Summary of Contents for Dolphin IBP-G4x16-5
- Page 1 IBP-G4x16-5 IBP-G4x16-5 Backplane Users Guide Version 1.01 Date: 14 December 2023 IBP-G4x16-5 - Five slot expansion card User’s Guide Page 1...
- Page 2 IBP-G4x16-5 - Five slot expansion card User’s Guide Page 2...
-
Page 3: Table Of Contents
ONNECT A POWER TOGGLE SWITCH OR JUMPER SUPPORT ..................................8 COMPLIANCE AND REGULATORY TESTING ........................9 WEEE N ..................................9 OTICE LIMITED WARRANTY..............................10 ................................10 ARRANTY ERIOD ..................................10 OVERAGE ................................10 ERVICE ROCEDURE IBP-G4x16-5 - Five slot expansion card User’s Guide Page 3... -
Page 4: Disclaimer
PRODUCTS TO IMPROVE RELIABILITY, FUNCTION, OR DESIGN. TO THE FULLEST EXTENT PERMITTED BY LAW, DOLPHIN WILL NOT BE LIABLE FOR ANY INDIRECT, INCIDENTAL, SPECIAL OR CONSEQUENTIAL DAMAGES (INCLUDING LOST PROFITS, LOST DATA, OR LOSS OF USE) ARISING OUT OF ANY USE OF DOLPHIN’S PRODUCTS, SOFTWARE OR SERVICE PROVIDED. -
Page 5: Leds
Specifications The IBP-G4X16-5 is a passive backplane supporting PCIe Gen1, Gen2, Gen3 and Gen4 speeds and x1, x2, and x4 link-widths. All Add- in slots are equal and can be used by any PCIe card. The silk print specifies an Add-in and Target cable adapter slot. -
Page 6: Dip Switches
- Pin 2-3: Short to Pull-Down ATX 24pin Power Connector Pin16 (PS-ON) (For using the ON/OFF Switch on Switching Mode Power Supply) PWR_ON: Not in use PWR_LED: 3.3V Power LED Pin Header • 3pin Header (pitch=2.54mm) IBP-G4x16-5 - Five slot expansion card User’s Guide Page 6... -
Page 7: Block Diagram
Step 1 - Unpack board The IBP-G4X16-5 is shipped in an anti-static bag to prevent static electricity damage. The card should only be removed from the bag after ensuring that anti-static precautions are taken. Static electricity from your clothes or work environment can damage your PCI Express adapter card or your PC. -
Page 8: Step 5 - Install The Dolphin Pcie Uplink Card
ATX PSU power switch. Support More information about the product, support and software download can be found at http://www.dolphinics.com. For general support questions, please contact Dolphin via the Jira Service Management portal: https://www.dolphinics.com/csp. IBP-G4x16-5 - Five slot expansion card User’s Guide... -
Page 9: Compliance And Regulatory Testing
Compliance and Regulatory Testing EMC Compliance The IBP-G4X16-5 is not tested for EMC compliance. It is the customer's responsibility to install the backplane in a proper cabinet and install the PCIe adapter cards of choice before conducting their own EMC test. -
Page 10: Limited Warranty
Damage caused by any power source out of range or not provided with the product. • Normal wear and tear. • Attempts to repair, modify, open, or upgrade the product by personnel or agents not authorized by Dolphin. • Products for which the serial number label has been tampered with or removed. •...
