Geti GPR170 Quick Start Manual

Multifunctional animal repeller Geti GPR170
06430158
In order to guarantee appropriate operation, please read these operating in-
structions including safety information completely and carefully before use!
1) Product description
2) Applicability
Geti GPR170 repeller is an ideal way to get rid of uninvited animal visitors in
your garden. Animals have a hard time adjusting to unpleasant sounds and
harsh light, so it is very effective at repelling them.
3) Battery or adapter installation
Battery
1. Unscrew the screws and open the battery
2. Insert the 9 V battery in the battery
Down
3. Close the battery cover.
4. Screw the screws back on.
Adapter
Up
1. Take out the rubber cap.
2. Insert 9V DC adapter to a main socket.
Battery cover
4) Assembly
1. Push down sliding lost.
2. Connect the 2 pcs of aluminium tubes.
3. Insert the aluminium tube into
Connector
Microcomputer control switch
Push-and-pull rod
DC power supply sockets
Aluminium tube 1
Aluminium tube 2
cover.
compartment.
the Push–and–pull rod.
5) How does it work
1. Choose required mode.
2. Internal sensors detect moving animals (dogs, cats, etc.) as soon as they
enter the field of detection.
3. The required mode comes on.
6) Five working modes can be selected for diferent
environments
Yellow Green
light light
Ultrasound
LED
+ alarm
flashing
+ flashing
7) Set up
1. Plug the device into the power grid or use battery. 8 flashing LEDs indicate
that the device has been put into operation. After 2 seconds, the device
is ready for operation.
2. You can choose from five working modes according to the environment
in which the device will be used. Long press the button to enter the select-
ing mode. Then press the button shortly to choose the desired working
mode.
3. After selecting the operating mode, the device is in standby mode for
approximately 10 seconds. As soon as the passive infrared sensor detects
movement, the device will begin operating and re-enter standby after
30 seconds. This applies to the first four working modes operating at
a passive infrared angle. The fifth working mode (long-term ultrasound)
will work automatically once selected.
4. When the device is operating for approximately 10 seconds, the LED indica-
tor is automatically switched off (the device is still functional).
5. Long press the button to turn off the power supply of the device, all LEDs
will turn off and the device will stop functioning.
8) Technical parameters
Motion sensor detection: up to 8 - 10 m
●
● Infrared detection angle: 110°
● Power supply: battery 9 V or 9 V adaptor (included)
Sonic alarm frequency: around 3 kHz
●
● Ultrasonic frequency: around 20 kHz
● Sound pressure: 110 dB
IPX4
●
9) Safety warning
1. If you intend to use the device for a long period of time, it is advised to use
the 9 V adapter.
2. Do not put this device close to anyone's ear.
3. Even though the device is fully waterproof we do not recommend sub-
merging it in the water.
Environmental protection notice
This symbol on the device or the package indicates that disposal
of the device after its lifecycle could harm the environment. Do not
dispose of the unit (or batteries) as unsorted municipal waste; it
should be taken to a specialized company for recycling. This device
should be returned to your distributor or to a local recycling service.
Respect the local environmental rules.
5 working modes
Red Flashing
light red light
Ultrasound LED light lasts
+ alarm 30 seconds
Flashing
green light
Automatic
long term
ultrasound
