Horizon Hobby HANGAR 9 HAN1017 Instruction Manual

All instructions, warranties and other collateral documents are subject to change at the sole
discretion of Horizon Hobby, LLC. For up-to-date product literature, visit horizonhobby.com and
click on the support tab for this product.
Meaning of Special Language
The following terms are used throughout the product literature to indicate various levels of
potential harm when operating this product:
NOTICE: Procedures, which if not properly followed, create a possibility of physical property
damage AND a little or no possibility of injury.
CAUTION: Procedures, which if not properly followed, create the probability of physical property
damage
AND a possibility of serious injury.
WARNING: Procedures, which if not properly followed, create the probability of property
damage, collateral damage, and serious injury OR create a high probability of superficial injury.
WARNING: Read the ENTIRE instruction manual to become familiar with the features of
the product before operating. Failure to operate the product correctly can result in
damage to the product, personal property and cause serious injury.
This is a sophisticated hobby product. It must be operated with caution and common sense and
requires some basic mechanical ability. Failure to operate this Product in a safe and responsible
manner could result in injury or damage to the product or other property. This product is not
intended for use by children without direct adult supervision. Do not attempt disassembly,
use with incompatible components or alter product in any way without the approval of Horizon
Hobby, LLC. This manual contains instructions for safety, operation and maintenance. It is
essential to read and follow all the instructions and warnings in the manual, prior to assembly,
setup or use, in order to operate correctly and avoid damage or serious injury.
Age Recommendation: Not for children under 14 years. This is not a toy.
CAUTION: Iron surface will become hot. Operating temperature can exceed 200°C
(400°F). Use extreme caution when operating this product to avoid burns.
HAN1017
Digital Sealing Iron
Instruction Manual
NOTICE
Hangar 9 Digital Sealing Iron Instructions
Features
• Provides precise digital temperature control
• Temperature range: 100° to 200° C (212° to 392° F)
• LCD status indicator
• Adjustable temperature units
• Perfect for any heat shrink film or fabric covering
• Updated shoe design for easier covering
• Teflon coated shoe prevents scratching
• Metal stand and sock included
• Ergonomic handle design for comfortable handling
• Three-hour shutoff safety feature
Use of the sock is optional, though recommended. Use of the sock will help prevent marking and
potential creasing of the underlying airplane structure.
After installing the sock, place the iron on the included stand, then place it on a heat resistant
surface. Connect the iron to an appropriate AC wall outlet. Press the ON/OFF button to power the
iron on. Adjust the temperature to the desired level with the temperature adjustment buttons.
Holding both the ON/OFF and C/F buttons for approximately three seconds will change the
temperature display mode between Celsius and Fahrenheit.
Set the iron to the temperature recommended for the covering material being used. Once the
iron reaches the set temperature it is ready for use. You may find it helpful to test a scrap piece
of covering to ensure the temperature setting is appropriate for the task being performed. Often,
tacking and shrinking are performed at different temperatures.
LED Indications
The LED will illuminate when the iron is on.
Replacement Sock
HAN1018
LIMITED WARRANTY
What this Warranty Covers - Horizon Hobby, LLC, (Horizon) warrants to the original purchaser that the product
purchased (the "Product") will be free from defects in materials and workmanship at the date of purchase.
What is Not Covered - This warranty is not transferable and does not cover (i) cosmetic damage,
(ii) damage due to acts of God, accident, misuse, abuse, negligence, commercial use, or due
to improper use, installation, operation or maintenance, (iii) modification of or to any part of the
Product, (iv) attempted service by anyone other than a Horizon Hobby authorized service center,
(v) Product not purchased from an authorized Horizon dealer, (vi) Product not compliant with
applicable technical regulations, or (vii) use that violates any applicable laws, rules, or regulations.
