DGSI 92600099 Quick Start Manual

Resistance temperature sensor

Advertisement

This equipment should be installed, maintained, and operated by technically qualified personnel. Any errors
or omissions in data, or the interpretation of data, are not the responsibility of Durham Geo-Enterprises Inc.
The information herein is subject to change without notification.
This document contains information that is proprietary to Durham Geo-Enterprises Inc., and is subject to
return upon request. It is transmitted for the sole purpose of aiding the transaction of business between
Durham Geo-Enterprises Inc., and the recipient. All information, data, designs, and drawings contained
herein are propri-etary to and the property of Durham Geo-Enterprises Inc., and may not be reproduced or
copied in any form, by photocopy or any other means, including disclosure to outside parties, directly or
indirectly, without permission in writing from Durham Geo-Enterprises Inc.
DGSI
4561 Greer Circle, Suite 100
Tucker, Georgia 30083
Tel: 770-465-7557
Website: www.durhamgeo.com
Resistance
Temperature Sensor
92600099
Copyright ©2023 Durham Geo-Enterprises, Inc.. All Rights Reserved.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 92600099 and is the answer not in the manual?

Questions and answers

Summary of Contents for DGSI 92600099

  • Page 1 Resistance Temperature Sensor 92600099 Copyright ©2023 Durham Geo-Enterprises, Inc.. All Rights Reserved. This equipment should be installed, maintained, and operated by technically qualified personnel. Any errors or omissions in data, or the interpretation of data, are not the responsibility of Durham Geo-Enterprises Inc.
  • Page 2 Contents Introduction ..... . . 1 Installation Suggestions ... . 2 Taking Readings.
  • Page 3: Introduction

    Introduction Applications Resistance temperature sensors are used to monitor the heat of hydration in mass concrete. Operation The temperature sensor consists of a stainless steel body, an RTD or thermistor inside the body, and a signal cable. The resistance of the RTD or thermistor varies with temperature. The readout unit or data logger converts the resistance reading to degrees C Resistance Temperature Sensor, 2004/11/18...
  • Page 4: Installation Suggestions

    Installation Suggestions • Sensor When a temperature sensor is mounted in a particularly vulnerable position, consider spraying the area with marker paint, covering the gauge with a protective wire mesh, or placing some non-structural steel to protect the gauge. Damage is most likely to occur when the reinforcing gauge is lifted and then placed and also when the tremie pipe places the cement.
  • Page 5: Taking Readings

    Taking Readings VW Data Recorder Connect signal cable to the data recorder: Cable Part Numbers and Color Coding Binding Posts 50613524 52602320 52602300 RTD/Therm Blue RTD/Therm White & Blue Black Black Choose Hz + RTD -or- Hz + Thermistor. Press the Enter key (the sweep range has no effect). The recorder displays a RTD or Thermistor reading in degrees C.
  • Page 6: Diagnostics

    Diagnostics No Reading Set your handheld multimeter to a low-ohm range (5k ohm). • Measure the resistance between the RTD/Thermistor wires (blue and white). Thermistors should read about 3000 ohms. RTDs should read about 2000 ohms. If the reading is very high or infinite, the tempera- ture device is damaged (or the cable is severed).
