- Page 1 Intelligent Pipeline Technology EMTx30 Operating Manual Electromagnetic Transmitter www.iktrax.com...
- Page 2 CONFIGURATION INFORMATION SERIAL NUMBER : BATTERY TYPE PRODUCT CODE : FREQUENCY : RATE 1 PULSE LENGTH : RATE 1 REPETITION RATE : RATE 1 BATTERY LIFE AT +5°C : *RATE 2 PULSE LENGTH : *RATE 2 REPETITION RATE : *RATE 2 BATTERY LIFE AT +5°C : SPECIFIED ON PRESSURE : **SPECIFIED OFF PRESSURE : *Rate 2 only applicable when a Dual Rate Endcap is fitted.
-
Page 3: Table Of Contents
CONTENTS Page GENERAL DESCRIPTION ..................3 1.1. ENDCAP OPTIONS ....................3 SPECIFICATIONS: ....................4 RULES FOR SAFE OPERATION ................. 5 OPERATION ......................6 4.1. TURNING ON ..................... 6 4.2. FUNCTION TEST ....................6 4.3. INSTALLATION ....................6 4.4. DEPLOYMENT ....................8 4.5. -
Page 4: General Description
The EMTx30 transmitter produces a very strong signal for its size which can be detected through even the heaviest pipeline walls. Using the IK Trax EMTx Config application (Windows or Android) the transmitter frequency, power and pulse pattern can be configured to optimise performance and battery life. -
Page 5: Specifications
2. SPECIFICATIONS: NOTE THAT SPECIFICATIONS BELOW VALID STANDARD CONFIGURATION ONLY. REFER TO PAGE 1 OF THIS MANUAL FOR THE CONFIGURATION INFORMATION SPECIFIC TO THE TRANSMITTER BEING USED. Battery Type ............3x Alkaline DURACELL ID1400 C CELLS Lifetime at 100% power, continuous mode, +5°C (+41°F) ........2.0 days Lifetime at 100% power, continuous mode, +20°C (+68°F) ........ -
Page 6: Rules For Safe Operation
This manual should be read through and understood before installation and commissioning so that the operator is familiar with the equipment. Contact IK Trax immediately should any difficulty arise in the use of this equipment. ⚠... -
Page 7: Operation
4.2. FUNCTION TEST An EM receiver, such as an IT Trax EMRxEx Receiver is required to receive the signal from the transmitter. Refer to the relevant EM receiver manual for instruction on setup and operation of the EM receiver. - Page 8 ⚠ CAUTION: All EM transmitters will induce electrical currents in any conductive materials closely surrounding them which can result in a severe reduction in signal strength and/or battery lifetime. This effect can be minimised by reducing the amount of conducting material surrounding the transmitter and leaving as much of the transmitter exposed as possible.
-
Page 9: Deployment
Loosen the EMTx30 BATTERY ENDCAP 5 full turns using the supplied ENDCAP REMOVAL TOOL. The transmitter should turn off immediately. Use an EM receiver such as the IK Trax EMRxEx to confirm that the transmitter has turned off. 5. MAINTENANCE Familiarise yourself with all of the rules for the safe operation of this equipment as described in Section 3 RULES FOR SAFE OPERATION. -
Page 10: Battery Lifetime
4. Fully remove the BATTERY ENDCAP using the supplied ENDCAP REMOVAL TOOL. 5. Remove all cells and spacers. Visually inspect the cells, contact IK Trax immediately if there are any signs of damage or electrolyte leakage. Dispose of them in a responsible way. -
Page 11: O-Ring Replacement
EMTx30-0C3S predicted lifetimes (days), 0.4s pulse length, +5°C Power Cont. 1 sec 2 sec 3 sec 4 sec 5 sec Setting 100% (190mVpp) (134mVpp) (85mVpp) EMTx30-0C3S predicted lifetimes (days), 0.4s pulse length, +20°C Power Cont. 1 sec 2 sec 3 sec 4 sec 5 sec Setting... -
Page 12: Storage
6. STORAGE Familiarise yourself with all of the rules for the safe operation of this equipment as described in Section 3 RULES FOR SAFE OPERATION. If the transmitter is to be placed in storage for a long period of time remove the batteries from the transmitter and store separately. -
Page 13: Turning On
DUAL RATE ENDCAP - Can be fitted to an EMTx30 transmitter in place of the PCB ENDCAP to allow an external piece of equipment (e.g. an IK Trax 7000 ARGF) to switch between two pre- configured pulse rates. With a DUAL RATE ENDCAP fitted, the unit will transmit at pulse rate 1 when pins 1 and 2 on the IE55 Connector are open (resistance >... -
Page 14: Turning On
Remove the short from Pins 1 & 2, then loosen the BATTERY ENDCAP by 5 full turns using the supplied ENDCAP REMOVAL TOOL. Use an EM receiver such as IK Trax EMRx Topside to confirm that the transmitter has turned off. -
Page 15: Turning On
Remove the short from Pins 1 & 2, then loosen the BATTERY ENDCAP by 5 full turns using the supplied ENDCAP REMOVAL TOOL. Use an EM receiver such as IK Trax EMRx Topside to confirm that the transmitter has turned off. -
Page 16: Warranty
9. WARRANTY IK Trax products are guaranteed for one year from the date of purchase. Goods should be returned transportation prepaid to IK Trax. There is no charge for parts or labour should any product require repair due to a manufacturing deficiency during the guarantee period. -
Page 17: Declaration Of Conformity
11. DECLARATION OF CONFORMITY This declaration of conformity is issued under the sole responsibility of the manufacturer: Online Electronics Ltd Online House Blackburn Business Park Woodburn Road Blackburn Aberdeen AB21 0PS UNITED KINGDOM Object of declaration: EMTx30X range of electromagnetic transmitters With the following markings: II 2 G Ex db IIC Gb T5…T6...
