- Page 1 PRO DMX FAN User Manual...
-
Page 2: Notes Before Use
1. Notes Before Use • Before connecting to power, check if the voltage indicated on the machine matches your local AC voltage. Always connect to a grounded circuit to safeguard yourself. • Only use in a well-ventilated area. Leave a gap of at least 30cm around the unit. To get the best results, don't put anything in front of the fan. -
Page 3: Operation And Indication
3. Operation and indication 3.1 Interval of fan output Interval set XXXs Press the FUNCTION key, until the display reads . Set the value with the UP and DOWN keys. The S indicates the interval in seconds, value range 5~999s; M means interval in minutes, value range 1~999s. - Page 4 4. Timer And CH mode When TIMER DMX function is ON, there will be 3 DMX control channels. When turned OFF, there will instead be 1 DMX control channel. Channels when mode is turned ON: Channel 1: Fan speed Channel 2: Interval time (X-10min or X-10sec. X is the parameter chosen by DMX board. The parameter is only available starting from 10 on the console.) Channel 3: Duration (X-10min or X-10 sec.
-
Page 5: Technical Specifications
6. Technical Specifications Power AC 230V, 50~60Hz, 0.95A Fuse Power Consumption 200W 2100 r/min MAX Air flow 34m³/min MAX Noise 70dB max. (1m in front of machine) Gross Weight 10KGS Dimension 415*280*458(mm) Carton Dimension 460*430*400(mm) DMX channels 3 channels, 1 for fan output volume adjust, 2 for timer, 3 for duration Control DMX 5 PIN, LCD timer control, wireless receiver Accessories...
