Seal&Cut

MV1

INSTRUCTION & SERVICE MANUAL

Table of Contents

Need help?

Do you have a question about the Seal&Cut MV1 and is the answer not in the manual?

Questions and answers

Sarah

May 9, 2025

I am having trouble getting the sealer to work. No issues with the pin but the sealer keeps not wanting to work. I’m sure there is just something I am doing incorrectly. Thanks in advance

1 comments:

Mr. Anderson

May 19, 2025

If the Mano Médical Seal&Cut MV1 sealer is not working properly, follow these troubleshooting steps:

1. Observe the system display for an error code when the alarm sounds.
2. Note the error code and refer to the error table for its description and recommended action.
3. For key-related errors (codes 501–505):
- Turn OFF and then ON the generator.
- Do not press any key during self-test.
- Disconnect all accessories if the alarm repeats.
- Check or connect the ribbon cable between the display board and front panel.
- Replace the front keypad if needed.
- If the issue persists, contact technical support.
4. For switch-related error (code 601):
- Turn OFF and then ON the generator.
5. Perform general troubleshooting by identifying the malfunction and correcting it as described.

The system will not function until the error condition is resolved.

This answer is automatically generated

Summary of Contents for Mano Médical Seal&Cut MV1

Page 1 Seal&Cut INSTRUCTION & SERVICE MANUAL...
Page 2 USER GUIDE | Seal&Cut Version: 1.1 This document is a user guide for Mano Medical’s Seal&Cut MV1 Electrosurgical unit. This guide is intended to be used as a reference for a qualified and trained physician, surgeon or veterinary professional. This instrument is electrically hazardous. Any user operating this generator or technician consulted for servicing should read this user manually thoroughly.
Page 3: Electrical Hazard
USER GUIDE | Seal&Cut Version: 1.1 Symbols used in this document Warning Explains the possible damage which may occur to the machine OR minor injuries to person. Electrical Hazard Explains the possible risk associated with personal injury or death. Do Not Enter Explains actions by which the possible damage which may occur to instruments associated with machine and/or others so, should be prohibited.
Page 4 USER GUIDE | Seal&Cut Version: 1.1 INDEX 1. Introduction A. General Features B. Modes of Electrosurgery Monopolar Electrosurgery Bipolar Electrosurgery 2. Safety Instructions 3. Controls, Indicators & Output sockets A. Front Panel B. Rear Panel C. Welcome screen D. System Setting E.
Page 5: General Features
USER GUIDE | Seal&Cut Version: 1.1 CHAPTER 1 Introduction Mano Médical Seal&Cut MV1 Electrosurgical Generator provides necessary power for different types of surgical needs in Monopolar and Bipolar applications with multiple options of cut & coagulation effects with following features: A.
Page 6: Monopolar Electrosurgery
USER GUIDE | Seal&Cut Version: 1.1 B. MODES OF ELECTROSURGERY Monopolar Electrosurgery: In Monopolar electrosurgery, only one pole, active electrode is in the surgical site. An electric current from the generator is delivered to the surgical site through an active electrode & returned to generator via patient return electrode.
Page 7: Safety Instructions
USER GUIDE | Seal&Cut Version: 1.1 CHAPTER 2 Safety Instructions Read all the warnings and cautions provided with this generator before using. Hazardous Electrical Output: This instrument is to be used only by trained, licensed physician/surgeon. If the patient has an internal pacemaker, an internal cardiac defibrillator, or any kind of orthopedic implant, consult the manufacturer of the pacemaker, defibrillator or orthopedic implant for instructions before performing an electrosurgical procedure.
Page 8 USER GUIDE | Seal&Cut Version: 1.1 • Do not activate the generator, before touching the active electrode to the tissues, electrical arcs may be created. • Do not activate the generator in an open circuit condition. Do not short Active electrode with return electrode.
Page 9 USER GUIDE | Seal&Cut Version: 1.1 • Check if the earthing of power source in surgical room is correct. Make sure equipment chassis or cabinets are grounded. Never cut off or reverse the ground connection on a plug. • Please check if power from the main line (AC) is within the specified range as required for proper functioning of the generator.
Page 10 USER GUIDE | Seal&Cut Version: 1.1 Radio Frequency Burns: Warnings- • Keep the monitoring equipment electrode as far away as possible from electrosurgical site to reduce the risk of inadvertent electrosurgical burn. • Avoid skin-to-skin contact points such as fingers touching leg. Use dry cloth between contacts. •...
Page 11 USER GUIDE | Seal&Cut MV1 Version: 1.1 Vessel Sealing: Warnings- • Make use of appropriate Foot Switch for vessel sealing operation; perform manual settings when using single paddle Foot Switch. • Use appropriate power; apply adequate pressure on tissue before activating sealer. •...
Page 12 USER GUIDE | Seal&Cut MV1 Version: 1.1 Hemostat Buzzing: - Warnings- • It is not recommended to use hemostat buzzing method. • If using hemostat buzzing, firmly grip as much of the area hemostat as possible. • Touch the active electrode on the area of hemostat, which is closest to the patient. •...
Page 13: Front Panel
USER GUIDE | Seal&Cut MV1 Version: 1.1 CHAPTER 3 Controls, Indicators & Output Sockets A. FRONT PANEL Bipolar Socket: Accepts PREM Contact/Contact indicator: the standard 4mm bipolar It indicates the contact adequacy Back /Select interface cables. Active using process bars (Green) or gives Button HF cord in one hole &...
Page 14 USER GUIDE | Seal&Cut MV1 Version: 1.1 Key Symbol Key Functions (On the Main Screen) • On the main screen, use the Up / Down Key to navigate vertically between modes. • When in a particular “Mode” of a surgical procedure; the Up and Down key will increase/ decrease the power of the selected mode.
Page 15: Rear Panel
USER GUIDE | Seal&Cut MV1 Version: 1.1 B. REAR PANEL Heat Sink: Power Socket: To supply AC Volume Control: To adjust Do not place anything (230V / 50Hz) or (110V/60 Hz) volume of activation tones. near heat-sink to allow power to ESU. Please Note: Alarm volumes proper cooling of the are not adjustable...
Page 16: Welcome Screen
USER GUIDE | Seal&Cut MV1 Version: 1.1 C. WELCOME SCREEN Once the generator is turned ON successfully, Screen1 will be displayed. Select the check box after reading the instruction manual and press the “Proceed” button, Screen 2 will appear if ―Factory Reset‖ option was selected in ―Startup‖...
Page 17: System Setting
USER GUIDE | Seal&Cut MV1 Version: 1.1 D. SYSTEM SETTING Press Setup option from Main screen to enter into System setting option. Screen1 will be displayed. Select the desired option by selecting the relevant icon one the left hand side of the System setting screen.
Page 18 USER GUIDE | Seal&Cut MV1 Version: 1.1 Pulse Bi-cut Configuration: Used for selecting the output socket for Pulse Bi Cut mode. For Pulse Bi-Cut two modes are available. SEALER/BIPOLAR. Socket Selection will be decided according to user needs. Screen 4 will be displayed after pressing on Pulse BiCut from Screen 1: System Setting.
Page 19 USER GUIDE | Seal&Cut MV1 Version: 1.1 Function Time Setup (optional) User can set the time period of HF output and bipolar auto delay using Function Time Setup. SCREEN 7 How to set Time Out Function User may ensure that HF output is not activated unintentionally for a long period of time by using the Time Out Function.
Page 20 USER GUIDE | Seal&Cut MV1 Version: 1.1 Startup Press the Previous Activated key on the display to get the previously used settings every time the unit starts. Press the “Standby” option to disable any inputs and outputs from the generator. The generator will not respond to any sort of activation in standby mode.
Page 21 USER GUIDE | Seal&Cut MV1 Version: 1.1 E. How to select Power & Mode STEP 1: Enter the desired mode just by touching its icon as shown in SCREEN 1 & 2. Select sub-modes using Touch Selective Icons (SCREEN2). STEP 2: Once desired sub-mode (procedure) is selected, increase/decrease the power using on-screen or front panel keypad’s up/down arrow keys to.
Page 22 USER GUIDE | Seal&Cut MV1 Version: 1.1 F. How to set Auto Bipolar Mode (Optional feature) STEP 1: Enter the Auto Bipolar mode by touching its icon as shown in Screen 3 & 4. Green light indicates activation of Auto Bipolar mode. STEP 2: Select sub-modes using horizontal scroll keys (Refer Screen 3).
Page 23: Program Manager
USER GUIDE | Seal&Cut MV1 Version: 1.1 G. Program manager Program manager gives users the ability to edit, load & store custom user programs. Press the tab from main screen to enter Program Manager. User can load any program by selecting Program and pressing the Load button.
Page 24 USER GUIDE | Seal&Cut MV1 Version: 1.1 H. How to set Rapid Seal mode Main screen STEP1: Go to Click BIP COAG mode. STEP2: RAPID SEAL mode. STEP3: Press Génia USA – +1 (917) 797-6521 – contact@geniausa.com...
Page 25: Technical Specifications
USER GUIDE | Seal&Cut MV1 Version: 1.1 CHAPTER 4 Technical Specifications A. GENERAL SPECIFICATIONS Output Configuration: Isolated output with cardiac defibrillator protection. Duty Cycle of Operation: At maximum rated load conditions, pure cut-400 watt setting at 300 Ω. The system is suitable for activation time of 10 seconds ON, 30 seconds OFF for one hour. Cooling: Natural by convection: By side and rear panel vents.
Page 26 USER GUIDE | Seal&Cut MV1 Version: 1.1 Voltage Transients (Emergency Generator Mains Transfer) The Mano Médical Seal&Cut MV1 operates in a safe manner when the transfer is made between line AC and an emergency generator voltage source. Defibrillator Proof The Mano Médical Seal&Cut MV1 meets specifications for ―Defibrillator proof design. Dimensions and Weight Length: 38.0 cm Width: 31.5 cm...
Page 27: Low Frequency (50 - 60 Hz) Leakage Current
USER GUIDE | Seal&Cut MV1 Version: 1.1 Low Frequency (50 - 60 Hz) Leakage Current: Source current, patient leads, all outputs: Normal polarity, intact ground: <10A Normal polarity, ground open: <50  Reverse polarity, ground open: <50 Enclosure source current, ground open: <300A igh Frequency (RF) Leakage Current Monopolar (RF) leakage current: <...
Page 28: Output Characteristics
USER GUIDE | Seal&Cut MV1 Version: 1.1 C. OUTPUT CHARACTERISTICS Maximum Output for Bipolar and Monopolar Modes Power readouts reflect with actual power into rated load to within 20% or 10watts, whichever is greater. Mode Open Circuit Rated Load Power(max) Crest Factor (in Ωs) P-P Voltage...
Page 29: Area Of Application
USER GUIDE | Seal&Cut MV1 Version: 1.1 Blend 390 kHz bursts of sinusoid, recurring at 29 kHz intervals. 55% duty cycle envelope Endo 390 kHz sinusoid with moderate pulse interval Monopolar Coag Soft 460 kHz damped sinusoid repeated at 84 kHz. 20% duty cycle Swift 460 kHz damped sinusoidal repeating at 42 kHz Fulgurate...
Page 30 USER GUIDE | Seal&Cut MV1 Version: 1.1 F. OUTPUT POWER VS. LOAD GRAPHS M o n o p o la r L o w C u t M o d e 3 2 5 3 0 0 2 7 5 2 5 0 2 2 5 2 0 0...
Page 31 USER GUIDE | Seal&Cut MV1 Version: 1.1 Monopolar BlendCut Mode 125W 250W Load Resistance ( ohms ) Monopolar Coag - Soft 150W Load Resistance ( ohms ) Génia USA – +1 (917) 797-6521 – contact@geniausa.com...
Page 32 USER GUIDE | Seal&Cut MV1 Version: 1.1 Monopolar Coag - SWIIFT 120W Load Resistance ( ohms ) Monopolar Fulgurate Mode Load Resistance ( ohms ) Génia USA – +1 (917) 797-6521 – contact@geniausa.com...
Page 33 USER GUIDE | Seal&Cut MV1 Version: 1.1 Bipolar Mode - Bicut/Macro 50 watt 100 watt Load Resistance ( ohms ) Bipolar Mode - Micro Load Resistance ( ohms ) Génia USA – +1 (917) 797-6521 – contact@geniausa.com...
Page 34 USER GUIDE | Seal&Cut MV1 Version: 1.1 Bipolar Mode - Standard Load Resistance ( ohms ) MONOPOLAR COAG SPRAY 120 WATT 60 WATT Load Resistance ( ohms ) Génia USA – +1 (917) 797-6521 – contact@geniausa.com...
Page 35 USER GUIDE | Seal&Cut MV1 Version: 1.1 Bipolar Mode - Force 50 watt 100 watt Load Resistance ( ohms ) SEALER L1 - L3 Load Resistance ( ohms ) Génia USA – +1 (917) 797-6521 – contact@geniausa.com...
Page 36: Before Surgery
USER GUIDE | Seal&Cut MV1 Version: 1.1 CHAPTER 5 Before Surgery Electric Shock Hazard: Warning - Never remove the cover of the instrument. Before Surgery: Caution - Read all the Warnings, Cautions provided with this generator before using. Active accessories: Electric Shock Hazard: Warning - Avoid connection of wet accessories to the generator.
Page 37 USER GUIDE | Seal&Cut MV1 V Version: 1.1 C. CONNECTIONS Program Mode Settings for Surgeries: For Monopolar surgery, insert foot switching or hand switching accessory in socket on front panel and connect foot switch in Foot Switch socket on the rear panel. Also connect patient return electrode in front panel socket.
Page 38 USER GUIDE | Seal&Cut MV1 Version: 1.1 For bipolar surgery, insert bipolar instrument in bipolar front panel socket and foot switch in foot switch socket on the rear panel. For vessel sealing surgery, insert bipolar handle or sealer handle accessory in socket on front panel and connect foot switch in foot switch socket on the rear panel.
Page 39 USER GUIDE | Seal&Cut MV1 Version: 1.1 For sealing and cutting, insert desiccator in the socket on front panel, connect foot switch in foot switch socket on the rear panel and select Pulse Bi-cut option in cut mode and L2/L3 in coag mode.
Page 40 USER GUIDE | Seal&Cut MV1 Version: 1.1 Open Clamp for Sealer Mode Hand Switching Pencil Cut Switch Coag Switch HAND During normal Monopolar operation, Hand Switching electrode (Pencil) can be used for Monopolar Cut and Monopolar Coagulation operations. Pressing yellow button will activate Monopolar Cut output and pressing blue button will activate Monopolar Coagulation output.
Page 41: During Surgery
USER GUIDE | Seal&Cut MV1 Version: 1.1 CHAPTER 6 During Surgery Electric Shock Hazard: Warning - Never remove the cover of instrument. Generator Power Settings Warning - Use lowest power setting for desired surgical effect. Warning - Do not increase the power settings without first checking both active electrode & patient return electrode &...
Page 42 USER GUIDE | Seal&Cut MV1 Version: 1.1 (ii) Changing the Power Setting: Operator should verify the power setting for the selected mode with the surgeon. The power setting cannot change when the generator is activated.. To increase the power, press the up arrow key for the selected mode.
Page 43: Alarm Conditions
USER GUIDE | Seal&Cut MV1 Version: 1.1 E. ALARM CONDITIONS The following conditions can generate a PREM alarm: 1. The patient return electrode is not connected to the generator when the generator is activated for monopolar surgery. 2. The return electrode does not have adequate contact with the patient. 3.
Page 44: After Surgery
USER GUIDE | Seal&Cut MV1 Version: 1.1 CHAPTER 7 After Surgery Electric Shock Hazard: Warning - Never remove the cover of instrument. After Surgery: Electric Shock Hazard Warning - Always turn off & unplug the generator before cleaning. Caution - Do not clean the generator with abrasive cleaning that could damage the generator.
Page 45: Storing The Generator
USER GUIDE | Seal&Cut MV1 Version: 1.1 6. Brush the surfaces using soft brush. Handle cord connectors, fittings and joints with care. 7. Use the soft brushes in up and down motion to clean completely through the lumen. 8. Compressed air can be used for flushing if a precise nozzle is available and if the pressure can be controlled.
Page 46: Operating Principle
USER GUIDE | Seal&Cut MV1 Version: 1.1 CHAPTER 8 Operating Principle Operating Principle: This section will emphasize on the working principle of the system. • General description • Block diagram • Detailed description A. GENERAL DESCRIPTION 6SENSE Technology: This is a recent innovation in field of advance feedback controlled electrosurgical technology. The system maintains the set power by sensing- voltage, current, power, tissue density, patient return electrode monitoring and leakage RF current- at 4000 times per second.
Page 47: Block Diagram & Description
USER GUIDE | Seal&Cut MV1 Version: 1.1 Auto Bipolar: This is the unique feature of which system can deliver automatic bipolar output by sensing the tissue & stopping the power delivery when tissue gets completely coagulated. This function can work in all three bipolar modes. Auto start delay can also be adjusted. The steps to enable this mode are explained in Chapter 3, Section D- How to select power &...
Page 48: Circuit Board Description
USER GUIDE | Seal&Cut MV1 Version: 1.1 Circuit Board Description: CPU and Display Board: Processor and control board consists of – 1. Main microcontroller: IC U02 is main microcontroller and brain of the system, which controls overall function of a system using inbuilt I/O ports. U02 a built in program memory to store the system’s programs.
Page 49 USER GUIDE | Seal&Cut MV1 Version: 1.1 Power Supply and RF Main Board: This board can be divided in two parts, main power supply and output RF stage. This board circuitry also supports RF power delivery, hand switching logic, PREM and all other sense circuits. •...
Page 50 USER GUIDE | Seal&Cut MV1 Version: 1.1 • Audio circuit: Circuit generates different audio tones for cut, coag and bipolar activation. It gives two pulse outputs for ERROR conditions. Audio oscillator & driver stage comprises of U18 to U20. Signals are fed to speaker SPK 01 &...
Page 51: Testing Procedures
USER GUIDE | Seal&Cut MV1 Version: 1.1 CHAPTER 9 Testing Procedures Electric Shock Hazard - the generator power cord must be connected with only a properly Warning- grounded socket. Do not use power plug adaptors. Fire Hazard - Do not use extension cords. Warning- Do not stack equipment on top of the Mano Médical Seal&Cut MV1 or do Caution -...
Page 52 USER GUIDE | Seal&Cut MV1 Version: 1.1 Handle circuit boards by their nonconductive edges. Use an antistatic container for transport of electrostatic-sensitive components and circuit boards. The summary of safety checks: Inspect the generator and accessories. Inspect the internal components. Test the generator.
Page 53: Checking The Bipolar Output
USER GUIDE | Seal&Cut MV1 Version: 1.1 3. In case of damage or corroded foot switch connector, replace the foot switch connector. If found appropriate, reassemble the foot switches connector. 4. Inspect the foot switches for damage. 5. In case of damage foot switch, replace the Foot Switch. If found appropriate, reconnect the foot switches to the generator.
Page 54 USER GUIDE | Seal&Cut MV1 Version: 1.1 7. Set the foot switch in bipolar mode by pressing toggle switch provided on the top side off foot switch or by enabling the foot switch icon in the mode & power setting window. (Visible indication provided for foot switch selection on LCD display) 8.
Page 55: Checking Low Frequency Leakage Current And Ground Resistance
USER GUIDE | Seal&Cut MV1 Version: 1.1 7. Release the foot switch pedal. 8. Based on the voltmeter setting and the current transformer you are using calculate and record the output current. 9. Select Press the Fulgurate mode and repeat step 4. 10.
Page 56 USER GUIDE | Seal&Cut MV1 Version: 1.1 Output Socket and PREM Source Current 1. Set the DVM to AC volts (200 mV) and connect the leakage current test circuit. 2. Turn on the generator. 3. Measure between all the output sockets (including the PREM Patient Return Electrode socket) and earth ground.
Page 57 USER GUIDE | Seal&Cut MV1 Version: 1.1 Equipment • 200 Ω, 250 watt, noninductive resistor • Current transformer • True RMS voltmeter (Fluke 8920 or equivalent) • Dual paddle toggle (Bipolar/monopolar) foot switches and hand switching accessories • Leakage setup per INTERNATIONAL ELECTROTECHNICAL COMMISION 60601-2-2 clause 19.101 or 19.102 Checking Monopolar High Frequency Leakage Current 1.
Page 58: Calibration Procedures
USER GUIDE | Seal&Cut MV1 Version: 1.1 CHAPTER 10 Calibration Procedures Calibrating the Mano Médical Seal&Cut MV1 For normal running Mano Médical Seal&Cut MV1, program requires data constants, which are dependent on the hardware. All this data is stored in NV RAM after the calibration process is completed. Calibration is recommended after: •...
Page 59 USER GUIDE | Seal&Cut MV1 Version: 1.1 (Calibration Mode Screen) Calibration Step1 - PREM Calibration Equipment: • PREM plug (modified) • Resistor substitution box Procedure: 1) Select mode ‗1:1 REM min’. 2) Connect PREM plug in the PREM socket and connect appropriate substitution resistor as indicated by ‗Load R’, across the PREM socket.
Page 60 USER GUIDE | Seal&Cut MV1 Version: 1.1 A - Close Loop Current Calibration Sub step-1(BIP mode) Equipment • Dual paddle toggle foot switch. a) Small test cables with banana plugs b) True RMS current meter c) 50 Ω non-inductive power resistor. Verify: a) The display shows calibration mode 2:1.
Page 61 USER GUIDE | Seal&Cut MV1 Version: 1.1 3) Disconnect the test cables from Monopolar output. Sub step- 3 (Blend Mode) Equipment • Dual paddle toggle foot switch. a) Small test cables with banana plugs & PREM plug. b) True RMS current meter c) 50 Ω...
Page 62 USER GUIDE | Seal&Cut MV1 Version: 1.1 2) Check and adjust the V-max for bipolar output. a) Press the coag foot switch pedal & check if current reading is equivalent to 158 mA ± 5 mA RMS. b) Stop activation. If the output current is high decrease fire counts by pressing down key. I f low increase it by pressing up key.
Page 63 UUSER GUIDE | Seal&Cut MV1 Version: 1.1 Procedure: 1) Connect: a) One test cable from Monopolar socket in series with RMS current meter to 3000 Ω resistor. b) Another test cable from PREM socket to 3000 Ω resistor. c) Dual paddle toggle foot switch to the foot switch socket on the rear panel. 2) Check and adjust the V-max for Monopolar Blend output.
Page 64 UUSER GUIDE | Seal&Cut MV1 Version: 1.1 Verify: a) The display shows calibration mode 4:2. b) Resistor substitution box must of 300Ω. Procedure: 1) Connect: a) One test cable from Monopolar socket in series with RMS current meter to 300 Ω resistor. b) Another test cable from PREM socket to 300 Ω...
Page 65 USER GUIDE | Seal&Cut MV1 Version: 1.1 d) When reading is in stated range, press Write Counts for storing corresponding fire count reading in the system memory. 3) Disconnect the test cables from Monopolar output. D - Open Loop Power Calibration (Econ) (Soft/Swift/Fulgar/Spray) Equipment: •...
Page 66 USER GUIDE | Seal&Cut MV1 Version: 1.1 Verify : a) Mode displayed on the screen is 6: ‗x’ ( x may be 1,2,3,4 as per chosen mode) b) Resistance of connected resistance substitution box 5000Ω Procedure: 1) Connect: a) One test cable from socket PREM plug to 5000 Ω. b) Another test cable from Monopolar socket passes through true RMS current meter to 5000Ω.
Page 67: Care, Storage And Disposal
USER GUIDE | Seal&Cut MV1 Version: 1.1 CHAPTER 11 Care, Storage and Disposal After each use, perform the following cleaning procedures immediately. If cleaning is delayed, debris encrustation may become a source of infection. Encrustation may also result in electrosurgical unit malfunction.
Page 68 USER GUIDE | Seal&Cut MV1 Version: 1.1 11.3 CARE OF MAINS CABLE CAUTION The cable should not be sterilized by EtO gas or autoclaving. These methods will cause deformation and damage that will render the cable useless. Ensure that foreign matter does not enter the main cord end connection as this will result in poor connection.
Page 69: Troubleshooting
USER GUIDE | Seal&Cut MV1 Version: 1.1 CHAPTER 12 Trouble Shooting Trouble shooting If the generator is not functioning properly, use the information in this section to perform the following tasks: Identify and correct the malfunction. If a system alarm number is displayed, take the appropriate action to correct the alarm conditions. Inspecting the Generator If the Mano Médical Seal&Cut MV1 generator malfunctions, check for obvious conditions that may have caused the problem:...
Page 70 USER GUIDE | Seal&Cut MV1 Version: 1.1 Replace the front panel assembly. An alarm condition exists The generator Check the display for an alarm number. Note the is on, but did number and refer to Responding to System Alarms in this section.
Page 71 USER GUIDE | Seal&Cut MV1 Version: 1.1 Blown fuse on Main RF board Check the high voltage power supply fuse (F02) and Replace if necessary. If the indicator bar does not illuminate and the tone CPU board malfunction does not sound, replace the CPU board. High voltage power supply If high voltage is not present on the Main RF board, malfunction (high voltage is...
Page 72 USER GUIDE | Seal&Cut MV1 Version: 1.1 Check all connections to the generator. Intermittent connections Pacemaker metal-to-metal sparking It may be necessary to reprogram the pacemaker. Use bipolar instruments, if possible. If you must use a interference Current traveling from active to return electrode during...
Page 73 USER GUIDE | Seal&Cut MV1 Version: 1.1 B. RESPONDING TO ERROR CODES When a system alarm condition exists, an alarm tone sounds and the display indicates error code number. System will not work till error condition is cleared. Alarm conditions require some action to correct it. Following screen shows the error window.
Page 74 USER GUIDE | Seal&Cut MV1 Version: 1.1 Error Code Description Recommended Action • Turn OFF and again turn ON the generator. Up Key may be Stuck Do not press any Key during self-test. • If the alarm repeats, disconnect all Down Key may be Stuck accessories.
Page 75: Warranty
USER GUIDE | Seal&Cut MV1 Version: 1.1 Warranty Mano Médical warrants each product manufactured by it to be free from defects in material and workmanship under normal use and service for the period. Mano Médical’s obligation under this warranty is limited to the repair or replacement, at its sole option, of any product, or part thereof, which has been returned to it or its Distributor within the applicable time period shown below after delivery of the product to the original purchaser, and which examination discloses, to company’s satisfaction, that the product is defective.
