- Page 1 FSC-UP3311 Instruction manual FSC-UP3311 UWB beacon...
-
Page 2: Brief Introduction
FSC-UP3311 Instruction manual 1、 Brief introduction FSC-UP3311 is a positioning tag based on UWB (Ultra Wideband) technology. The main control chip adopts NRF52840 to realize the receiving and sending control of UWB signals, and the positioning chip adopts DW3220, which can realize different functions by burning different firmware. -
Page 3: Basic Parameter
FSC-UP3311 Instruction manual 2、 Basic parameter Working parameter Power supply mode Two dry batteries (2*AAA) Operating voltage 2.4-3V battery capacity 1000mAh Positioning distance ≥40m positioning accuracy ≤40cm Working temperature -20~60℃ product size 56×56×16mm BLE parameter Bluetooth version Bluetooth v5.2 Frequency 2.400 ~ 2.484GHz;... - Page 4 3.1.1 Mobile phone connection mode (just use the tag) Install Feasycom FeasyUWB app Connect under FSC-UP3311 working condition. When the following interface appears, it means the connection is successful. It can be operated normally For specific operation, please refer to the instructions for the positioning of Becon by...
- Page 5 FSC-UP3311 Instruction manual...
- Page 6 3.2.1 Indoor positioning mode (need to cooperate with UWB base station) For specific operation, please refer to the instructions for indoor positioning of Feasycom UWB. mp4. Contact us Shenzhen feasycom technology co., ltd Email: sales@feasycom.com Tel: 86-755-27924639 Website:www.feasycom.com Address: Rm 508, Building A, Fenghuang Zhigu, No.50, Tiezai Road, Xixiang,...
