- Page 1 Toll Free Digital TV Hotline: 1-877-993-6484 o p e r a t i n g g u i d e Copyright 2001, Zenith Electronics Corporation.
-
Page 2: Safety Warnings
REGULATORY INFORMATION: This equipment, trade name Zenith, model number, IQD61W35, has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a residential installation. -
Page 3: Important Safety Instructions
IMPORTANT SAFETY INSTRUCTIONS Important safeguards for you and your new product Your product has been manufactured and tested with your safety in mind. However, improper use can result in potential electrical shock or fire hazards. To avoid defeating the safeguards that have been built into your new product, please read and observe the following safety points when installing and using your new product, and save them for future reference. - Page 4 IMPORTANT SAFETY INSTRUCTIONS (Continued from previous page) 14. Outdoor Antenna Grounding If an outside antenna or cable system is connected to the product, be sure the antenna or cable system is grounded so as to provide some protection against voltage surges and built-up static charges.
-
Page 5: Ez Help
HELP (?) button on your remote control if you want to know about the highlighted item. Information about the highlighted item will be displayed on the right part of the TV screen. Simply press and hold to see the helpful information. -
Page 6: Table Of Contents
On-Screen Display ......20 Front Panel Controls ......21 Step 2. Customize your TV’s Features SETUP Menu EZ Scan . -
Page 7: Step 1. Hook Up Tv Rear Jack Panel
PC. Mini glossary JACK A connection on the back of a TV, VCR, or any other A/V device. This includes the RF jack and the Audio/Video jacks that are color- coded. SIGNAL Picture and sound traveling through cable, or on the air, to your television screen. -
Page 8: Front Jack Panel
Front Audio/Video Jacks There are four jacks on the right side of your Entertainment Machine that make connecting Audio/Video devices like video games and camcorders very simple. The jacks are like those found in the jack pack on the back of your Entertainment Machine. -
Page 9: Ant/Cable Hookup
300 to 75 Ohm adapter. It should be available from your local electronics dealer. Zenith recommends using a 75 ohm cable for your antenna con- nections in order to prevent inter- ference. -
Page 10: Cable Box
Locate the output jack on the back of your cable box. Connect this to the Antenna 1 jack on the back of your TV. Or find the composite video and audio jacks on the back of your cable box, and connect them following the instructions provided with your equipment. -
Page 11: Vcr
Entertainment Machine. If you want to receive your signals on Channel 3 or 4, locate the Out to TV jack on your VCR. Connect a cable from the Out to TV jack to the Antenna/Cable 1 jack on the back of your Entertainment Machine. -
Page 12: Dvd Player
Dolby Digital Audio Component Video A/V cables not included with TV Mini glossary COMPONENT VIDEO Some video equipment uses three separate lines (Y, Pb, Pr) to more precisely reproduce images. Your manual will explain how this relates to your equipment. -
Page 13: Pc Hookup
PC Hookup Find the audio and VGA jack on the back of your Computer, then connect them follow- ing the instructions provided with your equipment. Connect these cables to your Entertainment Machine as shown. Computer Adjustment of V-position/H-position/PHASE (Make sure to select RGB-PC before operating) - Press the UP/DOWN/LEFT/RIGHT arrows to adjust V-position/H-position and press the info button to adjust PHASE. -
Page 14: External Stereo
Set up your speakers through your analog stereo amplifier, according to those directions. Analog stereo amplifier P A G E 1 4 Audio cables not included with TV AUDIO CENTER MODE COMPONENT 480 i / p 720 p 1080 i... -
Page 15: Dolby Digital Audio Hookup
Rear Right Surround DOLBY DIGITAL S-VIDEO MONITOR VIDEO 2 INPUT Dolby Digital Use shielded 75 Video type cable Audio cables not included with TV ANTENNA 2 (DTV) INPUT COMPONENT 480 i / p 720 p 1080 i VIDEO AUDIO S-VIDEO MONO... -
Page 16: Room Setups For Home Theater
Room Setups for Home Theater This is just a general room design. Any number of set-ups are possible, and some changes may be needed to maximize your sound. However, a Dolby Digital Receiver is needed for 5.1 channel audio. A left and right speaker on either side of the set enhances separation. -
Page 17: Monitor Out
Your Entertainment Machine has a special feature which allows you to hook up a second TV or monitor. Just connect the second TV or monitor using the OUT Audio/Video jacks located on the back of your Entertainment Machine. See the Operating Manual of the second TV or monitor for further details regarding that device’s input settings. -
Page 18: Remote Button Functions
Button functions on your Remote MODE Lets you select a mode among TV, VCR, Cable, DVD and Satellite. Lets you select the analog/digital TV signal. VIDEO Lets you toggle between Video1 and Video 2 inputs. MUTE Switches the sound on or off. - Page 19 INFO surf menu info When you watch the TV program, it’s information displays on top of the screen. This information of TV program appears only in DTV. ENTER exit When in the menu system and other on-screen displays, selects high lighted items.
-
Page 20: On-Screen Display
Volume level is displayed here while adjusting the volume on your Entertainment Machine. Channel Label: If channel label has been set, then it will appear here. TV 13 - 0 STEREO PIP Display: This display appears only when PIP is active.. -
Page 21: Front Panel Controls
Front Panel Controls Use the Exit button as the Exit button on your remote. To access the Menus, push the menu button on the panel. Press the Enter button as the Enter button on your remote. Press the Flashbk button as the Flashbk button on your remote. -
Page 22: Ez Scan
Connect off-air TV, cable TV or DTV to the ANTENNA 1 and connect a DTV to ANTENNA 2 only. You don’t watch the DTV of the QAM signal. -
Page 23: Ch. Edit
CH. Edit Allows you to edit two other types of channel lists; custom list and surf list. A custom list can be created by toggling each channel on or off with channel is highlighted, you will be able to see whether the channel is currently shown or hidden by referring to the small window at the top-left corner of the screen. -
Page 24: Channel Label
ENTER to set the Label to the selected channel. Repeat steps five and six until all chan- nels are Labeled. Press EXIT to save and return to TV view- ing. P A G E 2 4 to set... -
Page 25: Input Source
Input Source Changes the screen source for main picture and PIP so you can watch your off-air TV, cable TV, VCR, DVD etc. that you have hooked up to your TV. DVD component video and PC source can’t be seen in PIP and digital source can’t be seen in PIP when that is seen... -
Page 26: Dtv Signal
Press ENTER or the RIGHT arrow button to access the Setup menu. Press UP/DOWN arrows to select the DTV Signal. Press EXIT to return to TV viewing. NOT all areas or programs are currently available in the DTV signal. When you select the DTV in INPUT SOURCE, you can check the DTV signal. -
Page 27: Pip/Pop
PIP/POP Press the PIP button on the remote con- trol to activate PIP (Picture in Picture) mode. Press the LEFT/RIGHT arrow to select CH+/-, Swap, Source, move. • CH +/- : Press the UP/DOWN arrow to select a program of sub picture. If you want to change a program of main picture, press pg up/dn button. -
Page 28: Ez Convergence
EZ Convergence Makes the color beams of the red, green and blue tubes better aligned to produce correct colors. When properly aligned, the outputs of the three tubes should be directly over each other to produce the white lines. Press the MENU button on the remote control, then use the UP/DOWN arrow button to select the Setup menu. -
Page 29: Video Menu
Each item has its predefined settings of the contrast, brightness, sharp- ness, color and tint. If the Digital Eye option is selected, the settings are automatically adjust- ed according to the amount of room-light surrounding your TV. vcr cable dvd sat mode... -
Page 30: Video Menu
All picture settings are increased Brightness. Digital EYE: Automatically adjust the picture settings according to the amount of light surrounding your TV in the room. • Contrast: Adjusts the difference between the light and dark lev- els of the picture. -
Page 31: Audio Menu
AUDIO Menu Lets you adjust the sound to suit your taste and room situations. Press the MENU button on the remote control, then use the UP/DOWN arrow button to select the Audio menu. Press ENTER or the RIGHT arrow button to access the Audio menu. -
Page 32: Audio Menu
This will make sure that the volume level will be consistent whether you are watching a commercial or a regular TV program. • EZ Audio: Allows you to choose an appropriate listening setting based on different audio option. They are: Off, News, Movie, Music and EZ Surround. -
Page 33: Auto Clock
Daylight Savings On or Off, depending on whether or not your viewing area observes Daylight Savings or not. Press EXIT to save and return to TV view- ing or press the ENTER button to save and return to the previous menu. -
Page 34: Manual Clock
Year, Date and Time. Use the UP/DOWN arrows to set the Year, Date and Time. Press EXIT to save and return to TV viewing or press the ENTER button to save and return to the previous menu. P A G E 3 4... -
Page 35: Off Time
Off Time Lets you set up the off time for your TV to turn itself off automatically. Press the MENU button on the remote control, then use the UP/DOWN arrow button to select the Time menu. Press ENTER or the RIGHT arrow button to activate the Time menu. -
Page 36: On Time
On Time Lets you set up the on time for your TV to turn itself on automatically. Press the MENU button on the remote control, then use the UP/DOWN arrow button to select the Time menu. Press ENTER or the RIGHT arrow button to activate the Time menu. -
Page 37: Sleep Timer
Sleep Timer Lets you select the amount of time before your TV Turns itself off automatically. Press the MENU button on the remote control, then use the UP/DOWN arrow button to select the Time menu. Press ENTER or the RIGHT arrow button to activate the Time menu. -
Page 38: Auto Off
Auto off Lets your TV automatically turn itself off when there is no video signal. If there is no input signal, the TV is switched off automatically in 10minutes. Press the MENU button on the remote control, then use the UP/DOWN arrow button to select the Time menu. -
Page 39: Aspect Ratio
Label is on the screen for a long time, it’ll be remain afterim- age. If you connect second TV or monitor to your entertain machine in DTV mode, second TV or monitor displays a image which is crop out left-right of original image. Only you can select 16:9 aspect ratio in COMPONENT/DTV 720p/1080i. -
Page 40: Captions/Text
Off, CC 1, CC 2, CC 3, CC 4, Text 1, Text 2, Text 3 and Text 4. Press EXIT to save and return to TV viewing or press the ENTER button to save and return to the previous menu. -
Page 41: On-Screen Language
Use the UP/DOWN arrow button to select the language you wish to view yours on-screen menus. Press EXIT to save and return to TV viewing or press the ENTER button to save and return to the previous menu. 206-03714... -
Page 42: Ez Demo
EZ Demo Shows you how to navigate through on-screen menus of your TV. Press the MENU button on the remote control, then use the UP/DOWN arrow button to select the Special menu. Press ENTER or the RIGHT arrow button to activate the Special menu. -
Page 43: Parental Lock
Parental Lock Lets you block specific channels, ratings and other sources based on the blocking schemes. A password is required to gain access to this menu. Press the MENU button on the remote control, then use the UP/DOWN arrow button to select the LOCK Menu. Press ENTER or the RIGHT arrow button to activate the LOCK Menu. - Page 44 Keep in mind that the movie ratings limit only applies to movies shown on TV, not TV programs, such as soap operas. • TVPG-Children : Keeps children from...
-
Page 45: Parental Lock
TV-G(General audience) : Most parents find this program suitable for all ages. TV-PG(Parental guidance) : This program contains material that parents may find unsuitable for younger children. TV-14(Parents strongly cautioned) : This program contains some material that many parents would find unsuitable for children under 14 years of age. -
Page 46: Programming The Remote
Programming the Remote The remote control of your HD receiver is a multi- brand or universal remote control that can be programmed to control most remote-controllable components of other manufacturers. Note that the remote control may not control all models of other brands. Test your remote control To find out whether your remote control can operate component without programming,... -
Page 47: Programming Codes
VIDIKRON VIDTECH 004 116 WARDS 004 008 009 019 028 060 061 063 064 072 074 116 143 164 YAMAHA 004 006 YORK 004 116 YUPITERU ZENITH 001 072 073 095 103 157 ZONDA P A G E 4 7... - Page 48 Codes TOTEVISION 040 101 UNITECH VECTOR RESEARCH VICTOR VIDEO CONCEPTS 012 034 046 VIDEOSONIC WARDS 003 013 017 024 031 033 034 040 053 054 131 YAMAHA 012 034 039 ZENITH 001 034 048 056 058 072 080 101 206-03714...
- Page 49 005 006 005 006 008 017 SAMSUNG 011 015 003 009 SONY Brand Codes VIEWSTAR WINEGARD 128 146 ZENITH 001 081 082 083 084 091 Brand Codes THOMPSON 005 006 TOSHIBA 019 008 YAMAHA 009 018 ZENITH 010 016 025...
-
Page 50: P A G E
039 040 056 TOSHIBA 011 048 071 UNIKA 007 014 024 072 073 074 UNITED CABLE 004 053 UNIVERSAL 005 007 014 024 026 027 Brand Codes 032 035 VIEWSTAR 012 015 018 086 087 088 ZENITH 001 060 093 206-03714... -
Page 51: Maintenance
Maintenance Early malfunctions can be prevented. Careful and regular cleaning can extend the amount of time you will have with your new Entertainment Machine. Be sure to turn the power off and pull out the plug before you begin any cleaning. SCREEN CLEANING 1. -
Page 52: P A G E
Maintenance cont’d PICTURE INTERFERENCE Even though you may be getting cable, the signal may be weak, which means the quality of your picture may suffer due to other factors. If there are problems with the image on your Entertainment Machine, consult the Troubleshooting guide on the following pages. VIDEO GAMES AND OTHER FIXED-PATTERN DISPLAYS If you use your Entertainment Machine to play video games or for other uses that have single, fixed images, such as a photo-CD player, you should avoid setting the Brightness level too high. -
Page 53: Troubleshooting
• The CC (closed caption) option may be in Text mode. Select Caption 1, or OFF in the Captions/Text menu. • Your program is in letterbox. This means that the shape of your TV is a square, but the program is a rectangle. Think of the bars as empty space the program doesn’t fill;... -
Page 54: P A G E
• Check that all the wires are connected properly. • Check to see if your input source for PIP is set correctly. •Look to see if the TV/VCR button on your VCR has the TV selected or change the PIP to another source. -
Page 55: Glossary
Each channel can carry a different signal simultaneously (front center, front left, front right, surround left, surround right and subwoofer). Refers to the jack that receives a signal into the TV, VCR or other A/V device. P A G E 5 5... - Page 56 TEXT TUNER P A G E 5 6 A connection on the back of a TV, VCR, or any other A/V device. This includes the RF jacks and the Audio/Video jacks that are color-coded. The mode determines the type of device (TV, VCR, Cable, Aux) that the remote is controlling.
-
Page 57: Product Specifications
CADTV: 1 - 125 (8VSB only) (3) - 7” Liquid cooled, Hi-Resolution 75 ohm external terminal for VHF/UHF 61” Width Remote control, batteries 2 size AA (Alkaline battery) 16 x 9 Copyright 2001, Zenith Electronics Corporation P A G E 5 7... - Page 58 Notes P A G E 5 8 206-03714...
- Page 59 Notes P A G E 5 9 206-03714...
- Page 60 Effective Warranty Date: Warranty begins on the date of sale of IQD61W35. For your convenience, keep the dated bill of sale or delivery ticket as evidence of the purchase date.
