SWS DLXT-121 Series Manual

Thinline Auxiliary
DLXT-121*** or DLXT-241***
(12 VDC)
GREEN
Pattern Select: Touch and release to ground to program
WHITE
Sync: Attach to White wires from other S-Link Lights for synchronization
GREEN w/WHITE
Split/Single: Connect with Black to Ground for Single Mode
Connect with Red to Switched Power for Split Mode
RED
Power: Connect to switched power
Warning BLACK
Ground: Connect to negative terminal of battery
Lights
ON/OFF
Switch
Use minimum
!
18AWG wire
-
BATTERY
12VDC or 24VDC
(depends upon model)
Pattern Programming and Synchronization
You can synchronize up to six
lights with compatibility.
DO NOT CONNECT WHITE WIRES
UNTIL PROGRAMMING HAS BEEN
COMPLETED FOR ALL LIGHTS!!
1. Power up the first unit and select a
Phase 1 pattern. Touch and
release the green wire to ground to
change patterns.
2. Program the second light with
the same Pattern Type.
Lights with the SAME phase
flash together (simultaneous).
Lights with DIFFERENT phases
flash opposite one another
(alternate).
3. After programming all lights, tie
off the green wires and connect
the white wires together.
4. Test lights by applying power to all of them at the same time.
Alternating Pattern Simultaneous Pattern
(Programmed for opposite Phases)
Light 1 Light 2
(ON) (OFF)
DLXT
(24 VDC)
Quick Install Guide
Mounting Surface
1 11
2 12
3 13
4 14
5 15
6 16
7 17
8 18
9 19
10 20
N/A
Pattern Shortcuts: Hold Green wire to ground for indicated
time.
Steady Burn: Not in pattern cycle. Only accessible through
(Programmed for same Phase) (Programmed for opposite Phases)
Light 1 Light 2
LED Lights
DLXT-124*** or DLXT-244***
(12 VDC)
Bezel
Rubber
Mounting
Gasket
Pattern Description
A Fast Singleflash (1.9 CPS)
B Flicker flash (1.7 CPS)
C Post pop (1.4 CPS)
D PSU-flicker (0.4 CPS)
E Random (1.9 CPS) (DEFAULT PATTERN)
Quadflash (1.0 CPS)
F
Quadflash
G
w/Post-Pop (1.0 CPS)
Singleflash (1.0 CPS)
H
Doubleflash (1.0 CPS)
I
J Delta-Omega (0.3 CPS)
Steady
(see below)
shortcut. Hold Green wire to ground for 18
seconds (light will flash 6 times).
Split Mode
In/Out Pattern Back & Forth Pattern
(Programmed for same Phase)
Light 1 Light 2
(OFF) (ON)
(24 VDC)
LED Array
Foam Compression Gasket
IMPORTANT
Shortcut
Pattern 1 :
(Phase 1)
3 sec or 1 flash
Pattern 11 :
(Phase 2)
9 sec or 3 flashes
Pattern 6 :
(Phase 1)
6 Sec or 2 flash
Pattern 16 :
(Phase 2)
12 sec or 4 flashes
18 sec or 6 flashes
Light 1 Light 2
