Summary of Contents for AGCO SimplEbale ACX3743740
- Page 1 Assembly Instructions SimplEbale - Road lamp kit Kit number: ACX3743740 North America November 2023 4205 River Green Parkway 79037895A_en Duluth GA 30096 USA English © AGCO 2023...
- Page 2 CALIFORNIA Proposition 65 Warning WARNING: Diesel engine exhaust and some of its constituents are known to the State of California to cause cancer, birth defects, and other reproductive harm. WARNING: Battery posts, terminals and related accessories contain lead and lead compounds, chemicals known to the State of California to cause cancer, birth defects, and other reproductive harm.
- Page 3 Make an order for missing parts. General If more assistance is necessary you should speak to your AGCO dealer. This manual is only applicable to the models specified on the front cover. Fastener torques Always replace fasteners with fasteners of the same specification.
- Page 4 1 Safety Part number references All parts that are supplied in the kit are referenced in the bill of materials. Each part is added to a table in the installation steps, below is an example. Description Quantity Number Part number X446235234000 Long key X446234100000...
- Page 5 1 Safety Safety icons The safety warnings show in the manual with these icons: DANGER: This is an immediately dangerous situation which, if you ignore it, will cause death or injury. WARNING: This is an immediately dangerous situation which, if you ignore it, can cause death or injury.
- Page 6 Do not change the equipment. An adjustment not specified by the manufacturer can change the function of the machine and cause damage or personal injury. Only use AGCO approved replacement parts. WARNING: To prevent injury and machine damage, you must: •...
- Page 7 1 Safety Waste disposal Incorrect disposal of waste can cause pollution to the environment. Some examples of dangerous waste materials include oil, fuel, coolant, battery chemicals and air-conditioning refrigerant. • Only use an approved container to collect the waste material. Always seal the container after you drain the fluids.
- Page 8 1 Safety SimplEbale - Road lamp kit 79037895A_en...
- Page 9 2 Introduction Bill of materials Fig. 1 Quantity Description Number Part number 700748473 Wiring harness 7883325 Bolt - 5/16 x 3/4 700742795 Socket ACX4201110 Bracket 704726 Nut - 5/16 700742794 Adapter harness ACX4185220 Frame ACX2972520 Lamp - amber ACX2972530 Lamp - red (10) 700746128 Bracket...
- Page 10 2 Introduction Description Quantity Number Part number (20) 70932619 Clamp (21) 700709601 Washer - 1/4 (22) 1703354 Nut - 1/4 (23) 6828107 Spacer (24) ACX4186320 Plate (25) 7703945 Bolt - 5/16 x 2 7724347 Cable tie SimplEbale - Road lamp kit 79037895A_en...
- Page 11 3 Installation Preparation 3.1.1 Assemble the road lamp kit Procedure Install the socket (4) to the bracket (1) with the bolts (5) and the nuts (3). Connect the adapter harness (2). Fig. 1 Description Quantity Number Part number ACX4201110 Bracket 700742794 Adapter harness 704726...
- Page 12 3 Installation Install the rubber grommets to the frame (1). Fig. 3 Quantity Description Number Part number ACX4185220 Frame Install the lamps (1) and (2) to the frame. Fig. 4 Description Quantity Number Part number ACX2972520 Lamp - amber ACX2972530 Lamp - red SimplEbale - Road lamp kit 79037895A_en...
- Page 13 3 Installation Install the module (3) with the bolt (2) and the nut (1). Fig. 5 Quantity Description Number Part number 1703354 Nut - 1/4 7770183 Carriage bolt - 1/4 x 1 700748478 Module Connect the wiring harness (1). Fig. 6 Description Quantity Number...
- Page 14 3 Installation Install the clamp (1) with the bolt (2) the washer (3) and the nut (4). Fig. 7 Quantity Description Number Part number 70932619 Clamp 7770183 Carriage bolt - 1/4 x 1 700709601 Washer - 1/4 1703354 Nut - 1/4 Attach the wiring harness to the top of bracket (1) with cable ties.
- Page 15 3 Installation 10. Install the bracket (3) with the bolts (1) and the nuts (2). Fig. 9 Quantity Description Number Part number 7883325 Bolt - 5/16 x 3/4 704726 Nut - 5/16 ACX3743880 Bracket 7724347 Cable tie SimplEbale - Road lamp kit 79037895A_en...
- Page 16 3 Installation Install the road lamp assembly Procedure Install the socket assembly with the existing fasteners. Connect the electrical connector to the main harness (Kit: ACX3743320). Connect the wiring harness harness (700748473) to the socket assembly, then connect other end to tractor 7 pin connector. Fig.
- Page 17 3 Installation Install the bracket (2) with the bolt (3) and the nut (1). Fig. 12 Quantity Description Number Part number 700711238 Nut - 3/8 700746128 Bracket 700047 Carriage bolt - 3/8 x 1 Install the plates (1), with the bolts (5), spacers (4), washers (3) and nuts (2).
- Page 18 © AGCO Corporation, 2023. All rights reserved. 79037895A_en (English) November 2023...
