J O N I X
C L I M AT E
USE AND MAINTENANCE MANUAL
FULL INVERTER AIR-TO-AIR HEAT PUMP UNIT
WITH INTEGRATED NON-THERMAL PLASMA TECHNOLOGY

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the CLIMATE Series and is the answer not in the manual?

Questions and answers

Summary of Contents for Jonix CLIMATE Series

  • Page 1 J O N I X C L I M AT E USE AND MAINTENANCE MANUAL FULL INVERTER AIR-TO-AIR HEAT PUMP UNIT WITH INTEGRATED NON-THERMAL PLASMA TECHNOLOGY...
  • Page 2 JONIX S.p.A. make any necessary change or improvement to its products and to the manual at any time and without notice. It is forbidden to reproduce in full or in part this manual without S.p.A.’s consent.
  • Page 3 JONIX CLIMATE Each unit has an identification plate that is JONIX S.p.A. located on its frame and inside the electrical Benefit Corporation Viale Spagna 31/33 - 35020 Tribano - PD - Italy control panel, which shows all the data Tel +39 049 9588511 - Fax +39 049 9588522 - info@jonixair.com- www.jonixair.com...

  • Page 4: Introduction

    Should scheduled and unscheduled maintenance be necessary, please contact our After-sales Technical Service for assistance and spare parts. Please find here attached our direct contacts in case you may need assistenace: JONIX S.p.A. Società Benefit Viale Spagna 31/33 35020 Tribano - PD - Italy...

  • Page 5: Start-Up Instructions

    JONIX CLIMATE 2 - START-UP INSTRUCTIONS YOUR INSTALLATION All the tips required for a perfect installation of the equipment can be found in the installation manual. FIRST START-UP Contact your local distributor for commissioning of the equipment. All the preliminary checks and testing of the machine will be carried out together with your staff.

  • Page 6: Table Of Contents

    JONIX CLIMATE TABLE OF CONTENTS 1 - INTRODUCTION 2 - START-UP INSTRUCTIONS 3 - GENERAL DESCRIPTION 3.1 - PRECAUTIONS FOR USE 3.2 - PREMISE 3.3 - LIABILITY 3.4 - INTENDED USE 3.5 - GENERAL INSTRUCTIONS 4 - SAFETY INSTRUCTIONS 4.1 - SAFETY PRESCRIPTIONS 5 - DESCRIPTION OF THE PRODUCT AND TECHNICAL DATA 5.1 - MAIN COMPONENTS...
  • Page 7 JONIX CLIMATE 10 - START-UP 10.1 - PRELIMINARY CHECKS 10.2 - START-UP THE UNIT 10.3 - SELECTING THE OPERATING MODES 10.4 - SETTING THE SET-POINTS 10.5 - CHECKS DURING OPERATION 10.6 - STOPPING THE UNIT 11 - ROUTINE MAINTENANCE AND CHECKS 11.1 - WARNINGS...

  • Page 8: General Description

    JONIX CLIMATE 3 - GENERAL DESCRIPTION 3.1 PRECAUTIONS FOR USE The operating rules contained in this manual are solely applicable for the units: JCLIMATE The instructions manual must be read and used as follows: – every unit operator and maintenance technician must carefully read the entire manual and comply with that stipulated therein;...

  • Page 9: Liability

    JONIX CLIMATE 3.3 LIABILITY The MANUFAC TURER cannot be held liable for any personal accident or damage to property, which may arise from: – failure to comply with the instructions provided in this manual regarding unit management, use and maintenance;...

  • Page 10: General Instructions

    JONIX CLIMATE Any other use is to be considered inappropriate and the manufacturer declines all liability for any damage caused to persons, property or the unit that may derive from such use. DANGER – Place the unit in environments where there is no risk of explosion, corrosion or fire.
  • Page 11 JONIX CLIMATE – This manual represents a reminder of the main operations to be performed by operators who have received specific training, for example by attending training courses held by the manufacturer, with reference to particular maintenance operations. – This manual is to be considered an integral part of the unit and must be stored near the unit in a special container until the unit is eventually demolished.

  • Page 12: Safety Instructions

    JONIX CLIMATE 4 - SAFETY INSTRUCTIONS ATTENTION The safety instructions below should be read carefully after understanding the operation of the unit, and before proceeding with its installation, commissioning and/or maintenance. Electrical equipment must be installed, used, and maintained by qualified personnel.
  • Page 13 JONIX CLIMATE 4.1.4 Fire extinguisher and a first aid kit Check the presence and location of the fire extinguisher. Regularly check that the fire extinguishers are charged and their operating instructions are clearly understood. It is required to be aware of where the first aid box is kept.
  • Page 14 JONIX CLIMATE ATTENTION It is forbidden to tamper with or replace parts of the unit unless this has been expressly authorised by the MANUFACTURER. The use of accessories, tools, consumables or spare parts other than those recommended by the MANUFACTURER and/or specified in this manual may be a hazard to operators and/or damage the unit.
  • Page 15 JONIX CLIMATE The materials and the equipment parts used, as well as the production, quality assurance and control processes meet the highest safety and reliability requirements. By using them for the purposes specified in this user manual, by operating them with the required diligence and performing accurate maintenance and overhauling in a workmanlike manner, consistent performance and functionality and durability can be ensured.
  • Page 16 JONIX CLIMATE 4.1.12 Warning plates Before starting any maintenance operation, turn off the unit. If other people start the unit and operate the control buttons while maintenance operations are being performed, serious injury or even death may result. To avoid these dangers, before carrying out maintenance, hang caution signs around the unit.

  • Page 17: Description Of The Product And Technical Data

    13 Reverse cycle 4-way valve 6 User fan 14 Compressor 7 Electrical cable entry 15 Electrical cable entry 8 Jonix sanitizing module 16 Liquid level indicator 17 Filter 18 Electronic thermostatic valve 19 Shut-off valves on the gas line 20 Liquid separator...

  • Page 18: Operating Limits

    JONIX CLIMATE 5.2 OPERATING LIMITS 5.2.1 Temperature limits Thermal carrier Maximum pressure on high pressure side (ps) 45,0 bar Maximum operating T +46°C Minimum operating T -20°C Maximum pressure on low pressure side 28 bar-r (*) Supply voltage +/- 10% compared to plate voltage Maximum storage Temp of the unit + 55°C...

  • Page 19: Calibration Of Control Devices

    JONIX CLIMATE 5.2.2.2 JCLIMATE operating limits in heating mode 5.3 CALIBRATION OF CONTROL DEVICES 5.3.1 General description All the control devices are set and tested in the factory before the unit is dispatched. However, after the unit has been in service for a reasonable period of time you can perform a check on the operating and safety devices.

  • Page 20: Liquid Refrigerant Lines And Refrigerant Charge

    JONIX CLIMATE 5.3.2 Maximum pressure switch The high pressure switch is of the manual reset type and classifiable as category IV under 97/23 EC. It directly stops the compressor when the discharge pressure exceeds the set value. ATTENTION Any kind of block or alarm must be promptly reported to the After Sales Service! WARNING The high pressure switch must be manually reset;...
  • Page 21 Building refrigeration lines that do not comply with the instructions provided in this paragraph, or reaching a height difference greater than 10 metres without the explicit authorisation of Jonix, will result in the immediate termination of the guarantee validity. It is also necessary to provide...
  • Page 22 JONIX CLIMATE Installation of the gas line with the remote unit located higher than the indoor unit 1°÷3° 1 Indoor unit 2 Outdoor unit 3 Siphons h=200 mm Radius=2D before entering the unit 4 Siphons to recover some height throughout long horizontal lines 5 Lines gradient between 1°...
  • Page 23 JONIX CLIMATE Installation of the gas line with the remote unit located lower than the indoor unit 1 Indoor unit 2 Outdoor unit 3 Siphons h=200 mm R=2D every 5 m of height 4 Siphons to recover some height throughout long horizontal lines 5 Lines gradient between 1°...
  • Page 24 JONIX CLIMATE 5.4.1 Oil and refrigerant charge 5.4.1.1 Refrigerant charge Refrigerant charge to add, due to the length of the line (15m – 5m)* x 0.15kg/m** = 1.5kg * - Line metres ** - Addition of refrigerant per metre of line 5.4.1.2 Addition of oil...

  • Page 25: System Booklet

    JONIX CLIMATE ATTENTION A unit originally filled at the factory with a R410A refrigerant type cannot be filled with different refrigerants. WARNING It is recommended to read the Material Safety Data Sheet (MSDS) before using R410A or R454B. TOXICITY: R-410A can be safely used in all applications for which it is intended, according to the processed data of the “Program for Alternative Fluorocarbon Toxicity Testing”...

  • Page 26: Ntp Technology (Non Thermal-Plasma)

    (atoms, molecules) and to produce excited species and ions. One of the most common ways to artificially create and maintain a plasma is through an electrical discharge in a gas. With Jonix NTP technology, so-called non-thermal discharges with the dielectric barrier method are used.
  • Page 27 CLIMATE 5.6.2 A choice of value, effectiveness and sustainability Jonix Non-Thermal Plasma Technology is an extremely versatile technology that can be used to treat air and surfaces, in any type of environment, regardless of size and use (medical, professional, home, school, beauty, food, tourism and restaurants, museum).

  • Page 28: Inspection, Transport And Positioning

    JONIX CLIMATE 6 - INSPECTION, TRANSPORT AND POSITIONING 6.1 INSPECTION Upon receipt of the unit, check the integrity. The machine has left the factory in perfect condition. ATTENTION Any damage must be immediately reported to the carrier and noted on the Delivery Sheet before signing this.
  • Page 29 JONIX CLIMATE 6.2.1 Description of the safety labels A. Warning: danger due to poor familiarity with all the functions of the unit and the resulting risks. B. Read the use and maintenance manual carefully before operating the unit. Electric power supply data plate.

  • Page 30: Lifting And Conveyance

    JONIX CLIMATE WARNING In order to avoid the risks listed above it is essentially important to: A. Set the control panel according to the manufacturer’s instructions. B. Not place metal objects inside the electrical control panel. C. Not store flammable materials near the machine.

  • Page 31: Retiring The Unit

    JONIX CLIMATE 7 - RETIRING THE UNIT When the unit has reached the end of its expected working life and therefore needs to be removed and replaced, a number of precautions must be followed: – the refrigerant gas that it contains should be recovered by specialised personnel and sent to a waste collection facility;...

  • Page 32: Waste Electrical And Electronic Equipment Management

    JONIX CLIMATE ATTENTION Caution is therefore recommended during maintenance operations in order to minimise refrigerant leaks as much as possible. In any case, refer to the laws in force in the country of installation. 7.2 WASTE ELECTRICAL AND ELECTRONIC EQUIPMENT MANAGEMENT This product falls within the application scope of the Directive 2012/19/EU concerning the management of waste electrical and electronic equipment (WEEE).

  • Page 33: Installation

    JONIX CLIMATE 8 - INSTALLATION 8.1 POSITIONING AND INSTALLATION 8.1.1 Positioning and minimum spaces of respect ATTENTION The spaces indicated in the dimensional drawings must be complied with for the units to function properly and routine maintenance to be performed.
  • Page 34 ATTENTION The positioning of the unit that does not respect the minimum spaces indicated in the following paragraph without the explicit authorization of Jonix will result in the immediate voidance of the guarantee. Make sure to install the indoor unit perfectly aligned along the x-axis and y-axis.
  • Page 35 JONIX CLIMATE 8.1.2 Unit installation The weight of the indoor unit is 230 kg. Provide suitable brackets for fixing the unit as shown in the following image: You should bear in mind the following aspects when choosing the best site for installing the unit and the relative connections: –...
  • Page 36 JONIX CLIMATE 8.1.3 Condensate discharge ATTENTION Prepare a condensate drain pipe and make a siphon as shown in the following image. WARNING It is necessary to prime the siphon by pouring water into it before starting the unit. Condensate discharge of internal unit...
  • Page 37 JONIX CLIMATE ATTENTION Prepare a condensate drain pipe on the outdoor unit as shown in the following image. Condensate discharge of external unit 1 Condensate water discharge 37 - 64...

  • Page 38: Requirements For The Installation Of Units With A2L Refrigerant

    JONIX CLIMATE 8.2 REQUIREMENTS FOR THE INSTALLATION OF UNITS WITH A2L REFRIGERANT IMPROVED TIGHTNESS REFRIGERANT SYSTEMS ACCORDING TO IEC 60335-2-40:2022, REQUIREMENT 22.125 Safety of household and similar electrical appliances - Part 2: Special rules for electric heat pumps, air conditioners and dehumidifiers Refrigerant charge in the machine with refrigeration line shorter than 5 metres.

  • Page 39: Installation Scheme Of The Units

    JONIX CLIMATE 8.3 INSTALLATION SCHEME OF THE UNITS Follow the directions below to install the units. Indoor unit installation Indoor unit power supply line derived from the outdoor unit 5G1,5 mm . Indoor unit signals derived from 8x1 outdoor unitmm .
  • Page 40 JONIX CLIMATE Outdoor unit installation Indoor unit power supply line derived from the outdoor unit 5G1,5 mm . Indoor unit signals derived from 8x1 outdoor unitmm . Sanitizer power supply (optional) derived from the external unit 2x1.5 mm 2 Refrigerant fluid delivery/return line GAS 28x1.5; LIQUID 16x1.

  • Page 41: Control And Safety Devices

    JONIX CLIMATE 8.4 CONTROL AND SAFETY DEVICES All control equipment is calibrated and tested at the factory before shipping the machine. However, after the unit has been operating for a reasonable period of time, it is advisable to check the operating and safety devices.
  • Page 42 JONIX CLIMATE High pressure switch The high pressure switch stops the compressor when the outlet pressure exceeds the set value. To check its operation, shut the air flow in the condensers the with the compressors running, and check on the compressor delivery pressure gauge (previously installed) that the pressure switch (compressor stop) is activated when the calibration value is reached.
  • Page 43 JONIX CLIMATE On and off timing The compressor switching on and off timing schedules programmed by the manufacturer on the units guarantee correct operation of the compressors and an increased durability and stability of the system. They establish: – the minimum activation time of a compressor, which must remain on for a time equal to the set time;...
  • Page 44 JONIX CLIMATE Example – One compressor switches off – Evaporation temperature increases – Overheating decreases – Valve closes – Refrigerant flow decreases – Refrigerating power decreases – Evaporation temperature decreases …and so on… 2÷3 min If, on the other hand, there is an electronic expansion valve (2), in case of a compressor switch on or off request: –...

  • Page 45: Electrical Connections

    JONIX CLIMATE 9 - ELECTRICAL CONNECTIONS 9.1 GENERAL DESCRIPTION ATTENTION The electrical connections must be carried out by qualified personnel. WARNING All connections must comply with the regulations imposed in the country of installation. Upstream of the unit’s power supply, an adequate sectioning unit must be provided, located near the unit, considering the electrical absorption indicated in the wiring diagram supplied with the unit and on the data plate.

  • Page 46: Connection Terminal Board Between Internal And External Unit

    JONIX CLIMATE ATTENTION The unit must operate within the above values, or the warranty will be invalidated. Carry out the electrical connections following the wiring diagram provided with the unit, as well as current regulations. ATTENTION Regarding the differential protection that needs to be installed upstream, it is necessary to use a type B switch that is sensitive to direct currents.

  • Page 47: Remote Summer-Winter Switching

    JONIX CLIMATE 9.4 REMOTE SUMMER-WINTER SWITCHING If you wish to include a remote control for summer/winter switching of the unit, you must remove the bridge between the contacts indicated in the wiring diagram and connect the remote control to the terminals themselves [see annexed wiring diagram].
  • Page 48 JONIX CLIMATE The user interface, PCO, consists of an LCD display and 6 keys. All the program operations can be run, the conditions of the operating unit can be displayed at any time and the parameters can be modified. The 6 keys and their use are described in the following table:...
  • Page 49 JONIX CLIMATE Icon Description Press the ALARM key to access the alarm list. The button lights up with red ALARM LED when an alarm is triggered. PROGRAM Press PRG to access the main menu. Press ESC to go back to the main menu or to the main mask.

  • Page 50: Start-Up

    JONIX CLIMATE 10 - START-UP 10.1 PRELIMINARY CHECKS – Check that all the valves in the cooling circuit are open. – Check that the electrical connections have been made properly and that all the terminals are securely tightened. – This check should also be included in a periodic sixmonth inspection.

  • Page 51: Start-Up The Unit

    JONIX CLIMATE ATTENTION Consult the manuals supplied for all maintenance and/or advanced set-up operations. WARNING The commissioning of the unit must comply with the statutory regulations of the State where the machine is installed. The responsibility for correct use is exclusively ascribable to the user.
  • Page 52 JONIX CLIMATE ATTENTION The unit will start if there are no active alarms; otherwise, reset the alarm to enable the start-up. WARNING If the unit fails to start up, check whether the service thermostat has been set at the rated calibration values.

  • Page 53: Selecting The Operating Modes

    JONIX CLIMATE WARNING If one or several options among the ones listed in this paragraph have been activated, all the selected sources must provide their consent to switch on the unit. 10.3 SELECTING THE OPERATING MODES The active mode of the utility is indicated in the status bar on the main mask. The following table summarises the possible indications: Pos.
  • Page 54 JONIX CLIMATE Select from digital input If selection from a digital input has been enabled, the input must be closed (with inverse logic) so that the unit can be set to summer mode (open with direct logic). In summer mode, the unit is adjusted to produce cold air, and in winter mode, hot air.

  • Page 55: Setting The Set-Points

    JONIX CLIMATE 10.4 SETTING THE SET-POINTS To change the working set-point, select from the main control menu the icon “thermometer” and press ENTER. Once you have entered the setting template: 1. Use the ENTER key to select the setpoint to edit;...

  • Page 56: Stopping The Unit

    JONIX CLIMATE – Make sure the overheating of the cooling fluid is limited to between 5 and 8 °C. To this end: 1. detect the temperature indicated by a contact thermometer placed on the compressor intake pipe; 2. read the temperature indicated on the scale of a pressure gauge likewise connected to the intake side;...

  • Page 57: Routine Maintenance And Checks

    JONIX CLIMATE 11 - ROUTINE MAINTENANCE AND CHECKS ATTENTION The only tasks to be performed by the end user are turning the chillers on and off and switching them between the cooling and heating functions as the seasons change. All other operations are maintenance tasks and must be performed by qualified personnel who are able to operate according to the laws and regulations in force.

  • Page 58: Maintenance Table

    JONIX CLIMATE 11.2 MAINTENANCE TABLE To make sure performance remains constant in time, it is recommended to respect the following maintenance and control schedu.le in addition to what is required by the regulations in force. Activity Frequency Check the efficiency of all the control and safety devices.

  • Page 59: Refrigeration Circuit Repairs

    JONIX CLIMATE For the CO2 Teqs contained in the equipment, refer to the identification label supplied with it. WARNING In Italy the booklet is regulated by the D.P .R. 146/2018. 11.3 REFRIGERATION CIRCUIT REPAIRS ATTENTION While performing repairs on the cooling circuit or maintenance work on the compressors, make sure the circuit is left open for as little time as possible.

  • Page 60: Troubleshooting

    JONIX CLIMATE 12 - TROUBLESHOOTING 12.1 UNIT ALARM ATTENTION If an alarm is triggered and the ALARM button lights up, do not press the ALARM button reset the alarm and immediately contact our After Sales Service. For the fill list of alarms, refer to the documentation enclosed with the unit.

  • Page 61: Safety Data Sheet Of Refrigerant

    JONIX CLIMATE 13 - SAFETY DATA SHEET OF REFRIGERANT For refrigerant fluid safety data sheet, please refer to the documents supplied with the unit. 14 - MAINTENANCE TABLE Fill in the following table to keep the track of the maintenance carried out:...

  • Page 62: Notes

    JONIX CLIMATE NOTES ..........................................................................................................................................................................................................................................................................................................................................................................................................................62 - 64...
