OE electrics GST08 Installation Instructions

GST08 Cable Locking Clip installation instructions
1
Remove P-Clip if required
Connect GST08 cables
3
together
GST08 text on
interconnecting leads
5
Fold over clip to secure into place
UK -
sales@oeelectrics.co.uk / +44 (0) 1924 367 255
AUS - sales@oeelsafe.com.au / 1300 ELSAFE (357 233)
P-Clip
Only remove P-Clip
with mounting hole
Cables should slot into
place easily. Do not force
INSTR1301
Align GST08 locking clip with surface
and screw into place using No.6
2
countersunk screw. Length dependent
on surface mounted to
Fit GST08 cables into locking
4
clip, take note of alignment
GST08 CONNECTOR
ALIGNMENT
GST08 CONNECTOR ALIGNMENT
Align P-Clip with surface and screw into
place, half way along cable, using No.6
6
countersunk screw. Length dependent on
surface mounted to
DE - info@oeelectrics.de / +49 (0)2261 958 3001
U.S.A -
sales@oeelectrics.com / +1 (844)-927-0600
www.oeelectrics.com
Clamp cable using P-Clip
