THANK YOU FOR
PURCHASING THE
®
111 S PERGOLA!
MIRADOR
This manual will provide you with clear and detailed instructions on how to safely and correctly assemble and maintain your pergola, to ensure it
brings you many years of use and enjoyment.
IMPORTANT
Please read the entire manual carefully before installing and using your pergola, and please ensure the manual is kept in a safe place for
future reference.
Intended use
This pergola is suitable for outdoor use, and is primarily intended to protect users from direct sunlight, glare and heat.
Any use or modification to the pergola not included in this manual shall be considered as improper use, which may cause considerable danger to
users and property and will void the product warranty.
1
Advertisement
Related Manuals for MIRADOR 111 S
Summary of Contents for MIRADOR 111 S
- Page 1 THANK YOU FOR PURCHASING THE ® 111 S PERGOLA! MIRADOR This manual will provide you with clear and detailed instructions on how to safely and correctly assemble and maintain your pergola, to ensure it brings you many years of use and enjoyment.
-
Page 2: Table Of Contents
INSTALLATION VIDEO TABLE OF CONTENTS Visit www.miradoroutdoor.com for installation videos or scan the QR code below - Before Assembling Your Pergola - Important Safety Advice - List of Parts 111S-4 PILLARS 111S-6 PILLARS - Installation ASSEMBLY ASSEMBLY - Problem Solving, Care & Maintenance - Warranty &... -
Page 3: Before Assembling Your Pergola
BEFORE ASSEMBLING YOUR PERGOLA Make sure you have all necessary parts Compare the contents of the boxes to the List of Parts (see page 8). If any parts are missing or damaged, or if you have any questions, please refer to the contact section on page 34. -
Page 4: Important Safety Advice
Changes to the design or Electrical Installation may only Installation of non-Mirador If using power tools or a Hot items such as recently Working at heights can be Do not attempt to assemble... -
Page 5: List Of Parts
10’x10’ 10’x13’ 10’x20’ 10’x10’ 10’x13’ 10’x20’ LIST OF PARTS Part name Part name 38+4 50+4 76+6 Foot plate cover 4 pcs 4 pcs 6 pcs Cotter pin PLEASE NOTE that the anchor bolts provided may not be suitable for your chosen installation location. -
Page 6: Installation
INSTALLATION 1. SET UP THE PILLARS Slide the foot plate cover with its wide opening facing outwards on the straight end of corner pillar 10'x20' 10'X10' & 10'X13' GO TO CHAPTER 3 Push the foot plate against the straight end of the corner pillar . - Page 7 2. CONNECT SIDE BEAMS B/B3 TOGETHER, AND TO THEIR CORRESPONDING Loosen the socket screws and built-in screws PILLARS , AND of side beams B1/3 B2/4 Slot side beam into side beam B/B3 B1/B2 until the end section of has been fully B/B3 B/B3 inserted and is no longer visible.
- Page 8 Lay the side beams and pillars on the ground as shown in the opposite figure. Slide the connected side beams into their corresponding pillars , ensuring that the slot nuts of the side beams interlock with the pillar slots. 10'x10' & 10'x13' 10'x20' go to Chapter 4 Tighten the socket screws, and all built-in screws with the hex key...
- Page 9 3. CONNECT THE SIDE BEAM WITH GEARBOX TO THE CORNER PILLAR Fix the side beam with gearbox tightly onto the corner pillar with the four built-in screws, using the hex key provided. Using a hex key (large) , slightly loosen the 4 built-in screws at the same end of the side beam with gearbox Repeat steps...
- Page 10 4. SLIDE IN THE TWO END BEAMS This phase requires four persons and at least two stepladders. Make sure that the stepladders are standing securely to avoid falling. Slide the slot nuts of the end beams from above into the slots of the corner pillars Only use ladders suitable for this kind of installation work.
- Page 11 5. ATTACH THE CRANK TO THE GEAR BOX 6. CHECK THE ALIGNMENT OF THE FRAME AND THE DISTANCE BETWEEN THE CORNER PILLARS You are now almost done installing the main frame of the pergola. Please double check to ensure all corner pillars and beams have been installed and fitted correctly. You may have to unscrew certain bolts during this step.
- Page 12 Measure the distances between the adjacent Check that all corner pillars are straight and corner pillars. Adjust accordingly and ensure level using a spirit level. If the corner pillars the distances match those shown in the or beams are still not level, this means that opposite figure.
- Page 13 7. INSTALL THE LOUVERS, AND CONNECTING STRIP Place the louvers on the corresponding louver shaft support on both side beams ( & ), with each louver overlapping the next, and make sure that the driving Prepare the driving louver: select one of the louver is placed 2nd from the left.
- Page 14 Rotate the louver in the vertical position Take the connecting strip . Attach it to using the crank each louver fitting each of the holes onto the corresponding bolts of the louvers. Secure every bolt with a cotter pin inserting it through the small bolt hole. x 38 x 12 x 38...
- Page 15 8. INSTALL THE PILLAR COVER 9. SECURE THE CORNER PILLARS TO THE GROUND The pergola must be firmly and permanently secured to the ground. If the ground is not level or suitable, please refer to the section “Before assembling your pergola”. To install the pillar cover, fix a pillar cover to the top of each corner with three screws each...
- Page 16 10. END OF INSTALLATION Tighten the hexagonal ends of each bolt with a spanner/wrench.
-
Page 17: Problem Solving, Care & Maintenance
PROBLEM SOLVING, GENERAL CARE & MAINTENANCE CARE & MAINTENANCE Dust and dirt will collect on the Use a water/detergent mixture and a pergola and will require periodic Air dry or wipe with a soft clean cloth soft clean cloth to clean the pergola. cleaning Issue Explanation or Action to take... -
Page 18: Warranty & Complaints Procedure
DISPOSAL OF THE PRODUCT The product is covered by a 3 -year warranty. For the full warranty terms and Incorrect disassembly of the pergola may lead to serious injury and product damage. conditions, please contact your local Mirador sales representative. ®...
Need help?
Do you have a question about the 111 S and is the answer not in the manual?
Questions and answers
how are the posts secured to the ground or deck?
The posts of the MIRADOR 111S pergola are secured to the ground using four foot plates. To fix the corner pillars, holes must be drilled through each foot plate using a hammer drill. The pergola must be firmly and permanently secured to ensure stability.
This answer is automatically generated
Can the pillars of the 111s be cut down shorter to account for an uneven mounting surface?
No, the manual does not mention cutting the pillars. Instead, it advises adjusting the height of the lower pillars using leveling methods if the mounting surface is uneven. Cutting the pillars may be considered improper use and could void the warranty.
This answer is automatically generated
what is the highth of the gondolla after install
