Summary of Contents for TIMPANO TPT-EQ7 10v
- Page 1 TPT-EQ7 10v 1 / 2 D I N 7 - B A N D E Q U A L I Z E R / H I G H V O LTA G E L I N E USER MANUAL...
- Page 2 Thank you so much for choosing a TIMPANO product! The equalizer was developed with the most advanced technology for adjustment and audio equalization with high-fidelity sound. Resources The equalizer has 2 input channels and 3 output channels, namely: INPUT CONNECTIONS...
-
Page 3: Before Installing
Before installing Read this manual carefully before installing the equalizer. The assembly instructions must be followed as well as the connections, to the best use of the product. If needed, consult our Customer Service. Before use, it’s indispensable to pay attention to some info: •... -
Page 4: Input Connections
Input Connections HI INPUT CONNECTION: Use the connection when the radio/player does not have RCA output. The input has a stereo signal (L and R) identified at the product. Check the radio/player output signals before making the connections. For remote triggering of the amplifier, use the REM connection. R CHANNEL The positive is connected through the BLUE wire. - Page 5 TPT-EQ7 10v Controls SUBWOOFER OUTPUT CONTROLS • SUB LEVEL: Allows the signal adjustment of the level provided at the output of the SUB channel. • L.P.F. FREQ: Knob control to select the maximum frequency which will be reproduced by SUB channel, just like an amplifier or crossover Low Pass Filter (L.P.F.).
-
Page 6: Output Connections
Example of impacts in each equalization control represented on the audio chart: +12dB -12dB -12dB +12dB -12dB 50Hz 125Hz 315Hz 750Hz 2,2KHz 6KHz 16KHz Output connections SUB OUTPUT: RCA output (L+R) dedicated for use in SUBWOOFERS. It has controls dedicated to LEVEL and L.P.F. FREQUENCY for precise lower frequencies adjustment. - Page 7 Allows activation of the equalizer when this connection is energized. Plug the output remote of the radio/player, through a cable with a gauge of 20AWG or use a key on/off connected to +12V. Radio/Player REM (remote) 20AWG cable TIMPANO POWER SUPPLY 20AWG cables Fuse (max. 1 feet of the battery)
-
Page 8: Installation Example
Installation example REAR FRONT Amplifier Amplifier FULLRANGE SUBWOOFER Radio / Player TIMPANO 1/2 Din 7-Band Equalizer TPT-EQ7 10v... -
Page 9: Problems Solution
Problems solution DOES NOT TURN ON OR LED’S DO NOT LIGHT UP: • Power cables are not connected correctly or poorly contacted (terminals +12V, GND, and REM). Check connections and grounding. • Remote activation (REM) connection with no voltage. Verify that the connection is receiving voltage near 12V. - Page 10 • Make a good grounding of the product. For this, remove the ink from the chassis of the vehicle on the wanted point and screw the wire, using a ground terminal. To protect it from oxidation, insulate it with ink. •...
-
Page 11: Technical Specifications
Technical specifications Inputs: MAIN IN (RCA) and HI INPUT (WIRE) Outputs: SUB OUT, FRONT and REAR SUB LEVEL and L.P.F. FREQUENCY INPUT SELECTOR (MAIN and HI INPUT) LEVEL (MAIN and HI INPUT) Audio Controls: FADER (FRONT and REAR) EQUALIZER (-12dB ~ +12dB) SUB frequency control: 60Hz ~ 90Hz Vout @ 14.4V:...
