Summary of Contents for MARXON G300
- Page 1 User Manual G300 Portable Power Station G300 www.marxon.net...
- Page 3 User Manual, the company("Marxon") is not liable for any damages caused. In compliance with laws and regulations, Marxon holds the final explanation right of this document and all related documents of the product. For the latest product information, please visit Marxon's official website at www.marxon.net.
-
Page 5: Table Of Contents
CONTENTS 1. Safety Instruction 1.1. Usage Guide 1.2. Disposal Guide 2. Specifications 3. Getting Started 3.1. Product Details 3.2. LCD Screen 3.3. Power On/Off 3.4. Product Output Guide 3.4.1. AC Output 3.4.2. USB Output 3.4.3. 12V DC Output 3.5. Product Input Guide 3.5.1. -
Page 6: Safety Instruction
Do not use unofficial components or accessories. If you need to replace any components or ccessories, please contact support@marxon.net to get further help from the official professionals. Do not lock the fan forcibly during use or place the product in an unventilated or dusty area. -
Page 7: Disposal Guide
During thunderstorms or stormy weather, please disconnect the AC charging or solar charging. If the product is struck by lightning, it may cause electric shock, fire, and other accidents. Ensure that the product is kept out of reach of children and pets. 1.2Disposal Guide If conditions permit, make sure that the battery is fully discharged before disposing of it in a designated battery recycling bin. -
Page 8: Specifications
2. Specifications General Information Cell Chemistry Lithium-ion Cell Cycle Life 800 Cycles to 80%+ Capacity Capacity 25.2V 12AH (300Wh) Dimensions 271*179*232mm Net Weight Approximately 12.12lbs (5.5Kg) Certification FCC, UL Protection Over Voltage Protection, Overload Protection, Over Temperature Protection, Short Circuit Protection, Low Temperature Protection, Low Voltage Protection, Overcurrent Protection, Overcharge Protection, Over-discharge Protection... -
Page 9: Getting Started
3. Getting Started 3.1Product Details LCD Screen 12V DC Lighting Output Port DC Output Button Lighting Button Type-C Port USB-A Ports Main Power Button G300 Front Cooling Fan Cooling Fan AC Output Anderson Button Input Port AC Output AC Input Ports Port... -
Page 10: Lcd Screen
Low Temperature Warning 3.3Power On/Off G300 Press & Hold Main Power Button for 2 Seconds Press and hold the Main Power Button for 2 seconds to turn the product on or off. After the power is on, short press the Main Power Button to turn the screen on or off. -
Page 11: Product Output Guide
3.4Product Output Guide 3.4Product Output Guide Make sure the main power is turned on before using the product. 3.4.1AC Output Short press the AC Output Power Button to turn the AC output on, short press AC Output Power Button again to turn it off. The screen will display the AC output indicator and the current output power. -
Page 12: Usb Output
DC output is enabled. Note: Excess rated current of the devices may trigger overcurrent protection of the product and it will stop the DC output. G300 Short Press DC Output Button 12VDC... -
Page 13: Product Input Guide
AC Input Indicator Please use the official Marxon cable for AC charging. Directly plug the product through an AC cable into the wall outlet that supports a current over 10A. Marxon is not responsible for any damage caused by using unofficial... -
Page 14: Solar Charging
3.5.2Solar Charging Note: This product comes with a built-in 120W MPPT. Do not use solar panels with extra MPPT. Marxon is not responsible for any damage caused by the use of unofficial charging cables and the use of non-standard operating methods. -
Page 15: Car Charging
3.5.3Car Charging Users can charge the product through the cigarette lighter interface on the car. Be sure to ignite the vehicle before using the car charger in case the car battery loses power and will not start. Meanwhile, users should check the 12V Anderson Input Port, car charging cable, and cigarette lighter for good contact. -
Page 16: Troubleshooting
Battery Failure Contact Marxon Support Team. After discharging the power station until System Halted the battery is drained, charge the product No response after pressing the and restart it. - Page 17 Indicator/Content Problem Solution USB-A output will be resumed automatically after you remove the overloaded device and USB-A Overload USB-A Output Failure restart the product. Protection Do not use electrical appliances that exceed the rated power of the product. USB-C output will be resumed automatically after you remove the overloaded device and USB-C Overload USB-C Output Failure...
-
Page 18: Faqs
5. FAQs What devices can the product’s AC output port power? With 300W rated power and 600W peak power, the product’s AC output port can power most household appliances. Before you use it, we recommend that you confirm the power of the appliances first and ensure the power sum of all loaded appliances is lower than the rated power. -
Page 19: What's In The Box
7. What’s in the Box G300 AC Charging Cable x 1 Car Charging Cable x 1 Marxon G300 x 1 User Manual x 1... - Page 20 Scan the QR Code to Learn More About Us. www.marxon.net...
