LogiFire
41CPE112R
ADDRESSABLE
FIRE ALARM CONTROL PANEL
INSTALLATION MANUAL
Attention!
This manual contains information on limitations regarding product use
and function and information on the limitations as to liability of the
manufacturer. The entire manual should be carefully read.
The information in this manual is a subject to change without
notice!

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the LogiFire 41CPE112R and is the answer not in the manual?

Questions and answers

Related Manuals for Comelit LogiFire 41CPE112R

Summary of Contents for Comelit LogiFire 41CPE112R

  • Page 1 LogiFire 41CPE112R ADDRESSABLE FIRE ALARM CONTROL PANEL INSTALLATION MANUAL Attention! This manual contains information on limitations regarding product use and function and information on the limitations as to liability of the manufacturer. The entire manual should be carefully read. The information in this manual is a subject to change without notice!

  • Page 2: Table Of Contents

    41CPE112R Addressable Fire Alarm Panel – Installation and Programming Manual Table of Contents 1. INTRODUCTION ................................4 1.1. General Description ............................4 1.2. General Specifications ........................... 4 1.2.1 General Technical Specifications ....................4 1.2.2 Possible Hardware Configurations ....................5 1.2.3 Environment ............................ 5 1.2.4 Electrical Characteristics ........................
  • Page 3 APPENDIX D ................................... 55 APPENDIX E ................................... 56 DoP No: 044 Comelit Group S.p.A. Via Don Arrigoni 5 - 24020 Rovetta S. Lorenzo BG Italy tel. +39 0346 750 011 - fax +39 0346 71436 email: info@comelit.it - export.department@comelit.it EN 54-2:1997/A1:2006/AC:1999; EN 54-4:1997/A2:2006/AC:1999 41CPE112R Intended for use in fire detection and fire alarm systems in and around buildings.

  • Page 4: Introduction

    41CPE112R is an addressable fire panel with maximum coverage of 48 zones and up to 2 loops. The panel supports communication protocol Comelit and operation with Comelit addressable device series. Every Loop provides up to 250 devices (detectors and modules, regardless of the type).

  • Page 5: Possible Hardware Configurations

    41CPE112R Addressable Fire Alarm Panel – Installation and Programming Manual 9 groups for zones’ organization • • 5 monitored potential outputs: SND1 (Sounder 1) SND2 (Sounder 2) FIRE FAULT (The output is deactivated in case of fault event.) EXT (Extinguishing / Fire Protection – An output for sending an fire alarm signal to automatic fire extinguishing system) 3 specialized inputs: •...
  • Page 6 41CPE112R Addressable Fire Alarm Panel – Installation and Programming Manual Main power supply In normal operating conditions, the fire panel is powered from the mains voltage line. In case of mains voltage line loss the fire panel is equipped with one rechargeable battery. The characteristics of the main power supply are as follows: Main power supply: 90 ÷...

  • Page 7: Installation

    41CPE112R Addressable Fire Alarm Panel – Installation and Programming Manual 2. INSTALLATION 2.1. Wall Mounting • The panel must be installed in a clean dry place and must not be subjected to impact or vibrations (Figure 1). It must be situated far from heating appliances. The temperature must be within -5ºС and + 50ºC. The fire panel is not waterproof! •...

  • Page 8: System Components

    41CPE112R Addressable Fire Alarm Panel – Installation and Programming Manual • Use the template in the set to fix the mounting holes of the metal box on the wall. • Drill holes (suitable for anchors Ø6mm) on the wall and fix the metal box. •...
  • Page 9 41CPE112R Addressable Fire Alarm Panel – Installation and Programming Manual PROTECTION CONFIRMED EXTINGUISHING STARTED CONFIRMATION. Lights on permanently in (yellow) activation of the specialized “In PC” input – see the description on page 12. PROTECTION PANEL FAULT EXTINGUISHING SYSTEM FAULT. Lights on permanently in activation of the (yellow) specialized “In FP”...

  • Page 10: Configuration Of The Basic Modules

    41CPE112R Addressable Fire Alarm Panel – Installation and Programming Manual 2.2.2 Configuration of the basic modules Figure 6 – Configuration of the modules in the box: 1 – Main PCB (control panel) 2 – Second loop controller (optional, it may not be present in your system configuration) 3 –...
  • Page 11 41CPE112R Addressable Fire Alarm Panel – Installation and Programming Manual FAULT – Potential, monitored output for connection of auxiliary devices, 24 VDC/ 0.3А. This output is • deactivated in case of system trouble or fault. EXT - Potential, monitored output for fire extinguishing, 24 VDC/ 0.3А. This output is activated in case of a fire •...

  • Page 12: Connection Of Signaling Devices

    41CPE112R Addressable Fire Alarm Panel – Installation and Programming Manual 2.3. Connection of Signaling Devices The monitored outputs SND, at activation, provide 24VDC@0,5A to the load connected between them and GND*. The monitored outputs FAULT, EXT and FIRE, provide 24VDC@0,3A to the load connected between them and GND*.

  • Page 13: Loop Controller

    • communication line. Up to 250 Comelit devices can be connected to 41CPE112R loop controller. The general connection diagram of devices to the loop controller is shown on Figure 13. The maximum current consumption of the devices in the communication line is Imax = 500mA. If the consumption exceeds this value an over-load protection would be turned on.

  • Page 14: Connecting To The Main Power Source

    41CPE112R Addressable Fire Alarm Panel – Installation and Programming Manual 2.4. Connecting to the Main Power Source The mains power supply of 41CPE112R fire alarm panel is realized with connection of the main power cable to the 230V terminal, mounted in the metal box under the powers source. The connection between the 230V terminal and the main power source is done from the manufacturer.

  • Page 15: Connecting A Network Module

    3.1. Programming via LogiProg Software The specialized LogiProg software is designed for programming of intruder and fire alarm panels produced by Comelit. To program the fire alarm panel 41CPE112R you should first to install the LogiProg software on your computer – the...

  • Page 16: Programming Via Panel's Keyboard

    ATTENTION! The firmware update of the main microprocessor of fire alarm panel 41CPE112R should be performed by qualified personnel only and after held training program by the producer Comelit! 3.3.1 Firmware Update from Computer To start a firmware update from a computer you should first to have a copy of an image update file (with *.bin extension) saved on your computer.

  • Page 17: Firmware Update From Usb Drive

    41CPE112R Addressable Fire Alarm Panel – Installation and Programming Manual  The panel will reset itself automatically after a successful firmware update. 3.3.2 Firmware Update from USB Drive To start a firmware update from a USB drive you should first have to copy the new image update file (with *.bin extension) in the main directory of the USB removable disk.

  • Page 18: Codes And Access Levels

    41CPE112R Addressable Fire Alarm Panel – Installation and Programming Manual There is no access to the menus of the panel during that procedure. Upon the initial startup, the panel does not hold any configurations. Initialization may take several minutes. The initialization time needed depends on the number of periphery and loop devices –...
  • Page 19 41CPE112R Addressable Fire Alarm Panel – Installation and Programming Manual Access Level Mode/ Menu Description Viewing the Alarms Messages in the system. ALARMS    Viewing the Faults Messages in the system. FAULTS    Viewing the active disablements in the system. DISABLED ...

  • Page 20: Description Of The Operation Modes

    41CPE112R Addressable Fire Alarm Panel – Installation and Programming Manual 6. DESCRIPTION OF THE OPERATION MODES In this section you can find detailed descriptions of all operation modes of 41CPE112R addressable fire alarm panel. The modes for reviewing of system events are accessible only from level 1 without entering access code. If no alarm, fault or warning messages, active tests and disablements are present, then the panel is in normal operation mode and only the current day and time is displayed.

  • Page 21: Review Of Disablements

    41CPE112R Addressable Fire Alarm Panel – Installation and Programming Manual 6.3. Review of Disablements The messages for disablements are displayed with normal priority. If no alarm or fault events are present, and there are active disablements in the system, the DISABLED mode is blinking together with the number of the first disablement.

  • Page 22: Review Of Warning Messages

    41CPE112R Addressable Fire Alarm Panel – Installation and Programming Manual After choosing the button (2) TESTS the screen displays: To exit the review of running tests mode, press CANCEL button. 6.5. Review of Warning Messages The messages for warnings are displayed with low priority. If no alarm or fault events or disablements and tests are present, and there are active warnings in the system, the WARNINGS mode is blinking together with the number of the first message.

  • Page 23: Silencing The Internal Buzzer

    41CPE112R Addressable Fire Alarm Panel – Installation and Programming Manual NOTE: If you are programming parameters at Access Level 2 (Maintenance) or Access Level 3 (Installer) and there is an alarm or fault event in the system, the panel will automatically display a list with messages. After reviewing the events, you can return to the programming mode with single pressing the CANCEL button.

  • Page 24: Description Of The Programming Menus

    41CPE112R Addressable Fire Alarm Panel – Installation and Programming Manual 7. DESCRIPTION OF THE PROGRAMMING MENUS The programming menus are accessible from level 2 (Maintenance) and level 3 (Installer) after entering a valid access code. In level 2 could be realized partial programming of parameters, and some values are accessible only for reviewing. In level 3 could be realized full programming and settings, and also to restore the factory default settings, including access codes.

  • Page 25: Review Of List Of Events By Date

    41CPE112R Addressable Fire Alarm Panel – Installation and Programming Manual 7.1.2 Review of List of Events by Date From the main screen of VIEW LOG menu press (2) FROM button. In “FROM” submenu the installer can extract a list of events by date. Set in sequence the day, the month and the last two digits of the year. The edited digit is flashing. Scroll between the fields using the left and the right arrows.

  • Page 26: Zones Menu

    41CPE112R Addressable Fire Alarm Panel – Installation and Programming Manual 7.2. Zones Menu This menu allows the installer to review and change the status of every zone. In the ‘ZONES’ menus the installer can test and enable/ disable the zones. Up to 48 zone numbers are available for settings. The currently edited zone number is blinking.

  • Page 27: Disabling Zones

    41CPE112R Addressable Fire Alarm Panel – Installation and Programming Manual 7.2.3 Disabling Zones From the main screen of ZONES menu, select a zone number using the up and down arrow buttons and press button (4) DISABLE. The zone status is changed to DISABLED – the panel stops following the status of the connected devices to the zone and will not alert for alarms and faults from them.

  • Page 28: Programming Delays Т2

    41CPE112R Addressable Fire Alarm Panel – Installation and Programming Manual • Examples for 2 DEVICES action mode operation: EXAMPLE 1 EXAMPLE 2 5 min 5 min Time Time 1 – An incoming alarm signal from Detector 1 and zone reset; 2 –...

  • Page 29: Arranging Zones In Groups

    41CPE112R Addressable Fire Alarm Panel – Installation and Programming Manual The set time delays T2 are confirmed with the ENTER button. 7.2.8 Arranging Zones in Groups The zones in 41CPE112R addressable fire alarm panel can be organized for operation in separate groups. The maximum number of the permissible groups is 9.

  • Page 30: Saving The New Found Devices

    41CPE112R Addressable Fire Alarm Panel – Installation and Programming Manual Submenu (2) DEV. VIEW allows the User to check the total number of the devices connected to Loop 1 or Loop 2 – the loop number to which the selected device is currently connected. The exit to the main screen of DEVICES SETUP menu is with pressing ENTER or CANCEL button.

  • Page 31: Fixing Of Wrong Type Devices

    The 41CPE112R fire alarm addressable panel operates with full range of addressable detectors, call points, sounders and modules via Comelit communication protocol. According the type of the device, the setting parameters are different. Use the descriptions below to set the devices in your system configuration.
  • Page 32 41CPE112R Addressable Fire Alarm Panel – Installation and Programming Manual Button ON/ OFF TURN – Using this button the installer can manually to turn on the LED of a device (or the • sound for sounders 41SAI000 and 41SAB100) when checking its place of installation or checking for double addresses in the system.
  • Page 33 41CPE112R Addressable Fire Alarm Panel – Installation and Programming Manual – (1) CLASS Press the button to enter the submenu for setting the class for DAY and NIGHT alarm mode. Use the functional buttons (2) and (3) to select the class: A1R/ A2S/ BS. The selected class is confirmed with ENTER button.
  • Page 34 41CPE112R Addressable Fire Alarm Panel – Installation and Programming Manual (3) EVENT EVACUATION/ ALARM – Every pressing of the button alternatively changes the type of the event generated with activation of the manual call point: - Event EVACUATION – The sounders will be activated immediately, as the set time delays Т1 and Т2 are ignored.
  • Page 35 41CPE112R Addressable Fire Alarm Panel – Installation and Programming Manual * Sounders 41SCB100. (3) MODE – Press to choose the operation mode of the sounder: SND – Sounder activation only in FIRE mode; FLASH – Flash indication only in FIRE mode; SND/ FLASH –...
  • Page 36 41CPE112R Addressable Fire Alarm Panel – Installation and Programming Manual Sound Level Sound Level (HIGH + LOW) 41SAI000 ____ x 10mA ____ x 4mA 41SCI000 ___ x 16,5mA ____ x 11mA 41SAB100 ____ x 10mA ____ x 3mA 41SCB100 ____ x 10mA ____ x 3mA Consumption of the sounders in the loop: 41IOM010 –...
  • Page 37 41CPE112R Addressable Fire Alarm Panel – Installation and Programming Manual Use buttons to select an activation event. The installer has to choose an activation event using the up and down arrows. Use the left and right arrows to switch over the editable fields. DEVICE - Activation from a device.
  • Page 38 41CPE112R Addressable Fire Alarm Panel – Installation and Programming Manual NAME - Press the functional button (3) to enter a specific name for this activation output event. BEHAVIOR CHANGE - Press the functional button (4) to set the behavior Latched or Unlatched. The set activation event is confirmed with ENTER button.

  • Page 39: Addressing Menus

    (when operating with Comelit conventional detectors is a must to connect an EOL module at the end of the line).

  • Page 40: Set Address

    41CPE112R Addressable Fire Alarm Panel – Installation and Programming Manual The installer can use the following approaches for adding devices to the system configuration: • The devices are directly connected to the panel Loop 1 and/ or Loop 2. The panel will recognize them and gives automatically addresses according the order of the devices in the line.

  • Page 41: Change Address

    41CPE112R Addressable Fire Alarm Panel – Installation and Programming Manual The system automatically shows the first address in the system. Use the button ‘CHANGE’ to switch to loop 2 if present in the system. The address is free if ‘SAVE’ button is active. To find a free address use the up and down arrows to scroll over the address numbers.

  • Page 42: Panel Outputs Menus

    41CPE112R Addressable Fire Alarm Panel – Installation and Programming Manual The self-addressing menu shows information about the total number of devices connected to every loop. On the third row the panel shows the first free address for every of the loops. The panel skips all already set address numbers and will jump to the next free address number.

  • Page 43: Extinguishing Output

    41CPE112R Addressable Fire Alarm Panel – Installation and Programming Manual (4) - Press to set the time delay operation. Every pressing of the button changes the ‘Delay’ setting: • ON - The delay of sounder outputs will be active when DAY operation mode is set - see the description for menu 6.3 DAY/ NIGHT operation modes.

  • Page 44: Relay Outputs

    41CPE112R Addressable Fire Alarm Panel – Installation and Programming Manual 7.5.5 Relay Outputs Attention: The relay outputs are available for setting parameters only from access level 3! In this submenu the installer can the set parameters of the relay outputs on the control panel PCB. To access the RELAY OUTS submenu, enter in the installer’s menu - 5.

  • Page 45: Setting The Date And Time

    41CPE112R Addressable Fire Alarm Panel – Installation and Programming Manual The settings are analogical for both levels. Use the functional buttons to set access code for: (1) - Press to change INSTALLER CODE (2) - Press to change MAINTENANCE CODE (3) - Press to enter a submenu for setting time for automatic exit from the INSTALLER and MAINTENANCE menus.

  • Page 46: Setting Day/ Night Alarm Modes

    41CPE112R Addressable Fire Alarm Panel – Installation and Programming Manual 24VDC/ 15A Set a jumper on JT7 terminal to enable the BATT1 7.6.3 Setting Day/ Night Alarm Modes In this submenu the installer can set the operation alarm mode of the panel. To access the DAY/ NIGHT submenu, enter in the installer’s menu - 6.

  • Page 47: Panel General Settings

    41CPE112R Addressable Fire Alarm Panel – Installation and Programming Manual Press the functional button ‘2’ to select the preferred alarm mode: NIGHT - Select to set nighttime alarm mode. The devices will operate only in night alarm mode. DAY - Select to set daytime alarm level. The devices will operate only in day alarm mode.

  • Page 48: Delay Т1

    41CPE112R Addressable Fire Alarm Panel – Installation and Programming Manual 7.6.5 Delay Т1 In this submenu the installer sets the time to Delay T1. T1 is the time delay needed for reaction of the security personnel on the protected site. T1 provides a time delay for the personnel to go to the zone in fire alarm and to check the situation.

  • Page 49: Company Logo

    41CPE112R Addressable Fire Alarm Panel – Installation and Programming Manual - ON – Set this time interval from 1 to 600 seconds*. During evacuation mode the sounders will operate with the setting of (4) MORE button described above – for example when SND/FLASH option is set the sounders will sounding and flashing at the same time (for the models available).

  • Page 50: Software Revision

    41CPE112R Addressable Fire Alarm Panel – Installation and Programming Manual 7.9. Software Revision In this menu the installer can review the software versions of the main board and used loop modules and also has possibility for firmware update of the main processor unit. The screen displays: 7.10.

  • Page 51: Active Isolators Menu

    41CPE112R Addressable Fire Alarm Panel – Installation and Programming Manual Use the (3) CHANGE button to set the options: NONE – The panel cannot send any commands to other • panels in the redundant network. COMMANDS – The panel can send commands to other •...
  • Page 52 41CPE112R Addressable Fire Alarm Panel – Installation and Programming Manual Sounder1 Open Circuit broken at Sounder 1 output. Sounder2 Open Circuit broken at Sounder 2 output. Fire Output Short Short circuit detected at Fire output. Fire Output Fault Circuit broken at Fire output. EXT Output Short Short circuit detected at Extinguishing output.
  • Page 53 41CPE112R Addressable Fire Alarm Panel – Installation and Programming Manual Network Fault Redundant network breakdown. Loop Device Disabled The loop device is disabled. Chamber Fault Fault in the detector. Clean Me Now Dirty detector chamber. Loop Device Input Fault Fault in loop device input. Loop Device Output Fault Fault in loop device output.
  • Page 54 41CPE112R Addressable Fire Alarm Panel – Installation and Programming Manual APPENDIX C Initial power up of the system.
  • Page 55 41CPE112R Addressable Fire Alarm Panel – Installation and Programming Manual APPENDIX D Two steps of alarming Algorithm.
  • Page 56 41CPE112R Addressable Fire Alarm Panel – Installation and Programming Manual APPENDIX E Tree structure of the programming menus. The presented tree structure describes the full access to the programming menus from level 3 – Installer. From access level 2 – Maintenance, some of the programming menus are not displayed or the operation with them is partially limited –...
  • Page 57 41CPE112R Addressable Fire Alarm Panel – Installation and Programming Manual Tree structure of the menus – continue.
