilized to offer maximum flex- ibility during installation. This factory mounted transformer powers the L35 Series controller and associated low voltage coils on the contactors (relays). -
Page 16: Connecting The Power Supply
Yellow Brown - 277V Fuse Replace with 1.0A Select either 120 or 277V to HOT Slow Blow Fuse Only! Black - HOT www.Lumisys.com Page 16 Due to continuous product improvement, Lumisys reserves the right to change product specifications without notice. -
Page 17: Connecting Branch Circuit Wires
Installation Guide Connecting Branch Circuit Wires The L35 Series panel is equipped with contactors capable of switching up to 20 amperes at 277 VAC (Canadian versions, 347VAC). Each contactor can be easily assigned to any of the unit’s zones. Refer to the “Lighting Relay Panel Controller User’s... - Page 18 Fuse or Breaker Lighting Load L35 Series LTR Relay Lighting Load L35 Series LTR Relay Fuse or Breaker Neutral (size per N.E.C.) www.Lumisys.com Page 18 Due to continuous product improvement, Lumisys reserves the right to change product specifications without notice.
-
Page 19: Connecting Switch Inputs
Connecting Switch Inputs The L35 Series Controller comes standard with 24 programmable switch input capacity. The 24 termination points are divided into three sections of eight, with each section containing one ground point ( all three grounds are common ). All points are numbered, and ground points are labeled “G”. - Page 20 Assigned zone is activated during contact open*. Collector (NPN Darlington Output) Emitter (“-” on power source) *Switch defined as normally open polarity in software. www.Lumisys.com Page 20 Due to continuous product improvement, Lumisys reserves the right to change product specifications without notice.
-
Page 21: Connecting Lumisys Ls5 Photocell Inputs
L35 Series Installation Guide Connecting Lumisys LS5 Photocell Inputs The L35 Series Controller comes with one input for the LS5 Series Photocells. Each LS5 photocell ships with one pigtail wiring harness. The contents as shipped are shown in Figure 12. The LS5 photocells have three (3) wires each. -
Page 22: Connecting The Rs-485 Network
Connecting the RS-485 Network The L35 Series is capable of being networked to a Building Automation System or Lumisys’s BASnet LightView over a two or three wire RS-485 communication network. A terminal block is provided to connect the two communication wires plus the shield wire. -
Page 23: Adding And Removing Ltr Relays
See Figure 5. Install branch circuit wires. Refer to “Connecting Branch Circuit Wires” Coil Pin of this installation guide. www.Lumisys.com Page 23 Due to continuous product improvement, Lumisys reserves the right to change product specifications without notice. -
Page 24: Upgrading The L35 Series
Lumisys’s LEXP Switch Input Expansion Module enables 32 additional low voltage switch inputs. Up to three (3) LEXP modules can be installed with the L35 Series depending on the L35 Series relay capacity. Refer to Table 2 below to determine the number of LEXP modules that can be installed in your L35 Series. - Page 25 Series. The letters denote the range of switch inputs that will connect to each board. Board A interfaces inputs 25-56; Board B, 57-88; Board C, 89-120. The LEXP ships with a mounting plate. The LEXP mounts into the L35 Series with four screws. Mounting holes in the L35 Series are located on mounting brackets of the interior between all relays. Use...
- Page 26 Ribbon Cable connection to the LEXP 2 which receives inputs 57-88. 57 - 72 Ribbon cable end plugged into “EXPANSION INPUTS” socket. www.Lumisys.com Page 26 Due to continuous product improvement, Lumisys reserves the right to change product specifications without notice.
-
Page 27: Connecting Expansion Board Switch Inputs
J5 (with positions A and B) and J6 (positions C and D). The L35 Series can accept up to 120 programmable switch inputs, comprised of 24 from the controller and 3 X 32 from expansion boards. -
Page 28: Installing Digi-Touch Module (Ddn-L35)
Installation Guide Installing Digi-Touch Module (DDN-L35) The DDN Module for the L35 Series (Cat# DDN-L35) mounts to the back side the hinged plate upon which the LMB is mounted. Figure 29 for its location. The DDN module communicates with the LMB through a ribbon cable, and it receives its power from the LMB through a 2-wire connection. - Page 29 DDN module. Power harness from transformer. DDN-L35 power wire connection from Power connection on DDN Module. the LMB. www.Lumisys.com Page 29 Due to continuous product improvement, Lumisys reserves the right to change product specifications without notice.
-
Page 30: Terms And Conditions Of Sale
Terms and Conditions of Sale AGREEMENT OF SALE: Acceptance by Lumisys, (hereinafter “Seller”) of any order, placed for the goods described on the Acknowledgment, Invoice or Sales Contract hereof shall be subject to Seller’s Standard Terms and Conditions of Sale and is conditioned upon the Buyer’s acceptance of these Standard Terms and Conditions of sale as stated on this Sales Contract.
