LBT-217
MTS5200
W E SUPPORT
P R OF E S S I ONA L
C E R T I F I C A T I ON
www . a v i o n d e ma n d . c o m

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the LBT-217 and is the answer not in the manual?

Questions and answers

Summary of Contents for AVI LBT-217

  • Page 1 LBT-217 MTS5200 W E SUPPORT P R OF E S S I ONA L C E R T I F I C A T I ON www . a v i o n d e ma n d . c o m...

  • Page 2: Table Of Contents

    BOSCH MTS 5200 LAB SCOPE Presented by Bob Pattengale Disclaimer of Warranties: This manual contains test procedures and test information obtained by an ASE Certified Master Technician with known good test equipment on real vehicles, your tests may vary due to your equipment or technician procedures. No warranty can be made from the ideas presented due to personal testing procedures, nor does the author or anyone connected with him assume responsibilities or liabilities.

  • Page 3: Overview

    BOSCH MTS 5200 LAB SCOPE Presented by Bob Pattengale OVERVIEW For this training session we will be discussing the Bosch MTS 5200 Lab Scope. Why is the use of a lab scope in your diagnostic strategy important? The answer is that a scan tool can only go so far.

  • Page 4: How To Get Started With Your Lab Scope

    BOSCH MTS 5200 LAB SCOPE Presented by Bob Pattengale WHAT MAKES A GOOD LAB SCOPE? (CONTINUED) 5200 is that the refresh rate of the screen is 12 times per second, which is double of what the human eye can actually see. Another feature that you want to make sure the lab scope has is a multi-channel connection.

  • Page 5: O2 Sensor Demonstration

    BOSCH MTS 5200 LAB SCOPE Presented by Bob Pattengale HOW TO GET STARTED WITH YOUR LAB SCOPE (CONTINUED) Another thing that you need to do is to use your lab scope to test known good vehicles. It is critical that you do this because if you don’t, you will find that you will be trying to learn how to use your lab scope while attempting to fix vehicles under pressure.
  • Page 6 BOSCH MTS 5200 LAB SCOPE Presented by Bob Pattengale HOW TO GET STARTED WITH YOUR LAB SCOPE (CONTINUED) O2 Sensor Demonstration Once we have scrolled down to the O2 sensor and selected it, the tool automatically sets itself up to test O2 sensors. From this screen you will be able to access information on how to connect the scope to the sensor, freeze the data on the screen, view...

  • Page 7: Navigating The Mts 5200

    BOSCH MTS 5200 LAB SCOPE Presented by Bob Pattengale NAVIGATING THE MTS 5200 This portion of the presentation will cover how to navigate the MTS 5200 menu system and what the menus are used for. Later on in the presentation we will cover the outside connections of the lab scope and what they are used for.
  • Page 8 BOSCH MTS 5200 LAB SCOPE Presented by Bob Pattengale NAVIGATING THE MTS 5200 (CONTINUED) Primary & Secondary Ignition We have selected the analyzer utilities menu and you can see that there are three options available. Setup, Tools and File Manager. Once we have chosen the tools menu option, the Tools Menu will appear and as you can see in the screen capture above there are a few choices we can make here as well.
  • Page 9 BOSCH MTS 5200 LAB SCOPE Presented by Bob Pattengale NAVIGATING THE MTS 5200 (CONTINUED) Primary & Secondary Ignition This allows you to get better acquainted with the Engine Analyzer controls, allowing for smoother operation when hooked to a vehicle. Once we have enabled the ignition demonstration we can back out to the main menu and select Primary Ignition.
  • Page 10 BOSCH MTS 5200 LAB SCOPE Presented by Bob Pattengale NAVIGATING THE MTS 5200 (CONTINUED) Primary & Secondary Ignition Once the firing order has been chosen, the ignition scope screen appears and is configured for primary ignition. Notice that all eight cylinders are displayed in the correct firing order across the bottom of the screen but the patterns for each cylinder are very small.
  • Page 11 BOSCH MTS 5200 LAB SCOPE Presented by Bob Pattengale NAVIGATING THE MTS 5200 (CONTINUED) Primary & Secondary Ignition If you are in doubt about how the connections from the tool to the vehicle should be made, click on the menu option “Lead Help” in the left sidebar of the screen. As you can see in the above screen capture, a detailed schematic will appear on the screen giving you good direction on how to make the connections.

  • Page 12: Trigger Set Up

    BOSCH MTS 5200 LAB SCOPE Presented by Bob Pattengale NAVIGATING THE MTS 5200 (CONTINUED) Primary & Secondary Ignition Trigger Set-Up While viewing live data, you can access all trigger properties through the Trigger Setup touch screen display button to the left of the signal display area as illustrated in the screen capture above.

  • Page 13: Freeze

    BOSCH MTS 5200 LAB SCOPE Presented by Bob Pattengale NAVIGATING THE MTS 5200 (CONTINUED) Primary & Secondary Ignition Freeze Also in the main menu is a menu option called “Freeze”. The Freeze button is available any time the MTS 5200 is collecting data in any of the display modes. The Freeze button stops the collection of live data and freezes the signal on the display, allowing you to analyze the frozen signal.

  • Page 14: Superimposed Display

    BOSCH MTS 5200 LAB SCOPE Presented by Bob Pattengale NAVIGATING THE MTS 5200 (CONTINUED) Primary & Secondary Ignition Superimposed Display Superimposed Display mode allows you to view the waveform of each cylinder in the firing order on a single screen, simultaneously. Each cylinder waveform is positioned beginning with the firing spike at the trigger position.

  • Page 15: Raster Display

    BOSCH MTS 5200 LAB SCOPE Presented by Bob Pattengale NAVIGATING THE MTS 5200 (CONTINUED) Primary & Secondary Ignition Raster Display Raster Display mode allows you to view the waveform of each cylinder in the firing order on a single screen, simultaneously. Selecting a cylinder from the Cylinder Selection buttons at the bottom of the touch screen display causes the MTS 5200 to hide or display the selected cylinder.

  • Page 16: Single Cylinder Display

    BOSCH MTS 5200 LAB SCOPE Presented by Bob Pattengale NAVIGATING THE MTS 5200 (CONTINUED) Primary & Secondary Ignition Single Cylinder Display Single Cylinder Display mode allows you to view the waveform characteristics of a single cylinder in the firing order. By pressing the Cylinder Selection buttons at the bottom of the touch screen display, you have the ability to view each cylinder’s waveform individually.

  • Page 17: Firing Volts Bar Chart Display

    BOSCH MTS 5200 LAB SCOPE Presented by Bob Pattengale NAVIGATING THE MTS 5200 (CONTINUED) Primary & Secondary Ignition Firing Volts Bar Chart Display Bar Chart Display mode allows you to view the voltage levels of each cylinder in the firing order on a single screen.

  • Page 18: Secondary Quick Check

    BOSCH MTS 5200 LAB SCOPE Presented by Bob Pattengale NAVIGATING THE MTS 5200 (CONTINUED) Secondary Quick Check During diagnosis of a secondary ignition system you might encounter situations where you want to display information on one specific cylinder. A Diagnostic Trouble Code (DTC) such as a P0302 (cylinder #2 misfire) would direct you immediately to the cylinder.
  • Page 19 BOSCH MTS 5200 LAB SCOPE Presented by Bob Pattengale NAVIGATING THE MTS 5200 (CONTINUED) Secondary Quick Check Although the Secondary Quick Check is fully functional on Distributor Ignition (DI) systems, some applications filter the ignition signal as it passes through the distributor. This distorts the signal at the individual spark plug wires.

  • Page 20: Graphing Multimeter

    BOSCH MTS 5200 LAB SCOPE Presented by Bob Pattengale NAVIGATING THE MTS 5200 (CONTINUED) Graphing Multimeter Graphing Multimeter is a powerful diagnostic tool that allows you to view circuit operation over extended periods of time. All measurements are plotted horizontally from left to right to show the measurement over time and vertically to display the measured value.

  • Page 21: Dc Voltage Button

    BOSCH MTS 5200 LAB SCOPE Presented by Bob Pattengale NAVIGATING THE MTS 5200 (CONTINUED) Graphing Multimeter DC Voltage Button DC voltage mode measures and displays the DC voltage of a sampled signal. The MTS 5200 can measure DC voltages from 0 - 200 volts. Frequency Button Frequency mode measures and displays the frequency of the sampled signal.

  • Page 22: Duty Cycle Button

    BOSCH MTS 5200 LAB SCOPE Presented by Bob Pattengale NAVIGATING THE MTS 5200 (CONTINUED) Graphing Multimeter Duty Cycle Button This mode measures the ratio of the high/low portion of a signal period to the entire signal period and displays the results as a percentage of time. The MTS 5200 allows you to select either the percentage of high or low signal.

  • Page 23: Vacuum Button

    BOSCH MTS 5200 LAB SCOPE Presented by Bob Pattengale NAVIGATING THE MTS 5200 (CONTINUED) Graphing Multimeter Vacuum Button This mode displays the pressure measured by the Bosch Vacuum Probe. The Vacuum Probe has a measurement range of 30 inHg – 15 psi (0-30 psia). Two different units of measure selections can be used: inHg and mbar.

  • Page 24: Capturing A Snap Shot

    BOSCH MTS 5200 LAB SCOPE Presented by Bob Pattengale NAVIGATING THE MTS 5200 (CONTINUED) Graphing Multimeter Capturing a Snap Shot The Snapshot function gives you the ability to capture, save, and playback a length of data collected from a vehicle. When a snapshot is captured, the MTS 5200 collects data from the vehicle for a length of time you select.
  • Page 25 BOSCH MTS 5200 LAB SCOPE Presented by Bob Pattengale NAVIGATING THE MTS 5200 (CONTINUED) Graphing Multimeter Capturing a Snap Shot Adjusting Trigger Point Pre- and post-trigger times are adjusted with the “Right” and “Left” arrow buttons on either the touch screen or the keypad. The pre-trigger setting is displayed on the left side of the Trigger Point adjustment bar and is displayed in seconds.
  • Page 26 BOSCH MTS 5200 LAB SCOPE Presented by Bob Pattengale NAVIGATING THE MTS 5200 (CONTINUED) Graphing Multimeter Capturing a Snap Shot SNAPSHOT CONTROLS Main Menu The Main Menu button returns you to the main menu of the operating mode from which you accessed Snapshot mode.

  • Page 27: Playback Mode

    BOSCH MTS 5200 LAB SCOPE Presented by Bob Pattengale NAVIGATING THE MTS 5200 (CONTINUED) Graphing Multimeter Capturing a Snap Shot RECORDING INDICATOR In the top left corner of the grid there is a text box that displays the status of the snapshot. One beep is sounded when a snapshot has been triggered.
  • Page 28 BOSCH MTS 5200 LAB SCOPE Presented by Bob Pattengale NAVIGATING THE MTS 5200 (CONTINUED) Graphing Multimeter Playback Mode Snapshot The Snapshot button exits the Playback Mode and returns to the Snapshot menu where another snapshot can be captured. The Exit keypad button operates the Snapshot button as well. If an unsaved snapshot exists when the Playback Mode is exited, you are prompted to either save the snapshot to memory or disregard the snapshot.
  • Page 29 BOSCH MTS 5200 LAB SCOPE Presented by Bob Pattengale NAVIGATING THE MTS 5200 (CONTINUED) Graphing Multimeter Playback Mode Once the Save button is pressed, the Save Options menu is displayed (see Figure 11-4). This menu offers the following selections: Save Snapshot This selection saves the complete snapshot to memory where it can be recalled and viewed from the File Manager.

  • Page 30: Digital Volt Ohm Meter (Dvom)

    BOSCH MTS 5200 LAB SCOPE Presented by Bob Pattengale NAVIGATING THE MTS 5200 (CONTINUED) Digital Volt Ohm Meter (DVOM) Overview The Digital Volt Ohm Meter (DVOM) is a powerful diagnostic tool that allows you to determine specific values of different measurement modes. The DVOM modes include DC and AC voltages, resistance, continuity, and diode check.

  • Page 31: Operating Modes

    BOSCH MTS 5200 LAB SCOPE Presented by Bob Pattengale NAVIGATING THE MTS 5200 (CONTINUED) Digital Volt Ohm Meter (DVOM) Operating Modes There are five operating modes in the DVOM application. DC VOLTAGE DC voltage mode displays the DC voltage of a sampled signal in the DVOM. The MTS 5200 can measure DC voltage from 0 mV to ±400 V.

  • Page 32: 4-Channel Oscilloscope

    BOSCH MTS 5200 LAB SCOPE Presented by Bob Pattengale NAVIGATING THE MTS 5200 (CONTINUED) 4-Channel Oscilloscope Overview The 4-Channel Oscilloscope is an easy-to-use and versatile tool that allows access to any automotive computer-controlled circuit. Once you are familiar with the oscilloscope layout and features, you can take full advantage of the most powerful tool in its class.

  • Page 33: Connecting Leads

    BOSCH MTS 5200 LAB SCOPE Presented by Bob Pattengale NAVIGATING THE MTS 5200 (CONTINUED) 4-Channel Oscilloscope Connecting Leads Before using the oscilloscope, connect your leads to the color-coded ports positioned above the touch screen display on the face of the MTS 5200. The oscilloscope leads are shielded to eliminate noise and interference from the vehicle.

  • Page 34: Component Selection

    BOSCH MTS 5200 LAB SCOPE Presented by Bob Pattengale NAVIGATING THE MTS 5200 (CONTINUED) 4-Channel Oscilloscope Component Selection When you choose Component Selection, the oscilloscope automatically configures itself for the vehicle component you designate. After touching the Component Selection button on the touch screen display, you see a menu of vehicle component categories from which to choose.

  • Page 35: Trigger Setup

    BOSCH MTS 5200 LAB SCOPE Presented by Bob Pattengale NAVIGATING THE MTS 5200 (CONTINUED) 4-Channel Oscilloscope Trigger Setup The MTS 5200 has a set of trigger controls that determine the exact instant the trace begins the sweep across the screen. If a trigger is set at a specific voltage level, and the signal being sampled achieves that trigger level voltage, then the MTS 5200 displays the signal.
  • Page 36 BOSCH MTS 5200 LAB SCOPE Presented by Bob Pattengale NAVIGATING THE MTS 5200 (CONTINUED) 4-Channel Oscilloscope Trigger Setup Trigger Type There are four different types of triggers to choose from when viewing a signal—Auto, Normal, Single Shot, and Free Run. Trigger type is available in the Trigger Setup menu. When the Trigger Type button is selected from the upper left corner of the Trigger Setup menu, a pop-up menu appears with the four trigger types to choose from.
  • Page 37 BOSCH MTS 5200 LAB SCOPE Presented by Bob Pattengale NAVIGATING THE MTS 5200 (CONTINUED) 4-Channel Oscilloscope Trigger Setup the trigger position. If the signal does not meet the trigger level condition, the MTS 5200 does not display a signal. If you lose the trigger condition while viewing a signal, the signal display area freezes and remains frozen until the signal reaches the trigger level.

  • Page 38: Signal Finder

    BOSCH MTS 5200 LAB SCOPE Presented by Bob Pattengale NAVIGATING THE MTS 5200 (CONTINUED) 4-Channel Oscilloscope Signal Finder If you have correctly configured the oscilloscope but see no waveform on the touch screen display, Signal Finder provides a quick and easy way to find the signal and display it. Signal Finder examines the input signal and automatically adjusts the settings for your selected channels in order to display the signal.

  • Page 39: Other Functions

    BOSCH MTS 5200 LAB SCOPE Presented by Bob Pattengale NAVIGATING THE MTS 5200 (CONTINUED) 4-Channel Oscilloscope Cursors When the cursors are activated, a Cursor Information Box appears at the bottom of the display showing the delta measurement between the cursors. Cursor information appears in the units of measure that are applicable to the channel that is selected for cursor measurement (i.e., the same units that are displayed in the Time/Div and Volts/Div selection boxes).

  • Page 40: Cranking Kv Test

    BOSCH MTS 5200 LAB SCOPE Presented by Bob Pattengale NAVIGATING THE MTS 5200 (CONTINUED) Cranking kV Test The Cranking kV Test allows you to perform a quick diagnosis of the secondary ignition system’s ability to produce spark at cranking engine speed. This test gives you a simple pass/fail result along with detailed information about the health of the secondary ignition system.
  • Page 41 BOSCH MTS 5200 LAB SCOPE Presented by Bob Pattengale NAVIGATING THE MTS 5200 (CONTINUED) Vehicle Selection You must use the manual setup if you wish to select a vehicle with a Coil Near Plug (CNP) or Coil On Plug (COP) ignition system. CNP and COP vehicles are not currently included in the vehicle database.

  • Page 42: Analyzer Utilities

    BOSCH MTS 5200 LAB SCOPE Presented by Bob Pattengale NAVIGATING THE MTS 5200 (CONTINUED) Vehicle Selection 5. Select the correct firing order on the Select Firing Order pop-up menu. The Page Down and Page Up buttons move you one complete page at a time, allowing faster access to the firing order selections.
  • Page 43 BOSCH MTS 5200 LAB SCOPE Presented by Bob Pattengale NAVIGATING THE MTS 5200 (CONTINUED) Analyzer Utilities (Setup) SET DATE AND TIME The MTS 5200 utilizes a date and time function in memory as part of its software function. Date and time are used to put a time stamp on files that are recorded and saved. To set the time and date, simply touch the Set Date and Time button, bringing up the Set Date/ Set Time menu.

  • Page 44: Analyzer Utilities (Tools)

    BOSCH MTS 5200 LAB SCOPE Presented by Bob Pattengale NAVIGATING THE MTS 5200 (CONTINUED) Analyzer Utilities (Tools) SOFTWARE VERSION NUMBER Software Version displays internal MTS 5200 software information. The internal software version number and release date are displayed on the SW Version button. Once pressed the following information is displayed in the S/W Version Information screen: •...
  • Page 45 BOSCH MTS 5200 LAB SCOPE Presented by Bob Pattengale NAVIGATING THE MTS 5200 (CONTINUED) Analyzer Utilities (Tools) CHARGE BATTERY To charge the battery pack, connect the tester to a 12 VDC power source such as the vehicle battery or the 12-volt AC/DC power supply. You must select Start Battery Charging from the Analyzer Utilities/Tools/Charge Battery screen to start battery charging.
  • Page 46 BOSCH MTS 5200 LAB SCOPE Presented by Bob Pattengale NAVIGATING THE MTS 5200 (CONTINUED) Analyzer Utilities (Tools) ENABLE IGNITION DEMONSTRATION The Enable Ignition Demonstration function allows for selection of a stored ignition waveform program. This program operates in DI Secondary Ignition, Secondary Quick Check, and Primary Ignition.

  • Page 47: Conclusion On Navigating The Mts 5200

    BOSCH MTS 5200 LAB SCOPE Presented by Bob Pattengale NAVIGATING THE MTS 5200 (CONTINUED) Conclusion On Navigating The MTS 5200 This concludes the broad overview on navigating the MTS 5200. As stated at the beginning of this section, a more detailed description of the navigation process can be found in the owners manual included with the MTS 5200 and is also available for download at: http://www.boschdiagnostics.com/support/documentation/Pages/DiagnosticsDocumentation.a spx?type=UnderHood...

  • Page 48: The Graphing Multimeter

    BOSCH MTS 5200 LAB SCOPE Presented by Bob Pattengale THE GRAPHING MULTIMETER Throttle Position Sensor (TPS) In this portion of the presentation we are going to go a little deeper into the Graphing Multimeter function of the MTS 5200. Pictured right you can see that we have connected the lab scope to a demonstration board.
  • Page 49 BOSCH MTS 5200 LAB SCOPE Presented by Bob Pattengale THE GRAPHING MULTIMETER Throttle Position Sensor (TPS) A normal TPS sensor will have a low voltage with the throttle released and voltage going higher as the throttle is depressed. Pictured above is a waveform captured from the screen of the lab scope.
  • Page 50 BOSCH MTS 5200 LAB SCOPE Presented by Bob Pattengale THE GRAPHING MULTIMETER Throttle Position Sensor (TPS) Pictured above is the same waveform from the demonstration board but the glitch switch on the board has been turned ON. Note that the pattern now has three distinct drops in voltage indicated by the three lines going down in the pattern.

  • Page 51: Frequency

    BOSCH MTS 5200 LAB SCOPE Presented by Bob Pattengale THE GRAPHING MULTIMETER Frequency We just looked at a voltage waveform for a TPS using the MTS 5200 connected to a demonstration board. Now let’s look at a frequency waveform. A frequency waveform would be useful in diagnosing such things as a MAF sensor on Ford vehicles or even a CKP signal during a no start condition.

  • Page 52: Coolant Sensor

    BOSCH MTS 5200 LAB SCOPE Presented by Bob Pattengale THE GRAPHING MULTIMETER Frequency For this type of signal it is important to keep an eye on the minimum and maximum values. This is because if you had a Ford vehicle that had a hesitation problem, you would look for the minimum signal to fall to 0.0Hz.

  • Page 53: The Lab Scope (Square Wave With & Without Glitch)

    BOSCH MTS 5200 LAB SCOPE Presented by Bob Pattengale THE LAB SCOPE (SQUARE WAVE WITH & WITHOUT GLITCH) Using the lab scope on the connected to the variable frequency signal terminal of the demonstration board you can see that we have a waveform on the screen. Also note that the voltage goes off of the screen.
  • Page 54 BOSCH MTS 5200 LAB SCOPE Presented by Bob Pattengale THE LAB SCOPE (SQUARE WAVE WITH & WITHOUT GLITCH) Using the signal finder function is one way to set the scope up quickly, however it may not give you the display that you actually want. If we use the Component Selection function and actually choose the sensor that we are testing, we can set the scope up to view the patterns exactly how we want to.

  • Page 55: Triggers

    BOSCH MTS 5200 LAB SCOPE Presented by Bob Pattengale THE LAB SCOPE (SQUARE WAVE WITH & WITHOUT GLITCH) Triggers The MTS 5200 has a set of trigger controls that determine the exact instant the trace begins the sweep across the screen. If a trigger is set at a specific voltage level, and the signal being sampled achieves that trigger level voltage, then the MTS 5200 displays the signal.
  • Page 56 BOSCH MTS 5200 LAB SCOPE Presented by Bob Pattengale THE LAB SCOPE (SQUARE WAVE WITH & WITHOUT GLITCH) Triggers Trigger edge set to “Rising” position A good way of understanding trigger points is this. Imagine that you are driving down the road and you have a camera in your hands and you want to take a series of pictures.
  • Page 57 BOSCH MTS 5200 LAB SCOPE Presented by Bob Pattengale THE LAB SCOPE (SQUARE WAVE WITH & WITHOUT GLITCH) Triggers Single Shot Trigger Single Shot trigger is used when you want to capture a certain characteristic of a known signal. If the signal under examination does not reach your trigger threshold setting, the MTS 5200 does not display any signal.

  • Page 58: The Lab Scope (Injector Signal)

    BOSCH MTS 5200 LAB SCOPE Presented by Bob Pattengale THE LAB SCOPE (INJECTOR SIGNAL) We have moved our test lead on the the demonstration board to the injector signal terminal. In the Signal Finder mode we have also selected Fuel Injectors from the Component Selection menu.

  • Page 59: The Lab Scope (Missing Trigger)

    BOSCH MTS 5200 LAB SCOPE Presented by Bob Pattengale THE LAB SCOPE (MISSING TRIGGER) An important thing we need to cover before moving on to the hands on portion are missing triggers (missing events). Depending upon how you set up your scope you may not be catching what you think that you should be catching.

  • Page 60: The Lab Scope (Recording & Screen Capture Saving)

    BOSCH MTS 5200 LAB SCOPE Presented by Bob Pattengale THE LAB SCOPE (RECORDING & SCREEN CAPTURE SAVING) The file management system of the MTS 5200 allows you to view and manipulate saved images, snapshots, and text files by using the following functions: •...

  • Page 61: 1995 Nissan Ignition Case Study

    BOSCH MTS 5200 LAB SCOPE Presented by Bob Pattengale 1995 NISSAN IGNITION CASE STUDY Now that we have covered the navigation and functions of the MTS 5200 it is time to take a look at the power it has when used in your diagnostic strategy. Up until now we have only demonstrated how to use the lab scope using one channel.
  • Page 62 BOSCH MTS 5200 LAB SCOPE Presented by Bob Pattengale 1995 NISSAN IGNITION CASE STUDY Coil Power (green) Coil Control (red) Coil Ground (blue) Coil #2 (yellow) Now that we know that the PCM is not commanding the coil to fire we have to find out why. The instructor has connected all four of the channels of the scope to the ignition coil as shown in the screen capture above.
  • Page 63 BOSCH MTS 5200 LAB SCOPE Presented by Bob Pattengale 1995 NISSAN IGNITION CASE STUDY The first sensor that was the easiest to get to was the CMP sensor. As you can see in the waveform above, that at no time did the CMP sensor signal drop out, but the ignition pattern at the bottom is still dropping out intermittently.
  • Page 64 BOSCH MTS 5200 LAB SCOPE Presented by Bob Pattengale 1995 NISSAN IGNITION CASE STUDY Crank Signal (blue) Signal (red) Since we have determined that the problem is NOT with the CKP sensor or the CMP sensor, we need to look closer at the relationship between the camshaft and the crankshaft. Pictured above is a waveform overlay that has the crankshaft signal in blue and the camshaft signal in red.
  • Page 65 BOSCH MTS 5200 LAB SCOPE Presented by Bob Pattengale 1995 NISSAN IGNITION CASE STUDY Pictured above is a screen capture of a CMP/CKP signal waveform taken from the IATN website. This waveform is showing us what a known good waveform for each looks like along with the relationship between the two.

  • Page 66: Live Vehicle Testing (Secondary Ignition Cop Wand)

    BOSCH MTS 5200 LAB SCOPE Presented by Bob Pattengale LIVE VEHICLE TESTING (SECONDARY IGNITION COP WAND) In this portion of the presentation we are going to take a look at some of the basic signals and circuits underneath the hood of a live vehicle. We will use the MTS 5200 and demonstrate how you connect it to the most common signals that you will be testing.
  • Page 67 BOSCH MTS 5200 LAB SCOPE Presented by Bob Pattengale LIVE VEHICLE TESTING (SECONDARY IGNITION COP WAND) You can see in the screen capture above that this vehicle has a multi-strike ignition system as indicated by the three firing patterns in the waveform. The first thing we need to look at is the primary (1st strike) ignition pattern of each ignition coil.

  • Page 68: Live Vehicle Testing (Secondary Ignition Cop Loop)

    BOSCH MTS 5200 LAB SCOPE Presented by Bob Pattengale LIVE VEHICLE TESTING (SECONDARY IGNITION COP LOOP) Many times on vehicles that have COP ignition systems it is difficult to spot a misfire at idle. Normally misfires on COP ignition vehicles occur when the vehicle is running down the road. To detect misfires while driving the vehicle we want to use a COP loop.
  • Page 69 BOSCH MTS 5200 LAB SCOPE Presented by Bob Pattengale LIVE VEHICLE TESTING (SECONDARY IGNITION COP LOOP) You can see in the screen capture above that the scope has been set up with the trigger point on the leading edge of the waveform. Also note that the Time/Div has been increased giving more resolution to the pattern for easier viewing.

  • Page 70: Secondary Ignition Testing With The Lab Scope

    BOSCH MTS 5200 LAB SCOPE Presented by Bob Pattengale SECONDARY IGNITION TESTING WITH THE LAB SCOPE So far we have covered two ways to diagnose secondary ignition problems. We have used the COP wand and the COP loop but there is also another method you can try, and that is using the 4 channel lab scope to diagnose the ignition patterns.

  • Page 71: Secondary Ignition Testing Review

    COP loop. Keep in mind that to use this method you need to know what cylinder is misfiring. This is a completely different subject that is covered on other AVI training programs. Visit www.auto-video.com or call 1-800-718-7246 for more information about Misfire Diagnostics.

  • Page 72: Live Vehicle Testing (Fuel Pump)

    BOSCH MTS 5200 LAB SCOPE Presented by Bob Pattengale LIVE VEHICLE TESTING (FUEL INJECTORS) The screen capture above illustrates what a known good injector pattern looks like on our subject vehicle. As with the previous ignition patterns, you can switch between channel 1 and channel 2 to compare signals.
  • Page 73 BOSCH MTS 5200 LAB SCOPE Presented by Bob Pattengale LIVE VEHICLE TESTING (FUEL PUMP) You will get very good at using this current probe as you get better at using your lab scope. You need to get in the habit of testing every fuel pump on every high mileage vehicle that comes through your shop.
  • Page 74 BOSCH MTS 5200 LAB SCOPE Presented by Bob Pattengale LIVE VEHICLE TESTING (FUEL PUMP) Using a suitable scan tool we can duty cycle the fuel pump without the vehicle running, and analyze the waveform on the lab scope. If your scan tool is not capable of this, you may have to find another way to command the fuel pump on.

  • Page 75: Live Vehicle Testing (Tps - Gmm)

    BOSCH MTS 5200 LAB SCOPE Presented by Bob Pattengale LIVE VEHICLE TESTING (TPS - GMM) For this portion of the presentation we are going to take a closer look at the throttle position sensor (TPS). The TPS is a very common sensor and when it fails you will usually have a hesitation or problems that are very similar to hesitations.

  • Page 76: Live Vehicle Testing (Recap)

    BOSCH MTS 5200 LAB SCOPE Presented by Bob Pattengale LIVE VEHICLE TESTING (TPS - GMM) In the screen capture above you can see that as we exercise the throttle from WOT to closed, the signal trace on the screen follows the movement indicating that the TPS is working correctly. There is one thing to keep in mind here.

  • Page 77: Mts 5200 Faq's

    BOSCH MTS 5200 LAB SCOPE Presented by Bob Pattengale MTS 5200 FAQ’S Where To Find The Manual Again we want to congratulate you for taking the initiative in buying this DVD and taking the time to watch it. Also, don’t forget to download the users manual and read it thoroughly. you can find the users manual at: http://www.boschdiagnostics.com/support/documentation/Pages/DiagnosticsDocumentation.a spx?type=UnderHood...

  • Page 78: Where To Find Shop Foreman Pro

    BOSCH MTS 5200 LAB SCOPE Presented by Bob Pattengale MTS 5200 FAQ’S Where To Find Shop Foreman Pro Shop Foreman Pro can be downloaded free of charge at: http://www.boschdiagnostics.com/software/diagnosticssoftware/pages/software.aspx?type=un derhood From there make sure that you choose “MTS 3100 Mastertech” from the drop down menu. Click on the “Shop_Foreman_Pro_5.7.11.0.exe”...

  • Page 79: Loading The Software On The Mts 5200

    BOSCH MTS 5200 LAB SCOPE Presented by Bob Pattengale MTS 5200 FAQ’S Loading The Software On The MTS 5200 Something that may occur during the use of your lab scope is that the screen may not appear as it should. It may appear that some of the displays and menus have become jumbled up and not readable.
  • Page 80 BOSCH MTS 5200 LAB SCOPE Presented by Bob Pattengale MTS 5200 FAQ’S SFP Software Access - Website The other end of the crossover cable needs to be connected to the LAN port connection on the PC that you will be using. Once both connections have been made, power both the MTS 5200 and the PC.

  • Page 81: In Conclusion

    BOSCH MTS 5200 LAB SCOPE Presented by Bob Pattengale IN CONCLUSION Practicing the techniques and tricks that we have showed you during this demonstration will help you to learn the ins and outs of the daily use of the MTS 5200. We have given you some common areas and issues that you will be using on a frequent basis to aid in your diagnostics.
