L-Cube
Mounting instructions
55
701
# LC 7650
Please observe the mounting instructions for bathroom furniture with a power supply.
Instructions for use
The bathroom furniture range complies with the standards and guidelines applicable at the time of delivery and is designed for use in bathrooms.
Direct contact with water should be avoided, for example, when showering.
A power supply of 110 V – 230 V must be available on site.
We reserve the right to make technical improvements and design modifications to the products illustrated.
MAL_L-Cube_LC7650/16.02.1
55
# LC 9895
74
76
Cutout dimensions for built-in cabinets
2x 100
4x S8
4x 5,5x50
# LC 7650
74
76
360
1 4
660
4x S8
4x 4,5x100
2
