Summary of Contents for Kingsley BUSHRANGER BLACK MAX 55X12
- Page 2 | Black Max Compressor Page 2...
- Page 3 Congratulations on your purchase of the Bushranger® Black Max Compressor. To take full advantage of this product, please read this manual carefully before using. Retain this manual for future reference for installation and warranty. |Black Max Compressor Page 3...
- Page 4 General Operating Instructions (please read) Please read and follow the operating instructions carefully to understand and get the most from your Black Max Compressor. Important: Always operate the compressor within its maximum pressure rating. Refer to the specications section o this manual or details. Operations exceeding maximum pressure rating will result in damage to air compressor and void warranty.
-
Page 5: Maintenance
Maintenance • The air lter housing has a screw-on lid to gain access to the replaceable air lter element inside. The compressor’s perormance will be greatly reduced by a clogged lter element. Old elements should be replaced beore performance is affected. •... - Page 6 Tyre Infation Attach quick connect coupler to air compressor. Fit brass connector onto tyre valve stem. Check to make sure defator collar lock is disengaged. Turn compressor switch ‘On’ to begin infation. When desired pressure is reached turn compressor ‘O’. Hands Free Continuous Defation Fit connector onto tyre valve stem.
-
Page 7: Important Safety Instructions
Fitting Air Filter Unit The air compressor comes originally packed without the air lter unit tted Procedure: Remove the temporary protective red plug from the air inlet port. Screw in the air lter unit & hand tighten. Do not use Tefon tape or lubricants on the thread. - Page 8 Warning: To prevent injuries • Parts o this compressor will become very HOT during & immediately ater use. Do not touch any o these parts with your bare hands as you could receive a severe burn. • Never allow children to operate this compressor. Close supervision is necessary when this compressor is being used near children.
-
Page 9: Troubleshooting
Troubleshooting Problem Cause Action Compressor will not run 1. No power is reaching the 1. Make sure compressor compressor. switch is “On”. 2. Blown fuse. 2. Disconnect compressor from power source, replace use (Reer to Specications sections for correct fuse). 3. -
Page 10: Speci Cations
Specications Part number: 55X12 Description: Black Max Compressor Motor voltage: 12 Volt Motor type: Permanent Magnetic Max Working Pressure: 150 psi Max fow rate @ 0 psi (13.8V): 66 Litres per minute Max Duty Cycle: 30 mins @ 40psi @ 24°C Max. -
Page 11: Warranty
Kingsley. Any costs incurred in making a Warranty claim or returning a Product to the place o purchase are to be borne by the person making the Warranty claim unless otherwise agreed by Kingsley. Exclusions This Warranty does not cover any deect or injury caused by, or associated with improper installation or maintenance;... - Page 12 bushranger.com.au Free Call |1800 654 767 (Australia only) International |+61 2 8700 0400 Fax |+61 2 8700 0499 Email | sales@kingsleyenterprises.com.au Address | 6A Brooks Road, Ingleburn NSW 2565 | Black Max Compressor Page 12...
