Installationsanleitung
Installation Guide
V1.1
EcoFlow PowerOcean DC Fit
Für das neueste Dokument, bitte scannen Sie den QR-Code oder besuchen
Sie:
For the latest documents, please scan the QR code or visit:
Pour obtenir le dernier document, scannez le code QR ou visitez:
Per ottenere la versione più aggiornata del documento, si prega di
scansionare il codice QR o visitare il sito:
https://enterprise.ecoflow.com/eu/documentation
WICHTIG/IMPORTANT
• Lesen und beachten Sie vor der Montage, dem Betrieb und der Wartung
des Geräts Montageanleitung und das Sicherheitshinweise.
• Die Bilder in diesem Leitfaden dienen nur zur Veranschaulichung.
• Before installing, operating, and maintaining the equipment, read and follow
up Installation Guide and Safety Instructions.
• Images in this guide are for demonstration only.
Advertisement
Table of Contents
Related Manuals for EcoFlow PowerOcean DC Fit
Summary of Contents for EcoFlow PowerOcean DC Fit
- Page 1 Installationsanleitung Installation Guide V1.1 EcoFlow PowerOcean DC Fit Für das neueste Dokument, bitte scannen Sie den QR-Code oder besuchen Sie: For the latest documents, please scan the QR code or visit: Pour obtenir le dernier document, scannez le code QR ou visitez: Per ottenere la versione più...
-
Page 3: Table Of Contents
CONTENTS English Safety Precautions Preparing Tools and Instruments Package Inspection Installation Environment Installation Space System Installation Installing Battery Base Installing Battery Pack Installing PV Storage Converter Installing Protective Earthing Conductor Electrical Connection System Preview Connecting to PV System Connecting Smart Meter Connecting to the Internet Installation Review System Power-On... -
Page 4: Safety Precautions
• When the photovoltaic (PV) array is exposed to light, it supplies direct WARNING current voltage to the power conversion equipment (PCE). • Do not touch the exposed electrical cable with bare hands. EcoFlow PowerOcean DC Fit: PV Storage Converter Battery Pack (expandable to 3 batteries) -
Page 5: Preparing Tools And Instruments
Preparing Tools and Instruments ·ESSENTIAL CABLES & CONNECTORS Grounding cable Solar extension cable RJ45 connectors Twisted pair cable Shielded network cable Cat 5e or higher) (4 mm² copper conductor) (4 mm² - 6 mm²) (Cat 5e or higher) (2*0.5 mm²) ·ESSENTIAL TOOLS (SL3) (PH3) -
Page 6: Package Inspection
• Check if the deliverables are intact and complete. If any item is missing or damaged, NOTICE contact the supplier. Inspection • Retain the original packaging and documentation for further needs. ·ECOFLOW POWEROCEAN PV STORAGE CONVERTER ×1 ×1 ×2 EcoFlow PowerOcean PV Storage Converter... -
Page 7: Installation Environment
Installation • The installation and use environment must meet relevant international, national, WARNING and local standards for lithium batteries, and be in accordance with the local laws Environment and regulations. • When installing the equipment in a garage, keep it away from the drive way. NOTICE •... -
Page 8: System Installation
System • When drilling screw holes, avoid the water pipes and power cables buried in the DANGER wall and under the floor. Installation • When moving heavy equipment, assign enough personnel (two or more). CAUTION • When moving the battery pack, hold the handles on top of it. NOTICE •... -
Page 9: Installing Battery Pack
×1 Installing Battery Pack ×2 ×2 ×1 1.3 N·m 5.0 N·m 2.5 N·m ❶ ❷ ❷ ❶ ×2 ×2 ×1 ×2 ×1 ×2... -
Page 10: Installing Pv Storage Converter
Installing Protective DANGER • Grounding terminals should be fully connected. Earthing Conductor ×2 Heat gun PE Cable Cable core (4 mm² copper conductor) L = L1+3 mm ×2 Heat-shrink tubing OT terminal 1.3 N·m Crimping tool EcoFlow PowerOcean DC Fit PE-busbar... -
Page 11: Electrical Connection
• Use cables that meet local regulations and the recommended specifications. NOTICE EcoFlow PowerOcean PV Storage Converter ‐ BATTERY SWITCH EcoFlow PowerOcean DC Fit stores the excess electricity generated by solar panels, and then supplies it to the home load when solar power is insufficient. -
Page 12: System Preview
System Preview RS485 Ethernet Wi-Fi Solar Panels EcoFlow PowerOcean DC FIT Solar Inverter Grid Smart Meter Load Router Internet • Power off the solar inverter from all voltage sources (both DC and AC sides) and Connecting to DANGER disconnect it from the grid. - Page 13 De-energize all electrical equipment. All switches connected to the existing solar power system should be OFF status. PV Switch DC Breaker AC Breaker Solar Panels Solar Inverter Grid Cut existing solar cables. Prepare solar connectors for the PV strings and the inverter. Extension cable PV String Extension cable...
- Page 14 • For an inverter that only supports single PV string input, adjust the connection using the EcoFlow Y-branch Solar Connector*. • For an inverter that supports multiple PV strings (≥ 2 strings) in one input, avoid paralleling the EcoFlow PowerOcean DC Fit...
-
Page 15: Connecting Smart Meter
Connecting • Use the smart meter provided in the package. NOTICE Smart Meter ×1 RS485 A RS485 B 10-15 mm (SL3) Load L1 Load L2 Load L3 Load N RS485 A RS485 B Grid L1 Grid L2 Grid L3 Grid N... - Page 16 • For a three-phase house wiring, always adhere to the three-phase wiring diagram · Wiring diagram (three-phase) NOTICE when installing the smart meter, irrespective of whether a single-phase inverter is in use. Load RS485 A RS485 B DC Fit Utility Meter Breaker Fuse...
-
Page 17: Connecting To The Internet
• Use Cat 5e or higher rating shielded network cable. Connecting to the NOTICE Internet · Method 1: Via a Wired Network ×1 Both ends of the network cable use the T568B wiring standard (straight-through cable). T568B 10-20 mm T568B Test network cable connection. -
Page 18: Installation Review
System Power-Off 1. Shut down the EcoFlow Powerocean DC Fit via the EcoFlow app. 2. Turn the BATTERY SWITCH on the converter to the OFF-BYPASS position. 3. Press and hold the BATTERY ON/OFF button on the converter for about 10 seconds. -
Page 19: Led Indicators
Abnormal smart meter communication. Battery is faulty. Converter is faulty. Abnormal IoT communication. Abnormal battery communication. Abnormal converter communication. If the LED displays a faulty status, visit the EcoFlow / EcoFlow Pro app to retrieve the error code. -
Page 20: System Commissioning
Select Ethernet to set IP mode. ADD SYSTEM Tap Add System or + to automatically search for Bluetooth devices nearby, and select EcoFlow PowerOcean DC Fit to bind. • In DHCP mode, the device obtains IP address automatically. • You can find the device serial number (S/N) in the product •... - Page 21 Step3: Device Settings Tap Device Settings to set necessary parameters. CUSTOMER SERVICE Help the home owner to download the EcoFlow app and bind the device. Step1: Install EcoFlow App (FOR USER) Scan the QR code or download at: https://download.ecoflow.com/app...
- Page 22 © 2023 EcoFlow Inc. All rights reserved.
