User's Manual

P/N 069538-003

Trakker Antares

241X Hand-Held Terminal

Table of Contents

Need help?

Do you have a question about the Intermec Trakker Antares 241X and is the answer not in the manual?

Questions and answers

Summary of Contents for Unova Intermec Trakker Antares 241X

Page 1 User's Manual P/N 069538-003 ® Trakker Antares 241X Hand-Held Terminal...
Page 2 Intermec Technologies Corporation 6001 36th Avenue West P.O. Box 4280 Everett, WA 98203-9280 U.S. service and technical support: 1.800.755.5505 U.S. media supplies ordering information: 1.800.227.9947 Canadian service and technical support: 1.800.688.7043 Canadian media supplies ordering information: 1.800.268.6936 Outside U.S. and Canada: Contact your local Intermec service supplier. The information contained herein is proprietary and is provided solely for the purpose of allowing customers to operate and/or service Intermec manufactured equipment and is not to be released, reproduced, or used for any other purpose without written permission of Intermec.
Page 3 c o d e 39 nuggetf Manual Change Record This page records changes to the manual. The manual was released at Revision 001. Revision Date Description of Change 8/99 This manual was revised to add the Important Data Collection Browser Information sheet, Part No. 070012-001. 2/00 This manual was revised to update the IEEE 802.11 radio parameters and make other minor changes to support firmware v6.12.
Page 4 c o d e 39 nuggetf blank...
Page 5: Table Of Contents
c o d e 39 nuggetf Contents Contents Before You Begin xv Warranty Information xv Safety Summary xv Warnings and Cautions xvi About This Manual xvi Other Intermec Manuals xix Learning About the Terminals What Are the Trakker Antares 241X Terminals? 1-3 Options for the Terminals 1-4 Accessories for the Terminals 1-5 Understanding the Terminal’s Features 1-6...
Page 6 c o d e 39 nuggetf Trakker Antares 241X Hand-Held Terminal User’s Manual Using the Terminal’s Scanner 1-23 Scanning Options 1-26 Using the Terminal for the First Time 1-27 Operating the Terminals in a Network How the Terminals Fit Into Your Network 2-3 Connecting the Terminal to a Wired Network 2-10 Choosing a Communications Protocol 2-10 Binary Protocol 2-11...
Page 7 c o d e 39 nuggetf Contents Configuring the 2415 Through the Network 3-17 Sending a Command From the DCS 300 3-17 Sending a Command From the Host 3-19 Configuring the 2415 in a UDP Plus Network 3-19 Configuring the 2415 in a TCP/IP Direct Connect Network 3-20 Transferring Files in a TCP/IP Direct Connect Network 3-23 Saving Configuration Changes to Flash Memory 3-28 Restoring the Terminal’s Default Configuration 3-29...
Page 8 c o d e 39 nuggetf Trakker Antares 241X Hand-Held Terminal User’s Manual Problems Transmitting Data Through the DCS 300 5-15 Bar Code Labels Will Not Scan 5-16 Booting and Resetting the Terminal 5-18 Booting the Terminal 5-18 Booting the Terminal on Resume 5-18 Using the Boot Menu 5-19 Resetting the Terminal 5-20 Cleaning the Scanner Window and Terminal Screen 5-21...
Page 9 c o d e 39 nuggetf Contents Serial Port Test 6-27 Subsystem Versions 6-28 Reader Command Reference Using Reader Commands 7-3 Using Accumulate Mode 7-4 Backspace 7-5 Clear 7-5 Enter 7-6 Enter Accumulate Mode 7-6 Exit Accumulate Mode 7-6 Operating Reader Commands 7-7 Backlight On and Off 7-7 Boot Terminal 7-8 Change Configuration 7-8...
Page 10 c o d e 39 nuggetf Trakker Antares 241X Hand-Held Terminal User’s Manual Configuration Command Reference Using Configuration Commands 8-3 Configuration Commands Listed by Category 8-4 Entering Variable Data in a Configuration Command 8-7 Acknowledgement Delay Lower Limit 8-8 Acknowledgement Delay Upper Limit 8-10 AP Density 8-12 AP MAC Address 8-13 Append Time 8-13...
Page 11 c o d e 39 nuggetf Contents Controller IP Address 8-51 Data Bits 8-53 Decode Security 8-54 Default Router 8-55 Display Backlight Timeout 8-57 Display Contrast 8-59 Display Font Grid Type 8-60 Display Row Spacing 8-61 Display Video Mode 8-62 Domain 8-63 Dynamic Host Configuration Protocol (DHCP) 8-65 End of Message (EOM) 8-66...
Page 12 c o d e 39 nuggetf Trakker Antares 241X Hand-Held Terminal User’s Manual MSI 8-90 Network Activate 8-92 Network Loopback 8-93 Network Name 8-94 Network Port 8-96 Parity 8-98 Plessey 8-99 Poll (Polling) 8-100 Postamble 8-101 Power Management 8-103 Preamble 8-104 Radio MAC Address 8-105 RAM Drive Size 8-106 Receive All Multicast 8-108...
Page 13 c o d e 39 nuggetf Contents Station Name 8-126 Stop Bits 8-127 Subnet Mask 8-128 Suspend/Resume Control 8-130 TCP Maximum Retries 8-131 TCP/IP Maximum Transmit Timeout 8-133 Terminal IP Address 8-135 Time and Date 8-137 Time in Seconds 8-139 Timeout Delay 8-140 Transmit Mode 8-142 Transmit Rate 8-143...
Page 14 c o d e 39 nuggetf Trakker Antares 241X Hand-Held Terminal User’s Manual Full ASCII Charts Full ASCII Table B-3 Full ASCII Bar Code Chart B-6 Control Characters B-6 Symbols and Punctuation Marks B-7 Numbers B-8 Uppercase Letters B-9 Lowercase Letters B-10 International Character Support Trakker Antares Terminal Font Set C-3 English and Western European Font Set C-3...
Page 15: Before You Begin
c o d e 39 nuggetf Before You Begin Before You Begin This section introduces you to standard warranty provisions, safety precautions, warnings and cautions, document formatting conventions, and sources of additional product information. A list of Intermec manuals is also provided to guide you in finding the appropriate information.
Page 16: Warnings And Cautions
c o d e 39 nuggetf Trakker Antares 241X Hand-Held Terminal User’s Manual Warnings and Cautions The warnings and cautions in this manual use the following format. Warning A warning alerts you of an operating procedure, practice, condition, or statement that must be strictly observed to avoid death or serious injury to the persons working on the equipment.
Page 17 c o d e 39 nuggetf Before You Begin Terminology You should be aware of how these terms are being used in this manual: Term Description Host The term “host” refers to a personal computer or other computer that communicates with the terminal. DCS 300 The term “DCS 300”...
Page 18 c o d e 39 nuggetf Trakker Antares 241X Hand-Held Terminal User’s Manual Conventions for Bar Codes You can scan the bar codes listed in this manual to enter data or perform a command. The bar code labels in this manual are printed in the Code 39 symbology. Each bar code includes the name and human-readable interpretation.
Page 19: Other Intermec Manuals
c o d e 39 nuggetf Before You Begin Conventions for Commands This manual includes sample commands that are shown exactly as you should type them on your terminal or network device. The manual also describes the syntax for many commands, defining each parameter in the command.
Page 20 blank...
Page 21: Learning About The Terminals
C o d e 39 Nugget Learning About the Terminals...
Page 22 C o d e 39 Nugget...
Page 23: What Are The Trakker Antares 241X Terminals
C o d e 39 Nugget Learning About the Terminals This chapter explains the terminals’ features, including the status LEDs, status beeps, battery pack, and drives. It also lists the options and accessories you can order. What Are the Trakker Antares 241X Terminals? The Trakker Antares 2410 and 2415 terminals are small, lightweight, hand-held data collection terminals that are designed for a range of applications, including commercial applications such as in-store retail.
Page 24: Options For The Terminals
C o d e 39 Nugget Trakker Antares 241X Hand-Held Terminal User’s Manual Options for the Terminals These options are available for the 2410: • Programmable terminal with 55-key alphanumeric, 37-key alphanumeric with large numeric, or 37-key function key with large numeric keypads. Each keypad supports overlays for English or international languages.
Page 25: Accessories For The Terminals
C o d e 39 Nugget Learning About the Terminals Accessories for the Terminals You can use these accessories (sold and ordered separately) with the terminals: Standard (Single-Cell) or High Performance (Dual-Cell) Battery Packs These lithium-ion battery packs (Part No. 069428 and Part No. 069429) provide the main power to the terminal.
Page 26: Understanding The Terminal's Features
C o d e 39 Nugget Trakker Antares 241X Hand-Held Terminal User’s Manual Understanding the Terminal’s Features This section provides an overview of the terminal’s features. The next sections provide detailed descriptions of how to use these features. CGA-compatible display Status LEDs Keypad Integrated...
Page 27: Using The Terminal's Keypad
C o d e 39 Nugget Learning About the Terminals Using the Terminal’s Keypad This table lists the terminal’s keypad options and overlays: 55-Key 37-Key Alphanumeric 37-Key Function Key Alphanumeric With Large Numeric With Large Numeric Programmable International 5250 TE 3270 TE VT/ANSI TE dcBrowser/Native TE...
Page 28: Finding The Special Keys
C o d e 39 Nugget Trakker Antares 241X Hand-Held Terminal User’s Manual Finding the Special Keys There are some special keys that are on the keypads. You will need to use these special keys with all keypad overlays. The special keys that you use to type characters or perform functions are explained in the next sections.
Page 29: Using The Suspend/Resume Key
C o d e 39 Nugget Learning About the Terminals Using the Suspend/Resume Key The Suspend/Resume key is the key in the middle of the bottom row of the keypad. When you press to turn off the terminal, the terminal does not actually shut off, but goes into a Suspend mode.
Page 30: Capitalizing All Characters
C o d e 39 Nugget Trakker Antares 241X Hand-Held Terminal User’s Manual Capitalizing All Characters To type all alphabetic characters as uppercase letters, you either press before every letter you type or you enable the Caps Lock feature. Note: You can also use the Keypad Caps Lock configuration command to enable or disable Caps Lock on the terminal.
Page 31: Using The International Keypad
C o d e 39 Nugget Learning About the Terminals Using the International Keypad Whether your terminal has an alphanumeric or a numeric keypad, you can order it with an international overlay. This overlay supports English and most Western European languages, such as French, German, Italian, Portuguese, Spanish, and others.
Page 32: Using The Te Keypads
C o d e 39 Nugget Trakker Antares 241X Hand-Held Terminal User’s Manual To type characters with a diacritical mark 1. (37-key) Press . The Modifier LED turns on. (55-key) Press . The Modifier LED turns on. 2. Press the key that the diacritical mark appears above. To Type 37-Key 55-Key...
Page 33: Using The Terminal's Serial Port
C o d e 39 Nugget Learning About the Terminals Using the Terminal’s Serial Port Serial ports, also called COM (communications) ports, are locations from which data can be passed into and out of the terminal. The terminal supports RS-232 serial communications.
Page 34: Using The Terminal's Screen
C o d e 39 Nugget Trakker Antares 241X Hand-Held Terminal User’s Manual Using the Terminal’s Screen You can use the terminal’s screen to view data, run applications, monitor the terminal’s status, and for many other functions. The screen is a backlit LCD that is CGA compatible and it has a maximum of 16 lines by 20 characters.
Page 35: Understanding The Terminal's Status Leds
C o d e 39 Nugget Learning About the Terminals Understanding the Terminal’s Status LEDs You can use the status LEDs to monitor the status of bar code scanning, of network communications, of special keys, and of battery power. The status LEDs only flash or turn on to indicate the current status.
Page 36: Understanding The Terminal's Status Beeps
C o d e 39 Nugget Trakker Antares 241X Hand-Held Terminal User’s Manual Understanding the Terminal’s Status Beeps The terminal has a beeper that provides you with audio feedback as you use the terminal. For example, you hear a beep tone each time you enter or scan a valid command. You can change the beep volume and the beep duration to meet the needs of your working environment.
Page 37: Connecting An Input Device To The Terminal
C o d e 39 Nugget Learning About the Terminals Connecting an Input Device to the Terminal The terminal has an integrated I/O connector that lets you connect input devices to the terminal using special cables. Intermec Input Device Cable Part No. 1550C laser scanners 069813 1551C laser scanners...
Page 38: Using The Terminal's Battery Pack
C o d e 39 Nugget Trakker Antares 241X Hand-Held Terminal User’s Manual Using the Terminal’s Battery Pack Warning The lithium-ion battery pack that is used in this device may present a fire or chemical burn hazard if it is mistreated. Do not disassemble it, heat it above 100ºC (212ºF) or incinerate it.
Page 39: Charging The Battery Pack
C o d e 39 Nugget Learning About the Terminals Charging the Battery Pack You can charge the battery pack using any of these Trakker Antares accessories: • Battery charger (2-pack or 4-pack) • Communications dock connected to an external power supply The charger uses a charging method that maximizes battery life.
Page 40: Removing The Battery Pack
C o d e 39 Nugget Trakker Antares 241X Hand-Held Terminal User’s Manual Removing the Battery Pack Caution Removing the battery pack while the terminal is on may cause loss of data. Conseil Ne détachez pas le paquet de piles pendant que le terminal est actif car cela pourrait entraîner la perte de données.
Page 41: Managing Battery Power
C o d e 39 Nugget Learning About the Terminals Managing Battery Power To maximize the life of the battery pack, use these power management features. Situation Ways to Save Battery Power You are operating the terminal Press to turn off the terminal. Remove the battery and the Battery LED turns on.
Page 42: Defining The Terminal's Drives
C o d e 39 Nugget Trakker Antares 241X Hand-Held Terminal User’s Manual Defining the Terminal’s Drives The terminal comes with two flash drives and a configurable RAM drive. On the 2410 you can purchase an optional extended storage drive. On each drive, filenames are customer defined using eight characters with a three-character extension.
Page 43: Using The Terminal's Scanner
C o d e 39 Nugget Learning About the Terminals On the terminals, applications are customer defined. You have 512K total RAM that you can use for the application execution space. You can also configure this RAM to be the RAM drive (up to 256K).
Page 44 C o d e 39 Nugget Trakker Antares 241X Hand-Held Terminal User’s Manual To scan a bar code label with the scanner 1. Press to turn on the terminal. 2. Hold the terminal at a slight angle a few inches from the bar code label. The scanner must be pointing toward the label.
Page 45 C o d e 39 Nugget Learning About the Terminals To successfully read a bar code label, the laser beam in the scan module must see all the bars in a label and a “quiet zone” at each end of the label. A quiet zone is a clean, non- printed space.
Page 46: Scanning Options
C o d e 39 Nugget Trakker Antares 241X Hand-Held Terminal User’s Manual Scanning Options You can set several configuration commands to configure the scanner to meet your needs. For help understanding the scanner configuration commands, see Chapter 8, “Configuration Command Reference.” The commands that are available are: Decode Security Defines the security level to use when decoding bar codes.
Page 47: Using The Terminal For The First Time
C o d e 39 Nugget Learning About the Terminals Using the Terminal for the First Time Before you can use the terminal for the first time, you must perform certain steps, such as setting the time and date. You can find this information throughout this user’s manual. However, if you want to start using the terminal immediately, see the Trakker Antares 241X Hand-Held Terminal Getting Started Guide.
Page 48 1-28...
Page 49: Operating The Terminals In A Network
C o d e 39 Nugget Operating the Terminals in a Network...
Page 50 C o d e 39 Nugget...
Page 51: How The Terminals Fit Into Your Network
C o d e 39 Nugget Operating the Terminals in a Network This chapter explains how the terminals fit into a data collection network and what parameters to configure for your serial or RF network. How the Terminals Fit Into Your Network The Trakker Antares 2410 and 2415 terminals are versatile hand-held terminals that you can easily add to your network or distributed data collection system.
Page 52 C o d e 39 Nugget Trakker Antares 241X Hand-Held Terminal User’s Manual You can also use the serial port to connect to a 900 MHz RF network via the 9189 RF Gateway. The terminal communicates with the 900 MHz RF network using Polling Mode D protocol.
Page 53 C o d e 39 Nugget Operating the Terminals in a Network In a UDP Plus network, 2415s communicate with a host computer through the DCS 300. The DCS 300 translates UDP Plus packets on the RF network into TCP/IP packets on the wired network and vice versa.
Page 54 C o d e 39 Nugget Trakker Antares 241X Hand-Held Terminal User’s Manual In a TCP/IP network, 2415s communicate with a host computer directly using TCP/IP for the RF protocol. The access point acts as a bridge between the wired network and the RF network.
Page 55 C o d e 39 Nugget Operating the Terminals in a Network You can install 2415s and access points in one subnetwork and install the DCS 300 or host in another subnetwork. If the 2415s are communicating across a subnetwork, you must configure additional network parameters (subnet mask and default router).
Page 56 C o d e 39 Nugget Trakker Antares 241X Hand-Held Terminal User’s Manual In a UDP Plus network, you can install 2415s, access points, and DCS 300 as shown in the next illustration. All the terminals and access points in this illustration communicate with the DCS 300 at IP address 192.9.175.7.
Page 57 C o d e 39 Nugget Operating the Terminals in a Network In a TCP/IP network, you can install the 2415s and access points as shown in the illustration below. All the terminals and access points in this illustration communicate with the host at IP address 192.9.175.7.
Page 58: Connecting The Terminal To A Wired Network
C o d e 39 Nugget Trakker Antares 241X Hand-Held Terminal User’s Manual Connecting the Terminal to a Wired Network The terminals have a serial port (COM1) that lets them transfer data to and receive data from another device via RS-232 serial communications. If you insert the terminal into a communications dock, you can transmit data to and receive data from a host computer or PC via RS-232 serial communications.
Page 59: Binary Protocol
C o d e 39 Nugget Operating the Terminals in a Network Binary Protocol Binary protocol has no protocol. Characters are sent and received without being altered. The Data Link Escape character (DLE) is not inserted before any character. DLE characters are not stripped out of the incoming data stream and no protocol characters, such as EOM or SOM, are added.
Page 60: Master Polling Protocol
C o d e 39 Nugget Trakker Antares 241X Hand-Held Terminal User’s Manual Master Polling Protocol Master Polling Mode D protocol requires the terminal to ask the downline serial device for data it may have (polling) and to request to send data to the serial device (selecting). There is no automatic polling, so your application must poll periodically for data.
Page 61: Connecting The 2415 To An Rf Network
C o d e 39 Nugget Operating the Terminals in a Network Connecting the 2415 to an RF Network Caution Make sure all components with antennas are at least 30 centimeters (1 foot) apart when power is applied. Failure to comply could result in equipment damage. Conseil Assurez-vous que la distance entre tous les éléments avec antennes soit d'au moins 30 centimètres (un pied) avant de faire la connexion avec l'alimentation électrique,...
Page 62: Configuring The Dcs 300
C o d e 39 Nugget Trakker Antares 241X Hand-Held Terminal User’s Manual Configuring the DCS 300 The DCS 300 supports and manages communications with other devices in the UDP Plus network. When you install and configure the DCS 300, you identify the host computer(s) and 2415s in your network.
Page 63: 2.4 Ghz Openair Network
C o d e 39 Nugget Operating the Terminals in a Network If you go out of range of all access points in the network, the data is stored in the terminal’s radio buffer. The Network Status LED turns off. You can continue to collect data until the radio buffer is full.
Page 64: About The Network Parameters
C o d e 39 Nugget Trakker Antares 241X Hand-Held Terminal User’s Manual About the Network Parameters When you install the 2415 in a network, you must configure the network parameters that control how the terminal communicates in the network. The set of network parameters you must configure depends on whether you install the terminal on the same subnetwork as the DCS 300 or host (TCP/IP), or if you install the terminal on a different subnetwork.
Page 65: Monitoring Rf Communications Using The Status Leds
C o d e 39 Nugget Operating the Terminals in a Network Monitoring RF Communications Using the Status LEDs Once you have configured the devices in the RF network, you can begin using the application on the 2415 to collect and transmit data via RF communications. If the terminal is communicating with your host computer, the terminal will connect and begin running the application that shipped on the terminal.
Page 66: About Network Connectivity And Protocols
C o d e 39 Nugget Trakker Antares 241X Hand-Held Terminal User’s Manual About Network Connectivity and Protocols The Trakker Antares 2410 and 2415 terminals are hand-held data collection terminals with network support. The terminals communicate with a host computer or other serial device through the terminal’s serial port.
Page 67: Operating The Terminals In A Network
C o d e 39 Nugget Operating the Terminals in a Network Trakker Antares Terminal Protocol Stack and the OSI Model 241XU028.eps 2-19...
Page 68 C o d e 39 Nugget Trakker Antares 241X Hand-Held Terminal User’s Manual The terminals use these protocols: Layer Protocol Description Physical 2.4 GHz radio Provides spread spectrum radio signal control. Serial Port Provides serial communications. Data Link 2.4 GHz RF protocol Provides RF media access control.
Page 69 C o d e 39 Nugget Configuring the Terminals...
Page 70 C o d e 39 Nugget...
Page 71: How To Configure The Terminal
C o d e 39 Nugget Configuring the Terminals This chapter explains the different methods that you can use to configure the terminals. It also explains how to transfer files in a TCP/IP network, how to save configuration changes to flash memory, and how to restore the default configuration. How to Configure the Terminal You can customize many operating characteristics of the Trakker Antares 2410 and 2415 terminals, such as the volume of their audio signals and the bar code symbologies they...
Page 72: Configuring The Terminal With The Menu System
C o d e 39 Nugget Trakker Antares 241X Hand-Held Terminal User’s Manual Configuring the Terminal With the Menu System The TRAKKER Antares 2400 Menu System is a menu-driven application that lets you configure the terminal, manage files, view system information, and run diagnostics. You can access the TRAKKER Antares 2400 Menu System while running any application.
Page 73 C o d e 39 Nugget Configuring the Terminals System Menu Choose the System Menu to manage files, load the default configuration, set the time and date, store the terminal’s configuration in flash memory, and upgrade the firmware. About TRAKKER 2400 Choose this option to see the part number, firmware version, radio, and RF protocol (UDP Plus or TCP/IP) that is loaded on the terminal.
Page 74: Accessing Online Help
C o d e 39 Nugget Trakker Antares 241X Hand-Held Terminal User’s Manual Accessing Online Help The TRAKKER Antares 2400 Menu System provides online help for the menus and commands. To access a help screen • Press to access a help screen. To exit a help screen •...
Page 75 C o d e 39 Nugget Configuring the Terminals A command, when it is executed, performs a task or displays a screen. Press to choose a command from a menu and then press 8 . For example from the System Menu, press to set the time and date.
Page 76: Marking Check Boxes
C o d e 39 Nugget Trakker Antares 241X Hand-Held Terminal User’s Manual To exit a screen • To save the changes to the current configuration file, press to choose OK and press . Or, press with the cursor in any field except the Cancel button. Or, to discard the changes, press to choose Cancel and press .
Page 77: Entering Ascii Control Characters
C o d e 39 Nugget Configuring the Terminals Entering ASCII Control Characters You can include ASCII control characters in a postamble or preamble by using the TRAKKER Antares 2400 Menu System. For a definition of the postamble or preamble, see Chapter 8, “Configuration Command Reference.”...
Page 78 C o d e 39 Nugget Trakker Antares 241X Hand-Held Terminal User’s Manual 6. Type the control character, extended ASCII character, or escape character sequence in the preamble or postamble field. • To type a control character or extended ASCII character in the preamble or postamble field, use this syntax: \x hh where hh is the two-digit hexadecimal number for the control character or the...
Page 79: Exiting The Menu System
C o d e 39 Nugget Configuring the Terminals Exiting the Menu System 1. Press until you exit the TRAKKER Antares 2400 Menu System. If you have made any changes to the current configuration, this screen prompts you to save the configuration parameters that are currently enabled on the terminal to RAM.
Page 80 C o d e 39 Nugget Trakker Antares 241X Hand-Held Terminal User’s Manual & 4. Choose Yes and press to save your changes to flash memory. The terminal saves the current configuration as the active configuration. The Exiting TRAKKER Antares 2400 Menu System screen appears. &...
Page 81: Configuring The Terminal By Scanning Bar Code Labels
C o d e 39 Nugget Configuring the Terminals Configuring the Terminal by Scanning Bar Code Labels You can configure the terminal by scanning bar code labels that are listed in this manual or by creating your own Code 39 or Code 93 bar code labels. For example, you can scan this bar code label to set the beep volume to a quiet audio level: Set Beep Volume to Quiet *$+BV1*...
Page 82 C o d e 39 Nugget Trakker Antares 241X Hand-Held Terminal User’s Manual When you create a bar code label to set several configuration commands, follow these rules: • The bar code label must be printed using Code 39 or Code 93 symbology. If you need to scan a Code 39 bar code label that includes quotes or periods, you must configure the terminal to use Code 39 in Full ASCII mode.
Page 83: Configuring The Terminal Through The Serial Port
C o d e 39 Nugget Configuring the Terminals Configuring the Terminal Through the Serial Port You can write a host application that configures the terminal by sending reader and configuration commands through the serial port. You must connect the terminal to the host by either using a special cable or a communications dock and a special cable.
Page 84 C o d e 39 Nugget Trakker Antares 241X Hand-Held Terminal User’s Manual Example with TMF In the host application, you want to set the values for the beep volume and the display backlight timeout on the terminal. Send this transaction from the host application: CS$+BV4DF30.+1 Note: SOM and EOM are not shown in this example.
Page 85: Configuring The 2415 Through The Network
C o d e 39 Nugget Configuring the Terminals Configuring the 2415 Through the Network You can configure the 2415 by using one of these methods: • Send a command from the DCS 300 (UDP Plus network only). • Send a command from an application on the host computer (UDP Plus and TCP/IP networks).
Page 86 C o d e 39 Nugget Trakker Antares 241X Hand-Held Terminal User’s Manual To send commands from the DCS 300 1. Using the Download Server feature on the server, select the terminal or group to which you want to download the reader and configuration commands and then choose Edit.
Page 87: Sending A Command From The Host
C o d e 39 Nugget Configuring the Terminals Sending a Command From the Host You can write a host application that configures the terminal. This host application must be able to communicate with the DCS 300 in a UDP Plus network or be able to communicate directly through the access point in a TCP/IP direct connect network.
Page 88: Configuring The 2415 In A Tcp/Ip Direct Connect Network
C o d e 39 Nugget Trakker Antares 241X Hand-Held Terminal User’s Manual TMF field is a 2-byte field containing one of these values: Configuration Get request sent from the host application. Configuration Get response sent from the 2415 to the host. Configuration Set request sent from the host application.
Page 89 C o d e 39 Nugget Configuring the Terminals where: TMF field is a 2-byte field containing one of these values: Configuration Get request sent from the host application. Configuration Get response sent from the 2415 to the host. Configuration Set request sent from the host application. Configuration Set response sent from the 2415 to the host.
Page 90 C o d e 39 Nugget Trakker Antares 241X Hand-Held Terminal User’s Manual Example 2 In the host application, you want to set the value for two configuration commands on the 2415. Send this transaction from the host application: CS$+BV4DF30 Note: The transaction header is not shown in this example.
Page 91: Transferring Files In A Tcp/Ip Direct Connect Network
C o d e 39 Nugget Configuring the Terminals Transferring Files in a TCP/IP Direct Connect Network In a TCP/IP direct connect network, you can use a host application to transfer files and to send data between the terminal and a host. To initiate file transfers from the host, you must write a host application that can communicate directly with a 2415.
Page 92 C o d e 39 Nugget Trakker Antares 241X Hand-Held Terminal User’s Manual is the source for a sample application you can run on the host. You can use CLIENT.CPP to send reader commands to the 2415 and receive the resulting messages. CLIENT.CPP The source code for the sample utilities and the include file...
Page 93 C o d e 39 Nugget Configuring the Terminals CLIENT.CPP Sample Application for a TCP/IP Direct Connect Network #include <windows.h> #include <stdio.h> #include "d:\class\Utils.h" // our application uses a fixed port number const unsigned short SERVER_PORT = 6000; const unsigned short CLIENT_PORT = 6001; // we will default to the local host machine // unless argv[1] has a hostname const char SERVER_HOSTNAME[] = "ncm";...
Page 94 C o d e 39 Nugget Trakker Antares 241X Hand-Held Terminal User’s Manual CLIENT.CPP Sample Application for a TCP/IP Direct Connect Network (continued) // attempt to connect to the server error = connect(connection, (const SOCKADDR *)&serverAddress, sizeof(serverAddress)); if (error != 0) ErrorMessage("connect", WSAGetLastError());...
Page 95 C o d e 39 Nugget Configuring the Terminals CLIENT.CPP Sample Application for a TCP/IP Direct Connect Network (continued) Rcount++; printf("receive failed %d\n", Rcount); ErrorMessage("receive", WSAGetLastError()); bConnectionAlive = FALSE; // printf the converted string printf("response:%s\n",rz); printf("\n> "); Sleep(1000); else bConnectionAlive = FALSE; // release the resources held by the socket error = closesocket(connection);...
Page 96: Saving Configuration Changes To Flash Memory
C o d e 39 Nugget Trakker Antares 241X Hand-Held Terminal User’s Manual Saving Configuration Changes to Flash Memory If you configure the terminal by scanning bar code labels, through the serial port, or from the network, you may want to save the changes in flash memory using one of these methods.
Page 97: Restoring The Terminal's Default Configuration
C o d e 39 Nugget Configuring the Terminals 4. Choose OK to save the configuration in flash memory. To exit without saving the configuration, choose Cancel. The System Menu appears. 5. Press to exit the System Menu. The Main Menu appears. 6.
Page 98 C o d e 39 Nugget Trakker Antares 241X Hand-Held Terminal User’s Manual & 3. Choose the Load Default Values command and press . The Load Default Values screen appears. LOAD DEFAULT VALUES Load default configuration values in RAM? (Overwrites current configuration) CANCEL 241XU048.eps...
Page 99: Using Custom Applications
C o d e 39 Nugg Using Custom Applications...
Page 100 Co de 39 Nugg...
Page 101: How To Download And Run Applications
Co de 39 Nugg Using Custom Applications This chapter explains how to create, download, and run custom applications on the programmable terminals. How To Download and Run Applications Here’s a brief summary of the steps you follow to download applications and files to the programmable terminals.
Page 102: About The Trakker Antares Programmable Terminals
C o d e 39 Trakker Antares 241X Hand-Held Terminal User’s Manual Use a host application to download applications and files to the 2415 1. Create your applications using the Trakker Antares PSK or EZBuilder. For help, see page 4-6. 2.
Page 103 Co de 39 Nugg Using Custom Applications Trakker Antares Programmable Terminal Specifications Products: 2410 2415 Serial communications: RS-232 serial communications via the terminal’s serial port or the terminal in a communications dock. RF communications: 2.4 GHz (to 2.4835 GHz ) RF network support: There are two options: •...
Page 104: Creating Applications For The Terminal
C o d e 39 Trakker Antares 241X Hand-Held Terminal User’s Manual Creating Applications for the Terminal You create applications for the terminal using the Trakker Antares Programmer’s Software Kit (PSK) or EZBuilder and Microsoft C/C++ functions.The terminal runs applications that are programmed in Microsoft C. To start creating applications 1.
Page 105: Converting Applications Between Janus And Trakker Antares
Co de 39 Nugg Using Custom Applications It contains: • EZBuilder software • Microsoft Visual C++ version 1.5X • Application Simulator • PSK libraries • FileCopy utility • Sample EZBuilder programs • EZBuilder Getting Started Guide (Part No. 066450) • EZBuilder Tutorial (Part No.
Page 106: Converting The Application To A Binary File
C o d e 39 Trakker Antares 241X Hand-Held Terminal User’s Manual Converting the Application to a Binary File To run a DOS * application on your terminal, you simply download the executable .EXE ) file. However, if you want to run a native Trakker Antares application, it must *.EXE be stored as a binary file ( ).
Page 107: Using The Serial Port To Transfer Applications And Files
Co de 39 Nugg Using Custom Applications Using the Serial Port to Transfer Applications and Files You can download or upload applications and files between a host computer or PC and the terminal through the terminal’s serial port. Once the terminal is connected, there are three ways to transfer files: •...
Page 108 C o d e 39 Trakker Antares 241X Hand-Held Terminal User’s Manual Trakker Antares FileCopy Utility Dialog Box 4. Check the serial port and serial communications parameters to verify that the settings for your PC match the values that are set for the terminal’s serial port. a.
Page 109 Co de 39 Nugg Using Custom Applications 6. Select the FileCopy tab to download or upload applications and files. a. In the PC filename and path field, type the path and filename (filename .EXE filename .BIN ) for the file on your PC. You can select a previously used filename from a list by clicking on the down arrow.
Page 110 C o d e 39 Trakker Antares 241X Hand-Held Terminal User’s Manual 8 0 ) 8 5. On the terminal, press or press or scan this bar code label: Enter Test and Service Mode *..-.* *..-.* The Main Menu appears.
Page 111 Co de 39 Nugg Using Custom Applications 8. Choose OK to continue. The next screen appears. Are you sure you want to continue? Selecting YES will upgrade and replace all of the terminal's firmware. Selecting NO will exit without upgrading firmware. 241XU091.eps 9.
Page 112: Using The Dcs 300 To Download Applications And Files
C o d e 39 Trakker Antares 241X Hand-Held Terminal User’s Manual Using the DCS 300 to Download Applications and Files You can download applications and files to a 2415 using either the serial port or RF communications. For help downloading via the serial port, see the previous section. The advantage to downloading files via RF communications is that you can download multiple files to one or more terminals.
Page 113 Co de 39 Nugg Using Custom Applications Restore User Files Dialog Box 6. In the Available Files list box, add all the files that you want to restore to the Selected Files list box. a. Select the file name. b. Choose Select. The file name appears in the Selected Files list box. If the Selected Files list box shows any files that you do not want to restore, select the file name and choose Remove.
Page 114: Downloading Applications And Files To The 2415
C o d e 39 Trakker Antares 241X Hand-Held Terminal User’s Manual Downloading Applications and Files to the 2415 Once the applications and files are stored on the DCS 300, you can use the Download Server feature on the DCS 300 to download applications and files to one or more 2415s. To prepare the terminal 1.
Page 115 Co de 39 Nugg Using Custom Applications 5. Choose Edit. The Configure Device Initialization Download dialog box appears. 6. Verify that there are no files (or entries) listed in the Files and Data list box. If there are entries, then choose Clear to remove them. 7.
Page 116 C o d e 39 Trakker Antares 241X Hand-Held Terminal User’s Manual 12. Choose Add. The file appears in the Files and Data list box with a B for binary in the leftmost column. 13. Repeat Steps 7 through 12 to select another application. 14.
Page 117: Running The Application On The Terminal
Co de 39 Nugg Using Custom Applications Running the Application on the Terminal Once you have downloaded an application to the terminal, you are ready to run and use it. There are three ways to run an application: • Use the FileCopy utility. For help, see “Using the Serial Port to Transfer Applications and Files”...
Page 118 C o d e 39 Trakker Antares 241X Hand-Held Terminal User’s Manual 2. Choose System Menu and press . The System Menu appears. SYSTEM MENU File Manager Load Default Values Set Time and Date Store Configuration Upgrade Firmware ⁄ _` Select item [Enter] Next screen [F1] Help [Esc] Exit...
Page 119: Using Screen Mapping (Dcs 300 V1.1)
Co de 39 Nugg Using Custom Applications & 5. Choose an application and then press . The terminal boots, resets all firmware, and runs the application. If you also made configuration changes while you were working in the menu system, you will be prompted to store your changes in flash memory.
Page 120 4-22...
Page 121: Troubleshooting And Maintaining The Terminals
Troubleshooting and Maintaining the Terminals...
Page 123: How To Use This Chapter
C o d e 39 Nugget Troubleshooting and Maintaining the Terminals This chapter explains how to troubleshoot and maintain the terminals. It also explains how to upgrade the terminal’s firmware. How to Use This Chapter If you have any problems with the Trakker Antares 2410 and 2415 terminals, use this table as a guide to find the problem and solution in this chapter: Problem See This Section to Find a Solution...
Page 124: Finding And Solving Problems
C o d e 39 Nugget Trakker Antares 241X Hand-Held Terminal User’s Manual Finding and Solving Problems Caution There are no user-serviceable parts inside the terminal. Opening the unit will void the warranty and may cause damage to the internal components. Conseil La terminal ne contient pas de pièces révisibles par l’utilisateur.
Page 125: Terminal Will Not Turn On
C o d e 39 Nugget Troubleshooting and Maintaining the Terminals Terminal Will Not Turn On If you press to turn on the terminal and nothing happens, check the terminal for these possible problems. Problem Solution A battery pack is not installed. The Battery Make sure the battery pack is installed correctly.
Page 126 C o d e 39 Nugget Trakker Antares 241X Hand-Held Terminal User’s Manual Problems While Operating the Terminal (continued) Problem Solution The terminal appears to be locked up and you Try these possible solutions: cannot enter data. • (2415 only) Wait at least 10 seconds and try again. If the 2415 is still connecting to the DCS 300 or the host, it ignores any input from the keypad or scanner.
Page 127: Problems While Configuring The Terminal
C o d e 39 Nugget Troubleshooting and Maintaining the Terminals Problems While Configuring the Terminal You can configure the terminal by using the TRAKKER Antares 2400 Menu System or by scanning configuration commands. If you have problems configuring the terminal, check these possible problems and solutions.
Page 128 C o d e 39 Nugget Trakker Antares 241X Hand-Held Terminal User’s Manual Problems While Configuring the Terminal (continued) Problem Solution On a 2415, you see this error message when The 2.4 GHz RF network is enabled and there is a problem with the exiting the Configuration Menu: network configuration.
Page 129 C o d e 39 Nugget Troubleshooting and Maintaining the Terminals Problems While Configuring the Terminal (continued) Problem Solution You are configuring the serial port and see You cannot set EOM or SOM to any of these values: AFF (ACK), this error message when exiting the DLE, NEG (NAK), Poll, RES (EOT), REQ (ENQ), SEL, XOFF, or Configuration Menu:...
Page 130 C o d e 39 Nugget Trakker Antares 241X Hand-Held Terminal User’s Manual Problems While Configuring the Terminal (continued) Problem Solution You see this error message when exiting the The two-character name (syntax) of the configuration command that Configuration Menu: failed is listed on the first line of the error message.
Page 131 C o d e 39 Nugget Troubleshooting and Maintaining the Terminals Problems While Configuring the Terminal (continued) Problem Solution On the 2415, you scan a configuration If the Network Activate command is enabled (2.4 GHz RF network command to set one of these parameters and enabled) and you are configuring the 2415, these IP addresses must be hear three low beeps: valid.
Page 132: 2415 Will Not Communicate With Rf Network Devices
C o d e 39 Nugget Trakker Antares 241X Hand-Held Terminal User’s Manual 2415 Will Not Communicate With RF Network Devices If you cannot get the 2415 to communicate with other devices in the 2.4 GHz RF network, check these possible problems. Problem Solution The Connect LED is off.
Page 133 C o d e 39 Nugget Troubleshooting and Maintaining the Terminals 2415 Will Not Communicate With RF Network Devices (continued) Problem Solution The Connect LED blinks and you see this The 2415 is connected to the access point, but is trying to establish message: communications with the DCS 300 and the host computer.
Page 134: Problems Transmitting Data Through The Serial Port
C o d e 39 Nugget Trakker Antares 241X Hand-Held Terminal User’s Manual Problems Transmitting Data Through the Serial Port If you are having problems sending or receiving data through the integrated I/O port on the terminal, check these possible problems: •...
Page 135: Problems Transmitting Data Through The Dcs 300
C o d e 39 Nugget Troubleshooting and Maintaining the Terminals Problems Transmitting Data Through the DCS 300 If you have a problem while running the application on the terminal in a UDP Plus network, check these possible communications problems. Problem Solution Transaction Buffer Full.
Page 136: Bar Code Labels Will Not Scan
C o d e 39 Nugget Trakker Antares 241X Hand-Held Terminal User’s Manual Bar Code Labels Will Not Scan If you cannot scan bar code labels or you are having problems with the scan module, check these possible problems. Problem Solution The terminal is turned off.
Page 137 C o d e 39 Nugget Troubleshooting and Maintaining the Terminals Bar Code Labels Will Not Scan (continued) Problem Solution The scanner will not read the bar code label. Try one of these solutions: • Make sure you aim the scanner beam so it crosses the entire bar code label in one pass.
Page 138: Booting And Resetting The Terminal
C o d e 39 Nugget Trakker Antares 241X Hand-Held Terminal User’s Manual Booting and Resetting the Terminal You seldom need to boot or reset the terminal. When you boot the terminal, it runs through power-on self test (POST) to test each major subsystem. The terminal uses the configuration currently saved in flash memory.
Page 139: Using The Boot Menu
C o d e 39 Nugget Troubleshooting and Maintaining the Terminals Using the Boot Menu The Boot menu appears after you • reset the terminal. • remove the battery pack and wait longer than 15 minutes to install a charged battery pack.
Page 140: Resetting The Terminal
C o d e 39 Nugget Trakker Antares 241X Hand-Held Terminal User’s Manual Resetting the Terminal If the terminal or application is locked up and the terminal will not respond to any key sequences, try the following steps in order: 1.
Page 141: Cleaning The Scanner Window And Terminal Screen
C o d e 39 Nugget Troubleshooting and Maintaining the Terminals Cleaning the Scanner Window and Terminal Screen The terminals are built for use in a light industrial working environment. You may need to perform these minor maintenance tasks to keep the terminal in good working order: •...
Page 142: Upgrading The Terminal
C o d e 39 Nugget Trakker Antares 241X Hand-Held Terminal User’s Manual Upgrading the Terminal This section explains how to upgrade the firmware on the terminal and how to load double-byte fonts, if you choose to order them after you receive your terminal. You can also upgrade the terminal for: •...
Page 143 C o d e 39 Nugget Troubleshooting and Maintaining the Terminals 5. Change to the directory where the upgrade files are located. 6. Type: INSTALL The batch file explodes the TKANTxxx.EXE file to a new directory. This new directory contains all the files you need to perform an upgrade. 8 0 ) 8 7.
Page 144 C o d e 39 Nugget Trakker Antares 241X Hand-Held Terminal User’s Manual 10. Choose OK to continue. The next screen appears. Are you sure you want to continue? Selecting YES will upgrade and replace all of the terminal's firmware. Selecting NO will exit without upgrading firmware.
Page 145: Loading Double-Byte Fonts
C o d e 39 Nugget Troubleshooting and Maintaining the Terminals Loading Double-Byte Fonts You can order the terminal pre-loaded with different Asian fonts. If you did not order your terminal pre-loaded with a double-byte font, but you did order the optional 4MB flash drive (drive D), you can load the font yourself.
Page 146 C o d e 39 Nugget Trakker Antares 241X Hand-Held Terminal User’s Manual 7. Choose Yes to continue and upgrade the firmware. The terminal reboots and then displays the Loader Waiting screen. Note: If you reach the Loader Waiting screen and cannot upgrade or continue, press once or twice to exit without upgrading the firmware.
Page 147: Running Diagnostics
C o d e 39 Nugg Running Diagnostics...
Page 148 C o d e 39 Nugg...
Page 149: What Diagnostics Are Available
Co de 39 Nugg Running Diagnostics This chapter explains how to run the diagnostics that are on the terminal. What Diagnostics Are Available? You can run diagnostics on the Trakker Antares 2410 and 2415 terminals to help you analyze hardware and firmware problems, fix application problems, and view system information.
Page 150 Co de 39 Nugg Trakker Antares 241X Hand-Held Terminal User’s Manual Diagnostic Tests (continued) Diagnostic Test Description Page No. Keypad Table Lists the number of the keypad table that is loaded in 6-11 the terminal. Keypad Test Shows the hexadecimal, decimal, and scan code value 6-18 for any key or key combination on the keypad.
Page 151: Running Diagnostics From The Menu System
Co de 39 Nugg Running Diagnostics Running Diagnostics From the Menu System The TRAKKER Antares 2400 Menu System is a menu-driven application that lets you configure the terminal, view system information, and run diagnostics. You can access the TRAKKER Antares 2400 Menu System and run diagnostics while running any application.
Page 152 Co de 39 Nugg Trakker Antares 241X Hand-Held Terminal User’s Manual & 3. Choose Software Diagnostics, Hardware Diagnostics, or System Diagnostics and press . One of these menus appears. SOFTWARE DIAGNOSTICS SYSTEM DIAGNOSTICS HARDWARE DIAGNOSTICS Error Logger Subsystem Versions Hardware Config Application Events Access Point Battery/PIC Status...
Page 153: Defining The Diagnostics Screens
Co de 39 Nugg Running Diagnostics Defining the Diagnostics Screens You can find the following information about each diagnostic test: • Description and purpose • Menu where the diagnostic is available • Sample diagnostic screen • Definition and explanation of the diagnostic screen The diagnostics are grouped into three categories: •...
Page 154: Clear Task Profiles
Co de 39 Nugg Trakker Antares 241X Hand-Held Terminal User’s Manual Clear Task Profiles Purpose: Clears the task profile counters so that you can begin accumulating statistics on the firmware subsystem tasks from a known point in time. Where Available: Software Diagnostics menu Sample Screen: CLEAR TASK PROFILES...
Page 155: Error Logger
Co de 39 Nugg Running Diagnostics Error Logger Purpose: You can use the Error Logger screen to display any errors that the system detected while you were using the terminal. For help solving an error, contact your local Intermec service representative. Where Available: Software Diagnostics menu Sample Screen:...
Page 156: Font Test
Co de 39 Nugg Trakker Antares 241X Hand-Held Terminal User’s Manual Font Test Purpose: You can use this diagnostic to identify which double-byte font, if any, that you have loaded on your terminal. Where Available: Software Diagnostics menu Sample Screen: FONT TEST FONT TEST DB Font 13...
Page 157: Keypad Table
Co de 39 Nugg Running Diagnostics Keypad Table Purpose: You can use this diagnostic to identify the number of the keypad table that you have loaded on your terminal. Where Available: Software Diagnostics menu Sample Screen: KEYPAD TABLE Keypad Table 0x01 [Esc] Exit Definition:...
Page 158: Task Status
Co de 39 Nugg Trakker Antares 241X Hand-Held Terminal User’s Manual Task Status Purpose: A programmer can use the Task Status screens to view the task name, stack, and the percentage of time a task has been running. You can also use the Task Status screen to determine the type of RF network protocol, TCP/IP or UDP Plus, loaded on the terminal.
Page 159: Defining The Hardware Diagnostics Screens
Co de 39 Nugg Running Diagnostics Defining the Hardware Diagnostics Screens Each hardware diagnostic screen is defined in this section. Battery/PIC Status Purpose: Use the Battery/PIC status screen to get information about the lithium-ion battery pack. Where Available: Hardware Diagnostics menu, Battery/PIC Status, Main Battery/PIC Sample Screen: BATTERY/PIC MONITOR Main Battery...
Page 160: Beeper Test
Co de 39 Nugg Trakker Antares 241X Hand-Held Terminal User’s Manual Beeper Test Purpose: You can test the terminal beeper to make sure the entire beep volume range and beep frequency range are available and working correctly. The Beeper Test can also help you distinguish the different beep volumes to choose a level that you can hear in your working environment.
Page 161: Destructive Ram Test
Co de 39 Nugg Running Diagnostics Destructive RAM Test Purpose: Use the Destructive RAM Test if you have any problems storing files on the RAM drive or running an application that uses RAM memory. Where Available: Choose the Main Board Menu from the Hardware Diagnostics menu. Sample Screen: DESTRUCTIVE RAM TEST The following test...
Page 162: Display Test
Co de 39 Nugg Trakker Antares 241X Hand-Held Terminal User’s Manual Display Test Purpose: Use the Display Test to make sure that every pixel on the terminal screen is working correctly. For example, you may want to test the screen if you do not see complete characters on the screen.
Page 163: Hardware Configuration
Co de 39 Nugg Running Diagnostics Hardware Configuration Purpose: If you are discussing a problem with Intermec, you can use the Hardware Configuration screen to tell the Intermec representative the exact version of hardware that was installed on the terminal at the Intermec factory. Where Available: Hardware Diagnostics menu Sample Screen:...
Page 164: Keypad Test
Co de 39 Nugg Trakker Antares 241X Hand-Held Terminal User’s Manual Keypad Test Purpose: An application programmer can use the Keypad Test screen to quickly find the hexadecimal key code value, the decimal key code value, and the scan code for any key on the keypad.
Page 165: Radio Test
Co de 39 Nugg Running Diagnostics Radio Test Purpose: Use the Radio Test screen on a 2415 to verify that you have a working radio. Where Available: Hardware Diagnostics menu Sample Screen: RADIO TEST TESTING Test: PASSED [Esc] Exit 241XU086.eps Definition: Before you start the test, make sure the radio (Network Activate command) is enabled.
Page 166: Scanner Test
Co de 39 Nugg Trakker Antares 241X Hand-Held Terminal User’s Manual Scanner Test Purpose: Use the Scanner Test to make sure the laser scanner and Scan button are operating correctly. Where Available: Hardware Diagnostics menu Sample Screen: SCANNER TEST Press ENTER to turn the laser on for 3 seconds.
Page 167: Serial Port Loopback Test
Co de 39 Nugg Running Diagnostics Serial Port Loopback Test Purpose: Use the Serial Port Loopback test to verify that the hardware for the serial port is functioning correctly. To run this diagnostic test, you must connect the terminal to a host computer or other serial device via a special cable (Part No.
Page 168: Defining The System Diagnostics Screens
Co de 39 Nugg Trakker Antares 241X Hand-Held Terminal User’s Manual Defining the System Diagnostics Screens Each system diagnostic screen is defined in this section. Access Point Purpose: Use the Access Point screen to get version and address information about the access point the terminal is communicating with across the RF network.
Page 169: Application Efficiency
Co de 39 Nugg Running Diagnostics Application Efficiency Purpose: Use the Application Efficiency screen to find out if your application is making the best use of and maximizing battery life on the terminal. Where Available: System Diagnostics menu Sample Screen: APP EFFICIENCY Subsystem Versions Application is...
Page 170: Code Verify
Co de 39 Nugg Trakker Antares 241X Hand-Held Terminal User’s Manual Code Verify Purpose: A programmer or application developer can use this diagnostic to determine if the terminal’s firmware has been overwritten. Where Available: System Diagnostics menu Sample Screen: CODE VERIFY TEST CODE VERIFY TEST FAILED beeper...
Page 171: Malloc Application Information
Co de 39 Nugg Running Diagnostics Malloc Application Information Purpose: A programmer or application developer can use the Malloc Application Information screen to see how memory is allocated from the application Malloc pool. Where Available: Choose the Malloc Info Menu from the System Diagnostics menu. Sample Screen: APPLICATION Total Free:...
Page 172: Malloc Firmware Information
Co de 39 Nugg Trakker Antares 241X Hand-Held Terminal User’s Manual Malloc Firmware Information Purpose: A programmer or application developer can use the Malloc Firmware Information screen to see how memory is allocated from the firmware Malloc pool. The firmware includes the operating environment, firmware, drivers, and TRAKKER Antares 2400 Menu System.
Page 173: Serial Port Test
Co de 39 Nugg Running Diagnostics Serial Port Test Purpose: Use the Serial Port Test screen to test or troubleshoot serial communications between the terminal and the host computer or serial device. To run this diagnostic test, you must connect the terminal to a host or other serial device via a special cable (Part No. 069589) or the communications dock.
Page 174: Subsystem Versions
Co de 39 Nugg Trakker Antares 241X Hand-Held Terminal User’s Manual Subsystem Versions Purpose: If you are discussing a problem with Intermec, you can use the Subsystem Versions screen to tell the Intermec representative the exact version of firmware subsystems loaded on the terminal.
Page 175: Reader Command Reference
Reader Command Reference...
Page 177: Using Reader Commands
C o d e 39 Nugget Reader Command Reference Using Reader Commands A reader command causes the Trakker Antares 2410 and 2415 terminals to perform a task. For example, you can turn the backlight on to easily view the terminal’s screen when you are working in a dimly lit environment.
Page 178: Using Accumulate Mode
C o d e 39 Nugget Trakker Antares 241X Hand-Held Terminal User’s Manual Using Accumulate Mode You can use Accumulate mode to collect data from a series of bar code labels and enter them as a single label. When you put the terminal in Accumulate mode, the terminal will collect all scanned bar code labels in the terminal’s buffer until you scan either the Enter or Exit Accumulate mode command.
Page 179: Backspace
C o d e 39 Nugget Reader Command Reference 3. If necessary, edit the accumulated data by scanning these bar code labels: Backspace Clear Enter *-+* *--* *-+* *- -* 4. Scan this bar code label to exit Accumulate mode and enter the data record. Exit Accumulate Mode *-/* *-/*...
Page 180: Enter
C o d e 39 Nugget Trakker Antares 241X Hand-Held Terminal User’s Manual Enter Purpose: Enters the current data record and remains in Accumulate mode. If no data exists, a null string is entered. From Network: Not supported Keypad or Menu: Not supported Scan: Enter...
Page 181: Operating Reader Commands
C o d e 39 Nugget Reader Command Reference Operating Reader Commands This section explains the reader commands that you can use to operate or change the terminal’s configuration. The commands are: • • Backlight On and Off Reset Firmware •...
Page 182: Boot Terminal
C o d e 39 Nugget Trakker Antares 241X Hand-Held Terminal User’s Manual Boot Terminal Purpose: Boots the terminal. The terminal runs through power-on self test (POST) to test each major subsystem. The terminal uses the configuration currently saved in flash memory to boot and then your application appears on the screen.
Page 183: Default Configuration
C o d e 39 Nugget Reader Command Reference Default Configuration Purpose: Sets both the current and active configurations on the terminal to the default configuration, resets the firmware, boots the terminal, and runs your application. However, it does not reset the time and date. The default configuration for the terminal is listed in Appendix A.
Page 184: Reset Firmware
C o d e 39 Nugget Trakker Antares 241X Hand-Held Terminal User’s Manual Reset Firmware Purpose: Resets all firmware on the terminal, resets the application, and runs the application. You can use this command to restart your application if you are having problems. From Network: Keypad or Menu: From the Main Menu, choose System Menu and then Upgrade Firmware.
Page 185: Scanner Trigger On And Off
C o d e 39 Nugget Reader Command Reference Scanner Trigger On and Off The Scanner Trigger On and the Scanner Trigger Off commands are the same as pushing and releasing the Scan button on the keypad. The Scan button and scanner trigger commands control the integrated scanner.
Page 186: Set Time And Date
C o d e 39 Nugget Trakker Antares 241X Hand-Held Terminal User’s Manual Set Time and Date Purpose: Sets the time and date on the terminal. When the terminal receives the time broadcast command from the 9154 or 9161 controller, the command sets the clock on the terminal. You can configure the clock with seconds or without seconds.
Page 187: Test And Service Mode
C o d e 39 Nugget Reader Command Reference Test and Service Mode Purpose: Starts the TRAKKER Antares 2400 Menu System. Note: You can use the Command Processing configuration command to disable the Test and Service Mode reader command. If you disable this reader command, you can no longer access the TRAKKER Antares 2400 Menu System using the keypad.
Page 188: Delete File
C o d e 39 Nugget Trakker Antares 241X Hand-Held Terminal User’s Manual Delete File Purpose: Deletes a file from a drive on the terminal. From Network: ..-- drive : filename where: is the command to delete a file. ..–– drive indicates the drive where you want to delete a file.
Page 189: List Files
C o d e 39 Nugget Reader Command Reference List Files Purpose: A list files reader command is not available in the current release. However, if you want to see a list of files on the terminal, you can use the TRAKKER Antares 2400 Menu System.
Page 190 C o d e 39 Nugget Trakker Antares 241X Hand-Held Terminal User’s Manual Receive File Through the Serial Port (continued) Receives a batch of files using .%Y n , drive : YMODEM where: is the command to receive a file using protocol.
Page 191: Receive And Convert 7-Bit Ascii Files To 8-Bit Binary Files
C o d e 39 Nugget Reader Command Reference Receive File Through the Serial Port (continued) 5. Scan this bar code label to exit Accumulate mode and receive the file. Exit Accumulate Mode *-/* *-/* You can create your own bar code labels to receive files by creating a bar code in this command format: (for .%X n , drive : filename...
Page 192 C o d e 39 Nugget Trakker Antares 241X Hand-Held Terminal User’s Manual Receive and Convert 7-Bit ASCII Files to 8-Bit Binary Files (continued) On the host, you use a hexadecimal conversion utility to convert the 8-bit binary file to a 7-bit ASCII hexadecimal file.
Page 193: Receive File Via Rf Communications
C o d e 39 Nugget Reader Command Reference Receive and Convert 7-Bit ASCII Files to 8-Bit Binary Files (continued) 3. Scan the bar code label(s) for the file you want to receive. You can scan labels from the “Full ASCII Bar Code Chart” in Appendix B. The label must use this format: drive : filename 4.
Page 194 C o d e 39 Nugget Trakker Antares 241X Hand-Held Terminal User’s Manual Receive File Via RF Communications (continued) drive indicates the drive on the 2415 where you want to receive and store the file. You must include the colon (:) after the drive letter. tofilename is the name of the file you want to save on the 2415.
Page 195: Rename File
C o d e 39 Nugget Reader Command Reference Rename File Purpose: Renames a file stored on the terminal. From Network: ...- drive:oldfilename,drive : newfilename where: is the command to rename a file..- drive indicates the drive where the oldfilename is stored. You must include the colon (:) after the drive letter.
Page 196: Run Program
C o d e 39 Nugget Trakker Antares 241X Hand-Held Terminal User’s Manual Run Program Purpose: Runs the specified program or application that is stored on the terminal. For help, see Chapter 4, “Using Custom Applications.” Note: You cannot store and run applications from the RAM drive (E). From Network: // drive : filename where:...
Page 197: Transmit File
C o d e 39 Nugget Reader Command Reference Transmit File There are two ways to transmit files from the terminals: • Use the serial port to transmit files from the terminal. • Use RF communications to transmit files from the 2415. For help connecting the terminal to a host computer or the DCS 300, see Chapter 2, “Operating the Terminals in a Network.”...
Page 198 C o d e 39 Nugget Trakker Antares 241X Hand-Held Terminal User’s Manual Transmit File Through the Serial Port (continued) Scan: 1. Scan this bar code label: Enter Accumulate Mode / Transmit File *+/%%* *+/%%* 2. Scan the bar code label for the communications protocol you want to use. XMODEM XMODEM-1K YMODEM...
Page 199: Transmit And Convert 8-Bit Binary Files To 7-Bit Ascii Files
C o d e 39 Nugget Reader Command Reference Transmit and Convert 8-Bit Binary Files to 7-Bit ASCII Files Purpose: Converts the file from an 8-bit binary file to a 7-bit ASCII hexadecimal file, transmits the file from the terminal through the serial port, and saves the file on the host computer. You must have the terminal connected to the host through a serial port.
Page 200 C o d e 39 Nugget Trakker Antares 241X Hand-Held Terminal User’s Manual Transmit and Convert 8-Bit Binary Files to 7-Bit ASCII Files (continued) Scan: 1. Scan this bar code label: Note: To scan these bar code labels, you must configure the terminal to use Code 39 in Full ASCII mode.
Page 201: Transmit File Via Rf Communications
C o d e 39 Nugget Reader Command Reference Transmit File Via RF Communications Purpose: Transmits a file from the 2415 and saves it on the DCS 300 or host. From Network: %%R, drive : fromfilename,tofilename where: is the command to transmit a file over the RF network. The “R” indicates a file transmitted via RF communications from the 2415 to the DCS 300 or host.
Page 202 C o d e 39 Nugget Trakker Antares 241X Hand-Held Terminal User’s Manual Transmit File Via RF Communications (continued) You can create your own bar code labels to transmit files by creating a bar code in this command format: %%R, drive : fromfilename,tofilename 7-28...
Page 203 Configuration Command Reference...
Page 204 C o d e 39 Trakker Antares 241X Hand-Held Terminal User’s Manual Nugget...
Page 205: Using Configuration Commands
Configuration Command Reference This chapter is an alphabetical list of all the configuration commands supported on the terminal. Using Configuration Commands A configuration command changes the way the Trakker Antares 2410 and 2415 terminals operate. For example, you can change the Beep Volume command and make the terminal beep very loudly in a noisy environment.
Page 206: Configuration Commands Listed By Category
C o d e 39 Nugget Trakker Antares 241X Hand-Held Terminal User’s Manual Configuration Commands Listed by Category This chapter lists the configuration commands in alphabetical order. Use these lists to find the configuration commands you need to set for bar code symbologies, operations, serial network communications, or RF network communications.
Page 207 Configuration Command Reference Configuration Commands Listed by Category (continued) RF Network Communications 2.4 GHz OpenAir RF Network Acknowledgement Delay Lower Limit, 8-8 Domain, 8-63 Acknowledgement Delay Upper Limit, 8-10 Inactivity Timeout, 8-75 AP MAC Address, 8-13 Roaming Flag, 8-112 Controller Connect Check Receive Timer, 8-47 Security Identification (ID), 8-121 Controller Connect Check Send Timer, 8-49 Transmit Mode, 8-142...
Page 208 C o d e 39 Nugget Trakker Antares 241X Hand-Held Terminal User’s Manual Configuration Commands Listed by Category (continued) Serial Network Communications Baud Rate, 8-16 Configuration Commands Via Serial Port, 8-45 Data Bits, 8-53 End of Message (EOM), 8-66 Flow Control, 8-70 Handshake, 8-72 LRC (Longitudinal Redundancy Check), 8-84 Parity, 8-98...
Page 209: Entering Variable Data In A Configuration Command
Configuration Command Reference Entering Variable Data in a Configuration Command You can enter variable data for many of the configuration commands. For example, you can set a preamble that is up to 25 ASCII characters long. You need to follow these general instructions to enter variable data.
Page 210: Acknowledgement Delay Lower Limit
C o d e 39 Nugget Trakker Antares 241X Hand-Held Terminal User’s Manual Acknowledgement Delay Lower Limit Purpose: When the 2415 sends a message to the DCS 300, the terminal waits to receive a response acknowledging the message. If no response is received within the Acknowledgement Delay Lower Limit time, the terminal sends the message again at the time interval set for the lower limit.
Page 211 Configuration Command Reference Acknowledgement Delay Lower Limit (continued) 2. Scan a numeric value for data from these bar codes: 3. Scan this bar code: Exit Accumulate Mode *-/* *-/*...
Page 212: Acknowledgement Delay Upper Limit
C o d e 39 Nugget Trakker Antares 241X Hand-Held Terminal User’s Manual Acknowledgement Delay Upper Limit Purpose: When the 2415 sends a message to the DCS 300, the terminal waits to receive a response acknowledging the message. If no response is received within the Acknowledgement Delay Lower Limit time, the terminal sends the message again at the time interval set for the lower limit.
Page 213 Configuration Command Reference Acknowledgement Delay Upper Limit (continued) 2. Scan a numeric value for data from these bar codes: 3. Scan this bar code: Exit Accumulate Mode *-/* *-/* 8-11...
Page 214: Ap Density
C o d e 39 Nugget Trakker Antares 241X Hand-Held Terminal User’s Manual AP Density Purpose: (IEEE 802.11 DS radio parameter) Controls the roaming sensitivity of the radios. You can use this parameter to virtually reduce the range of the radio. When you increase the AP density, you do not reduce the absolute range of the radio, but the roaming algorithms are modified to allow significant overlap of the radio coverage.
Page 215: Ap Mac Address
Configuration Command Reference AP MAC Address Purpose: Returns the MAC address of the radio that is installed in the access point that the 2415 is communicating with. You can only use this read-only command in an application to return the value (MAC address) to the application. Syntax: Default: None...
Page 216: Automatic Shutoff
C o d e 39 Nugget Trakker Antares 241X Hand-Held Terminal User’s Manual Automatic Shutoff Purpose: Defines the maximum length of time the terminal remains on when there is no activity. When you do not use the terminal for the length of time set with this command, the terminal automatically turns off as if you had pressed to turn it off.
Page 217 Configuration Command Reference Automatic Shutoff (continued) 2. Scan a numeric value for data from these bar codes: 3. Scan this bar code: Exit Accumulate Mode *-/* *-/* 8-15...
Page 218: Baud Rate
C o d e 39 Nugget Trakker Antares 241X Hand-Held Terminal User’s Manual Baud Rate Purpose: Sets the baud rate for the serial port on the terminal. The baud rate must match the baud rate of the device (i.e., the host computer) that the terminal is communicating with through the serial port.
Page 219 Configuration Command Reference Baud Rate (continued) 3. Scan the baud rate from these bar codes: 1200 Baud 2400 Baud 4800 Baud 9600 Baud 19200 Baud 38400 Baud 4. Scan this bar code: Exit Accumulate Mode *-/* *-/* Other: For COM1 only. To provide compatibility with earlier Trakker Antares firmware versions, you can also use this syntax: IAdata where data is a value from 3 to 8.
Page 220: Beep Duration
C o d e 39 Nugget Trakker Antares 241X Hand-Held Terminal User’s Manual Beep Duration Purpose: Sets the length of the terminal’s audio signals. You can define a different duration for the high and the low beep volume. Use the beep duration with the beep volume to define beeps according to operator preference and work environment.
Page 221 Configuration Command Reference Beep Duration (continued) 2. Scan a numeric value for data from these bar codes: 3. Scan the beep volume for which you are setting the beep duration: High 4. Scan this bar code: Exit Accumulate Mode *-/* *-/* 8-19...
Page 222: Beep Volume
C o d e 39 Nugget Trakker Antares 241X Hand-Held Terminal User’s Manual Beep Volume Purpose: Adjusts the volume of the terminal’s audio signals. Use the beep duration with the beep volume to define audio signals (beeps and keyclicks) according to operator preference and work environment.
Page 223: Codabar
Configuration Command Reference Codabar Purpose: Enables or disables decoding of Codabar symbology. Codabar is a self-checking, discrete symbology. The American Blood Commission (ABC) Codabar requires that you retain and transmit the start/stop code digits when processing a Codabar symbol. As a result, configuration CD10 is an illegal configuration.
Page 224 C o d e 39 Nugget Trakker Antares 241X Hand-Held Terminal User’s Manual Codabar (continued) Standard, Discard Start/Stop *$+CD20* *$+CD20* Standard, Transmit ABCD Start/Stop *$+CD21* *$+CD21* Standard, Transmit DC1-DC4 Start/Stop *$+CD22* *$+CD22* Concatenated, Discard Start/Stop *$+CD30* *$+CD30* Concatenated, Transmit ABCD Start/Stop *$+CD31* *$+CD31* Concatenated, Transmit DC1-DC4 Start/Stop...
Page 225: Code 11
Configuration Command Reference Code 11 Purpose: Enables or disables decoding of Code 11 symbology. Code 11 is a very high density, discrete numeric bar code. It is most extensively used in labeling telecommunications components and equipment. Syntax: CGdata Acceptable values for data are: Disabled Code 11 enabled with one check digit Code 11 enabled with two check digits...
Page 226: Code 16K
C o d e 39 Nugget Trakker Antares 241X Hand-Held Terminal User’s Manual Code 16K Purpose: Enables or disables decoding of Code 16K symbology. Code 16K is a two-dimensional (stacked rows), high density bar code. It is based on Code 128 and is used widely to label unit-dose packaging for the healthcare industry.
Page 227: Code 2 Of 5
Configuration Command Reference Code 2 of 5 Purpose: Enables or disables decoding of Code 2 of 5 symbology. Code 2 of 5 uses the bars to encode information and the spaces to separate the individual bars. This code is discrete and self-checking.
Page 228 C o d e 39 Nugget Trakker Antares 241X Hand-Held Terminal User’s Manual Code 2 of 5 (continued) 2. Scan a two-digit numeric value to set the label length (01-32) from these bar codes. 3. Scan this bar code: Exit Accumulate Mode *-/* *-/* 8-26...
Page 229: Code 39
Configuration Command Reference Code 39 Purpose: Enables or disables decoding of Code 39 symbology. Code 39 is discrete, variable length, and self-checking. The character set is uppercase A to Z, 0 to 9, dollar sign ($), period (.), slash (/), percent (%), space ( ), plus (+), and minus (-). There are three types of ASCII the terminal decodes: •...
Page 230 C o d e 39 Nugget Trakker Antares 241X Hand-Held Terminal User’s Manual Code 39 (continued) Other printers encode the data $%a as: *$%+A* *$%+A* The $ and % are valid Code 39 characters in the non-full ASCII character set. However, the terminal will not decode this label if it is configured for full ASCII, because the data is not represented by valid full ASCII character pairs.
Page 231 Configuration Command Reference Code 39 (continued) Second digit: Discard check digit Transmit check digit Third digit: Code 39 non-full ASCII Code 39 full ASCII Code 39 mixed-full ASCII Note: Selecting HIBC Code 39 automatically sets the configuration to non-full ASCII with the check digit transmitted.
Page 232 C o d e 39 Nugget Trakker Antares 241X Hand-Held Terminal User’s Manual Code 39 (continued) 3. Scan one of these bar codes to set the second digit: Discard Check Digit Transmit Check Digit 4. Scan one of these bar codes to set the third digit: Code 39 Non-Full ASCII Code 39 Full ASCII Code 39 Mixed-Full ASCII...
Page 233: Code 49
Configuration Command Reference Code 49 Purpose: Enables or disables decoding of Code 49 symbology. Code 49 is a multirow symbology for high data density. The last character in each row is used for row checking and the last two characters of the symbol are used for overall checking. Function codes designate where to place the predefined data string in a Code 49 label.
Page 234 C o d e 39 Nugget Trakker Antares 241X Hand-Held Terminal User’s Manual Code 49 (continued) Scan: To disable any of the function codes, scan one of these bar codes: Disable Function Code 1 *$+CK* *$+CK* Disable Function Code 2 *$+CL* *$+CL* Disable Function Code 3...
Page 235 Configuration Command Reference Code 93 Purpose: Enables or disables decoding of Code 93 symbology. Code 93 is a variable length, continuous symbology that uses four element widths. Syntax: CFdata Acceptable values for data are: Disabled Enabled Default: Disabled Menu System: From the Main Menu, choose Configuration Menu, then Symbologies Menu, and then Code 93.
Page 236: Code 128
C o d e 39 Nugget Trakker Antares 241X Hand-Held Terminal User’s Manual Code 128 Purpose: Enables or disables decoding of Code 128 symbology. Code 128 is a very high density alphanumeric symbology that supports the extended ASCII character set. It is a variable length, continuous code that uses multiple element widths.
Page 237: Isbt Code 128
Configuration Command Reference ISBT Code 128 Purpose: Enables and configures decoding of ISBT Code 128 symbology. ISBT Code 128 is the global bar code labeling standard for the blood banking industry. It is used to support the world-wide distribution, tracking, and handling of blood bags and blood components. For more information on ISBT Code 128, see the ISBT 128 Bar Code Symbology and Application Specification for Labeling of Whole Blood and Blood Components prepared by the International Council for Commonality in Blood Banking Automation.
Page 238 C o d e 39 Nugget Trakker Antares 241X Hand-Held Terminal User’s Manual ISBT Code 128 (continued) Digits Values Description 000-999 Bar code concatenation control parameters. If digit 10 is “d,” digits 7 and 8 refer to the nominal distance in millimeters between the stop characters of two bar code labels that can be concatenated, and digit 9 is the bar code label positioning tolerance.
Page 239 Configuration Command Reference ISBT Code 128 (continued) 2. Scan one of these bar codes to disable or enable symbology ID: Symbology ID Disabled Symbology ID Enabled Note: Steps 3 through 9 are optional. 3. Scan one of these bar codes to disable or enable concatenation: Disable Concatenation Enable Concatenation If you disabled concatenation, go to Step 10.
Page 240 C o d e 39 Nugget Trakker Antares 241X Hand-Held Terminal User’s Manual ISBT Code 128 (continued) National Special Test Unit Exclusion Status */F/H* */F/A* *&(* *&!* National Special Donor Donation ID Number (See Note) */F%F* *%H* *&;* National Use Bar Code (See Note) */F* *&* 5.
Page 241 Configuration Command Reference ISBT Code 128 (continued) National Special Test Unit Exclusion Status */F/H* */F/A* *&(* *&!* National Special Donor Donation ID Number (See Note) */F%F* *%H* *&;* National Use Bar Code (See Note) */F* *&* 7. For the Donation ID Number or the National Use Bar Code, scan an alphanumeric bar code from Appendix B.
Page 242 C o d e 39 Nugget Trakker Antares 241X Hand-Held Terminal User’s Manual ISBT Code 128 (continued) 9. Scan one of these bar codes to set distance or time: Distance Time *+D* *+T* 10. Scan this bar code to exit accumulate mode: Exit Accumulate Mode *-/* *-/*...
Page 243: Command Processing
Configuration Command Reference Command Processing Purpose: Command processing lets you disable or enable reader commands. For example, you can disable the Backlight command. There are two ways to enable or disable reader commands: • Use the Command Processing configuration command described here. •...
Page 244 C o d e 39 Nugget Trakker Antares 241X Hand-Held Terminal User’s Manual Command Processing (continued) Scan: To enable all the reader commands or override the current settings, scan one of these bar codes: Disable All Reader Commands Enable All Reader Commands *$+DC0* *$+DC1* *$+DC0*...
Page 245 Configuration Command Reference Command Processing (continued) Default/Save Configuration Delete File *.+* *..--* *.+* *..--* Enter Accumulate Mode (continued) Exit Accumulate Mode (continued) Receive File Rename File *.%* *...-* *.%* *...-* Reset Firmware Run Program *-.* *//* *-.* *//* Scanner Trigger Off Scanner Trigger On */%* */.*...
Page 246 C o d e 39 Nugget Trakker Antares 241X Hand-Held Terminal User’s Manual Command Processing (continued) 4. Repeat Steps 2 and 3 to disable or enable another reader command. Note: You can accumulate up to 250 characters in the buffer. If the data accumulated exceeds 250 characters, you will hear an error beep and the terminal will reject the last bar code read.
Page 247: Configuration Commands Via Serial Port
Configuration Command Reference Configuration Commands Via Serial Port Purpose: Lets you control the data the terminal receives through the serial port. You can set this command to execute reader and configuration commands received through the serial port, or treat all data as data without checking for special command syntax. There are three options: Disabled All data received through the serial port is treated as data.
Page 248 C o d e 39 Nugget Trakker Antares 241X Hand-Held Terminal User’s Manual Configuration Commands Via Serial Port (continued) Scan: One of these bar codes: COM1 Commands Via Serial Port Disabled *$+YT1.0* *$+YT1.0* COM1 Commands Via Serial Port Enabled With TMF *$+YT1.1* *$+YT1.1* COM1 Commands Via Serial Port Enabled Without TMF...
Page 249: Controller Connect Check Receive Timer
Configuration Command Reference Controller Connect Check Receive Timer Purpose: During periods of inactivity on the 2415, the terminal still sends messages to the DCS 300 to check the RF connection. If no message is received within the time set for the Controller Connect Check Receive Timer, the terminal is no longer connected to the DCS 300 and the Connect LED blinks.
Page 250 C o d e 39 Nugget Trakker Antares 241X Hand-Held Terminal User’s Manual Controller Connect Check Receive Timer (continued) 2. Scan a numeric value for data from these bar codes: 3. Scan this bar code: Exit Accumulate Mode *-/* *-/* 8-48...
Page 251: Controller Connect Check Send Timer
Configuration Command Reference Controller Connect Check Send Timer Purpose: During periods of inactivity on the 2415, the terminal still sends messages to the DCS 300 to check the RF connection. The terminal sends a message at the time interval set for the Controller Connect Check Send Timer. The timer countdown resets each time a valid message is sent or received.
Page 252 C o d e 39 Nugget Trakker Antares 241X Hand-Held Terminal User’s Manual Controller Connect Check Send Timer (continued) 2. Scan a numeric value for data from these bar codes: 3. Scan this bar code: Exit Accumulate Mode *-/* *-/* 8-50...
Page 253: Controller Ip Address
Configuration Command Reference Controller IP Address Purpose: Defines the IP address assigned to the DCS 300 in your network. You assign a unique IP address to each device in a TCP/IP network. The controller IP address you set on the 2415 must match the address that is set on the DCS 300.
Page 254 C o d e 39 Nugget Trakker Antares 241X Hand-Held Terminal User’s Manual Controller IP Address (continued) 2. Scan a numeric value from 0 to 255 to set an n field of the controller IP address from these bar codes. 3.
Page 255 Configuration Command Reference Data Bits Purpose: Sets the number of data bits the terminal uses when communicating with another device (i.e., host computer) through the serial port. Syntax: YIn.data where n is: COM1 port Acceptable values for data are: 7 data bits 8 data bits Default: Menu System:...
Page 256: Decode Security
C o d e 39 Nugget Trakker Antares 241X Hand-Held Terminal User’s Manual Decode Security Purpose: Defines the security level to use when decoding bar codes. When you select a lower decode security level, the terminal can decode bar codes with poorer print quality. Note: Only use the low parameter as a temporary solution until you can improve the bar code label print quality.
Page 257: Default Router
Configuration Command Reference Default Router Purpose: Defines the IP address that is assigned to the default router in the network. The router provides a software and hardware connection between two or more subnetworks that permits traffic to be routed from one subnetwork to another on the basis of the intended destinations of that traffic.
Page 258 C o d e 39 Nugget Trakker Antares 241X Hand-Held Terminal User’s Manual Default Router (continued) 2. Scan a numeric value from 0 to 255 to set an n field of the default router address from these bar codes. 3. Scan this bar code: .
Page 259: Display Backlight Timeout
Configuration Command Reference Display Backlight Timeout Purpose: Defines the amount of time the backlight stays on as long as there is no keypad or scanning activity on the terminal. The backlight timeout resets each time there is activity. This setting significantly affects the terminal’s battery life. If you set a longer backlight timeout value, you will use the power in the main battery pack at a faster rate.
Page 260 C o d e 39 Nugget Trakker Antares 241X Hand-Held Terminal User’s Manual Display Backlight Timeout (continued) 2. Scan a two-digit numeric value for data from these bar codes. 3. Scan this bar code: Exit Accumulate Mode *-/* *-/* 8-58...
Page 261: Display Contrast
Configuration Command Reference Display Contrast Purpose: Defines the contrast (low or high) of the characters against the terminal screen. When the contrast is set to 0, the characters are bright against a bright background. When the contrast is set to 7, the characters are dark against a dark background. Syntax: DJdata Acceptable values for data are 0 (low) to 7 (high).
Page 262: Display Font Grid Type
C o d e 39 Nugget Trakker Antares 241X Hand-Held Terminal User’s Manual Display Font Grid Type Purpose: Sets the number of rows and columns that are on the terminal screen. You can set a regular size font grid (8x8), a font grid with double-height characters (8x16), or a font grid with double-width and double-height characters (16x16).
Page 263: Display Row Spacing
Configuration Command Reference Display Row Spacing Purpose: Sets the row spacing on the terminals. Row spacing lets you define the amount of additional space (scan lines) between the lines on the screen. The number of scan lines is two times the value you set for the row spacing. A scan line is a row of pixels. For example, a row spacing of 8 adds 16 blank scan lines between lines on the screen Syntax: DLdata...
Page 264: Display Video Mode
C o d e 39 Nugget Trakker Antares 241X Hand-Held Terminal User’s Manual Display Video Mode Purpose: Sets the Display Video mode that is used on the terminal screen. You can set the Display Video mode to original, normal, or inverse. Original displays black characters on a white background.
Page 265: Domain
Configuration Command Reference Domain Purpose: (OpenAir radio parameter) Defines an RF subnetwork. To communicate, all access points and 2415s in the subnetwork must have the same domain number. You can roam between access points as long as all of the RF devices have the same domain number. You can assign different domain numbers if you want to establish different RF subnetworks in the same area.
Page 266 C o d e 39 Nugget Trakker Antares 241X Hand-Held Terminal User’s Manual Domain (continued) 2. Scan a numeric value for data from these bar codes: 3. Scan this bar code: Exit Accumulate Mode *-/* *-/* 8-64...
Page 267: Dynamic Host Configuration Protocol (Dhcp)
Configuration Command Reference Dynamic Host Configuration Protocol (DHCP) Purpose: If your DCS 300 is operating as a DHCP client, its IP address will change each time it is turned on. By enabling DHCP on the 2415, the terminal can locate and use the DCS 300’s new IP address.
Page 268: End Of Message (Eom)
C o d e 39 Nugget Trakker Antares 241X Hand-Held Terminal User’s Manual End of Message (EOM) Purpose: Attaches an EOM to the end of a data block to indicate the end of data transmission to and from a terminal. When EOM is disabled, the terminal communicates in Character mode.
Page 269 Configuration Command Reference End of Message (continued) To disable EOM, scan this bar code: Disable EOM for COM1 *$+YZ1.* *$+YZ1.* To set EOM to one or two ASCII characters for one serial port: 1. Scan this bar code: Enter Accumulate Mode / Set EOM */K/O/D/KYZ* *+/$+YZ* 2.
Page 270: Flash Memory Configuration
C o d e 39 Nugget Trakker Antares 241X Hand-Held Terminal User’s Manual Flash Memory Configuration Purpose: Configures the use of the optional 2MB flash memory. If you have a terminal with the 4MB flash memory option, you can configure the extra 2MB of flash memory either as a drive D or you can use it to store a 2MB double-byte font.
Page 271 Configuration Command Reference Flash Memory Configuration (continued) Note: When you boot or reset the terminal, any fonts or files in flash memory are erased. 4. If you configured the flash memory to store double-byte fonts, use the Trakker Antares Font Editor to download the double-byte font set to the terminal. See your local Intermec sales representative for information about the Trakker Antares Font Editor.
Page 272: Flow Control
C o d e 39 Nugget Trakker Antares 241X Hand-Held Terminal User’s Manual Flow Control Purpose: Regulates the data transmission through the serial port. The terminal is a DTE (Data Terminal Equipment) device. There are several flow control options: • CTS checking where Clear To Send (CTS) is a hardware signal flow control.
Page 273 Configuration Command Reference Flow Control (continued) To set the flow control for one serial port: 1. Scan this bar code: Enter Accumulate Mode / Set Flow Control *+/$+YL* *+/$+YL* 2. Scan one of these bar codes to set the COM port: COM1 *1.* *1.*...
Page 274: Handshake
C o d e 39 Nugget Trakker Antares 241X Hand-Held Terminal User’s Manual Handshake Purpose: Enables or disables the handshake event that is an affirmative acknowledge to a message received through the serial port. Note: Before you can enable Handshake, you must configure the EOM command. Handshake is also referred to as AFF (affirmative acknowledge) on other Intermec devices.
Page 275: Host Ip Address
Configuration Command Reference Host IP Address Purpose: Defines the IP address assigned to the host computer in the TCP/IP network. You assign an IP address to each device in a TCP/IP direct connect network. The host IP address you set on the 2415 must match the address that is set on the host. Syntax: NCn.n.n.n where each n address segment is a number from 0 to 255.
Page 276 C o d e 39 Nugget Trakker Antares 241X Hand-Held Terminal User’s Manual Host IP Address (continued) 2. Scan a numeric value from 0 to 255 to set an n field of the host IP address from these bar codes. 3.
Page 277: Inactivity Timeout
Configuration Command Reference Inactivity Timeout Purpose: (OpenAir radio parameter) Defines the amount of time the radio on the 2415 waits to go into a low power state. If no data is sent or received within the inactivity timeout period set, the radio goes into a low power state to conserve battery power. If you set a high value, the radio stays on longer at a higher power rate and uses battery power at a faster rate.
Page 278 C o d e 39 Nugget Trakker Antares 241X Hand-Held Terminal User’s Manual Inactivity Timeout (continued) 2. Scan a numeric value for data from these bar codes: 3. Scan this bar code: Exit Accumulate Mode *-/* *-/* 8-76...
Page 279: Interleaved 2 Of 5
Configuration Command Reference Interleaved 2 of 5 Purpose: Enables or disables decoding of Interleaved 2 of 5 (I 2 of 5) symbology. I 2 of 5 is a high-density, self-checking, continuous numeric symbology. It is mainly used in inventory distribution and the automobile industry. Enabling I 2 of 5 automatically disables Code 2 of 5.
Page 280 C o d e 39 Nugget Trakker Antares 241X Hand-Held Terminal User’s Manual Interleaved 2 of 5 (continued) To set Interleaved 2 of 5 to a fixed length: 1. Scan this bar code: Enter Accumulate Mode / Set Fixed Length *+/$+CA* *+/$+CA* 2.
Page 281: Keypad Caps Lock
Configuration Command Reference Keypad Caps Lock Purpose: Turns the caps lock on and off. With the caps lock turned on, all alphabetic characters you type on the keypad will be uppercase or capital letters. Syntax: KAdata Acceptable values for data are: Caps lock off Caps lock on Default:...
Page 282: Keypad Clicker
C o d e 39 Nugget Trakker Antares 241X Hand-Held Terminal User’s Manual Keypad Clicker Purpose: Enables or disables the keypad clicker. The terminal sounds a click each time you press a key or decode a row of a two-dimensional symbology. Note: If the Beep Volume command is set to off, you will not hear any audio signals including the keyclick.
Page 283: Keypad Control
Configuration Command Reference Keypad Control Purpose: Enables or disables the keypad. When you disable the keypad, you cannot use the keypad to enter information into the terminal. Syntax: KEdata Acceptable values for data are: Disable keypad Enable keypad Default: Enabled Menu System: Not supported.
Page 284: Keypad Type
C o d e 39 Nugget Trakker Antares 241X Hand-Held Terminal User’s Manual Keypad Type Purpose: The keypad type is initially configured in the terminal’s firmware at the Intermec factory. If you change the keypad overlay, you must configure the keypad type to match the new keypad overlay.
Page 285 Configuration Command Reference Keypad Type (continued) Set 37-Key (Alphanumeric w/Large Numeric) Keypad Type to Programmable Keypad *$+KTP* *$+KTP* Set 37-Key (Alphanumeric w/Large Numeric) Keypad Type to TE 2000 Keypad *$+KTQ* *$+KTQ* Set 37-Key (Alphanumeric w/Large Numeric) Keypad Type to International Keypad *$+KTR* *$+KTR* Set 37-Key (Function Key w/Large Numeric) Keypad Type to Programmable Keypad...
Page 286: Lrc (Longitudinal Redundancy Check)
C o d e 39 Nugget Trakker Antares 241X Hand-Held Terminal User’s Manual LRC (Longitudinal Redundancy Check) Purpose: The Longitudinal Redundancy Check (LRC) character is an error-checking character that you can append to transmitted and received blocks of data. Note: Before you can enable LRC, you must enable the EOM command. Syntax: YFn.data where n is:...
Page 287: Maximum Retries
Configuration Command Reference Maximum Retries Purpose: Defines the number of times the 2415 will attempt to send a disconnect request message to the DCS 300. The 2415 sends connect and disconnect request messages to the DCS 300 when you turn the terminal on and off. Tip: Intermec strongly recommends that you use the optimum setting of 7 retries.
Page 288 C o d e 39 Nugget Trakker Antares 241X Hand-Held Terminal User’s Manual Maximum Retries (continued) 2. Scan a numeric value for data from these bar codes: 3. Scan this bar code: Exit Accumulate Mode *-/* *-/* 8-86...
Page 289: Maximum Sleep Duration
Configuration Command Reference Maximum Sleep Duration Purpose: (IEEE 802.11 DS radio parameter) Specifies the maximum amount of time the radio is allowed to sleep. Note: Before you set the maximum sleep duration, you must enable the Power Management command. Syntax: LIdata Default: Acceptable values for data are from 0 to 65535 ms.
Page 290 C o d e 39 Nugget Trakker Antares 241X Hand-Held Terminal User’s Manual Maximum Sleep Duration (continued) 2. Scan a numeric value for data from these bar codes: 3. Scan this bar code: Exit Accumulate Mode *-/* *-/* 8-88...
Page 291: Medium Reservation
Configuration Command Reference Medium Reservation Purpose: (IEEE 802.11 DS radio parameter) Determines if the 2415 uses medium reservation (RTS/CTS). You should enable this parameter when you expect that your network will have hidden stations. When you enable this parameter, you also need to set the Reservation Threshold command.
Page 292 C o d e 39 Nugget Trakker Antares 241X Hand-Held Terminal User’s Manual Purpose: Enables or disables decoding of MSI symbology. MSI code is similar to Plessey code in that it includes a start pattern, data characters, 1 or 2 check digits, and a stop pattern. Syntax: CNdata Acceptable values for data are:...
Page 293 Configuration Command Reference MSI (continued) MSI With 2 Modulus 10 Check Digits, Discard Check Digits *$+CN30* *$+CN30* MSI With 2 Modulus 10 Check Digits, Transmit Check Digits *$+CN31* *$+CN31* 8-91...
Page 294: Network Activate
C o d e 39 Nugget Trakker Antares 241X Hand-Held Terminal User’s Manual Network Activate Purpose: Enables or disables network communications between the 2415 and other devices in the RF network. When you enable this parameter, the terminal attempts to establish communications with the DCS 300 or host computer.
Page 295: Network Loopback
Configuration Command Reference Network Loopback Purpose: Transmits all messages received from the DCS 300 back to the DCS 300. Messages received by the radio are not passed on to the 2415 applications unless they are configuration commands. Messages continue to be looped back to the DCS 300 as long as this feature is enabled.
Page 296: Network Name
C o d e 39 Nugget Trakker Antares 241X Hand-Held Terminal User’s Manual Network Name Purpose: (IEEE 802.11 DS radio parameter) Defines an RF subnetwork. To communicate, all access points and 2415s in the subnetwork must have the same network name, which is case-sensitive.
Page 297 Configuration Command Reference Network Name (continued) 3. Scan this bar code: Exit Accumulate Mode *-/* *-/* 8-95...
Page 298: Network Port
C o d e 39 Nugget Trakker Antares 241X Hand-Held Terminal User’s Manual Network Port Purpose: Defines the network port that the TCP/IP or UDP Plus network protocol uses for communications in the RF network. In a TCP/IP network, set the network port to the appropriate port for the application you are using on the 2415.
Page 299 Configuration Command Reference Network Port (continued) 2. Scan a numeric value for data from these bar codes: 3. Scan this bar code: Exit Accumulate Mode *-/* *-/* 8-97...
Page 300: Parity
C o d e 39 Nugget Trakker Antares 241X Hand-Held Terminal User’s Manual Parity Purpose: Sets the parity for the serial port. The terminal uses parity for error checking in data transmissions. Syntax: YBn.data where n is: COM1 port Acceptable values for data are: No parity Even parity Odd parity...
Page 301: Plessey
Configuration Command Reference Plessey Purpose: Enables or disables decoding of Plessey symbology. Plessey code is pulse-width modulated like most other bar codes. It includes a start character, data characters, an eight-bit cyclic check digit, a termination bar, and usually a reverse start character. The code is continuous and not self-checking.
Page 302: Poll (Polling)
C o d e 39 Nugget Trakker Antares 241X Hand-Held Terminal User’s Manual Poll (Polling) Purpose: Solicits or requests data from a polled device. Note: Before you can enable poll, you must configure the EOM and Handshake commands. Syntax: YRn.data where n is: COM1 port Acceptable values for data are:...
Page 303: Postamble
Configuration Command Reference Postamble Purpose: Sets the postamble that is appended to any data you scan with the terminal. Common postambles include cursor controls such as a tab or a carriage return line feed. You can set the postamble to use characters from the extended ASCII character set such as the Field Exit code for 5250 TE.
Page 304 C o d e 39 Nugget Trakker Antares 241X Hand-Held Terminal User’s Manual Postamble (continued) Example: You want to set a postamble that includes quotation marks. To scan a bar code label that includes quotation marks, you must configure the terminal to use Code 39 in Full ASCII mode.
Page 305: Power Management
Configuration Command Reference Power Management Purpose: (IEEE 802.11 DS radio parameter) Determines if power management is enabled for the radio. If you enable power management, the radio conserves power by sleeping between messages. Enabling power management decreases the performance of the RF network, but it increases the life of battery-powered devices.
Page 306: Preamble
C o d e 39 Nugget Trakker Antares 241X Hand-Held Terminal User’s Manual Preamble Purpose: Sets the preamble that precedes any data you scan with the terminal. Common preambles include a data location number or an operator number. You can set the preamble to use characters from the extended ASCII character set. However, you cannot scan in extended ASCII characters in the Preamble command.
Page 307: Radio Mac Address
Configuration Command Reference Preamble (continued) Example: You want to set a preamble that includes quotation marks. To scan a bar code label that includes quotation marks, you must configure the terminal to use Code 39 in Full ASCII mode. For help, see “Code 39” earlier in this chapter. Enter the preamble by scanning this full ASCII bar code label: Set Preamble to “B”...
Page 308: Ram Drive Size
C o d e 39 Nugget Trakker Antares 241X Hand-Held Terminal User’s Manual RAM Drive Size Purpose: Configures the size and use of the RAM drive. You can use the RAM drive (drive E) to temporarily store data and files. You can also disable the RAM drive and use the additional 256K for application execution space or programmable (Malloc) memory allocations.
Page 309 Configuration Command Reference RAM Drive Size (continued) 2. Scan a numeric value for data from these bar codes: 3. Scan this bar code: Exit Accumulate Mode *-/* *-/* 4. Scan this bar code to save the configuration change in flash memory: Save Configuration in Flash Memory *.+1* *.+1*...
Page 310: Receive All Multicast
C o d e 39 Nugget Trakker Antares 241X Hand-Held Terminal User’s Manual Receive All Multicast Purpose: (IEEE 802.11 DS radio parameter) Determines if the 2415 needs to receive all multicast messages. If you enable this parameter, the radio will stay awake to receive all multicast messages that are forwarded by the access point.
Page 311: Reservation Threshold
Configuration Command Reference Reservation Threshold Purpose: (IEEE 802.11 DS radio parameter) Specifies the maximum packet size that the 2415 can send before it uses medium reservation (RTS/CTS). That is, packets that are greater than or equal to this packet size use the medium reservation mechanism to help prevent collisions with packets from other devices.
Page 312 C o d e 39 Nugget Trakker Antares 241X Hand-Held Terminal User’s Manual Reservation Threshold (continued) 2. Scan a numeric value for data from these bar codes: 3. Scan this bar code: Exit Accumulate Mode *-/* *-/* 8-110...
Page 313: Resume Execution
Configuration Command Reference Resume Execution Purpose: Defines the way in which the terminal resumes when you press to turn on the terminal. If you set this parameter to resume execution not allowed and you press to turn on the terminal, the terminal will boot and restart the application that was running when you turned off the terminal.
Page 314: Roaming Flag
C o d e 39 Nugget Trakker Antares 241X Hand-Held Terminal User’s Manual Roaming Flag Purpose: (OpenAir radio parameter) Determines whether or not the 2415 can roam between access points. All access points are master stations and each master has a unique channel. If you have five access points in one domain, the 2415 will connect to one access point when you turn it on.
Page 315: Scan Ahead
Configuration Command Reference Scan Ahead Purpose: Enables or disables scan ahead. If you enable this parameter, you can scan a number of labels that are held in a stack until the terminal can process the data. If you disable this parameter, the terminal processes each label you scan before you can scan the next label.
Page 316: Scanner Mode
C o d e 39 Nugget Trakker Antares 241X Hand-Held Terminal User’s Manual Scanner Mode Purpose: Defines how the scanner operates when you press the Scan button or activate a cabled laser scanner. There are two types of modes: • In One-Shot mode, you must press the Scan button or activate the cabled laser scanner each time you want to scan a bar code.
Page 317: Scanner Redundancy
Configuration Command Reference Scanner Redundancy Purpose: Defines the number of scans (voting) of a bar code label that must decode correctly for a good read of the label. Voting requires the terminal to decode the same bar code multiple times during a single scanner event, and to compare the decoded information a specific number of times before signaling a good read.
Page 318: Scanner Selection
C o d e 39 Nugget Trakker Antares 241X Hand-Held Terminal User’s Manual Scanner Selection Purpose: Identifies the type of scanner you have connected to the terminal. The terminal can optimize the scanning performance by using the scanner you define in this command. When you select a specific scanner, other scanners may not function properly.
Page 319 Configuration Command Reference Scanner Selection (continued) Scan: One of these bar codes: All Compatible Scanners *$+SS0* *$+SS0* Compatible Symbol Scanners *$+SS5* *$+SS5* 155X Laser Scanners *$+SS6* *$+SS6* Integrated Scanner (No Aim) *$+SS11* *$+SS11* Integrated Scanner (Short Aim) *$+SS12* *$+SS12* Integrated Scanner (Long Aim) *$+SS13* *$+SS13* 8-117...
Page 320: Scanner Timeout
C o d e 39 Nugget Trakker Antares 241X Hand-Held Terminal User’s Manual Scanner Timeout Purpose: Defines the maximum length of time the scanner stays after you press the Scan button or activate a cabled laser scanner. Syntax: SAdata Acceptable values for data are: Disabled 1-60 Shutoff time in seconds...
Page 321 Configuration Command Reference Scanner Timeout (continued) 2. Scan a numeric value for data from these bar codes: 3. Scan this bar code: Exit Accumulate Mode *-/* *-/* 8-119...
Page 322: Scanner Trigger
C o d e 39 Nugget Trakker Antares 241X Hand-Held Terminal User’s Manual Scanner Trigger Purpose: Scanner trigger lets you set level triggering or edge triggering. • With level triggering, you activate the scanner and the laser turns on and stays on until you release the button or the trigger on a cabled scanner.
Page 323: Security Identification
Configuration Command Reference Security Identification Purpose: (OpenAir radio parameter) Defines a password for secured transmission and receipt of data between devices in the RF network. To communicate, all access points and 2415s in the subnetwork must have the same security ID. Note: The Network Activate command must be configured to 2.4 GHz RF network before you can save any changes to this parameter.
Page 324: Serial Port Protocol
C o d e 39 Nugget Trakker Antares 241X Hand-Held Terminal User’s Manual Serial Port Protocol Purpose: Lets you set the protocol that the serial port uses to communicate with the connected device. Communications protocols determine exactly how data is transmitted between the terminal and the serial device.
Page 325 Configuration Command Reference Serial Port Protocol (continued) 3. Scan the protocol setting: Configurable Polling Mode D Master Polling Binary *12* *12* 4. Scan this bar code: Exit Accumulate Mode *-/* *-/* 8-123...
Page 326: Start Of Message (Som)
C o d e 39 Nugget Trakker Antares 241X Hand-Held Terminal User’s Manual Start of Message (SOM) Purpose: SOM is the first character in a message sent to or received from the host computer through the terminal’s serial port. SOM cannot equal the same value that is set for EOM. You cannot set SOM to any of these values: •...
Page 327 Configuration Command Reference Start of Message (continued) To set SOM to an ASCII character for one serial port: 1. Scan this bar code: Enter Accumulate Mode / Set SOM */K/O/D/KYY* *+/$+YY* 2. Scan the serial port from these bar codes: COM1 *1/N* *1.*...
Page 328: Station Name
C o d e 39 Nugget Trakker Antares 241X Hand-Held Terminal User’s Manual Station Name Purpose: (IEEE 802.11 DS radio parameter) Identifies the 2415 to the network. For example, you may want to define station names so that you can identify 2415s when using site survey tools.
Page 329 Configuration Command Reference Stop Bits Purpose: Sets the number of stop bits on the serial port. Syntax: YCn.data where n is: COM1 port Acceptable values for data are: 1 stop bit 2 stop bits Default: Menu System: From the Main Menu, choose Configuration Menu, then Communications Menu, and then Serial Port.
Page 330: Subnet Mask
C o d e 39 Nugget Trakker Antares 241X Hand-Held Terminal User’s Manual Subnet Mask Purpose: Defines the mask that is used to separate the subnetwork address from the local IP address. The TCP/IP protocol stack performs a bit-wise AND on the mask and the IP address.
Page 331 Configuration Command Reference Subnet Mask (continued) 2. Scan a numeric value from 0 to 255 to set an n field of the subnet mask address from these bar codes. 3. Scan this bar code: . (Period) 4. Repeat Steps 2 and 3 to set the next three numbers in the subnet mask address field. After you scan the last address segment, go to Step 5.
Page 332: Suspend/Resume Control
C o d e 39 Nugget Trakker Antares 241X Hand-Held Terminal User’s Manual Suspend/Resume Control Purpose: Controls the operation of the key (suspend/resume). When the key is enabled, you can turn the terminal on and off. When the key is disabled, you cannot turn off the terminal.
Page 333: Tcp Maximum Retries
Configuration Command Reference TCP Maximum Retries Purpose: Defines the maximum number of times that TCP will attempt to transmit data before giving up and terminating the TCP connection. Syntax: NJdata Acceptable values for data are any number from 5 to 50. Default: Menu System: Not supported...
Page 334 C o d e 39 Nugget Trakker Antares 241X Hand-Held Terminal User’s Manual TCP Maximum Retries (continued) 3. Scan this bar code: Exit Accumulate Mode *-/* *-/* 8-132...
Page 335: Tcp/Ip Maximum Transmit Timeout
Configuration Command Reference TCP/IP Maximum Transmit Timeout Purpose: Defines the maximum timeout that TCP will allow between retries of a transmission in a TCP/IP direct connect network before it gives up. Intermec has determined that the optimum setting is 20 seconds. Syntax: NHdata Acceptable values for data are:...
Page 336 C o d e 39 Nugget Trakker Antares 241X Hand-Held Terminal User’s Manual TCP Maximum Transmit Timeout (continued) 2. Scan a numeric value for data from these bar codes: 3. Scan this bar code: Exit Accumulate Mode *-/* *-/* 8-134...
Page 337: Terminal Ip Address
Configuration Command Reference Terminal IP Address Purpose: Defines the IP address that is assigned to the 2415 in your network. This IP address must match the address that is set for this terminal on the DCS 300 or host computer. Syntax: NDn.n.n.n where each n address segment is a number from 0 to 255.
Page 338 C o d e 39 Nugget Trakker Antares 241X Hand-Held Terminal User’s Manual Terminal IP Address (continued) 2. Scan a numeric value from 0 to 255 to set an n field of the terminal IP address from these bar codes. 3.
Page 339: Time And Date
Configuration Command Reference Time and Date Purpose: Sets the time and date on the terminal. Syntax: DBdata Acceptable values for data are 12 digits corresponding to: 00-99 Year 01-12 Month of the year 01-31 Day of the month 00-23 Hour 00-59 Minutes 00-59...
Page 340 C o d e 39 Nugget Trakker Antares 241X Hand-Held Terminal User’s Manual Time and Date (continued) 3. Scan this bar code: Exit Accumulate Mode *-/* *-/* 8-138...
Page 341: Time In Seconds
Configuration Command Reference Time in Seconds Purpose: If you enable the Append Time command, you can enable the Time in Seconds command to append the seconds to each bar code label that is scanned on the terminal. To append the time in only hours and minutes, disable the Time in Seconds command. Syntax: DAdata Acceptable values for data are:...
Page 342: Timeout Delay
C o d e 39 Nugget Trakker Antares 241X Hand-Held Terminal User’s Manual Timeout Delay Purpose: If handshaking is enabled, the terminal expects a response to each message that is sent to the host through the serial port. The timeout delay is the amount of time the terminal waits to receive a response.
Page 343 Configuration Command Reference Timeout Delay (continued) To set the timeout delay for one serial port: 1. Scan this bar code: Enter Accumulate Mode / Set Timeout Delay *+/$+YE* *+/$+YE* 2. Scan the serial port from these bar codes: COM1 *1.* *1.* 3.
Page 344: Transmit Mode
C o d e 39 Nugget Trakker Antares 241X Hand-Held Terminal User’s Manual Transmit Mode Purpose: (OpenAir radio parameter) Defines the transmit mode that the 2415 radio uses. There are three modes: BFSK Binary Frequency Shift Key. A broadcasting method the radio uses that lengthens the range, but halves the throughput.
Page 345: Transmit Rate
Configuration Command Reference Transmit Rate Purpose: (IEEE 802.11 DS radio parameter) Sets the bit rate for data transmissions. The slower transmit rate provides a better range. You should configure the terminals that are on the perimeter of the access point coverage area to the slower transmit rate. The faster transmit rate provides better throughput.
Page 346: Transmit Rate Fallback
C o d e 39 Nugget Trakker Antares 241X Hand-Held Terminal User’s Manual Transmit Rate Fallback Purpose: (IEEE 802.11 DS radio parameter) Determines if the 2415 will try slower speeds than the specified transmit rate. A packet may be undeliverable to a device at a given rate due to interference or range limitations.
Page 347: Upc/Ean
Configuration Command Reference UPC/EAN Purpose: Enables or disables the decoding of Universal Product Code (UPC)/European Article Numbering (EAN) symbology. UPC/EAN are fixed length, numeric, continuous symbologies that use four element widths. A terminal that is configured to decode EAN bar codes can decode UPC, but the reverse is not true. UPC code is a subset of EAN code.
Page 348 C o d e 39 Nugget Trakker Antares 241X Hand-Held Terminal User’s Manual UPC/EAN (continued) Fourth digit: Supplementals allowed Fifth digit: Transmit check digit Sixth digit: Transmit number system digit Seventh digit: Retain leading zero for UPC-A Menu System: From the Main Menu, choose Configuration Menu, then Symbologies Menu, and then UPC/EAN.
Page 349 Configuration Command Reference UPC/EAN (continued) 4. Scan one of these bar codes to set the third digit: Disable EAN-8 Enable EAN-8 Expand Zeroes 5. Scan one of these bar codes to set the fourth digit: Supplementals Not Allowed Supplementals Allowed Supplementals Required Two-Digit Supplementals Required Five-Digit Supplementals Required...
Page 350 C o d e 39 Nugget Trakker Antares 241X Hand-Held Terminal User’s Manual UPC/EAN (continued) 8. (Optional) Scan one of these bar codes to set the seventh digit: Discard Leading Zero for UPC-A Transmit Leading Zero for UPC-A Note: This option applies only when you enable UPC-A/EAN-13. 9.
Page 351: Wakeup On Broadcast
Configuration Command Reference Wakeup On Broadcast Purpose: (OpenAir radio parameter) Determines if the 2415 can receive broadcast messages sent from the network. If the wakeup on broadcast is enabled, the 2415 radio will turn on to receive broadcast messages. If this command is disabled, the terminal radio will ignore broadcast messages.
Page 352: Wep Encryption
C o d e 39 Nugget Trakker Antares 241X Hand-Held Terminal User’s Manual WEP Encryption Purpose: (IEEE 802.11 DS radio parameter) Determines if you want the 2415 to use the Wired Equivalent Privacy (WEP) algorithm for data encryption of wireless communications. WEP protects the transmitted data using a 64-bit seed key and the RC4 encryption algorithm.
Page 353: Wep Key 1, Wep Key 2, Wep Key 3, Wep Key 4
Configuration Command Reference WEP Key 1, WEP Key 2, WEP Key 3, WEP Key 4 Purpose: (IEEE 802.11 DS radio parameter) Sets the values for the WEP default keys. The 2415 can receive a WEP encryption that uses any of these four WEP keys. The WEP keys must appear in the same order on both the UAP and the 2415.
Page 354: Wep Transmit Key
C o d e 39 Nugget Trakker Antares 241X Hand-Held Terminal User’s Manual WEP Keys (continued) 2. Scan one of these bar codes to set a WEP key: Set WEP Key 1 Set WEP Key 2 *$+LM* *$+LN* *$+LM* *$+LN* Set WEP Key 3 Set WEP Key 4 *$+LO*...
Page 355 Configuration Command Reference WEP Transmit Key (continued) Scan: To set the default WEP transmit key, scan this bar code: Default WEP Transmit Key *$+LL1* *$+LL1* To set the WEP transmit key: 1. Scan this bar code: Enter Accumulate Mode / Set WEP Transmit Key *+/$+LL* *+/$+LL* 2.
Page 356 C o d e 39 Trakker Antares 241X Hand-Held Terminal User’s Manual Nugget 8-154...
Page 357: Specifications And Other Helpful Information
Specifications and Other Helpful Information...
Page 359: Specifications
Specifications and Other Helpful Information This appendix provides the physical and environmental specifications for the terminals. It also provides a quick reference keypad chart, the default configuration, and the configuration commands by syntax. Specifications This section lists the physical and environmental specifications for the Trakker Antares 2410 and 2415 terminals.
Page 360 Trakker Antares 241X Hand-Held Terminal User’s Manual Temperature Specifications Celsius Fahrenheit Type of Operation Temperature Range Temperature Range Charging the battery pack 0 to 40°C 32 to 104°F Operating the terminal -20 to 50°C -4 to 122°F Storing the terminal -20 to 60°C -4 to 140°F (with or without batteries installed)
Page 361 Specifications and Other Helpful Information Radio Options • 2.4 GHz (to 2.4835 GHz) OpenAir, frequency hopping spread spectrum radio • 2.4 GHz (to 2.4835 GHz) IEEE 802.11, direct sequence spread spectrum radio Memory • 2MB programmable flash memory, 750K available •...
Page 362 Trakker Antares 241X Hand-Held Terminal User’s Manual Pin Assignments for COM1 Signal Direction From Terminal Ground (GND) Scan Good Read Trigger LASEN VBATF Video Outgoing VCC-EXT 5V@200 mA Incoming Incoming Outgoing Auxiliary 1 Auxiliary 2 Ground (GND) Cables for the Terminal To connect the terminal to a PC, host computer, or another RS-232 serial device, use these cables.
Page 363 Specifications and Other Helpful Information Cables for the Communications Dock To connect the communications dock to a host computer or another RS-232 serial device, use this cable. Cable RS-232 Connector Part Number 9-pin, null modem 9-pin 059167 Bar Code Symbologies •...
Page 364 Trakker Antares 241X Hand-Held Terminal User’s Manual Long-Range Scan Module Optical Parameters (650 nm) Bar Code Specification Depth of Field/Scanning Range 10 mil code 29.9 to 49.8 cm 11.6 to 19.6 in 20 mil code 21.8 to 98.0 cm 8.6 to 38.6 in 30 mil code 24.4 to 192.0 cm 9.6 to 75.6 in...
Page 365: Default Configuration
Specifications and Other Helpful Information Default Configuration The next tables show the terminal’s default configuration. You can use the TRAKKER Antares 2400 Menu System to set the terminal to the default configuration. For help, see “Restoring the Terminal’s Default Configuration” in Chapter 3. Default Configuration for Bar Code Symbologies Parameter Default...
Page 366 Trakker Antares 241X Hand-Held Terminal User’s Manual Default Configuration for Operations (continued) Parameter Default Display Font Grid Type 8x8 (8 pixels wide by 8 pixels high) Display Row Spacing 0 (one scan line) Display Video Mode Original Flash Memory Configuration Configure for double-byte fonts Keypad Caps Lock Caps lock off...
Page 367 Specifications and Other Helpful Information Default Configuration for RF Network Communications (2415 Only) RF Network Parameter Default Acknowledgement Delay Lower Limit 300 ms Acknowledgement Delay Upper Limit 5000 ms AP MAC Address None Controller Connect Check Receive Timer 60 seconds Controller Connect Check Send Timer 35 seconds Controller IP Address...
Page 368 Trakker Antares 241X Hand-Held Terminal User’s Manual Default Configuration for RF Network Communications (continued)) IEEE 802.11 DS RF Network Parameter Default Network Name INTERMEC Power Management Enabled Receive All Multicast Enabled Reservation Threshold Station Name TRAKKER 2400 Transmit Rate Maximum available Transmit Rate Fallback Enabled WEP Encryption...
Page 369 Specifications and Other Helpful Information Configuration Commands by Syntax The next table lists all of the configuration commands that are available on the Trakker Antares 2410 and 2415 terminals. The configuration commands are listed in alphabetic order by syntax. Syntax Command ADdata Preamble...
Page 370: Configuration Commands By Syntax
Trakker Antares 241X Hand-Held Terminal User’s Manual Configuration Commands by Syntax (continued) Syntax Command DNdata Display Video Mode DTdata Display Font Grid Type EFdata Suspend/Resume Control ERdata Resume Execution EZdata Automatic Shutoff FFdata Flash Memory Configuration FRdata RAM Drive Size KAdata Keypad Caps Lock KCdata...
Page 371 Specifications and Other Helpful Information Configuration Commands by Syntax (continued) Syntax Command NGdata Network Port NHdata TCP/IP Maximum Transmit Timeout NIdata Dynamic Host Configuration Protocol (DHCP) NJdata TCP Maximum Retries NLdata Network Loopback NPdata Controller Connect Check Receive Timer NQdata Controller Connect Check Send Timer NRdata Maximum Retries...
Page 372 Trakker Antares 241X Hand-Held Terminal User’s Manual Configuration Commands by Syntax (continued) Syntax Command YFn.data LRC (Longitudinal Redundancy Check) YIn.data Data Bits YJn.data Handshake (also know as AFF) YLn.data Flow Control YRn.data Poll (Polling) YTn.data Configuration Commands Via Serial Port YUn.data Serial Port Protocol YYn.data...
Page 373: Full Ascii Charts
Full ASCII Charts...
Page 375: Full Ascii Table
C o d e 39 Nugg Full ASCII Charts This appendix contains the full ASCII table and the full ASCII chart of Code 39 bar code labels. Full ASCII Table This table lists the ASCII characters and their binary, hexadecimal, and Code 39 equivalents.
Page 376 C o d e 39 Nugg Trakker Antares 241X Hand-Held Terminal User’s Manual Full ASCII Table (continued) Binary Decimal Code 39 ASCII Binary Decimal Code 39 ASCII 01000000 01100000 01000001 01100001 01000010 01100010 01000011 01100011 01000100 01100100 01000101 01100101 01000110 01100110 01000111 01100111...
Page 377 C o d e 39 Nugg Full ASCII Charts Notes for the Full ASCII Table Bit positions are 76543210. This column lists the hexadecimal value. This column lists the ASCII character. SP is the SPACE character. The Code 39 characters /P through /Y may be interchanged with the numbers 0 through 9. %T may be interchanged with %X or %Y or %Z.
Page 378: Full Ascii Bar Code Chart
C o d e 39 Nugg Trakker Antares 241X Hand-Held Terminal User’s Manual Full ASCII Bar Code Chart The charts in this section list the Code 39 bar code label for each ASCII character. To use these bar code labels, you must configure the Trakker Antares 2410 or 2415 terminal to use Code 39 in Full ASCII mode.
Page 379: Symbols And Punctuation Marks
C o d e 39 Nugg Full ASCII Charts Control Characters (continued) *$X* *$Y* *$Z* *$X* *$Y* *$Z* *%A* *%B* *%C* *%A* *%B* *%C* *%D* *%E* *%T* *%D* *%E* *%T* Symbols and Punctuation Marks ! (exclamation point) " (quotation marks) */A* */B* */C*...
Page 380: Numbers
C o d e 39 Nugg Trakker Antares 241X Hand-Held Terminal User’s Manual Symbols and Punctuation Marks (continued) < > *%J* *%G* *%I* *%J* *%G* *%I* *%V* *%K* *%M* *%V* *%K* *%M* ~ (tilde) _ (underline) *%S* *%N* *%O* *%S* *%N* *%O* ` (left single quote)
Page 381: Uppercase Letters
C o d e 39 Nugg Full ASCII Charts Uppercase Letters...
Page 382: Lowercase Letters
C o d e 39 Nugg Trakker Antares 241X Hand-Held Terminal User’s Manual Lowercase Letters *+A* *+B* *+C* *+A* *+B* *+C* *+D* *+E* *+F* *+D* *+E* *+F* *+G* *+H* *+I* *+G* *+H* *+I* *+J* *+K* *+L* *+J* *+K* *+L* *+M* *+N* *+O* *+M*...
Page 383: International Character Support
International Character Support...
Page 385: Trakker Antares Terminal Font Set
C o d e 39 Nugg International Character Support This appendix lists some of the international characters that the terminal can display. Trakker Antares Terminal Font Set The Trakker Antares 2410 and 2415 terminals use an English and Western European font set that supports languages such as French, German, Italian, Portuguese, and Spanish.
Page 386 C o d e 39 Nugg Trakker Antares 241X Hand-Held Terminal User’s Manual English and Western European Character Set (continued) Character Terminal Keys Decimal Scan Code Hexadecimal ¶ § È Ê É Ç Space " & ’...
Page 387 C o d e 39 Nugg International Character Support English and Western European Character Set (continued) Character Terminal Keys Decimal Scan Code Hexadecimal , (comma) - (dash) . (period) " < > "...
Page 388 C o d e 39 Nugg Trakker Antares 241X Hand-Held Terminal User’s Manual English and Western European Character Set (continued) Character Terminal Keys Decimal Scan Code Hexadecimal & & _ (underline)
Page 389 C o d e 39 Nugg International Character Support English and Western European Character Set (continued) Character Terminal Keys Decimal Scan Code Hexadecimal " & | (solid pipe) 53E0 Ç 1 ü...
Page 390 C o d e 39 Nugg Trakker Antares 241X Hand-Held Terminal User’s Manual English and Western European Character Set (continued) Character Terminal Keys Decimal Scan Code Hexadecimal ! é â ä à å ç...
Page 391 C o d e 39 Nugg International Character Support English and Western European Character Set (continued) Character Terminal Keys Decimal Scan Code Hexadecimal ƒ 4DE0 á % í + ó 1 ú ñ & Ñ ¿...
Page 392 C o d e 39 Nugg Trakker Antares 241X Hand-Held Terminal User’s Manual English and Western European Character Set (continued) Character Terminal Keys Decimal Scan Code Hexadecimal 6000 ¢ 6100 ¥ 6200 6300 A600 1A86 1A8F 2E87 2E80 0DF8 Ã Ã...
Page 393 C o d e 39 Nugg International Character Support English and Western European Character Set (continued) Character Terminal Keys Decimal Scan Code Hexadecimal 07F3 2C00 6D00 0F00 ¦ (broken pipe) % Ì 5A00 Ó 52 / 78 β + Ô...
Page 394 C o d e 39 Nugg Trakker Antares 241X Hand-Held Terminal User’s Manual English and Western European Character Set (continued) Character Terminal Keys Decimal Scan Code Hexadecimal ÷ None ¸ None ° (degree) ¨ None • (dot) None ¹ (superscript) ³...
Page 395: Japanese Katakana Font Set
C o d e 39 Nugg International Character Support Japanese Katakana Font Set This table lists the characters that you can display on the terminal using the 8x16 font grid type or the 16x16 font grid type. To display these characters, you create an application and use the Trakker Antares PSK functions im_putchar_kana_8x16 and im_puts_kana_8x16.
Page 396 C o d e 39 Nugg Trakker Antares 241X Hand-Held Terminal User’s Manual Japanese Katakana Character Set (continued) Character Decimal Hexadecimal ¢ Î Í ¬ " & ’ C-14...
Page 397 C o d e 39 Nugg International Character Support Japanese Katakana Character Set (continued) Character Decimal Hexadecimal < > C-15...
Page 398 C o d e 39 Nugg Trakker Antares 241X Hand-Held Terminal User’s Manual Japanese Katakana Character Set (continued) Character Decimal Hexadecimal ¥ ‘ C-16...
Page 399 C o d e 39 Nugg International Character Support Japanese Katakana Character Set (continued) Character Decimal Hexadecimal ¦ (broken pipe) Â ‚ € C-17...
Page 400 C o d e 39 Nugg Trakker Antares 241X Hand-Held Terminal User’s Manual Japanese Katakana Character Set (continued) Character Decimal Hexadecimal — & < C-18...
Page 401 C o d e 39 Nugg International Character Support Japanese Katakana Character Set (continued) Character Decimal Hexadecimal " º C-19...
Page 402 C o d e 39 TRAKKER Antares 241X Hand-Held Terminal User’s Manual Nugg C-20...
Page 403: Using The Default Applications
Using the Default Applications...
Page 405: About The Applications Shipped On The Terminal
nugget Using the Default Applications This appendix explains the APPTSK.BIN and EM9560.BIN applications that are shipped on the terminals. It also explains how to use each application. About the Applications Shipped on the Terminal The Trakker Antares 2410 and 2415 terminals ship loaded with at least these two applications: •...
Page 406: Defining The Emulation Features Of Em9560.Bin
nugget Trakker Antares 241X Hand-Held Terminal User’s Manual Defining the Emulation Features of EM9560.BIN With the application, you can use the programmable terminals as a remote EM9560.BIN input/output terminal in which all prompts and commands are controlled by the host computer.
Page 407: Using Display Control Codes
nugget Using the Default Applications • The Exit Configuration Mode, Save Settings configuration command ($-) is not required, but bar code labels with this command scan correctly. Using Display Control Codes You can use control codes to position the cursor or to format the terminal display. The application recognizes the display control codes listed next.
Page 408: Using Display Modes
nugget Trakker Antares 241X Hand-Held Terminal User’s Manual Using Display Modes With the application, you can use Buffered display mode and Transparent EM9560.BIN display mode. In Buffered mode, new data is placed on a new line keeping blocks of data separated.
Page 409: Using Accumulate Mode
nugget Using the Default Applications Using Accumulate Mode With the application, you can emulate Accumulate mode (Emulation mode) EM9560.BIN and combine keypad data with scanned data. Data that you accumulate appears on the bottom line of the terminal display. You can edit this data using the reader commands for backspace and clear or you can use the key.
Page 410: Setting Preambles And Postambles
nugget Trakker Antares 241X Hand-Held Terminal User’s Manual Setting Preambles and Postambles With the application, you can set Preamble A, Preamble B, and Postamble EM9560.BIN C on the terminal and make it compatible with the 95XXs. The preambles are prepended and the postamble is appended to the data that is transmitted through all the serial ports.
Page 411 nugget Using the Default Applications Setting Preambles and Postambles (continued) To set the preamble or postamble using the +., ++, or +% reader commands: 1. Scan one of these bar code labels: Enter Accumulate Mode / Set Preamble A *+/+.* *+/+.* Enter Accumulate Mode / Set Preamble B *+/++*...
Page 412: Full Ascii Mode For Code 39
nugget Trakker Antares 241X Hand-Held Terminal User’s Manual Full ASCII Mode for Code 39 (continued) Command: Full ASCII configuration command (RB) Purpose: Configures the terminal to use Code 39 Full ASCII mode (enabled) or Code 39 Non-Full ASCII mode (disabled). For a list of ASCII characters, see the “Full ASCII Table” in Appendix B.
Page 413: Unsupported 95Xx Features
nugget Using the Default Applications Unsupported 95XX Features These 95XX features are not supported by the application on the 241X. EM9560.BIN • Capacity reader command (%$). • Command Override reader (data entry) command (DLE). • Download Program command from the 9154 or 9161 controller. Use the Transmit File reader command.
Page 414 nugget Trakker Antares 241X Hand-Held Terminal User’s Manual Running APPTSK.BIN and EM9560.BIN (continued) The terminal boots, resets all firmware, and runs the application. The initial screen for the application appears. You see one of these screens: APPTSK.BIN Screen EM9560.BIN Screen 1998/01/00 12:00:00 2.
Page 415 nugget Using the Default Applications Example 3 Connect the TD2400 communications dock to a serial port on the T2485. Use a T2420 to collect data. Use the TD2400 communications dock to upload data from the T2420 to the T2485. Data is transmitted to the T2485 and out the RF port to the connected network devices.
Page 416 D-14...
Page 417: Index
Index...
Page 418 Trakker Antares 241X Hand-Held Terminal User’s Manual...
Page 419 Index Acknowledgement Delay Upper Limit command, 8-10 Symbols active configuration, 3-3 key, See Function Left key AFF command, 8-72 key, See Function Right key Affirmative Acknowledge command, See Handshake key, See backlight, key command key, See Shift key AIAG check digit, Code 39, 8-28 keys, See cursor keys alphanumeric keypads, options, described, 1-7 American Blood Commission, See ABC Codabar...
Page 420 Trakker Antares 241X Hand-Held Terminal User’s Manual Automatic Shutoff command, 8-14 low battery charge, 5-5 managing battery power, 1-21 managing power, 1-18, 1-21 power specifications, A-3 removing, 1-20 terminal accessory, 1-5 backlight using, 1-18 configuring the timeout, 8-57 battery pack, power capacity remaining, 6-13 key, using, 1-14 Battery/PIC Monitor screen, defined, 6-13 turning on and off, 1-14...
Page 421 Index Clear Task Profiles screen, defined, 6-8 AP Density, 8-12 CLIENT.CPP sample application, 3-25 AP MAC Address, 8-13 Codabar command, 8-21 Append Time, 8-13 Code 11 command, 8-23 Automatic Shutoff, 1-21, 8-14 Code 128 command, 8-34 Baud Rate, 8-16 Code 16K command, 8-24 Beep Duration, 8-18 Code 2 of 5 command, 8-25 Beep Volume, 8-20...
Page 422 Trakker Antares 241X Hand-Held Terminal User’s Manual configuration commands (continued) configuring Plessey, 8-99 bar code labels, scanning, 3-13 to 3-14 Poll, 8-100 booting the terminal on resume, 5-18 Postamble, 8-101 Change Configuration command, using, 7-8 Default Configuration command, using, 7-9 Power Management, 8-103 Preamble, 8-104 default settings, list of, A-9 to A-12...
Page 423 Index Scanner Test screen, defined, 6-20 Serial Port Loopback screen, defined, 6-21 Data Bits command, 8-53 Serial Port Test screen, defined, 6-27 Data Collection Browser, See dcBrowser Subsystem Versions screen, defined, 6-28 data, accumulating in commands, 7-4, 8-7 summary of, 6-3 date, configuring, 8-137 Task Status screen, defined, 6-12 dcBrowser, configuring, 2-14...
Page 424 Trakker Antares 241X Hand-Held Terminal User’s Manual Enter reader command, 7-6 finding the special keys, 1-8 entering data firmware configuration commands, using, 8-7 applications, restarting, 7-10 keypad, using, 1-7 checking the version loaded, 3-5 reader commands, using, 7-4 Malloc diagnostic screen, defined, 6-26 terminal locked up, 5-6 upgrading, 5-22 EOM command, 2-11, 8-66...
Page 425 Index hardware diagnostics (continued) specifications, A-5 Scanner Test screen, defined, 6-20 using, 1-13 Interactive Reader Language, See IRL Serial Port Loopback Test screen, defined, 6-21 Hardware Diagnostics menu Interleaved 2 of 5 command, 8-77 diagnostic tests, defined, 6-13 disabled with Code 2 of 5, 8-25 using, 6-6 Intermec support services, xv Health Industry Bar Code, See HIBC, Code 39...
Page 426 Trakker Antares 241X Hand-Held Terminal User’s Manual keys (continued) Modifier status LED, 1-9, 1-10 diacritical marks, typing, 1-12 described, 1-15 Scan button, 1-23 MSI command, 8-90 Multi-Drop protocol receiving and converting files, 7-17 transmitting and converting files, 7-25 languages, table of characters, C-3 to C-19 Multiple-Read Labels reader command, 7-9 laser scanner, See scanner LEDs, See status LEDs...
Page 427 Index Point-to-Point protocol, 2-12 Poll command, 8-100 default configuration, saving, 7-9 Polling Mode D protocol, 2-12 saving configuration changes, 3-11 Portuguese, See European languages specifications, A-5 POST troubleshooting, 6-15 failed, error message, 5-6 RAM Drive Size command, 8-106 failed, status beeps, 1-16 Reader Command Menu, using, 3-8 success, status beeps, 1-16 reader commands...
Page 428 Trakker Antares 241X Hand-Held Terminal User’s Manual RF communications (continued) Scanner Selection command, 1-26, 8-116 controller connect check receive timer, configuring, 8-47 Scanner Test screen, defined, 6-20 controller connect check send timer, configuring, 8-49 Scanner Timeout command, 1-26, 8-118 controller IP address, configuring, 8-51 Scanner Trigger command, 1-26, 8-120 default router, configuring, 8-55 On and Off reader command, 7-11...
Page 429 Index sidebar buttons Suspend/Resume Control command, 8-130 Save and Activate, 3-3 Suspend/Resume key, using, 1-9 Save Configuration, 3-3 symbols, bar code labels to scan, B-7 Simulator, See Application Simulator syntax, configuration commands listed by, A-13 site survey, planning, 2-13 system diagnostics software diagnostics Access Point screen, defined, 6-22 Application Events screen, defined, 6-7...
Page 430 Trakker Antares 241X Hand-Held Terminal User’s Manual terminal (continued) Transmit Mode command, 8-142 features, described, 1-3, 1-6 Transmit Rate command, 8-143 firmware, upgrading, 5-22 Transmit Rate Fallback command, 8-144 getting started, list of steps, 1-27 troubleshooting keypad options, described, 1-7 audio signals, list of, 1-16 managing power, 1-21 bar code symbologies, 5-5...
Page 431 Index using key, 1-9 key, 1-9 key, 1-9 key, 1-9 key, 1-14 battery pack, 1-18 cursor keys, 1-10 integrated I/O port, 1-13 international keypad, 1-11 screen mapping, 4-21 serial port, 1-13 TE keypads, 1-12 terminal for the first time, 1-27 terminal scanner, 1-23 terminal screen, 1-14 using the terminal's keypad, 1-7...
Page 432 Trakker Antares 241X Hand-Held Terminal User’s Manual I-16...
